Taylor 428 User manual

The word Taylor and the Crown design
are registered trademarks in the United States
of America and certain other countries.
Taylor Company
750 N. Blackhawk Blvd.
Rockton, IL 61072

The word Taylor and the Crown design
are registered trademarks in the United States
of America and certain other countries.
Taylor Company
750 N. Blackhawk Blvd.
Rockton, IL 61072

ITEM DESCRIPTION PART NO.
1 LENS-LIGHT 052952
2 PLATE A.-DEC LIGHTED X52936
3 FILTER-AIR-17 X 13 X 7/16 052951
4 PANEL A.-SIDE*LEFT X62592
5 COVER A.-HOPPER X51152
6 TUBE-FEED 5/16 HOLE SS 028967-7
7 PANEL-REAR 062594
8 PANEL-SIDE*RIGHT 052935
ITEM DESCRIPTION PART NO.
9 CORD-POWER-125V 045666
10 GASKET-BASE·PAN 062619
11 PANEL-FRONT 054933
12 SHIELD-SPLASH 052980
13 SHELF-DRIP·TRAY 052979
14 TRAY-DRIP 052978
15 PAN-DRIP 22-29/32 LONG 053048
16 STUD-NOSE·CONE-5/16-18 013496
NOTE: STANDARD DOOR SHOWN (NO PRIME PLUG)

ITEM DESCRIPTION PART NO.
1 PIN A.-VALVE HANDLE X25929
2 VALVE-DRAW SLUSH 047734
3 O-RING-1”OD X .139W 032504
4 HANDLE A.-DRAW-SLUSH-BLK X47384
5 NUT-STUD 029880
6 DOOR A.-PARTIAL X39248-SER
7 BUSTER-ICE 047735
8 O-RING-.291 ID X .080W 018550
9 ARM-TORQUE 052450
10 TORQUE A. X14488
ITEM DESCRIPTION PART NO.
11 BEARING-GUIDE 014496
12 GASKET-DOOR 5.109”ID 014030
13 BEARING-FRONT 013116
14 BEATER A.-7QT-1 PIN X46233
15 SHAFT-BEATER 035418
16 SEAL-DRIVE SHAFT 032560
17 O-RING-7/8 OD X .139W 025307
18 BLADE-SCRAPER-PLASTIC 046237
19 CLIP-SCRAPER·BLADE 8.75” 046238
*NOTE: OPTIONAL TORQUE A. = X27027-1

Figure 3

1 KIT A.-TUNE UP X50413
2 BRUSH-MIX PUMP BODY-3”X7” 023316
3 BRUSH-DOUBLE ENDED 013072
4 BRUSH-REAR BRG 1IN.DX2IN 013071
5 BRUSH-DRAW VALVE 1X2X17 013073
6
7 PAIL-MIX 10 QT. 013163
8 LUBRICANT-TAYLOR 4 OZ. 047518
