Taylor T-2X User manual

USE 90 PSI MAXIMUM
Ref # Part # Descriptio Qty.
234X01
234X01A
2X02
3X02
4X02
2X03
34X03
234X04
234X05
234X06
234X07
234X08
234X09
234X10
234X11
234X12
H ndle
H ndle Complete
(Includes p rts #1,9,10,11,
12,13,14,15,16,17,&18)
2X Cylinder
3X Cylinder
4X Cylinder
2X Piston
3X, 4X Piston
Bushing
Vlve Block
Vlve
Pin
Vlve Se t
Throttle Bushing
Inlet Bushing
Vlve Stem
O-Ring
1
1
10
11
12
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
505 N. Railroad Ave. (33435)
P.O. Box 1117 (33425)
Boynton Beach, Florida
Ph. [phone]
Fax [phone]
oll Free 800-805-8665
Ref # Part # Descriptio Qty.
234X13
234X14
234X15
234X16
234X17
234X18A
234X19
234X20
T-5120
T-5210
-5710
-7922
-7922R
-8004
Spring
Plug
Pin
Pin
Assist nt Lever
Lever
Stopper Pin
Exh ust Cover
Quick Ch nge Spring (option)
Beehive Spring
OPTIONAL EXTRAS
Multi Position Regulater
Hose Swivel
Hose Swivel w/ reg.
Airtool Oil
13
14
15
16
17
18
19
20
21
22
1
1
1
1
1
1
1
1
-
1
2X
3X
4X
OILING INSTRUCTIONS:
OIL AFTER EACH USE WITH
A COUPLE DROPS OF AIRTOOL
OIL THROUGH THE AIR INLET.
RUN FOR ONE SECOND TO
COAT ALL INTERNAL PARTS
T-2X Aircraf
T-3X Rive ing
T-4X Hammers
2
2
2
3
3
4
5
6
7
8
9
FOR WARRANTY INFORMATION &
WARRANTY REGISTRATION VISIT
www.taylorpneumatic.com
0523T TC /all rights reserved /CO YRIGHT 2023/ final

505 N Railroad Ave. (33435)
P.O. Box 1117 (33425)
Boynton Beach, Florida
SEE OUR CATALOG
at
www.taylorp eumatic.com
PH. 561-732-1111
FAX [phone]
OLL FREE 800-805-8665
11/15 P C /all rights reserved /COPYRIGH 2015 / final
General Air Hammer
Main enance T-7111,T-7151,
T-1X, T-1XS,T-2X, T-3X, T-4X,& XS,5X,7X,9X,
T-#2,#3,#4 & T-#24B, T-#34B & T-#44B
- OILING & SPECIFIC HAMMER INSTRUCTIONS:
*ALWAY USE CLEAN DRY CO PRESSED AIR @ OR BELOW 90
PSI.
*USING DIRTY AIR CAN CAUSE THE VALVES OR PISTON TO
JA AND VOIDS THE WARRANTY.
*IF AIR IS WET, THE INSIDE OF THE TOOL CAN RUST AND
VOIDS THE WARRANTY.
*USING ORE THAN 90 PSI CAN DA AGE THE VALVES AND
PISTON (THEY ARE ONLY DESIGNED TO TAKE SO UCH
PRESSURE), USING HIGH PRESSURE VOIDS THE
WARRANTY.
*NEVER DRY FIRE TOOLS. THEY NEED TO BE AGAINST THE
CHISEL AND WORK BEFORE THE TRIGGER IS DEPRESSED.
IF THE TOOL IS DRY FIRED DA AGE TO THE PISTON AND
BARREL AY OCCUR AND THIS WILL VOID THE WARRANTY.
* ALWAYS CHECK TO BE SURE THAT THE BARREL IS TIGHT
IN THE HANDLE. LOOSE HANDLES CAN DA AGE THE
HANDLE THREADS AND VOID THE WARRANTY. OIL AFTER
EACH USE WITH 1/2 TEASPOON OF AIRTOOL OIL THROUGH
THE AIR INLET. RUN FOR ONE SECOND TO COAT ALL
INTERNAL PARTS.
- GENERAL INSTRUCTIONS
1. ALWAYS DISCONNECT THE TOOL FRO AIR SOURCE
WHEN CHANGING ACCESSORIES OR SERVICING THE TOOL.
2. USE SAFETY GLASSES, FULL FACE SHIELDS, HEARING
PROTECTION AND GLOVES.
3. USE WHIP HOSE FOR QUICK DISCONNECTS.
4. VIBRATION AY BE HAR FUL TO YOUR AR S AND HANDS.
WEAR PROTECTION.
5. INSPECT THE TOOL AND AIR SUPPLY ON A REGULAR
BASIS.
6. DO NOT RE OVE GUARDS OR SAFETY DEVICES. DO NOT
ODIFY OR DEFEAT SAFETY DEVICES.
7. DO NOT AKE CONTACT WITH ELECTRICAL LINES.
8. LEAVE TRIGGER OFF BEFORE CONNECTING THE TOOL TO
THE AIR SUPPLY. AVOID ACCIDENTAL STARTS.
9. WEAR THE PROPER CLOTHING. DO NOT WEAR JEWELRY,
LOOSE CLOTHING, OR LONG HAIR AS IT CAN GET CAUGHT
IN ROTATING PARTS. KEEP GLOVES AWAY FRO OVING
PARTS.
10. DO NOT WORK IN HAZARDOUS AT OSPHERES WHERE
SPARKS COULD IGNITE OR DETONATE FU ES.
11. WATCH WHAT YOU ARE DOING. USE CO ON SENSE
WHEN OPERATING PNEU ATIC TOOLS. DO NOT USE
PNEU ATIC TOOLS WHEN TIRED OR UNDER THE
INFLUENCE OF EDICATION, ALCOHOL OR DRUGS. SERIOUS
PERSONAL INJURY AY RESULT FRO A O ENTS
INATTENTION.
12. USE 90 PSI AT THE TOOL. USE 3/8”, 1/2” or 3/4” HOSE OR
LARGER WITH FITTINGS 9/32 INI U I.D. AS SPECIFIED
13. ONLY USE CLEAN DRY CO PRESSED AIR. NEVER USE
OXYGEN, CARBON DIOXIDE, CO BUSTIBLE GASES OR ANY
OTHER BOTTLED GAS TO POWER THIS TOOL.
14. SECURE YOUR WORK BEFORE STARTING - USE CLA PS
OR FIND A SUITABLE WAY TO AINTAIN STABILITY.
15. STORE TOOLS IN A CLEAN DRY ENVIRON ENT.
16. DO NOT USE DA AGED TOOLS - ARK, AND RETURN
FOR SERVICE.
17. NEVER FORCE THE TOOL, LET THE TOOL DO THE WORK.
18. STOP USE I EDIATELY IF TOOL IS AKING AN UNUSUAL
NOISE OR VIBRATION. HAVE TOOL CHECKED BY
PROFESSIONAL TECHNICIAN.
19. WORK IN A WELL VENTILATED AREA AND USE APPROVED
PERSONAL PROTECTIVE EQUIP ENT SUCH AS DUST
ASKS, THAT ARE SPECIFICALLY DESIGNED TO FILTER OUT
ICROSCOPIC PARTICLES. SO E DUST CREATED BY
POWER SANDING, SAWING, GRINDING AND OTHER
CONSTRUCTION ACTIVITIES CONTAIN CHE ICALS KNOWN
TO CAUSE CANCER, BIRTH DEFECTS OR OTHER
REPRODUCTIVE HAR . SO E EXA PLES OF THESE
CHE ICALS ARE: CRYSTALLINE SILICA FRO BRICKS,
CE ENT AND OTHER ASONRY PRODUCTS, ARSENIC AND
CHRO IU FRO CHE ICALLY TREATED LU BER AND
LEAD FRO LEAD BASED PAINTS. YOUR RISK FRO
EXPOSURE VARIES, DEPENDING ON HOW OFTEN YOU DO
THIS TYPE OF WORK. TO REDUCE YOUR EXPOSURE TO
THESE CHE ICALS WEAR PROTECTIVE ASKS AND
CLOTHING.
20. KEEP CHILDREN, PETS AND BYSTANDERS AWAY WHILE
OPERATING A PNEU ATIC TOOL. DISTRACTIONS CAN
CAUSE YOU TO LOSE CONTROL. PROTECT OTHERS IN THE
WORK AREA FRO DEBRIS SUCH AS ETAL FILINGS AND
SPARKS. PROVIDE BARRIERS OR SHIELDS AS NEEDED.
21. THESE WARNINGS AND INSTRUCTIONS CAN NOT COVER
ALL POSSIBLE CONDITIONS OR SITUATIONS. THE
OPERATOR UST UNDERSTAND THAT CO ON SENSE AND
CAUTIONS ARE FACTORS WHICH CAN NOT BE BUILT INTO
THE PRODUCT BUT UST BE SUPPLIED BY THE OPERATOR.
