TC Communications TC8926 User manual

TC8926
8- or 16-Ch.
Hoot-n-holler Bridge
User Manual
MNL-89260-01-00

2 TC8926 Rev 1.0 User Manual
All Rights Reserved
Copyright © 2019 by TC Communications. Products described in this publication are protected
by one or more U.S. and foreign patents.
Trademarks
The TC Communications® logo is a registered trademark.
JumboSwitch® is a registered trademark of TC Communications.
Other product and brand names may be trademarks or registered trademarks of their respective owners.
Documentation Disclaimer
This document is provided “as-is” and is to be used only as a general guide. TC Communications disclaims all
warranties, express or implied, regarding the accuracy of the information. TC Communications shall not be liable for
any indirect, special, incidental, or consequential damages (including damages for loss of business, loss of profits,
loss of business information, business interruption or other pecuniary loss) arising out of errors in this document.
The information given in this document is reviewed regularly and any necessary corrections will be included in
subsequent editions. We appreciate any suggested improvements. We reserve the right to make technical
improvements without notice.
Dissemination or reproduction of this document, or evaluation and communication of its contents, is not authorized
except where expressly permitted. Violations are liable for damages. All rights reserved, particularly for the
purposes of patent application or trademark registration. This document contains proprietary information, which is
protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced or
translated to another language without the prior written consent of TC Communications.
Record of Revisions
Revision Date Description of Changes
1.0 05/09/19 Initial Release of TC8926.
TC Communications
17881 Cartwright Road
Irvine, California U.S.A. 92614
Tel. [phone]
Fax [phone]
E-Mail: sales @tccomm.com
Website: tccomm.com

TC8926 Rev 1.0 User Manual 3
Guide to Alert Symbols
These alert symbols are used in Caution, Warning, and Danger notes.
Symbol Meaning
Pinching or crushing hazard
Electrical hazard.
Equipment alert: be careful of
damage from static electricity
General alert: used for all
other hazardous conditions
(referring to people, not
equipment).

TABLE OF CONTENTS
TOC-1 TC8926 Rev 1.0 User Manual
1Introduction
1.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2 Product Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
1.2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.2.2 Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2 Installation
2.1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.2 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.3 Equipment Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
2.4 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.5 Dry Contact Alarm Relay (DCAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.6 System Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.7 System Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
2.7.1 Front Panel (Analog Pin Assignments) . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.7.2 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
2.7.3 Electrical Signal Interface Connection & Pin Assignments . . . . . . . . 2-6
3 Troubleshooting
3.1 General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 All LEDs are OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.3 Alarm LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Appendix A 19” Rack Mount Card Cage
A.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.2 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
A.3 Chassis Ground . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Appendix B Return Policy
B.1 Return Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.1.1 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
B.1.2 Limitation of Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-2

TC8926 Rev 1.0 User Manual 1-1
Chapter 1 Introduction
In this chapter:
•Product Description, on page 1-1
•Specifications, on page 1-5
1.1 General Information
This manual is intended to describe the features and functionality in addition to
aiding in the planning, configuring, commissioning and maintaining of the
TC8926 Hoot-n-holler Bridge.
1.2 Product Description
The TC8926 provides the bridging of 4-wire analog audio, forming a traditional
Hoot N Holler system. When connected to hoot phones, the TC8926 bridges the
audio and forms a partyline. Whenever a handset is unmuted, the caller can speak
and broadcast to the everyone in the party.
TC8926 is available in two configurations:
• 8-channel 4-wire analog
• 16-channel 4-wire analog
Diagnostic LEDs are available to quickly identify issues with your analog lines.
Figure 1-1 TC8926 Hoot-n-holler Bridge

Chapter 1 Introduction Product Description
1-2 TC8926 Rev 1.0 User Manual
Figure 1-2 TC8926 Front Panel LED Definitions

Chapter 1 Introduction Product Description
TC8926 Rev 1.0 User Manual 1-3
Figure 1-3 TC8926 Rear Panel LED Definitions (Primary & Secondary)
1.2.1 Features
• 8 CH or 16 CH Hoot-n-holler Bridge
• Modular Design with 8 Channels per Module
• 64K Full Bandwidth Voice Transport
• Passes All Tones used for FSK, EIA Tone Control/Remote and Paging
• Supports Pilot/Guard Tone Operation
• Optional Power Redundancy
• 1U or 4U Rack Mount or 1S Standalone Chassis
• 12VDC, 24VDC, -48VDC, 125VDC
• LEDs for analog volume, alarm status, channel release tone, and loopback

Chapter 1 Introduction Product Description
1-4 TC8926 Rev 1.0 User Manual
1.2.2 Applications
The TC8926 provides the bridging of 4-wire analog audio, forming a traditional
Hoot N Holler system.
Figure 1-4 Typical Application using the TC8926

Chapter 1 Introduction Specifications
TC8926 Rev 1.0 User Manual 1-5
1.3 Specifications
Connection Capacity
600Ω(4-Wire) 8 ports
Electrical
Analog/Dry Contact Connector RJ-11
Impedance 600Ω
System
Visual Indicators System: PWR A, PWR B, Vcc, ALM
Paging: P#, R-Tone
Channel Status:
TX (1 each 600ΩAudio Ports 1-8)
RX (1 each 600ΩAudio Ports 1-8)
Diagnostic Functions Local Loopback
Power Source
Standard 12VDC @500mA
Optional 24VDC, -48VDC, 125VDC, or 100/240VAC
Temperature
Operating -10°C to 50°C
(Optional Hi-Temp Version) -20°C to 70°C
(Optional Extreme-Temp Version) -40°C to 80°C
Storage -40°C to 90°C
Humidity 95% non-condensing

Chapter 1 Introduction Specifications
1-6 TC8926 Rev 1.0 User Manual
Physical (Rack mount 1U “Pizza Box” with two cards)
Height (4.3 cm) 1.7"
Width (48.3 cm) 19"
Depth (26.7 cm) 10.5"

TC8926 Rev 1.0 User Manual 2-1
Chapter 2 Installation
In this chapter:
•Power Supply, on page 2-2
•System Configuration, on page 2-2
2.1 General Information
The installation section describes how to:
• Unpack the unit
• Ensure an optimum site location
• Install the power supply and dry contact connection
2.2 Unpacking
Before unpacking any equipment:
• Inspect all shipping containers for evidence of external damage caused during
transportation
• Inspect for damage after it is removed from the containers
2.3 Equipment Location
The TC8926 should be located in an area that provides adequate light, work space
and ventilation.
IMPORTANT Any claims concerning shipping damage should be made directly to
the pertinent shipping agencies. Any discrepancies should be
reported immediately to the Customer Service Department at TC
Communications, Inc. at [phone].
Important Avoid locating it next to any equipment that may produce electrical
interference or strong magnetic fields, such as elevator shafts or
heavy duty power supplies.
As with any electronic equipment, keep the unit from excessive
moisture, heat, vibration and freezing temperatures.

Chapter 2 Installation Power Supply
2-2 TC8926 Rev 1.0 User Manual
