TCE EVO Series User manual

Dichiarazione di conformità /Declaration of conformity
Il sottoscritto / The undersigned Valentino Mattiazzo
In qualità di legale rappresentante della ditta / As legal representative of the company TCE Group S.r.l.
con sede in Sede / located in: Via G. Di Vittorio 5/9 - 35046 - Borgo Veneto (PD)
Partita IVA / VAT Nr.:04458670280
Dichiara che il prodotto Caricabatterie con le seguenti specifiche
Declares that the product Battery Charger with the following specifics
È stato costruito rispettando le seguenti direttive e norme:
It was built in compliance with the following directives and standards:
•Direttiva 2014/35/UE nota come “Direttiva bassa tensione” (per gli aspetti di sicurezza) / Directive 2014/35/UE known as “Low voltage directive” (for
safety aspects)
•Direttiva 2014/30/UE nota come "Direttiva compatibilità elettromagnetica" / Directive 2014/30/UE known as “Electro-Magnetic compatibility”
•Direttiva 2011/65/CE nota come “RoHS” / Directive 2011/65/CE known as “RoHS”
•Direttiva 2009/125/CE relativa all'istituzione di un quadro per l'elaborazione di specifiche per la progettazione ecocompatibile dei prodotti connessi
all'energia / Directive 2009/125/CE regarding the establishment of a framework to elaborate specifics for the eco-compatible development of products
related to energy
•Direttiva delegata (UE) 2015/863 della commissione del 31 marzo 2015 recante modifica dell'allegato II della direttiva 2011/65/UE / Delegated Directive
(EU) 2015/863 to the commission of 31 March 2015 amending Annex II of Directive 2011/65 / EU
•Direttiva 2012/19/UE nota come “RAEE” / Directive 2012/19/UE known as “RAEE”
•Direttiva 2001/95/CE nota “Sicurezza generale dei prodotti” / Directive 2001/95/CE known as “General safety of the products”
•Norma IEC 61882:2016 metodo di analisi dei rischi secondo il metodo HAZOP / Standard IEC 61882:2016 risk analysis method according to the HAZOP
method
•Norma IEC 61511-1:2016 Sicurezza funzionale - - Sistemi di sicurezza strumentati per il settore dell'industria di processo - Parte 1: Quadri, definizioni,
requisiti di sistema, hardware e di programmazione dell'applicazione / Standard IEC 61511-1:2016 Functional safety - Safety instrumented systems for
the process industry sector - Part 1: Framework, definitions, system, hardware and application programming requirements
•UNI EN ISO 7010:2017 Titolo: Segni grafici - Colori e segnali di sicurezza - Segnali di sicurezza registrati / UNI EN ISO 7010:2017 Title: Graphic signs -
Colors and safety signs - Registered safety signs
•EN 60 60335-2-29: 2016 - Sicurezza degli apparecchi elettrici domestici e simili Parte 2: Requisiti particolari per caricabatterie / EN 60 60335-2-29:2016
- Safety of household and similar electrical appliances Part 2: Particular requirements for battery chargers
Ed è quindi conforme alle direttive e normative vigenti / And therefore it complies with the directives and regulations in force.
La presente dichiarazione di conformità è rilasciata sotto la responsabilità esclusiva del fabbricante / This declaration of
conformity is issued under the sole responsibility of the manufacturer.
Luogo e data / Place and date
Borgo Veneto, 28/10/2020
Firma / Signature
Etichetta prodotto
Product label

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
2

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
3
I N S T A L L A T I O N , U S E A N D M A I N T E N A N C E M A N U A L
E V O / S E S e r i e s B a t t e r y C h a r g e r
TCE Group S.r.l.
Head office: via Giuseppe di Vittorio 5/9 –35046 Borgo Veneto (Padova) - ITALIA
Tel. [phone]
E-mail: [e-mail]
Website: www.tcechargers.com

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
4
Summary
Dichiarazione di conformità / Declaration of conformity .......................................................................................1
Section 1 ......................................................................................................................................................5
DECLARATION OF CONFORMITY.............................................................................................................................6
PRODUCER INFORMATION.....................................................................................................................................6
SERVICE CENTER .....................................................................................................................................................6
PRESENTATION.......................................................................................................................................................7
Graphic Conventions...........................................................................................................................................8
Pictograms..........................................................................................................................................................8
ATTACHED DOCUMENTATION................................................................................................................................9
Section 2 ....................................................................................................................................................10
WARRANTY ..........................................................................................................................................................11
GENERAL SAFETY RULES .......................................................................................................................................12
Warning............................................................................................................................................................12
Safety Rules.......................................................................................................................................................12
DESCRIPTION and INTENDED USE.........................................................................................................................13
TECHNICAL DATA..................................................................................................................................................13
UNINTENTED USE .................................................................................................................................................13
DATA SHEET..........................................................................................................................................................14
Residual risks.....................................................................................................................................................16
Section 3 ....................................................................................................................................................18
WARNINGS...........................................................................................................................................................19
UNPACKING INSTRUCTIONS .................................................................................................................................19
INSTALLATION LOCATION.....................................................................................................................................19
HANDLING............................................................................................................................................................19
Manual handling ...............................................................................................................................................19
INSTALLATION AND CONNECTION........................................................................................................................20
Preliminary checks ............................................................................................................................................20
Installation........................................................................................................................................................20
Preparation.......................................................................................................................................................20
Electric Connection ...........................................................................................................................................21
USE.......................................................................................................................................................................21
Problems...........................................................................................................................................................21
Use procedures.................................................................................................................................................22
Section 4 ....................................................................................................................................................24
MAINTENANCE.....................................................................................................................................................25
Safety................................................................................................................................................................25
Periodic maintenance........................................................................................................................................25
Extraordinary Maintenance...............................................................................................................................25
DECOMMISSIONING.............................................................................................................................................26
Device deactivation...........................................................................................................................................26
Disposal ............................................................................................................................................................26

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
5
Section 1
Declaration of conformity
Producer information
Documentation information
Attached documentation

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
6
DECLARATION OF CONFORMITY
The EVO/SE Series described in this documentation is sold together with the declaration of conformity, drawn up in compliance
with the laws in force on the European territory.
NOTE
BEFORE USING THE DEVICE IN ANY FORM, CHECK THE PRESENCE OF THE DECLARATION OF
CONFORMITY.
NOTE
IF THE DEVICE IS GIVEN TO A THIRD PARTY, ALL THE DOCUMENTATION MUST BE GIVEN
TOGETHER WITH IT.
PRODUCER INFORMATION
Company Name
TCE Group S.r.l.
Head Office
Via G. di Vittorio 5/9 –35046 Borgo Veneto PD
VAT Nr.
04458670280
Office Telephone
+39 0429/89290
SERVICE CENTER
The authorized assistance on the EVO/SE Series is performed directly by TCE Group S.r.l. or by a qualified technician
appointed by the same.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
7
PRESENTATION
NOTE
UPON DEVICE RECEIVAL, BEFORE PERFORMING ANY OPERATION, READ THIS MANUAL
CAREFULLY.
This manual contains instructions for the installation, configuration, use and maintenance of the EVO/SE series. The manual is
made up of various sections, each of which deals with a series of topics, divided into chapters and paragraphs.
The summary lists all the topics covered in the entire manual. The numbering of the pages is progressive and each page shows the
number of the same. This manual is intended for the user responsible for the configuration, use and maintenance of the EVO/SE
Series and relates to its technical life after its production and sale.
In the event that it is transferred to third parties for any reason (sale, loan for use, or any other reason), the device must be
delivered complete with all its documentation.
Before starting any operation it is necessary to have at least read the entire manual and then studied the
topic relating to the operations to be carried out in depth.
This manual contains proprietary information and cannot be partially supplied to third parties for any use and in any form, without
the prior written consent of the company TCE Group S.r.l ..
TCE Group S.r.l. declares that the information contained in this manual is congruent with the technical and safety specifications
of the EVO/SE Series to which the manual refers.
Certified copy of this manual is filed in the technical file of the device, kept at TCE Group S.r.l ..
TCE Group S.r.l. does not recognize any documentation that has not been produced, issued or distributed by itself or by its
authorized representative.
This manual, same as the technical file, will be kept by the manufacturer for the period required by law (10 years).
During this period, a copy of the documentation accompanying the product may be requested when purchased.
The entire technical file remains available for this period exclusively for the control authorities, who may request a copy.
After this period, it will be an obligation and care of whoever manages the product to make sure that both the product and the
documentation comply with the laws in force at the time of the inspection.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
8
Graphic Conventions
In order to obtain a more immediate understanding of the topics, the graphic and typographic symbols and conventions
described below have been adopted in the manual.
Warning graphic conventions
NOTE
NOTES CONTAIN IMPORTANT INFORMATION, HIGHLIGHTED OUTSIDE THE TEXT TO WHICH THEY
REFER
WARNING
WARNING INDICATIONS INDICATE THOSE PROCEDURES WHICH TOTAL OR PARTIAL NON-
COMPLIANCE MAY CAUSE DAMAGE TO THE DEVICE, ITS COMPONENTS AND MAY EXPOSE
PEOPLE TO DANGER.
DANGER
THE DANGER INDICATIONS INDICATE THOSE PROCEDURES WHICH A TOTAL OR PARTIAL
NON-COMPLIANCE MAY CAUSE DAMAGE OR INJURY TO THE HEALTH OF PEOPLE. SERIOUS
DAMAGE TO THE DEVICE.
Pictograms
Nel dispositivo sono presenti i seguenti pittogrammi:
Electrocution Danger
Generic Danger
Obligation to read the manual
WARNING!
Pictograms that perform a safety function must not be removed, covered or damaged.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
9
ATTACHED DOCUMENTATION
NOTE
BEFORE USING THE DEVICE, CHECK THE PRESENCE OF ALL THE ATTACHED DOCUMENTATIONS.
NOTE
IF IT IS GIVEN TO A THIRD PARTY, ALL THE DOCUMENTATION OF THE DEVICE MUST BE DELIVERED
WITH IT.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
10
Section 2
Warranty
General safety rules
Technical specifics
Intended and unintended use
Residual risks

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
11
WARRANTY
The warranty rules, listed in full in the purchase contract, are valid only if the device is used in the conditions of intended use.
With the exception of the interventions described in section MAINTENANCE and performed with the procedures indicated, any
repair or modification made to the EVO/SE device by the user or by unauthorized companies will invalidate the warranty.
The warranty does not extend to damage caused by inexperience or negligence in the use of the device, or by bad or omitted
maintenance.
The warranty covers the products sold by us only and exclusively under the following conditions:
1)
The warranty is valid for a period of 12/24 months depending on the legal nature of the customer.
2)
1) The manufacturing company decides to replace, at its own discretion, the malfunctioning or incorrectly manufactured parts,
only after a careful control and verification of incorrect assembly.
2)
3)
3) The transport and/or shipping costs for the repair or replacement of the product are always charged to the buyer.
4)
4)
5) During the warranty period, the replaced products become the property of the manufacturer.
6)
5)
Only the original purchaser who has complied with the ordinary maintenance instructions contained in the manual can benefit
from this guarantee. Our warranty liabilityexpires when the original owner relinquishes ownership of the product, or changes
have been made to the product.
6)
The warranty does notinclude damage resulting from excessive stress such as the use of the product after finding an anomaly,
the use of unproper operating methods as well as the failure to observe the instructions for use and maintenance.
7)
7) The manufacturer assumes no responsibility for any difficulties that may arise in resale or use abroad due to the laws enforced
in the country in which the product was sold.
8)
8)
The defective product or part of the product will not be replaced without proof of purchase (invoice, copy of payment);
otherwise the replaced part will be charged to the buyer.
9)
9)
The warranty does not respond if there is tampering with the power plug (if it is already present in the device)
Notice: if it is deemed necessary to use the warranty, please indicate the following information:
•Type / Version
•Purchase date (presentation of the purchase document)
•Detailed description of the issue
NOTE
FAILURE TO COMPLY WITH THE METHODS OF INTERVENTION AND USE OF THE DEVICE
DESCRIBED IN THIS DOCUMENTATION WILL LEAD TO THE FOREIGNMENT OF THE WARRANTY
TERMS.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
12
GENERAL SAFETY RULES
Warning
On our site you can find all the documentation required by law for the sale of this product, if you wish to receive it in printed
format, you can request it to our customer service.
If part of the documentation is partially missing or even illegible, consult TCE Group S.r.l. before performing any further operation
on the device. On the TCE Group S.r.l. website you can find and download a copy of the installation/use and maintenance manual
of our products.
This chapter describes the general safety rules to be observed during any operation performed with the device. The intervention
procedures, described in the following chapters, must be carried out in compliance with both the methods of execution indicated
and the general safety rules of this chapter.
The safety rules and the configuration, use and maintenance procedures indicated in this document are also a complement to
the general workplace safety rules that must be respected.
Different nations may have different safety regulations. It is therefore specified that in all cases in which the documentation
standards are in conflict or reductive with respect to the standards of the country in which the EVO/SE Series is used, the standards
of the country will in any case have priority over those in the documentation.
NOTE
THE MANUFACTURER CANNOT BE HELD IN ANY CASE LIABLE FOR ACCIDENTS OR DAMAGES
RESULTING FROM THE INAPPROPRIATE USE OF THE DEVICE, AS WELL AS EVEN PARTIAL NON-
COMPLIANCE WITH THE SAFETY RULES AND INTERVENTION PROCEDURES DESCRIBED IN THE
DOCUMENTATION.
Failure to comply with the rules of use and the methods of intervention, configuration, use and maintenance of the EVO/SE Series
contained in the manual also results in the cancellation of the warranty terms.
Safety Rules
During the configuration and subsequent use of the EVO/SE series, incorrect operating situations may occur that are not foreseen
by the documentation. These completely anomalous situations can sometimes be caused by environmental factors or by
fortuitous failures not foreseeable by the manufacturer.
The manual must be kept by the user and/or by the personnel responsible for handling, maintaining and using the device.
In the event of deterioration or loss, a certified copy may be requested by the customer to the manufacturer. We suggest that you
keep a security copy in a place where it cannot be damaged or lost.
WARNING
BECAUSE IT WOULD BE IMPOSSIBLE TO DESCRIBE ALL THE OPERATIONS THAT SHOULD NOT OR
CANNOT BE PERFORMED, IT IS DEEMED THAT ALL THE OPERATIONS (OTHER THAN NORMAL
USE) THAT ARE NOT EXPLICITLY DESCRIBED IN THE MANUAL PROVIDED WITH THE DEVICE, ARE
NOT TO BE PERFORMED.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
13
DESCRIPTION and INTENDED USE
The SE / EVO series identifies 50hz products having as control an electronic board that determines the timers as regards the
charging cycle and a dispersed flux power transformer that guarantees the decreasing current curve during the charging
phase.The SE / EVO series identifies 50hz products having as control an electronic board that determines the timers as regards
the charging cycle and a dispersed flux power transformer that guarantees the decreasing current curve during the charging
phase.
TECHNICAL DATA
Mechanic data
Dimensions (mm)
SE (502x384x607h), EVO (374x514x856H), BIG (623x561x860H)
Weight (kg)
May variate based on the model / series
Grado di protezione
IP21
Electrical data
Power Supply (V)
Ref. device serail number label
Frequency (Hz)
50/60
Absorbed current (A)
Ref. device serail number label
Power (W)
Ref. device serail number label
Electrical safety class
Class I –groounded
Cable
Ref. Pag. 14
Connectors
Not included
The charger is equipped with several safety devices to ensure reliable and safe use.
The safety devices are used to protect the battery, the charger and the surrounding environment.
The control board offers safety on the charging cycle, as it monitors the various charging phases making sure that the recorded
and read values are always within an optimal range for the connected battery.
The fuse installed inside the device offers protection against short circuit and reverse polarity.
All TCE Group S.r.l. devices are equipped with different timers to provide reliability during nighttime charges or during weekends.
UNINTENTED USE
No use other than those described in the DESCRIPTION and INTENDED USE paragraph is allowed.
It is also absolutely forbidden:
•The use of the device with power supply networks other than those supported (see Technical data).
•The use of the device for applications that differ from those indicated.
•Tampering with the components of the device (hardware).
•Use the device with incompatible accessories.
•Use the device to recharge batteries other than lead-acid ones for traction and semi-traction.
•Use the device without installing the DC plug
The reuse of any unit after decommissioning the device relieves the manufacturer of any liability arising from the use of the same.
NOTE
THE MANUFACTURER CANNOT BE HELD IN ANY CASE LIABLE FOR ACCIDENTS OR DAMAGES
RESULTING FROM UNINTENDED USE OF THE DEVICE. ANY UNINTENDED USE ALSO LEADS TO THE
TERMINATION OF THE WARRANTY TERMS COVERAGE.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
14
Box Box Box Box Cavo
kw
Amp (A)
SE EVO kw
Amp (A)
SE Evo DC mmq
24060 60 2,20 3 C S - - - - 16
24080 80 2,80 4 C S 3,00 12 C S 16
24100 100 3,40 5 C S 3,80 17 C S 25
24120 120 4,00 6 C S 4,50 20 S S 25
24140 140 4,60 7 S S 5,20 24 S S 35
24160 160 5,30 8 S S 6,00 27 S S 35
24180 180 5,90 9 S S - - - - 50
36080 80 3,90 6 C S 4,50 20 C S 16
36100 100 4,90 7 C S 5,70 25 C S 25
36120 120 5,80 9 C S 6,80 30 S S 25
36140 140 6,80 10 S S 7,90 34 S S 35
36160 160 7,90 12 S S 9,00 39 S S 35
36180 180 9,80 13 S S - - - - 50
48060 60 3,80 6 C S 4,50 20 C S 16
48080 80 5,00 8 C S 6,00 27 C S 16
48100 100 6,40 10 C S 7,60 33 S S 25
48120 120 7,80 12 C S 9,10 39 S S 25
48140 140 9,00 14 S S - - - - 35
48160 160 9,60 16 S S - - - - 35
48180 180 10,40 22 S S - - - - 50
48200 200 11,70 28 S S - - - - 50
72080 80 7,80 12 C S 9,10 26 S S 16
72100 100 9,70 15 C S 11,20 32 S S 25
72120 120 11,50 18 C S 13,20 39 S S 25
80080 80 8,70 13 C S 10,10 42 S S 16
80100 100 10,40 16 C S 12,60 54 S S 25
80120 120 12,50 19 S S - - - - 25
80140 140 15,50 23 S S - - - - 35
80160 160 17,60 27 B B - - - - 35
80180 180 19,70 34 B B - - - - 50
80200 200 21,00 39 B B - - - - 50
72
80
400 Vac
230 Vac
24
36
48
Model.
Volt
(V)
Current
(A)
DATA SHEET

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
15
MOB. C
MOB. S
MOB. B

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
16
Residual risks
In the development phase TCE Group S.r.l. carried out a deep risk analysis on the system in question.
From this analysis, risks that cannot be eliminated due to their nature emerged. These risks have therefore been examined
individually and in this manual the guidelines on how to avoid them have been emphasized. It is therefore important that any user
responsible for configuring, using and maintaining the EVO/SE Series, has previously read the manual.
NOTE
THE MANUFACTURER CANNOT BE HELD IN ANY CASE LIABLE FOR ACCIDENTS OR DAMAGES
RESULTING FROM UNINTENDED USE OF THE DEVICE, AS A RESULT OF USER NEGLIGENCE
In particular:
•It is absolutely forbidden to make any modifications to the EVO/SE Series. Any damage to people, animals or things
resulting from the use of the device improperly modified by an unauthorized operator relieves the manufacturer from
any responsibility.
•Keep this manual carefully, as it is necessary for a correct and safe use of the EVO/SE Series. Periodically check the
status of the label applied to the product and restore it if it is damaged. (in case contact the service center)
•If the external structure of one of the components of the EVO/SE Series has sharp corners or edges following an
accidental impact, such as to make it dangerous, or to doubt the degree of the IP protection, it is necessary to contact
the service center and follow their instructions.
•Use only products with compatible devices as indicated in this document.
Important:
-Do not wet the electrical connections or any parts of the device with water or other liquids
-Proceed with caution during the installation phases to avoid damaging the device.
-The installation must be optimally performed by specialized personnel.
-The electrical connection to the existing system must be performed by qualified personnel in accordance with the laws
and regulations in force.
-The power supply line must have cables with an adequate section evaluated on the basis of the serial number label plate,
and in any case not less than 1.5mmq.
-Do not power at a voltage different from that indicated on the serial number label plate.
-The device must be separated from any heat source (such as lighting appliances and fireplaces) or other types of chargers
or any other object that may emit harmful substances.
-Make sure that the DC cables are complete with plug and always raised from the floor even when the device is NOT
operating
-Make sure the DC cables do not tangle causing damage to their own integrity.
OPERATIONS INVOLVING RISKS FOR THE OPERATOR:
During the configuration and commissioning operations, comply with the general accident prevention regulations.
In particular:
- if you work on electrical parts, make sure they are not live.
Already in the development phase, solutions have been adopted to ensure safe use of the device at all stages of use: transport,
assembly, adjustment, use and maintenance. However, not all possible risks for operators and the environment have been
eliminated, both for technological reasons (reliability of the devices) and for management (excessive difficulties in elimination),
consequently the residual risks present are reported.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
17
Any improper use of the device can cause:
•Injury or death to the user or to third party persons
•Damage to the device and/or to other material or assets belonging to the company where the device is located
•Damage to the environment surrounding the device
•Inefficient and non-compliant operations with the normal operating status of the device
The personnel involved in the use of the device must:
•Have a qualification in the use of electrical/electronic equipment
•Read the manual carefully to understand the correct operation of the device
•Comply with the safety regulations listed below
•Use the correct tools when repairing faults or during simple device maintenance
In case of further signs or notifications applied on the device for safety reasons, they must be:
•In a readable and understandable state for all
•Do not be damaged
•Not to be removed
•Do not cover existing writings or signs
•Do not be covered by other signs / stickers or colored with paint or color of any kind

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
18
Section 3
Installation location
Handling
Installation and connection
Use

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
19
WARNINGS
When handling and installing the product, it is necessary to provide for the use of personal protective equipment (PPE) such as:
- Clothing:
Complies with the essential safety requirements in force to protect against minor mechanical damage.
- Gloves:
Operating in areas with voltage and live parts, it is necessary to use CE-marked gloves as PPE that protect against all the
risks just analyzed.
- Safety shoes with non-slip sole:
They are necessary in all works where there is a risk of a potentially dangerous piece falling.
- Safety goggles:
They are necessary in all works where there is a danger that an object and/or material could be thrown into the eyes of an
operator.
UNPACKING INSTRUCTIONS
The device is delivered in a cardboard box. Inside the box you will find:
•Device complete with power cord and DC cable
•Instruction manual
•Any compliant accessories if requested by the customer when ordered
INSTALLATION LOCATION
It is good to keep in mind some aspects before proceeding with the handling, installation and subsequent use of the device. In
particular, it is necessary to check some factors:
•The product storage area must be chosen so that it cannot be hit by water, steam jets and corrosive acids. It must never
be subjected to atmospheric agents before installation.
•It must be fixed on a linear surface.
•Temperature range of use -30 ° C to +65 ° C
•Storage temperature range -40 ° C to + 95 ° C
•Maximum relative humidity conditions of the air:
oUp to 80% non-condensing during storage;
oUp to 95% in use;
•The device can be installed both indoors, provided they are well ventilated, and outdoors.
•Altitude up to 2000mt
HANDLING
It must be kept in mind that, even if carefully protected and packaged, the device must be considered and handled with care and
attention.
Before moving the device, check the integrity of the device and its parts. If you find any damage, lack, deformation or traces of
collisions, notify the authorized assistance service before proceeding with the following operations.
Manual handling
The weight of the assembled device, because of its heavy weight, can be manually handled by using the side handles accessory
supplied on request to TCE Group S.r.l. or with dedicated lift machineries.

TCE Group S.r.l. Installation, use and maintenance manual –Serie NEOS
20
INSTALLATION AND CONNECTION
The product has been developed, manufactured and tested to meet all specific standards (see the declaration of conformity), if
installed and connected in a proper manner.
All the products are tested and configured by the manufacturer before shipping and delivery to the customer.
If the installation, use and/or maintenance of the device are not carried out in a proper manner, anomalies may occur during
operational use, and safety problems may also occur. Inappropriate installation and maintenance will void the warranty terms.
WARNING
THE DEVICE CAN ONLY BE OPERATED AFTER IT HAS BEEN INSTALLED CORRECTLY.
Before installing, connecting and operating the device, completely remove any protection from dust or humidity and any
packaging material.
Preliminary checks
Check for any damage
Check that the various parts of the device do not show physical damage due to shocks, tears or abrasions.
Check in particular:
•That the cables are not damaged/ruined/cut
•That the device is not damaged/ruined/cut.
•That the power plug (if present) is not damaged or ruined
Damage Reporting Procedure
If any damage is found, interrupt the procedure in progress and report the nature of the damage to the manufacturer's
customer support office.
Installation
To install the product, proceed as follows:
1. Remove it from the packaging, making sure to remove all protections (inserted in order to protect the device from dust
and humidity and/or anything else that may occur during transport)
2. Proceed to a visual check of the integrity of the charger and all its connected parts
3. Proceed with the installation of the DC connector (ensuring compatibility with the battery)
Preparation
•Make sure the power and charging plugs are installed. If not, contact a specialized technician to install the properly sized
connectors for the device and the power supply network
•Make sure that the DC and AC charging cables are in perfect condition before proceeding with the installation
•Make sure that the mains socket into which the device will be connected is properly grounded and protected by adequate
safety measures
•Make sure that the device is suitable for the connected battery (check serial label)
•Make sure that the device is positioned in a place suitable for its purpose that does notlead to accidental fall and possible
damage.
•Avoid placing the device in areas with sparks and/or flames as the battery generates explosive gases during the charging
process
•Make sure the battery cells are in good condition and that there are no short circuits
•Make sure there are no objects on top of the battery cells before starting the charging cycle
•Make sure that ordinary maintenance of cleaning (every 6 months) has been carried out. Otherwise, proceed with
cleaning (with the charger not powered) to ensure optimal ventilation and heat dissipation
•It is recommended not to use and unplug the device during heavy thunderstorms
