TCL PR503SSF0 User manual
Etichettatura Ambientale degli Imballaggi
Cartone d'imballaggio (Pannello di fibra ondulato)20PAPPAP 20Collezione di cartaParti di protezione (Pannello di fibra ondulato)20PAPPAP 20Collezione di cartaCartone d'imballaggio (Pannello di fibra non ondulato)21PAPPAP 21Collezione di cartaParti di protezione (Pannello di fibra non ondulato)21PAPPAP 21Collezione di carta4LDPELDPE 4Collezione di plasticaSacchetto di plastica per l'imballaggio del manuale2HDPE
HDPE 2
Collezione di plasticaSacchetto di plastica per l'imballaggio del prodotto22PAPManualePAP 22Collezione di carta
Etichetta di efficienza energetica
22PAPPAP 22Collezione di carta22PAPScheda di garanziaPAP 22Collezione di carta22PAPAltra etichetta (Carta)PAP 22Collezione di carta4LDPEParti di protezione (EPE)LDPE 4Collezione di plasticaSchiuma EPS (EPS+PP)PS+PP 7Collezione di plastica7PS+PP6PSSchiuma EPS (EPS)PS 6Collezione di plastica6PSParti di protezione (EPS)PS 6Collezione di plastica5PPCintura di imballaggioPP 5Collezione di plastica
P16Care and maintenance ------------------------------------------------------------------Failure analysis ----------------------------------------------------------------------------Non-failure ---------------------------------------------------------------------------------- Technical parameter-----------------------------------------------------------------------Packing list-----------------------------------------------------------------------------------Safe recovery instructions Description of climate types P16Safety instructions ------------------------------------------------------------------------Product introduction ----------------------------------------------------------------------
Handling and placement -----------------------------------------------------------------
Preparations prior to use ----------------------------------------------------------------
Operation keys ---------------------------------------------------------------------------- Operation and diagram of display board ---------------------------------------
Food storage --------------------------------------------------------------------------
Ice-making ----------------------------------------------------------------------------- Disassembly and assembly method of accessory ---------------------------P2P5P6P7P8P8P11P12 P13P13P11P12
P15P14
Thank you for choosing our refrigerator. We appreciate your trust and suppo.We will do our best to see you. We hope you enjoy your new purchase!1.This appliance is not intended for use by persons (including children) with reduced physical, senso or mental capabilities, or lacking experience and knowledge, unless they are given supeision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supeised to ensure that they do not play with the appliance.2.If the power cord is damaged, it must be replaced by the manufacturer, its seice agent or similarly qualied persons in order to avoid a hazard.3.This appliance can be used by children aged from 8 years and above and persons with reduced physical, senso or mental capabilities or lacking experience and knowledge if they are given supeision or instruction concerning safe use of the appliance and understand the associated hazards. Children should not play with the appliance. Cleaning and user maintenance should not be made by children without supeision.4.WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.5.WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.6.WARNING: Do not damage the refrigerant circuit.7.WARNING: Do not use electrical appliances inside the food storage compaments, unless they are the type recommended by the manufacturer.8.Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.9.This appliance is intended to be used in household and similar applications such as— Sta kitchen areas in shops, oces and other working environments;— Farm houses and hotels, motels and other residential type environments;— Bed and breakfast type environments;— Catering and similar non-retail applications.
WarningWarning: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.Warning: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.Warning: Do not damage the refrigerating circuit.Warning: Do not use electrical appliances inside the food storage compaments, unless they are of the type recommended by the manufacturer.Warning: Do not put food and liquids in glass containers in the freezing chamber to avoid glass breakage.Warning: If powered o, the refrigerator will be powered on 5min later to avoid compressor damage.Warning: If any live pa, abnormal noise, smell, smoke or other abnormality is found during use, power o the appliance immediately and contact the aftersales seice timely.Warning: Do not inse your ngers or hands into the bottom of the refrigerator, especially into the bottom at the back; you can be hu by sharp objects.Warning: Children must not play with or climb the refrigerator. Children must be supeised by their parents to avoid danger.Warning: Do not put your hand between the doors when opening or closing the refrigerator door; otherwise you may get smashed ngers. Use the door handle to open or close the door.Warning: Under the climate classes SN, N , ST and T , the appliance should operate at ambient temperatures ranging from 10℃ to 43℃. If the appliance operates outside the rated climate class (ambient temperature range), it may not be able to maintain a satisfying interior temperature.Opening the door for long periods can cause a signicant temperature increase in the refrigerator compaments.Regularly clean suaces that can come in contact with food and accessible drainage systems.Clean water tanks if they have not been used for 48 hours.Store raw meat and sh in sealed or covered containers in the refrigerator to prevent them touching or dripping onto other food.Two-star frozen-food compaments are suitable for storing pre-frozen food, storing or making ice-cream and making ice cubes.One-, two- and three-star compaments are not suitable for freezing fresh food.If the refrigerator is left empty for an extended period of time, please leave it disconnected, defrosted, clean, and d, with the doors open to prevent mould developing within the appliance.Warning: When positioning the appliance, ensure the power cord is not trapped or damaged.
Warning: Risk of fire / flammable materials.Warning: Do not locate multiple poable socket-outlets or poable power supplies at the rear of the appliance.CautionCaution: The power supply shall be consistent with the information on the nameplate, and the standard independent 3-hole socket shall be used (above 10A, and reliably grounded). One socket must not be shared by more than one appliance; otherwise, re may be caused due to overheat.Caution: Never pull the power cord by hand. Hold and unplug the power connector from the socket to disconnect the power supply. Never touch the power cord or connector with wet hands to avoid electric shock.Caution: The power cord must not be squeezed by the refrigerator or any heavy load, and the power cord should not be bent extremely. The damage or peeling of power cord may result in re or electric shock. If the power cord is broken or cut, please contact the after-sales seice immediately.Caution: No ammables, explosives, corrosive acid or alkaline substances are allowed in the refrigerator.Caution: The refrigerator must not be used in the rain or under the sunshine.Caution: It is forbidden to place a container lled with liquid on the refrigerator because the breakage or turnover of the container may aect the electrical insulation of refrigerator and result in electric shock or re.Caution: The refrigerator must not be disassembled or modied without permission. The repair must be peormed by a specialist.Caution: In case of leakage of any ammable gas such as coal gas, close the leaking valve rst and then open the window for ventilation. Do not unplug the refrigerator connector immediately to avoid re or explosion caused by electric spark.Caution: Refrigerating appliances – in paicular a refrigerator-freezer Type I – might not operate consistently (possibility of defrosting of contents or temperature becoming too high in the frozen food compament) when sited for an extended period of time below the cold end of the range of temperatures for which the refrigerating appliance is designed.
Caution: Eeescent drinks should not be stored in food freezer compaments or cabinets or in low-temperature compaments or cabinets, and food like water ices should not be consumed too cold.Caution: Do not exceed the storage time(s) recommended by the food manufacturers for any kind of food.Caution: During defrosting, precautions are necessa to prevent an undue temperature rise of the frozen food, such as wrapping the frozen food with newspaper.Caution: A temperature rise of the frozen food during manual defrosting, maintenance or cleaning could shoen the storage life.Caution: Care is required for the frozen food in storage if the refrigerator is out of seice for an extended period of time (interruption of power supply or failure of the refrigerating system).Caution: Measures must be taken when the refrigerator is switched o and out of seice temporarily or for an extended period (e.g. emptied, cleaned and dried, and the door(s) or lid(s) propped ajar).
Warning: --When handling the refrigerator, at least two persons are required – one lifts the top of rear part, the other one handles the bottom (if one part is clamped, it is quite dangerous and may cause accident). --When moving the refrigerator, the lower runner may damage and scratch the floor. If you need to move the refrigerator for a long distance, the internal accessories shall be fixed using adhesive tape. Otherwise, the accessories may get damaged due to crashing each other. --Please place the refrigerator in the position with small vibration or little exposed to vibration. For users in the area where earthquake often occurs, please fix the refrigerator against the wall or pole. Otherwise, the falling of refrigerator will cause accident. --Sufficient clearance shall be left around. If the clearance is too small or if goods are placed on the top or close to the side, or paste on the sides, the heat dissipation of refrigerator will be affected, and thus to cause unnecessary electric energy waste as well as burn out of the wall and other goods; the contact between the back and wall will cause vibration and noise; --Adjust the front part and adjusting leg of the refrigerator to level it. A unlevel refrigeratorrefrigerator will cause vibration and noise.
This refrigerating appliance is not intended to be used as a built-in appliance
Replaceable (LED only) light source by a professional
Ice-making (If the appliance has it) Fill the ice-making box with 4/5 water and put the box into the freezing chamber. After the water in the box turns into ice, twist the box slightly to separate the ice from the box. However, don't bend the box. When separating the ice, wrap the box with dry box to avoid finger frostbite.
Disassembly and assembly method of accessory--Glass shelf in the refrigerating chamber: the height of the shelf is adjustable, which facilitates the storage of articles with different volumes. Pull the shelf outwardly and upwardly in a slight way to take out.--Fruit and vegetable box: for storing vegetables and fruits. It can be taken out by pulling outwardly.--Drawer in the freezing chamber: storing foods to be preserved for long-term, such as meat and fish. It can be taken out by pulling outwardly and lifting upwardly.Handy tips: It is recommended to put into the large piece of meat after being cut into small pieces, to avoid difficult cutting after being frozen. The quick-freezing foods shall be distributed uniformly and stored together after being frozen. --Bottle pedestal at the refrigerating door: storing eggs, various bottled drinks and other sundries. It can be taken out by being lifted up slightly. Note: Don't pull out the bottle pedestal at the refrigerating door forcibly during disassembly, to avoid damaging the refrigerator. Take out by pulling upwardly and outwardly in a slight wayTake out by pulling outwardly and upwardly in a slight wayGently pull and get out along the reverse direction of arrow--Components of water storage box: Used for storing the water yield needed by the water dispenser for the purpose of taking the drinkingwater.--Water-adding of water storage box: Firstly, open the box cover of water storage box by hand, then, pour the water into the water storage box from the container with water. After adding the water, close the box cover of water storage box. --Installation of components of water storage box: Before installing the water storage box, firstly, cover the water storage box firmly and reliably, then hold the both sides of the water storage bucket by hand with balanced force, and slowly press along the arrow direction until it cannot be pressed.--Disassembly of components of water storage box: The disassembly method of the water storage box is same with the installation method. Just implement it in the reverse direction. ★★ Warm prompt: When adding the water in the water storage box, the water addition cannot exceed the tip line of maximum water storage scale; To ensure the water quality, it is suggested to clean the water storage bucket and outlet water pipe regularly. During the maintenance and cleaning of water storage box and pipes, it is suggested to disconnect power supply to avoid the accident. Pay attention to the operating strength when opening the door,rest the water in the storage tank overflowed by opening the door too fast.
It is suggested to clean the refrigerator once per month; --Unplug the power plug to prevent from electric shock; --Use wet cloth or neutral detergent (cleanser essence) to wipe othe oil contamination and other dirt. Then completely wipe o theff detergent. --Do not use alkaline detergent, soap powder, gasoline and alcohol, talcum powder etc.; otherwise the coats or plastics may be damaged; --Regularly clean the refrigerator body and clear the ground dusts to keep the refrigerator clean. Inspections after maintenance: 1.. Whether there are damages to the power line and plug; Whether there are dusts on the power plug; 3. Whether there is abnormal heat on the plug; 4. Whether the socket is loose; 5. Whether the plug is totally inserted. Note: If the power line and plug is damaged and there exist dusts, electric shock or fire may occur; After unplugging the plug, 5 minutes must pass before re-plugging it; Do not put your hands under the refrigerator to avoid getting hurt.
Care and maintenance
Please use neutral detergent
Neutral detergent
Unplug the refrigerator plug before cleaning-- Water dispenser: The users can take the drinking water through the equipment at any time according to the own needs.- Water taking: When the users want to drink water, they need to press (extrude) the water-taking handle or use the rigid container to press (extrude) the water-taking handle until the water outlet flows the water and after meeting the needs. After taking water, stop pressing(extruding) , release the water-taking handle, and the water stops flowing. Before taking water, please ensure the water storage box has enough drinking water; Please ensure the water quality in the water storage box is withoutimpurities and foreign matters, etc., to avoid blocking the water outlet. The users are suggested to use 2.5L of drinking water at least in one week to ensure the fresh water source in the water way system. When taking water, it is suggested to close the door with water dispenser to avoid the shaking of refrigerator door, sprinkling of water and other accidents in the process of taking water. Due to the different areas and seasons, as well as the instability of indoor environment temperature and humidity, it is the normal phenomenon if the water dispenser has water droplets and condensation in other places except for the water outlet. Please wipe it with towel and duster cloth, thiswill not affect the usage. ★★ Warm prompt:
Water-taking handle
ff
The following items shall be inspected before occurring failures which require maintenance:Failures:Refrigerator does not work,The refrigeration effect is poorCauses:1. Check the connection of power supply. 2. Check whether the refrigerator is exposed to direct sunlight or whether there is heat source nearby. 3. Check whether there is heat dissipation space around refrigerator. Remedies:1. Connect the power supply. 2. Move the refrigerator to a place without direct sunlight and heat source. 3. Leave sufficient space between refrigerator and wall. Failures:Foods in refrigerating chamber are frozenCauses:1. Check whether the setting temperature is too low. 2. Check whether foods with too much water are too close to the rear wall. Remedies:1. Adequately increase the temperature. 2. Move the foods with too much water to the door side of glass shelfFailures:There is abnormal sound in refrigeratorCauses:1. Check whether the bottom of refrigerator is stable. 2. Check whether the refrigerator is too close to the wall. 3. Check whether the refrigerator touches other objects. Remedies:1. Adjust the bottom adjusting leg to stabilize the refrigerator. 2. Leave sufficient space around refrigerator. 3. Remove the obstacles. Failures:There is abnormal odor in refrigeratorCauses:1. Check whether the foods are sealed for storage. 2. Check whether the refrigerator is clean. 3. Check whether the foods are stored for too long .Remedies:1. Sealed foods for storage. 2. Regularly clean the refrigerator. 3.Do not store foods for too long time.
Non-failures
Phenomenon:Fever or hot on two sides and spacing part surface between refrigerating chamber and freezing chamber. Cause:Refrigerator pipes (condenser, anti-fog pipes) are on two sides and front part of refrigerator for heat dissipation and to prevent from condensation. Phenomenon:The door is too tight and not easy to openCause:Reopening of the door immediately after closing it is hard because hot air enters the refrigerator and contracts to produce pressure difference. It is easy to open the door after a while. Phenomenon:There is water ripple in refrigeratorCause:When starting or stopping the compressor, the refrigerant will make such sound;Water produced after defrosting will also make such sound. Phenomenon:There is “Click” sound or tick sound in refrigeratorCause:Shrinkage and swelling of case will make such sound;When the case is cold or the door is opened, this sound will occur;Phenomenon:There is hum sound in refrigeratorCause:Running of compressor will make such sound (if the refrigerator is not leveled, this sound will be louder)Phenomenon:There is condensation or frosting freezing chamber door surface or food surfaceCause:Temperature or humidity around the refrigerator is high;The door is opened for too long time;The foods with too much water are not sealed or tightly wrappedPhenomenon:There is condensation on the built-in light surfaceCause:Light will produce heat after being lit, and the door is opened for too long . So there is temperature difference, and thus the light case will have condensation. Phenomenon:There is condensation and water mist on bodyCause:Humidity around refrigerator is high, and the moisture in the air will gather in the case to form condensation
Description of climate types
SymbolAmbient temperature ranges℃STNSN+ 10 to + 32+ 16 to + 32+ 16 to + 38+ 16 to + 43TClassExtended temperateTemperateSubtropicalTropicalTable 1 Climate classesExtended temperate:‘this refrigerating appliance is intended to be used at ambient temperatures ranging from 10 °C to 32 °C’;temperate:‘this refrigerating appliance is intended to be used at ambienttemperatures ranging from 16 °C to 32 °C’;Subtropical:‘thisrefrigeratingapplianceisintendedtobeusedatambienttemperaturesrangingfrom16°Cto38°C’;Tropical:‘thisrefrigeratingapplianceisintendedtobeusedatambienttemperaturesrangingfrom16°Cto43°C’;Dear customerif you need customer service, please check warranty card for further information.DisposalOld appliances still have some surplus value. An environmentally friendly approach will ensure that valuable raw materials are recycled.The refrigerants used in your equipment and insulation materials require special handling procedures. Make sure there is no pipe damage on the back of the equipment before handling.Up-to-date information on the options for disposing of old equipment and packaging from old equipment can be obtained from the local council.Correct Disposal of this product.This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To retum your used device, please use the return and ollection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycing.
