TCL TRF-210 Installation instructions

TCL Home Appliances (HeFei) Co., Ltd.
Product model: TRF-210
Refrigerator Disassembly and
Recycling Manual

2
Disassembly Guide
Guidelines
Required tools:
1. A pair of white gloves
2. A Phillips screwdriver
3. A sleeve (size: 8mm)
4. Pincer pliers
A pair of white gloves A Phillips
screwdriver (electric)
A sleeve (size: 8mm) Pincer pliers

3
2. Pull the hinge cover
upwards to open
forcefully
3. Use an 8mm sleeve to
loosen three screws of
the upper hinge
4. Remove the bolts with
a cross screwdriver
Disassembly Guide
Disassembly guidelines for refrigerator chamber door
1. First disassemble the
upper hinge (the figure
shows the appearance of
the upper hinge)
5. The state after the
bolts are removed
6. Remove the upper
hinge
7. Gently lift up and remove the
refrigerator chamber door
8. Complete the disassembly of the
refrigerating chamber door

4
Disassembly guidelines for freezer door
2. Use an 8mm sleeve to
loosen two screws of the
middle hinge
4. Remove the middle
hinge (In this process, it is
necessary to hold the
door firmly)
3. Remove the bolts with a
cross screwdriver
5. After removing the
middle hinge, gently lift
up and remove the
freezer chamber door
6. Complete the
disassembly of the freezer
chamber door
1. First disassemble the
middle hinge and open
the freezer chamber door
Disassembly Guide

5
Disassembly of the temperature control lamp assembly
4. Pull out the wire
harness of the thermostat
from the inside of the box
1. Appearance of
temperature control
lamp assembly
8. The state of the temperature control
lamp assembly after disassembly
2. Use a cross screwdriver to
remove the screws on the
temperature control lamp
3. Remove the
temperature control lamp
assembly by hand
5. Unplug the wire harness
connection terminal on the
thermostat
6. Unplug the plug
terminal connected
to the thermostat
7. Remove the temperature
control lamp assembly
Disassembly Guide

6
Disassembly of the bottom adjusting foot
2. Use an 8mm sleeve to
loosen two screws of the
lower hinge
4. Use a cross screwdriver
to remove the other bolt
3. Remove the bolts with a
cross screwdriver
5. Remove the bottom
adjusting foot by hand
6. Complete the
disassembly of the bottom
adjusting foot
1. Appearance of
bottom adjusting foot
Disassembly Guide

7
Disassembly of the water tray of the compressor
compartment
1. Prepare to disassemble the
water tray of the compressor
compartment
4. Remove the water tray of the
compressor compartment
2. Use a cross screwdriver to
disassemble the screw at one
end of the lower water tray
3. Use a cross screwdriver to
disassemble the screw at the other
end of the lower water tray
Disassembly Guide

8
Disassembly of compressor chamber
Step I: Use pincer pliers to cut off all the high and low
pressure pipelines of the compressor chamber;
Step II: Use an 8mm sleeve and a Phillips
screwdriver to loosen four fixing screws on the
bottom of the compressor, and then remove the
compressor floor;
Step III: Use an 8mm sleeve and a Phillips
screwdriver to remove fixing screws on the
bottom of the compressor, and finally
remove the compressor;
