Radial Lead Inductors(Coils)
For Power Line
TSL Series TSL1112
FEATURES
• The TSL series feature low DC resistance and high current han-
dling capacities, making them ideal for power supply line appli-
cations.
• These parts are manufactured to a high degree of dimensional
accuracy using non-flammable material (UL94V-0).
• Available in tape packaging to support automated mounting
machines.
• It is a product conforming to RoHS directive.
APPLICATIONS
Televisions, VCRs, personal computers, and other electronic
equipment.
SPECIFICATIONS
PRODUCT IDENTIFICATION
(1)Series name
(2)Dimensions
(3)Packaging style
(4)Inductance value
(5)Inductance tolerance
(6)Rated current
(7)Lead-free compatible product
PACKAGING STYLE AND QUANTITIES
Conformity to RoHS Directive
Operating temperature range –40 to +85°C
[Including self-temperature rise]
Storage temperature range –40 to +85°C[Unit of products]
Terminal tensile strength 9.8N min.
Flow soldering condition 260°C /10 seconds
TSL 1112 RA- 3R3 M 5R9 - PF
(1) (2) (3) (4) (5) (6) (7)
1112 ø11.2×12.2mm (lead pitch 5mm)
RA Taping(Ammo-pack)
SBulk
3R3 3.3µH
100 10µH
J±5%
K±10%
M±20%
5R9 5.9A
R56 0.56A
PF Lead-free compatible product
Packaging style Quantity
Ta p i n g
(Ammo-pack) 500 pieces/box
Bulk 400 pieces/8tray
• Conformity to RoHS Directive: This means that, in conformity with EU Directive 2002/95/EC, lead, cadmium, mercury, hexavalent chromium, and specific
bromine-based flame retardants, PBB and PBDE, have not been used, except for exempted applications.

(2/2)
003-02 / 20080702 / e532_tsl1112.fm
• All specifications are subject to change without notice.
SHAPES AND DIMENSIONS
ELECTRICAL CHARACTERISTICS
∗1Rated current: Value obtained when current flows and the temperature has risen to 25°C or when DC current flows and the initial value of inductance has
fallen by 10%, whichever is smaller.
∗2: Please specify packaging style, S(Bulk) or RA(Taping).
TYPICAL ELECTRICAL CHARACTERISTICS
INDUCTANCE CHANGE vs. DC SUPERPOSITION
CHARACTERISTICS
Inductance
(µH)
Inductance
tolerance
Q
min.
Test
frequency
L/Q (Hz)
Self-resonant
frequency
(MHz)min.
DC
resistance
(Ω)max.
Rated current (A)∗1max.
Part No.
Based on inductance
change
Based on
temperature rise
1.0 ±20% 15 1k/7.96M 144 0.058 14 7.7 TSL1112 ∗2-1R0M7R7-PF
2.2 ±20% 15 1k/7.96M 70 0.073 10 6.7 TSL1112 -2R2M6R7-PF
3.3 ±20% 10 1k/7.96M 36 0.01 8.8 5.9 TSL1112 -3R3M5R9-PF
4.7 ±20% 10 1k/7.96M 28 0.015 7.2 4.8 TSL1112 -4R7M4R8-PF
6.8 ±20% 10 1k/7.96M 18 0.016 6.1 4.6 TSL1112 -6R8M4R6-PF
10 ±20% 20 1k/2.52M 16 0.025 5 3.7 TSL1112 -100M3R7-PF
15 ±20% 20 1k/2.52M 12 0.029 4.2 3.4 TSL1112 -150M3R4-PF
22 ±10% 20 1k/2.52M 9.5 0.04 3.4 2.9 TSL1112 -220K2R9-PF
33 ±10% 30 1k/2.52M 7 0.062 2.8 2.3 TSL1112 -330K2R3-PF
47 ±10% 30 1k/2.52M 5.8 0.075 2.3 2.1 TSL1112 -470K2R1-PF
68 ±10% 20 1k/2.52M 4.7 0.13 1.9 1.6 TSL1112 -680K1R6-PF
100 ±10% 20 1k/796k 3.8 0.16 1.6 1.4 TSL1112 -101K1R4-PF
150 ±10% 20 1k/796k 3.1 0.26 1.3 1.1 TSL1112 -151K1R1-PF
220 ±10% 20 1k/796k 2.5 0.33 1.1 1 TSL1112 -221K1R0-PF
330 ±10% 20 1k/796k 2 0.52 0.88 0.82 TSL1112 -331KR82-PF
470 ±10% 10 1k/796k 1.6 0.66 0.75 0.72 TSL1112 -471KR72-PF
680 ±10% 10 1k/796k 1.3 1.1 0.61 0.56 TSL1112 -681KR56-PF
1000 ±5% 20 1k/252k 1.1 1.4 0.51 0.5 TSL1112 -102JR50-PF
1500 ±5% 30 1k/252k 0.82 2.4 0.43 0.38 TSL1112 -152JR38-PF
2200 ±5% 20 1k/252k 0.76 3.2 0.35 0.33 TSL1112 -222JR33-PF
3300 ±5% 30 1k/252k 0.64 4.9 0.28 0.26 TSL1112 -332JR26-PF
4700 ±5% 30 1k/252k 0.54 7.6 0.24 0.21 TSL1112 -472JR21-PF
6800 ±5% 30 1k/252k 0.45 9.8 0.2 0.18 TSL1112 -682JR18-PF
10000 ±5% 30 1k/79.6k 0.38 18 0.17 0.14 TSL1112 -103JR14-PF
15000 ±5% 50 1k/79.6k 0.29 24 0.13 0.12 TSL1112 -153JR12-PF
12.2±0.35±1
5+1, –0.5
ø0.65±0.05
Weight: 3.3g
Dimensions in mm
ø11.2±0.3
DC current(A)
0.01 0.1 0.30.03 3110
10
3
1
100
1000
300
30
10000
3000
Inductance(µH)
1000µH
330µH
33µH
10µH
3.3µH
100µH
10000µH
3300µHA
L=0.1H
C=20000µF
Test circuit
DC
Universal bridge
Specimen
YHP model-4255A
or equivalent
