Teac GF-450K7 User manual

CEC6P10501630
CD recorder with turntable/cassette player
OWNER'S MANUAL
Z
GF-450K7

IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain
or moisture, does not operate normally, or has been dropped.
<Do not expose this apparatus to drips or splashes.
<Do not place any objects filled with liquids, such as vases, on the
apparatus.
<Do not install this apparatus in a confined space such as a book
case or similar unit.
<The apparatus draws nominal non-operating power from the AC
outlet with its STANDBY/ON switch in the standby position.
<The apparatus should be located close enough to the AC outlet
so that you can easily grasp the power cord plug at any time.
<An apparatus with Class ! construction shall be connected to an
AC outlet with a protective grounding connection.
<Batteries (battery pack or batteries installed) shall not be exposed
to excessive heat such as sunshine, fire or the like.
<Excessive sound pressure from earphones and headphones can
cause hearing loss.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
2
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

CAUTION
<DO NOT REMOVE THE EXTERNAL CASES OR CABINETS TO EXPOSE
THE ELECTRONICS. NO USER SERVICEABLE PARTS ARE WITHIN!
<IF YOU ARE EXPERIENCING PROBLEMS WITH THIS PRODUCT,
CONTACT TEAC FOR A SERVICE REFERRAL. DO NOT USE THE
PRODUCT UNTIL IT HAS BEEN REPAIRED.
<USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the equipment and/or the receiving
antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
CAUTION
Changes or modifications to this equipments not expressly
approved by TEAC CORPORATION for compliance will void the
user’s warranty.
For U.S.A.
3
Optical pickup :
Type : SF-W37SGT
Manufacturer : SANYO ELECTRIC CO., LTD.
Laser output : Less than 1 mW (Play) on the objective lens
Less than 5 mW (Record) on the objective lens
Less than 10 mW (Erase) on the objective lens
Wavelength : 783 nm
This product has been designed and manufactured according to
FDA regulations “title 21, CFR, chapter 1, subchapter J, based on the
Radiation Control for Health and Safety Act of 1968“, and is classified
as class 1 laser product. There is not hazardous invisible laser
radiation during operation because invisible laser radiation emitted
inside of this product is completely confined in the protective
housings.
The label required in this regulation is shown ①.
For U.S.A.
①

4
Contents
Thank you for choosing TEAC. Read this manual carefully to
get the best performance from this unit.
Beforeusingtheunit.............................................4
HandlingRecords................................................5
ReplacingtheStylus .............................................5
Discs ............................................................6
How to open/close the turntable cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
RemoteControlUnit.............................................8
HandlingCassettetape...........................................9
Connection.....................................................10
PartsoftheTurntable...........................................11
Unit Functions and Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
BasicOperation.................................................14
ListeningtotheRadio ..........................................14
ListeningtoaRecord............................................15
ListeningtoaCD................................................17
TimeDisplay....................................................18
RepeatPlayback ................................................19
Shuffle Playback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
ProgrammedPlayback..........................................20
ListeningtoaCassetteTape ....................................21
BeforeRecording ...............................................22
Recording ......................................................23
Finalize.........................................................26
EraseorUnfinalizeaCD-RW.....................................27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Messages.......................................................29
Specifications ..................................................29
Before using the unit
Read this before attempting any operations
<The nominal temperature should be between 5°C and 35°C (41°F
and 95°F). The CD-RW recorder is more sensitive to extremes of
temperature than ordinary CD players.
<Relative humidity should be 30 to 90 degrees noncondensing.
<As the unit may become warm during operation, always leave
sufficient space around the unit for ventilation.
<The voltage supplied to the unit should match the voltage as
printed on the rear panel. If you are in any doubt regarding this
matter, consult an electrician.
<Choose the installation location of your unit carefully. Avoid
placing it in direct sunlight or close to a source of heat. Also
avoid locations subject to vibrations and excessive dust, heat,
cold or moisture.
<Do not place the unit on an amplifier/receiver.
<Do not open the cabinet as this might result in damage to the
circuitry or electrical shock. If a foreign object should get into the
unit, contact your dealer or service company.
<When removing the power plug from the wall outlet, always pull
directly on the plug, never yank the cord.
<To keep the laser pickup clean, do not touch it, and always close
the disc tray.
<Do not attempt to clean the unit with chemical solvents as this
might damage the finish. Use a clean, dry cloth.
<Keep this manual in a safe place for future reference.
DO NOT MOVE THE UNIT DURING PLAYBACK
During playback, the disc rotates at high speed. Do NOT lift or
move the unit during playback. Doing so may damage the disc
or the unit.
WHEN MOVING THIS UNIT
When changing the unit’s location or packing the unit for
moving, be sure to remove the record or disc. Moving this unit
with the record or disc loaded may result in damage to this unit.
If the unit is to be packed and moved a great distance, it is also
advisable to tighten the turntable transport locking screw. See
Page 9 for instructions.

5
Handling Records
<Keep your records away from dust. Keep them in a cool, dry
place.
<To avoid dust and scratches, keep records in their sleeves and
jackets when not in use.
<Store records upright on their edges. Records stored horizontally
will eventually bend and warp.
<Do not expose records to direct sunlight or high humidity and
temperature. Long exposure to high temperatures will warp the
record.
<Do not store your records in the trunk of your car. The
temperature in a closed trunk can ruin your collection.
<Store records in an area with stable temperature and humidity.
<Should the record become dirty, gently wipe the surface in a
circular motion, using a soft anti-static cloth.
Commercial record cleaning systems are available from many
retailers or on-line. TEAC does not endorse any specific product
but, depending on the condition of your record collection, it may
be advisable to look into one of these systems. Clean records
protect your stylus from undue wear.
<Do not touch the record’s grooves. Only handle records, by
the edges or the label, with clean hands. Skin oils from even
clean hands can leave a residue on the record surface that will
gradually deteriorate the quality of your record.
label grooves
edge
How to Replace the Stylus
The stylus should last about 50 hours under normal use. However, it
is recommended that the stylus be replaced as soon as you notice a
change in sound quality.
Prolonged use of a worn-out stylus may damage the record.
Wear and tear on the stylus will be accelerated when playing 78
RPM records. The higher speed of 78 RPM records wears the stylus
more quickly.
Caution:
<Do not remove or bend the stylus.
<To avoid injury, do not touch the needle.
<Turn off the unit’s power before you replace the stylus.
<Keep out of the reach of children.
<Handle with care, as the stylus is delicate. Use of a bent or
broken stylus may damage the record and cause the turntable to
malfunction.
<Do not expose stylus to extreme heat.
<Contact a qualified repair company if you experience difficulty in
changing the stylus.
When removing the stylus (red part), hold the cartridge with your
hand, press down the uneven part in front of the stylus using a
small screw driver in direction A, and pull it to detach.
The replacement stylus for this GF-450K7 is a STL-103. A SPL-102
(2 pieces) for use with SP records only is also available. Please
contact TEAC Parts at [phone], extension 840 to order. Or
call our automated Service Agency Locator at: (800) 447- TEAC for
the closest authorized repair company that can replace the stylus
for you.
Installing a new stylus
1. Hold the tip of the stylus and insert the other edge by pressing in
the direction “B”.
2. Push up in the direction “C” until it locks at the tip.
A
B
C
