TEC E Series User manual

Customer Service Hotline
Magnetostrictive Displacement
Sensors Operating Manual
E Series
ES Structure
Analog/Modbus interface
V1.3
400-809-1101

Use Regulations
Magnetostrictive displacement sensor is used to detect the displacement of motion mechanism. According to
the selection regulations, the magnet ring (block) matched with magnetostrictive displacement detection electronic
components is selected for detection applications in different occasions. Please ensure that the cable, connector,
magnet ring (block) and sensor body are the original parts of the manufacturer when using. Please do not open the
shell of the sensor without authorization, so as not to affect the normal warranty period of the product.
Saftey matters
Please read the operating manual carefully before powering up the sensor. Firstly, conrm the outgoing mode
and pin signal denition, and make correct electrical connection to prevent power-on from damaging the sensor or
causing misoperation of the equipment.
During the construction and use of the sensor, the current of high-power equipment such as welding machine
should be avoided from entering the working circuit of the sensor.
If you nd abnormal sensor data or obvious changes in appearance (such as bumping deformation), please
stop using it immediately, and contact the manufacturer to conrm the current state of the sensor before continuing
to use it.
ES structure magnetostrictive displacement sensor has no LED lamp for status indication.
Status indication/fault analysis
Installation Dimensions
Electric interface
1
2
3
4
5
Pin Cable
color 1* Cable color 2/3* Function denition
1
2
3
4
5
Pin Cable
color 1* Cable color 2* Cable color 3* Function denition
Brown
White
Blue
Black
Grey
+24Vdc+20% power supply
GND（power supply circuit）
Do not connect
Do not connect
Do not connect
Dimensions of cable outlet
Outline dimensions of connector outlet
Stroke length
Stroke length
Position magnet ring
Liquid level floating ball
Cable outlet mode
Cable outlet mode
34
37.7
8 14
8 14
65
65
~15 /17
1 2
17
~∅5.6 /∅7.2
1 2
~∅5.6 /∅7.2
1 2
50.8
50.8*
63.5
63.5*
∅10/∅8
∅10
A向
A
1
2
34
1
2
34
5
PA40 PA50
Cable outlet mode
Connection mode of socket：PA40/PA50
1.PUR black cable
2.PVC black cable
Note
~∅5.6 /∅7.2
1 2
~29 /32
1 2
~59
~46
14.5
Red
Black
-
-
-
PA40/PA50 pin arrangement - 2-wire system
(Sensor Oriented)
Brown
White
Blue
Black
-
Red
Black
Blue
Green
-
GND（power supply circuit）
Magnet ring position signal +
Magnet ring position signal -
Do not connect
PA40/PA50 Pin Arrangement-Four Wire
(Sensor Oriented)
Red
Black
Brown
Green
-
PA40 PA50 PA40 PA50
Note：* Cable color1：Cable PUR sheath, black,-40~80℃, end scattered
* Cable color2：Cable PUR sheath, orange,-20~90℃, end scattered
* Cable color3：Cable PVC sheath, black,-40~80℃, end scattered
Analog Analog
+24Vdc+20% power supply
1
2
3
4
5
Pin Cable
color 1* Cable color 2* Cable color 3* Function denition
Brown
White
Blue
Black
-
GND（power supply circuit）
T+（A）
T- （B）
Do not connect
PA40 PA50
Modbus
+24Vdc+20% power supply
PA40/PA50 pin arrangement (Sensor Oriented)
Red
Black
Yellow
White
-
Red
Black
Brown
Green
-
Application environment
Magnetostrictive displacement sensor is a kind of magnetic measurement sensor. Make sure there is no
strong magnetic eld around the sensor, which may interfere with the data. The displacement output signal cable
of magnetostrictive displacement sensor should be away from the power cable or large current or strong pulse
interference source.Conrm the environmental parameters including temperature, vibration, etc., and ensure that
the working conditions are within the nominal working parameters of the sensor.
Installation
The installation of magnetostrictive displacement sensor mainly includes sensor body, magnet and cable
xing.
The installing forms of the sensor body are: thread installing, clamp installing and matching xing installing.
Before installation, make sure that the packaging is in good condition, and the sensor body has no obvious
bending and bumping. The sensor body should be assembled according to the specic installation form.
When installing magnets, please use matching magnetic insulation gaskets to ensure normal magnetic eld
circuit.
When installing plugs or cables, please connect them accurately according to the electrical interfaces in the
instructions.
After-sales support
If the sensor malfunctions, please contact the after-sales department of the company in time. Do not attempt
to repair it yourself.
(Note: * when selecting the float, the head
non-usable area ≥ 14 + the float radius）
