TEC M Series User manual

Customer Service Hotline
Magnetostrictive Displacement
Sensors Operating Manual
M Series
MI Structure
Analog interface
V1.2
400-809-1101

Use Regulations
Magnetostrictive displacement sensor is used to detect the displacement of motion mechanism. According to
the selection regulations, the magnet ring (block) matched with magnetostrictive displacement detection electronic
components is selected for detection applications in different occasions. Please ensure that the cable, connector,
magnet ring (block) and sensor body are the original parts of the manufacturer when using. Please do not open the
shell of the sensor without authorization, so as not to affect the normal warranty period of the product.
Saftey matters
Please read the operating manual carefully before powering up the sensor. Firstly, conrm the outgoing mode
and pin signal denition, and make correct electrical connection to prevent power-on from damaging the sensor or
causing misoperation of the equipment.
During the construction and use of the sensor, the current of high-power equipment such as welding machine
should be avoided from entering the working circuit of the sensor.
If you nd abnormal sensor data or obvious changes in appearance (such as bumping deformation), please stop
using it immediately, and contact the manufacturer to conrm the current state of the sensor before continuing to
use it.
Installation Dimensions
Electric interface
Connector external dimensions
External dimensions of cable outlet
∅11
12
∅15
11
∅22.5
-0.04 -0.02
∅28
∅22.5
-0.04 -0.02
∅28
∅7pressure-resistant rod
∅7pressure-resistant rod
38.5
60~250
6
M12×1
50~2500 36.5
22
50~2500 36.5
22
26.8 -0.2
0
37
6
26.8 -0.2
0
∅11
Stroke length End non-usable
area
Head non-
usable area
Stroke length End non-usable
area
Head non-
usable area
M12-4 pin socket
4 3
1 2
Analog (connector)
Scattered output
Special cable
No.
1
2
3
4
PA
Signal
Ground
PB
Ground
Signal
PC
Ground
Signal
Definition
Ground
Signal
PA
Brown
Blue
White
PB
White
Blue
Black
PC
Brown
Blue
Black
Definition
Ground
Signal
PA
Brown
Blue
White
PB
White
Blue
Black
PC
Brown
Blue
Black
PTScattered output
Definition
Power supply
Ground
Signal
Cable color
Brown
White
Green
Cable code：511815 Definition
Power supply
Ground
Signal
Cable color
Brown
White
Green
Cable color
M12-4Pin Definition 24
17
Analog output (Cable color definition
of female connector)
Analog output (Cable color definition
of right angle female connector)
M12-5pin female
connector Cable color
M12-5pin right angle
female connector
48
34.5
14.5
39
18
14.5
21
M12×1
109
16H8
44×
Power
supply
Power
supply
Power
supply
Power
supply
Power
supply
Do not
connect
Do not
connect
Do not
connect
Application environment
Magnetostrictive displacement sensor is a kind of magnetic measurement sensor. Make sure there is no strong
magnetic eld around the sensor, which may interfere with the data. The displacement output signal cable of
magnetostrictive displacement sensor should be away from the power cable or large current or strong pulse
interference source.Conrm the environmental parameters including temperature, vibration, etc., and ensure that
the working conditions are within the nominal working parameters of the sensor.
Installation
The installation of magnetostrictive displacement sensor mainly includes sensor body, magnet and cable xing.
The installing forms of the sensor body are: thread installing, clamp installing and matching xing installing.
Before installation, make sure that the packaging is in good condition, and the sensor body has no obvious bending
and bumping. The sensor body should be assembled according to the specic installation form.
When installing magnets, please use matching magnetic insulation gaskets to ensure normal magnetic eld
circuit.
When installing plugs or cables, please connect them accurately according to the electrical interfaces in the
instructions.
After-sales support
If the sensor malfunctions, please contact the after-sales department of the company in time. Do not attempt
to repair it yourself.
