Techcomp Dynamica Velocity 30R User manual

Velocity 30R
Benchtop Centrifuge
Instruction manual
Model VELOCITY 30R High-Speed Refrigerated Benchtop Centrifuge
Revision: D01-202006

1 PRODUCT DESCRIPTION
1.1 Usage in accordance with safety standards
1.1.1 General Information
1.1.1.1 Hazards and precautions
1.1.1.2 Brief description
1.1.1.3 Safety Standards
1.1.1.4 Extent of supply
1.1.1.5 Warranty
1.2 Installation
1.2.1 Installation of the centrifuge
1.2.1.1 Unpacking the centrifuge
1.2.1.2 Space requirements
1.2.1.3 Installation
1.3 Technical Data
1.4 Conformity Declaration
1.5 Basic Setup and the "operating data" mode
1.5.1 Access to the "basic adjustments" mode
1.5.2 Temperature indication
1.5.3 Sound signal turn on/off
1.5.4 Volume pre-selection of a sound signal
1.5.5 Song selection for sound signal - end of the run
1.5.6 Keyboard sound turn on/off
1.5.7 Call up of the "operating data" mode
2 OPERATION
2.1 Installation of rotors
2.1.1 Mounting and loading angle rotors
2.1.2 Mounting and loading swing out rotors
2.1.3 Overloading of rotors
2.1.4 Removing the rotors
2.2 Operation
2.2.1 Power switch
2.2.2 Lid release
2.2.3 Lid lock
2.2.4 Pre-selection of speed/RCF-value
2.2.5 Pre-selection of running time
2.2.6 Pre-selection of brake intensity and acceleration
2.2.7 Pre-selection of temperature
2.2.8 Pre-cooling
2.2.9 Radius correction
2.2.10 Storage of programs
2.2.11 Recall of stored programs
2.2.12 Leaving program mode
2.2.13 Starting the centrifuge
2.2.14 "Stop" key
2.3 Safety features
2.3.1 Imbalance detection
3 MAINTENANCE
3.1 Service and Maintenance
3.1.1 Maintenance and cleaning
3.1.2 Glass breakage
3.1.3 Disinfection of Alu-rotors
3.1.4 Disinfection of PP-rotors
CONTENTS
Page 2 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

4 TROUBLESHOOTING
4.1 Error messages: Cause / Solution
4.2 Survey of possible error messages and their solutions
4.2.1 Lid release during power failure
4.2.2 Description of the error message system
4.2.3 Error messages
5 RECEIPT OF CENTRIFUGES TO REPAIR
6 DISPOSAL
CONTENTS
Page 3 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
1.1 Usage in accordance with safety standards
1.1.1 General information
1.1.1.1 Hazards and precautions
Before setting the centrifuge into operation, please read this instruction manual carefully!
This centrifuge must not be operated by unqualified personnel not being familiar with the correct
use of the unit.
Always, use the original accessories only!
For your safety, please review the following precautions:
•The DYNAMICA VELOCITY 30R is not explosion-proof and therefore must not be operated in
explosion-endangered areas or locations. During centrifugation, it is prohibited to stay within the
safety zone of 30 cm around the centrifuge or deposit hazardous substances within this area.
•Centrifugation of flammable, explosive and radioactive substances or substances which reacts with high
energy, is strictly prohibited!
•Never spin toxic or pathogenic material without adequate safety precautions, i.e. centrifugation of
buckets / tubes without or with defective hermetic sealings is strictly prohibited.
The user is obligated to perform appropriate disinfection procedures in case dangerous substances have
contaminated the centrifuge and / or its accessories. When centrifuging infectious substances, always
pay attention to the General Laboratory Precautions. If necessary, contact your safety officer!
•It is prohibited to run the centrifuge with rotors other than listed for this unit.
•Under no circumstances open the lid of the centrifuge while the rotor is still running or rotating with a
speed of > 2 m/s.
Following rules must strictly be adhered to:
•Do not operate the centrifuge in case it is not installed correctly.
•Do not operate the centrifuge when dismounted (e.g. without metal cover).
•Do not run the centrifuge when mechanical or electrical assembly groups have been tampered with by
unauthorized persons.
•Do not use accessories such as rotors and buckets, which are not exclusively approved by
Dynamica Scientific Limited, except commercially available centrifuge tubes made of glass or
plastic.
•Do not spin extremely corrosive substances, as they may cause material damages and impair
mechanical resistance.
•Do not operate the centrifuge with rotors or buckets which show any sign of corrosion or mechanical damage.
Page 4 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
The manufacturer is responsible for the safety and reliability of the centrifuge, only if:
•The unit is operated in accordance to this instruction manual.
•Modifications, repairs or other adjustments are performed by DYNAMICA-authorized personnel and the
electrical installation of the related location corresponds to the IEC-regulations.
1.1.1.2 Brief description
Model VELOCITY 30R is a high-speed benchtop refrigerated centrifuge capable of running swing out and
angle rotors. All relevant run parameters can easily be set with the display keys and be pre-selected with the
main adjustment knob. All pre-selected and actual values are permanently displayed on the large LCD. The lid
is latched and released with an electromagnetic lid lock.
The centrifuge has a powerful, maintenance-free brushless induction drive with a low noise level. It also
has a CFC-free hermetically sealed refrigeration system (refrigerant type R 404 a).
1.1.1.3 Safety standards
The centrifuge corresponds with the General Requirements for Medical Units Regulations (MedGV) (group
3).
The following standards have been considered for the production of our centrifuges:
•Accident Prevention Regulation for electrical units and installations UVV VBG 4
•Accident Prevention Regulation for centrifuges as per BGR 500; Chapter 2.11; Part 3
•DIN 58970 part 1, 2 and 4 for centrifuges and tubes
•Electrical Interference Suppression according to interference degree B as per VDE 0871
•Electrical Safety as per IEC 1010-1 and IEC 1010-2-D
•European Standard PR EN 61 010-1 and PR EN 61 010-2-2
Page 5 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1.1.1.4 Extent of supply
Following parts are supplied as accessories with each centrifuge:
•1 instruction manual
•1 Allen key for removing rotors
Spare fuses are at the rear side of the centrifuge.
1 PRODUCT DESCRIPTION
1.1.1.5 Warranty
The centrifuge has been subjected to thorough testing and quality controls.
In the case of any manufacturing faults occurring, the centrifuge and rotors are covered by warranty for
one year from the date of delivery.
This warranty becomes invalid in case of mishandling, negligence and in case of inappropriate usage of
spare parts and / or accessories as well as any unauthorized modification to the unit.
Technical modification rights are reserved by the manufacturer with respect to technical
improvement.
1.2 Installation
1.2.1 Installation of the centrifuge
1.2.1.1 Unpacking the centrifuge
Model VELOCITY 30R is supplied in a pallet carton.
Remove the strap retainer, open the carton, remove the cover carton and the centrifuge. The instruction
manual must always be kept with the centrifuge.
1.2.1.2 Space requirements
The centrifuge should be installed on an even and solid surface, if possible on a laboratory cabinet
/ table or some other solid vibration-free surface.
In order to enable a safe and smooth operation, level the centrifuge with a spirit level.
The centrifuge must be placed in a way, that there is a minimum space of 30 cm on each side of the unit in
order to ensure necessary heat dissipation.
Do not place the centrifuge next to a window or a heater, where it could expose to excessive heat, as the
performance of the unit is based on an ambient temperature of 23°C.
Safety regulations require that the safety area of 30 cm around the unit is marked in order to indicate that
neither hazardous substances nor persons should be within this area during centrifugation.
Page 6 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
1.2.1.3 Installation
Follow these steps:
•Check whether power supply corresponds with the one named in the manufacturer's rating label which
is mounted on the rear panel.
•The line voltage circuit breaker is max. 16 A (type K) slow release for commonly used instruments.
•In case of emergency, there must be an emergency switch off installed outside the room in order to
disconnect the power supply of the unit.
•Remove the transport spacer blocks from the inside of the chamber (see following photos).
The socket for the power cord must be easy to reach for easy disconnection!
1.3 Technical Data
Manufacturer
Type / Model
Dimensions
Width
Depth
Height
Weight
Noise level (max.)
Max. speed
Max. volume
Max. RCF
Admissible density
Admissible kinetic energy
Electrical connection AC
Current
Connected load
Interference suppression
Test obligations
To be filled in by purchaser:
Inventory-No.:
Check-No.:
Location:
Maintenance contract:
Your service department
Your agent
Dynamica Scientific Limited
VELOCITY 30R
71.5 cm
51 cm
42 cm
91 kg
60 +2.0 dB (A)
30000 rpm
6 x 250 ml
65390 x g
1.2 kg/dm3
4.440 Nm
230 V / 50 Hz 1 ph
7A
1600 Watt
VDE 0871, Funkentstörgrad B
yes
Dynamica Scientific Limited
120 V / 60 Hz 1 ph
15 A
1800 Watt
Page 7 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
1.4 Conformity declaration
Please refer to the conformity declaration in the package
Page 8 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
1.5 Basic adjustments
When putting the centrifuge into operation, you have the options to set up using the following basic
adjustments:
1. Temperature indication in °C or °F
2. Sound signal turn on/off
3. Volume pre-selection of a sound signal
4. Song selection of sound signal "end of run"
5. Keyboard sound turn on/off
You can also call up the following operating data in this mode.
1. Number of starts
2. Operating hours of the centrifuge
3. Software-version
4. Error list
5. Operation of imbalance sensor
6. Operation of keyboard
7. Display test
1.5.1 Access to mode "Basic Adjustments"
If the centrifuge is still turned off, for software version up to 1.26, press simultaneously the keys "time" (10)
and "prog" (21) and turn on the main switch of the centrifuge. For the software version 1.27 onwards,
press the keys "time" (10) and "lid" (22) simultaneously and release both keys again. As a result, a display
test is executed for approx. 5 seconds. All possible indications will appear at the same time (see photo 1).
Photo 1
10 21 22
ATTENTION:
Please note that you must enter the program as described under point 1.5.1 in order to change the
adjustments in points 1.5.2 - 1.5.7. After you have stored the settings you can change to the
normal program mode again by switching off the centrifuge for a short while.
Page 9 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
1.5.2 Temperature indication
Proceed as described in point 1.5.1 to enter this program mode and then press the key "accel/decel" (12).
The word "service" appearsin the display "accel/decel". Now select the letter "C" with the adjusting knob (9).
As a result, the word "CELSI/temp" appears in the display "rpm/rcf" (17). If you press the key "rpm/rcf" (8) now,
the word "CELSI" flashes and you can change the display to Fahrenheit "FAREN" using the adjusting knob (9)
(see photo 2).
After you have stored the settings you can change to the normal program mode again by switching off the
centrifuge for a short while.
Photo 2
1.5.3 Sound signal turn on / off
8 12 9
Proceed as described under point 1.5.1 to enter this program mode and then press the key "accel/decel" (12).
The word "service" will appear in the display "accel/decel". Now select the letter "L" with the adjusting knob (9).
As a result, the words "On sound" appears in the display "rpm/rcf" (17). If you press the key "rpm/rcf" (8) now,
the word "On" flashes and you can switch off the sound "Off" with the adjusting knob (9) (see photo 3).
After you have stored the settings you can change to the normal program mode again by switching off the
centrifuge for a short while.
Page 10 of 36
Photo 3
INSTRUCTION MANUAL VELOCITY 30R
8
12 9
Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
1.5.4 Volume pre-selection of the sound signal
Proceed as described under point 1.5.1 to enter this program mode and then press the key "accel/decel" (12).
The word "service" will appear in the display "accel/decel". Now select the letter "U" with the adjusting knob (9).
As a result, the words "Vol=/Sound" will appear in the display "rpm/rcf" (17). After pressing the key "rpm/rcf" (8),
you can adjust the desired volume between 0 (low) and 9 (loud) using the adjusting knob (9). (see photo 4)
After you have stored the settings you change to the normal program mode again by switching off the
centrifuge for a short while.
Photo 4
812 9
1.5.5 Song selection for sound signal - end of the run
Proceed as described under point 1.5.1 to enter this program mode and then press the key "accel/decel" (12).
The word "service" will appear in the display "accel/decel". Now select the letter "G" with the adjusting knob (9).
As a result, the word "Song" willappears in the display "rpm/rcf" (17) After pressing the key "rpm/rcf" (8), you
can select a song using the adjusting knob(9). (see photo 5)
After you have stored the settings you can change to the normal program mode again by switching off the
centrifuge for a short while.
Photo 5
812 9
Page 11 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
1.5.6 Keyboard sound turn on / off
Proceed as described under point 1.5.1 to enter this program mode and then press the key "accel/decel" (12).
the word "service" will appear in the display "accel/decel". Now select the letter "b" with the adjusting knob (9).
As a result, the word "BeeP-x".appears in the display "rpm/rcf" (17) After pressing the key "rpm/rcf" (8), you
can turn the keyboard sound on (On) or off (Off) with the adjusting knob (9). (see photo 6)
After you have stored the settings you can change to the normal program mode again by switching off the
centrifuge for a short while.
Photo 6
812 9
ATTENTION:
All settings changed must be confirmed using the key "store" (20). Only when the word "store"
appears in the display "rpm/rcf" (17) - Only then the pre-selections are valid!!
(see photo 7)
Photo 7
20
Page 12 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

1 PRODUCT DESCRIPTION
1.5.7 Call up of operating data
you can call up the operating data of the centrifuge in the "Basic Adjustments"mode. Please
proceed as described in point 1.5.1 to enter this mode.
Press the key "accel/decel" (12). The word "service" will appear in the display "accel/decel".
With the adjusting knob (9) the different information can be called up:
A = previous start of the centrifuge
H = previous operating hours
S = software version
E = list of previous error messages
The list of the last 99 error messages can be looked over by pressing the key "rpm/rcf" (8) and scroll
through it by the adjusting knob (9). The respective error codes appear in the display "rpm/rcf" (17).
Please look up in chapter 4.2.3 of this instruction manual for the relevant meanings. (see photo 8)
Here as well you must shortly switch off the centrifuge for changing to the normal program mode again.
Photo 8
8 12 9
Page 13 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

2 OPERATION
2.1 Installation of rotors
2.1.1 Mounting and loading angle rotors
Clean the drive shaft as well as the rotor mounting boring with a clean, grease-free piece of cloth.
Place the rotor onto the drive shaft. (see photo 9)
Take care that the rotor is fully installed onto the motor shaft.
Photo 9
Photo 10
ATTENTION:
For safety reasons, always ensure that the rotor fixing screw is tightened before each run. (see
photo 10)
Page 14 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

2 OPERATION
Hold the rotor with one hand and secure the rotor to the shaft by turning the fixing screw (1)
clockwise. Tighten the fixing screw with enclosed Allen key (see photo 11).
1
Photo 11
It is allowed to operate e.g. an 8-place-rotor with 2 or 4 loaded tubes only. But the loaded borings must be
opposite to each other.
Photo 12: Incorrect Photo 13: Correct
ATTENTION:
Before the operation, tighten the rotor lid, if applicable!!
Page 15 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

2 OPERATION
2.1.2 Mounting and loading swing-out rotors
Clean the drive shaft as well as the device hole of the rotor with a clean and grease-free cloth. Put the rotor
onto the motor shaft. Take care that the rotor is fully installed onto the motor shaft.
Hold the rotor with one hand and secure the rotor to the shaft by turning the rotor nut (1) clockwise.
Tighten rotor nut with the enclosed Allen key (see photo 11).
The charging of the buckets and the adapters must be done appropriately as in photo 14 and photo 15.
In principle, the swing-out rotors may be taken in operation first if all buckets or racks are put into the
rotor.
The bolts at the rotor must be greased with silicone grease.
The glasses have to be filled evenly by eye and put into the drillings or tube racks. The weight difference of the
loaded buckets should not exceed approx. 1.0 g.
It is allowed to operate e.g. a 4-place-rotor with 2 loaded buckets only. But the loaded buckets must be
opposite to each other. Make sure that the unloaded buckets must also be put inside the rotor (see photos
14 and 15).
ATTENTION:
Swing out rotors may be taken in operation only if all locations are filled with the same sorts of
buckets or carriers!
Photo 14: Incorrect Photo 15: Correct
Page 16 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

2 OPERATION
2.1.3 Overloading of rotors
The maximum load permitted for a rotor, which is determined by the manufacturer, as well as the
maximum speed allowed for this rotor (see label on the rotor), must not be exceeded.
The liquids the rotors are loaded with, should have an average homogeneous density of 1.2 g/ml or less when
the rotor is running at maximum speed.
In order to spin liquids with a higher density, the speed has to be reduced according to the following
formula:
1.2
Reduced speed nred = x max. speed (nmax) of the rotor
higher density
Example:
1.2
nred = x 4.000 = 3.360 rpm
1.7
ATTENTION:
Please read the manufacturer's notes referring to the breaking point of the used tubes.
In case of any questions, please contact the manufacturer!
2.1.4 Removing the rotor
Untighten the rotor fixing screw and lift the rotor vertically out of the centrifuge.
ATTENTION:
Do not operate the centrifuge with rotors or buckets which show any signs of corrosion or
mechanical damage.
Do not operate with extremely corrosive substances that could damage the rotor and buckets.
Page 17 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

2.2 Operation
2.2.1 Power switch
The power switch is located on the bottom, left side of the unit.
Thepower switch is also the main fuse of the centrifuge.
Attention:
2 OPERATION
After turning on the power switch you must open the lid of the unit first, prior to starting the
centrifuge.
2.2.2 Lid release
After the run, respectively closing the lid of the centrifuge, the word "close" (1) appears in the display
"rpm/rcf". If there is a rotor in the centrifuge, it appears additional the word "rotor" (3), as well as the code
number of the respective rotor i. e. "nr 15" (4) will appear. During the run you can call up the rotor type at
any time by pressing the key "lid" (5). If there is no rotor in the centrifuge the word "rotor" (3) and the word
"no" (4) appears. By pressing the key "lid" (5) you can release the lid of the centrifuge. As soon as the
electromagnetic lid is completely released, it appears the word "open" (2). Now you can open the lid of the
centrifuge.
2
3
4
1
5
Photo 16
2.2.3 Lid lock
Attention:
Before closing the lid please ensure that the rotor is tight, and that all 4 buckets have been put in the
swing-out rotor.
The lid must only be laid down slightly. An electromagnetic lid lock closes the lid automatically, at the
same time the word "open" (2) disappears.
As a sign that the centrifuge is ready to start the word "close" (1)appears in the display "rpm/rcf".
Simultaneously the word "rotor" (3), as well as the code number of the rotor, which is in the centrifuge i. e.
"nr 15" (4 appears in that display).
With that all rotor specifically data, like e. g. max. speed, acceleration etc., are adopted.
Page 18 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

2 OPERATION
2.2.4 Pre-selection of speed / RCF-value
Through the key "rpm/rcf" (8) this pre-selection is activated. By pressing the key once the word "rpm" (6)
flashes.
By pressing the key once again the pre-selection of the centrifugal forces may be chosen. Then the
flashing word "rcf" (7) appears.
You can set the desired values with the adjusting knob (9). In the display (17) the regulated value is
shown permanently, before, during and after the run.
As long as no rotor is inserted, the speed is adjustable between 200 rpm and the maximum revolution of the
centrifuge.
If there is a rotor in the centrifuge the speed can only be pre-selected until the maximum permissible
revolution of that rotor.
It is the same with the pre-selection of the RCF-value. The setting range is between 20 xg and the
maximum permissible centrifugal force of the rotor. The maximum speed of the VELOCITY 30R is 30000
rpm.
67
17 17
89
Photo 17
Max. Revolution per minutes of the valid rotors VELOCITY 30R
Rotor-Number
221.21 V01
221.18 V01
221.20 V01
221.22 V01
221.17 V01
221.23 V01
221.19 V01
221.15 V01
221.16 V01
Max.
Revolution
10000 rpm
12000 rpm
20000 rpm
21000 rpm
20000 rpm
30000 rpm
4500 rpm
4000 rpm
4500 rpm
RCF
Value
15650 xg
18510 xg
41140 xg
41410 xg
42030 xg
65390 xg
2830 xg
2990 xg
2720 xg
Attention:
Please also check the maximum permissible revolutions of your test tubes! (Indicated by the
manufacturer)
Page 19 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited

2 OPERATION
2.2.5 Pre-selection of running time
The running time can be pre-selected in three different ranges from 10 seconds up to 99 hours 59 minutes.
1. Range from 10 seconds up to 59 minutes 50 seconds in steps of 10 seconds
2. Range from 1 hour up to 99 hours 59 minutes in steps of 1 minute
3. Range continuous run, which can be interrupted by the key "stop" (25).
The running time can be pre-selected with the lid open or closed.
To activate the setting of the running time press the key "time" (10).
In the display "time" flashes "m:s" or "h : m" (11), depending on the previous setting. To set the desired
value using the adjusting knob (9). After exceeding 59 min 50 sec the indication changes automatically to
"h : m". After exceeding of 99 hours 59 min the word "cont" appears in the display "time". That continuous
run can only be interrupted by pressing the key "stop" (25). The display shows always the remaining
running time.
11
Photo 18
10
25
9
Page 20 of 36 INSTRUCTION MANUAL VELOCITY 30R Dynamica Scientific Limited
