TECHCON SYSTEMS TS250 User manual

Techcon Systems
TS250 / 255
Precision Dispensers
User Guide
English, German, French, Italian and Spanish version
Copyright © OK International
TS250 / 255
Präzsions-Dosiergeräte
Benutzerhandbuch
TS250 / 255
Doseurs de
précision
Guide de
l'utilisateur
TS250 / 255
Dosatore di
precisione
Manuale dell’utente
TS250 / 255
Dosificadores de
precisión
Guía del usuario
2
CONTENTS
Page Number
1. Safety ……………………………………………………………2
2. Symbol Definitions …………………………………………………3
3. Specifications ……………………………………………….…………...3
4. Features ……………………………………………………………4
5. Connecting the Unit ……………………….…….………..…………5
6. Setup Instructions …………………………………………………5
7. Troubleshooting …………………………………………………6
8. Maintenance ……………………………………………………………7
9. Spare Parts and Accessories ………………………………………7
10. Warranty ……………………………………………………………7
11. I/O Configuration and End of Cycle Switch ……………………….…...7
1SAFETY
1.1 Intended Use:
WARNING: Use of this equipment in ways other than those described in this User
Guide may result in injury to persons or damage to property. Use this equipment
only as described in this User Guide.
OK International cannot be responsible for injuries or damages resulting from
unintended applications of its equipment. Unintended uses may result form taking
the following actions:
•Making changes to equipment that has not been recommended in the User
Guide
•Using incompatible or damaged replacement partsUsing unapproved
accessories or auxiliary equipment
1.2 Safety Precautions:
•Do not operate this unit in excess of maximum ratings/settings
•Always wear appropriate personal protective clothing or apparel
•Use only the following power adaptor models: PSA15R-240P(ZJ) or
PW118RA2403B01, PW118RA2403H01, PW118RA2403M01,
PW118RA2403G01
•Care must be taken to prevent the ingress of corrosive or flammable fluid back
into the unit. If corrosive or flammable fluids are used, an inline filter (881-
000-000), not included, must be installed on the dispenser to help prevent the
fluids from being sucked back into the unit
•The fluid being dispensed may be toxic and/or hazardous. Refer to Material
Safety Data Sheet for proper handling and safety precautions
•If a piston is not used with the barrel, an inline filter (881-000-000), not
included, and must be installed on the receiver head to help prevent fluids from

3
being sucked back into the unit. Also do not overfill the barrel and to lay the
barrel on its side
•Do not smoke or use open flame when flammable materials are being dispensed
•This equipment is for indoor use only
2SYMBOL DEFINITIONS
Symbol Definition
Power On/Off
Cycle Mode
Timer
Vacuum
Pressure
3SPECIFICATIONS
Size 152mm X 165mm X 178mm
(6” X 6.5” X 7.0”)
Weight 1.2 kg (2.6lbs)
Input Voltage 24 VDC
Rated Power 10 W
Air Input 100 psi (6.9 bar) Max.
Pollution Degree II
Installation Category I
Indoor Use Altitude up to 2,000m (6,562ft)
Operating Temperature 0˚C to 50˚C (32˚F to 122˚F)
Storage Temperature -10˚C to 60˚C (14˚F to 140˚F)
Max. Relative Humidity 80% for temperature up to 31˚C (87.8˚F) Decreasing
linearly to 50% relative humility at 40˚C (104˚F)
Air Output TS250 = 0-100 psi (0- 6.9 bar)
TS255 = 0-15 psi (0-1 bar)
Vacuum 406mm (16”) of Hg
Timer 0.020-60.000 seconds
Cycle Mode PURGE, TIMED
Timing Repeat Tolerance +/- 0.001%
Cycle Rate 600 cycles/min
LCD 16 X 2 display segments
4
4FEATURES
Figure 1.0
Items Description
1 Power Button
2 Mode Button
3 Counter Reset Button
4 Display
5 Air Pressure Gauge
6 Air Pressure Regulator
7 Pulsed Air Outlet
8 Vacuum Control
9 Time Control Knob
10 Receiver head air hose holder
11 Foot Switch Receptacle
12 Power Receptacle
13 I/O Connection
14 Exhaust Port
15 Air Inlet
16 Cord Lock
1
7
6
5
3
4
15
16
14
11
12
9
2
10
8
13

5
5CONNECTING THE UNIT
CAUTION: A 5-micron filter (TSD800-6), not included, must be installed with the unit to
ensure proper air filtration.
Figure 2.0
6SETUP INSTRUCTIONS
Refer to Figure 1.0
6.1 Manual Dispense Cycle Setting:
1. Turn on the unit by pressing the Power button (1)
2. Press the Mode button (2) until “PURGE” appears on the Display.
3. Turn up the air pressure by rotating the Air pressure regulator knob (6) until
the desired pressure is indicated on the Air pressure gauge (5)
4. After filling the barrel or using pre-packaged adhesive, attach syringe to
receiver head assembly. Make certain that the syringe locks into place.
5. Connect the plug end of the receiver head assembly to one of the air
dispense outlet (7)
6. If vacuum “suck back” is needed, rotate the Vacuum regulator (8) counter
clockwise until the desired vacuum pressure is obtained
7. Press and hold the Foot switch to activate dispensed cycle. (The
Purge/Manual Mode is now activated)
6.2 Automatic Dispense Cycle Setting:
1. Push the Mode button (2) to select “TIMED” mode
2. Rotate the Time control knob (9) to set desired dispense time
3. Repeat step 3 to 6 in Section 6.1
4. Depress Foot switch to activate timed dispensed cycle
Items Description
1 To Air Source
2 Air Filter (Not included)
3 Power Adapter
4 Foot Switch
2
1
3
4
6
6.3 Cycle Counter
The cycle counter records the numbers of dispense cycle being activated. Up
to 65,535 cycles can be recorded. This number is shown at the lower right
hand corner of the LCD. Press the Counter Reset button (3) to clear the
counter.
7TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTION
LCD does not
light •No power input
•Check power cord
connections
•Turn on power
System will not
actuate •Foot switch not
plugged in or
improperly plugged
in
•Defective foot
switch
•Broken wire or loose
connection inside
unit
•Defective solenoid
•Defective PC board
•Check foot switch
connection
•Foot switch needs to be
repaired or replaced
•Unplug power cord and
disconnect air supply.
Remove cover and check
for broken wires or loose
connections
•Replace solenoid
•Replace PC board
System will not
pressurize •Insufficient air
pressure
•Air hoses not
plugged in
•Regulator defective
•Increase air supply
pressure
•Check connection
•Replace regulator
System will not
pull vacuum •Vacuum setting is
too low
•Defective solenoid
•Defective vacuum
venturi
•Defective vacuum
needle valve
•Increase vacuum setting
•Replace solenoid valve
•Replace venture
•Replace needle valve
Inconsistent
dispensing •Air bubbles in
adhesive
•Dispense time is too
low
•Dispense needle
started to clog
•Reduce vacuum setting
•Increase dispensing time
•Replace needle

7
8MAINTENANCE
The dispenser is designed and built to be relatively maintenance free. To assure
trouble free operation, the following recommendations should be followed:
1. Make certain air supply is clean and dry.
2. Avoid turning barrels upside down or laying barrel so that material may
run through air line to internal components.
3. Avoid connecting the unit to excessive moisture or solvent saturation.
4. Avoid connecting air supply exceeding 100 psi (6.9 bar) for the TS250
and 15 psi (1.03 bar) for the TS255.
5. Use only Amyl Alcohol to clean outside surface of the main housing.
6. Use only soft cloth to clean the LCD.
9SPARE PARTS AND ACCESSORIES
For TS-3xx/2xx spare parts and accessories information, please visit the TS-3xx/2xx
User Guide webpage at www.adhesivedispensing.co.uk
10 LIMITED WARRANTY
OK International warrants this product to the original purchaser for a period of one
(1) year from date of purchase to be free from material and workmanship defects but
not normal wear-and-tear, abuse and faulty installation. Defective product or
subassembly and components under warranty will be repaired or replaced (at OK
International's option) free of charge.
11 I/O Configuration and End of Cycle Switch
For TS3xx/2xx I/O Configuration and End of Cycle Switch information, please visit
the TS-3xx/2xx User Guide webpage at http://www.adhesivedispensing.co.uk
2
INHALTSVERZEICHNIS
Seite
1Sicherheitshinweise........................................................................................2 - 3
2Erläuterung der Symbole................................................................................3
3Spezifikationen………………………......................…………………...…..4
4Hauptkomponenten.........................................................................................5
5Anschluss des Gerätes.....................................................................................6
6Setup Anleitung...............................................................................................6
7Fehlerbeseitigung............................................................................................7
8Wartung..........................................................................................................8
9Ersatzteile und Zubehör..................................................................................8
10 Garantie...........................................................................................................8
11 I/O Konfiguration und Schalter zum Beenden des Zyklus.............................8
1SICHERHEITSHINWEISE
1.1 Bestimmungsgemäßer Gebrauch
WARNUNG: Wird dieses Gerät für andere Zwecke eingesetzt als in diesem
Benutzerhandbuch beschrieben, kann es zu Personen- oder Sachschäden
kommen. Setzen Sie das Gerät nur gemäß der Anleitung ein.
OK International ist nicht haftbar für Personen- oder Sachschäden, die auf nicht
zweckgemäßen Einsatz der Geräte zurückzuführen sind. Zu nicht
bestimmungsgemäßem Gebrauch zählen:
•Änderungen am Gerät, die nicht ausdrücklich im Benutzerhandbuch
empfohlen werden
•Einsatz nicht kompatibler oder beschädigter Ersatzteile
•Verwendung nicht zugelassenen Zubehörs oder Hilfsgeräte
1.2 Sicherheitsvorkehrungen
•Betreiben Sie das Gerät ausschließlich mit den maximal zugelassenen
Nennleistungen/Einstellungen.
•Tragen Sie immer geeignete Schutzkleidung.
•Verwenden Sie nur die folgenden Adaptertypen: PSA15R-240P(ZJ) oder
PW118RA2403B01, PW118RA2403H01, PW118RA2403M01,
PW118RA2403G01
•Achten Sie darauf, dass korrosive oder brennbare Medien nicht in das Gerät
zurückfließen. Wenn korrosive oder brennbare Medien eingesetzt werden,
muss ein Inline-Filter (881-000-000), nicht im Lieferumfang enthalten, am
Dosiersystem installiert werden, so dass die Medien nicht in das Gerät
zurück gesaugt werden können.
