Techly I-ALARM-KIT001 User manual

WIRELESS GSM/APP
www.techly.com
Installation manual
SMS/GSM Alarm Wireless Starter kit
UP TO 159
ACCESSORIE S

EN
DE ITFR
2
Features
- GSM transmitter
- Supports up to 10 remote controls, 99 wireless accessories and 50 RFID tags
- Can store up to 5 phone numbers, 5 SMS numbers
- Arm / disarm the system by SMS, phone call, or App (on iOS or Android)
- Can be disarmed by RFID tag
- Call function from the panel
- SMS alerts for power failure, power recovery and low battery
- Audio surveillance of the site from distance
- 2 x 800mAh lithium batteries included (8h battery life in standby mode)
Specications
Product name
I-ALARM-KIT001
SKU
I-ALARM-KIT001
Control panel power supply
Input: AC 110-240V / 50-60 Hz
Output: DC 12V / 800 MA
GSM working frequency
850 / 900 / 1800 / 1900 mHz
Radio-frequency
433.92MHz (±75KHz)
Transmission distance
80m in open space
Standby current
80ma
Alarm current
300mA
Backup batteries
Lithium Batteries: 3.7V / 800 mAh x 2
(BL-5B)
(8h battery life in standby mode)
Internal siren
95dB
Housing material
ABS plastic
Operating conditions
Temperature: -10°C~55°C
Humidity: ≤ 80% (non-condensing)
Control panel dimensions (L x W x H)
188 x 125 x 25 mm
Box content
Control Panel x1
Motion Detector x1
Door / Window Contact x1
Remote Controls x2
RFID Tags x2
AC Adaptor x1
User manual x1

EN
DE ITFR
3
www.techly.com
Control Panel Layout (Front)
Control Panel Layout (Back)
Plans and position the alarm system
Power On/O
Adapter interface
24h Zone
Electronic lock
Wired siren
GND
SPK
LOCK
Z1
+12V
GND
Call
Clear
RFID Reader
Home Mode
LCD Display
Disarm
Record
Arm
SOS
Monitoring MIC
Speaker
Power Supply Interface
Tamper Switch
Power Switch
Battery Compartment
SIM Card Slot
Control panel
Remote control
Outdoor siren
Zone Sensor 1: "Front door"
Zone Sensor 2: "Living room PIR"
Zone Sensor 3: "Entrance window"
Zone Sensor 4: "Terrace Window"
Zone sensor 5: "Terrace door"
Zone sensor 6: "Bedroom Window"
Zone Sensor 7: "Bedroom PIR"
Zone Sensor 8: "Gas kitchen"
Zona sensor 9: "Bath water"
www.techly.com
A
B
C
1
2
3
4
5
6
7
8
9
9
3
A1
C
B
2
7
6
85
4

EN
DE ITFR
4
Quick Start-up Guide
Connect your System
Using the GSM transmitter (SIM card)
Open the battery compartment at the back of the control panel and insert a SIM
card in the control panel.
Important
Before using the Alarm System in GSM mode, you need to purchase a SIM card
that works on the GSM network with 850 / 900 / 1800 / 1900 MHz frequency. We
recommend you to subscribe to a plan with unlimited texts and one hour of voice.
For more information, please contact your local reseller.
Important
Make sure the SIM card does not require any PIN code. For more information,
please contact your local reseller.
Turning your System on
1. Plug the AC adaptor to an AC socket.
2. Plug the output connector of the AC
adaptor into the adaptor interface in
the battery compartment at the back
of the control panel.
3.Turn the power switch to "ON" (in the
battery compartment at the back of the
control panel).

EN
DE ITFR
5
www.techly.com
Mount the Control Panel
Before mounting the control panel on the wall, make sure the reception of the
GSM signal is sucient.
Fix the wall-mounting bracket on the wall with screws. Wedge the panel on the
bracket, make sure they t well.
Basic Operations
Arm the System
Press the Arm button " " on the control panel. The control panel beeps once:
the system is armed. The LCD display indicates "Armed" and the Arm icon on the
control panel is lit.
Note
If the Entry / Exit Delay is activated, all zones except the 24h zone will be armed
after the delay set (refer to the instructions on page 10 of this manual “Entry
/ Exit Delay”).
Disarm the System
Type your user code and press the Disarm button " " on the control panel. The
control panel beeps twice: the system is disarmed.
Home Mode
Press the Home button " " on the control panel. The control panel beeps once: the
system is armed in Home Mode.
All the sensors assigned to the Normal zone are armed. The sensors assigned to
the Home zone are disarmed.
Emergency Mode
Hold the “#SOS” button for 3 seconds. The alarm is triggered immediately and
the siren rings out. At the same time, the control panel dials the stored phone
numbers.

EN
DE ITFR
6
Speed Dial
Press the Call button “ ” on the control panel for 3 seconds: the panel auto-dials
the rst stored phone number. Press the Call button “ ” to end the call.
Hands-free Phone Call from the Panel
Through GSM
Press the Call button“ ” on the control panel, type the phone number you wish to
call and press the Call button “ ” again.
Record / Play a Voice Memo
Long press the Record Voice Memo button to record a 10-second voice message.
The Play Voice Memo Button blinks when a message has been recorded. Push the
center of the RFID reader in the control panel to listen to the voice memo. The
LED indicator turns o when the voice memo is being played. Touch it again to
replay the memo.
Hard Reset
Turn the control panel on. Press the tamper switch at the back of the control panel
5 times wirthin 5 seconds after having turned it on.
Settings will be restored to default values. Stored phone numbers and connected
accessories will be cleared.

EN
DE ITFR
7
www.techly.com
Setup from the control panel
The Alarm System must be set up before using for the rst time. During the setup
of the system, the control panel can be powered either by the AC power adapter
or by the backup batteries.
Default codes
- Admin code (necessary to set up your system): 123456
- User code (necessary to disarm your system or stop the alarm): 1234
- Duress code: 1111 (enables you to trigger a duress alarm)
- Open door code: 8888 (enables you to open an electronic door lock plugged to
your control panel)
All access codes can be changed. We recommend you to change these codes
before using your system for the rst time.
The control panel of your alarm system features an LCD display that enables you
to navigate through the menu of the control panel and set up your alarm system.
To enter the setting menu, type [your admin code + Enter] on the control panel.
In the table on the next page, each column represents a menu or a sub menu. Each
menu or submenu will be displayed on one of the two lines of the LCD display. On
the LCD display, the current menu, submenu, or setting is shown on the line at
the bottom, while the previous menu or submenu is shown on the line at the top.
Navigate and select the setting you wish to modify with the keys “ ” or “ ”, and
enter each menu or sub menu by pressing “Enter”.
How to use the keyboard
“ ” = delete
“ ” = move forward
“ ” = move backward
“Enter” = select / conrm
“Esc” = back / previous step in the menu / cancel
The tables on the next pages summarize all the settings that can be accessed and
modied on the control panel.

EN
DE ITFR
8
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3
Comments
Phone numbers
Phone [1~5] is:
-
Select the phone or SMS number you want to edit, type in the phone number and conrm with
the key "Enter". Use the key " " to clear.
5 phone numbers and 5 SMS numbers can be stored in the control panel.
SMS Num [1~5] Is:
Accessories Remote & Keypad
Add a new 01/10 30
The LCD screen displays “01/10” (at the left), which indicates the number of the remote control
you are about to connect (01 is the current remote control, 10 is the total number of remote
controls you can connect), and "30" (at the right), which indicates the time remaining to connect
the remote control. Press any key on the keypad or remote control, you hear one beep: the
connection is successful.
Once the remote control has been added, the countdown starts over from 30 so that you can
register another remote control in control panel (up to 10 remote control can be registered in
the control panel). Press Esc to exit.
Delete All 1=YES 0=NO
Delete a Remote Input 01-10:
Enter the number of the Remote Control you wish to delete and press "Enter".
Accessories RFID Tag
Add a new 01/50 30
The LCD screen displays “01/50” (at the left), which indicates the number of the RFID tag you are
about to connect (01 is the current RFID tag, 50 is the total number of tags you can connect), and
"30" (at the right), which indicates the time remaining to connect the RFID tag. Swipe the RFID
tag in front of the RFID reader, you hear one beep: the connection is successful.
Once the RFID tag has been added, the countdown starts over from 30 so that you can register
another RFID tag in control panel (up to 50 tags can be registered in the control panel). Press
Esc to exit.
Delete all 1=YES 0=NO
Delete a Tag Input 01-50:
Enter the number of the RFID tag you wish to delete and press "Enter".
Accessories Wireless
Sensors
Add a new
Home Zone
Delay Zone
Normal Zine
24-H Zone
Select the sensor type you wish your sensor to be assigned to (Normal Sensor, 24 Hour Sensor,
Delay Sensor, or Home Sensor), press “Enter” to conrm. For more information on zone setup,
please refer to page 14 of this manual.
The LCD screen displays “01/99” (at the left), which indicates the number of the sensor you are
about to connect (01 is the current sensor, 99 is the total number of sensors you can connect),
and "30" (at the right), which indicates the time remaining to connect the sensor. Trigger the
sensor, you hear one beep: the connection is successful.
Once the sensor has been added, the countdown starts over from 30 so that you can register
another sensor in control panel (up to 99 sensors can be registered in the control panel). In such
case, the sensor will be added to the same zone. Press Esc to exit.
Delete all? 1=YES 0=NO
Delete a Sensor Input 01-99:
Enter the number of the sensor you wish to delete and press "Enter".
Accessories Test Mode -
Trigger the sensors you have previously connected to the control panel. You hear 1 beep, the
LCD screen displays the signals that have been respectively sent by each sensor triggered.
Make sure all the sensors you have triggered are mentioned on the LCD screen. Press “Esc” to
exit the test mode.
This mode enables you to test if the sensors have been connected successfully to the control
panel.

EN
DE ITFR
9
www.techly.com
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3
Comments
Phone numbers
Phone [1~5] is:
-
Select the phone or SMS number you want to edit, type in the phone number and conrm with
the key "Enter". Use the key " " to clear.
5 phone numbers and 5 SMS numbers can be stored in the control panel.
SMS Num [1~5] Is:
Accessories Remote & Keypad
Add a new 01/10 30
The LCD screen displays “01/10” (at the left), which indicates the number of the remote control
you are about to connect (01 is the current remote control, 10 is the total number of remote
controls you can connect), and "30" (at the right), which indicates the time remaining to connect
the remote control. Press any key on the keypad or remote control, you hear one beep: the
connection is successful.
Once the remote control has been added, the countdown starts over from 30 so that you can
register another remote control in control panel (up to 10 remote control can be registered in
the control panel). Press Esc to exit.
Delete All 1=YES 0=NO
Delete a Remote Input 01-10:
Enter the number of the Remote Control you wish to delete and press "Enter".
Accessories RFID Tag
Add a new 01/50 30
The LCD screen displays “01/50” (at the left), which indicates the number of the RFID tag you are
about to connect (01 is the current RFID tag, 50 is the total number of tags you can connect), and
"30" (at the right), which indicates the time remaining to connect the RFID tag. Swipe the RFID
tag in front of the RFID reader, you hear one beep: the connection is successful.
Once the RFID tag has been added, the countdown starts over from 30 so that you can register
another RFID tag in control panel (up to 50 tags can be registered in the control panel). Press
Esc to exit.
Delete all 1=YES 0=NO
Delete a Tag Input 01-50:
Enter the number of the RFID tag you wish to delete and press "Enter".
Accessories Wireless
Sensors
Add a new
Home Zone
Delay Zone
Normal Zine
24-H Zone
Select the sensor type you wish your sensor to be assigned to (Normal Sensor, 24 Hour Sensor,
Delay Sensor, or Home Sensor), press “Enter” to conrm. For more information on zone setup,
please refer to page 14 of this manual.
The LCD screen displays “01/99” (at the left), which indicates the number of the sensor you are
about to connect (01 is the current sensor, 99 is the total number of sensors you can connect),
and "30" (at the right), which indicates the time remaining to connect the sensor. Trigger the
sensor, you hear one beep: the connection is successful.
Once the sensor has been added, the countdown starts over from 30 so that you can register
another sensor in control panel (up to 99 sensors can be registered in the control panel). In such
case, the sensor will be added to the same zone. Press Esc to exit.
Delete all? 1=YES 0=NO
Delete a Sensor Input 01-99:
Enter the number of the sensor you wish to delete and press "Enter".
Accessories Test Mode -
Trigger the sensors you have previously connected to the control panel. You hear 1 beep, the
LCD screen displays the signals that have been respectively sent by each sensor triggered.
Make sure all the sensors you have triggered are mentioned on the LCD screen. Press “Esc” to
exit the test mode.
This mode enables you to test if the sensors have been connected successfully to the control
panel.

EN
DE ITFR
10
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3
Comments Note
System Setting Date and Time YYYY-MM-DD TIME
(e.g. 2014-06-20 14H30)
System Setting Date Format
System Setting Entry Exit Delay
Entry Delay 000-300
This function can be used if you do not want to bring a
remote control or RFID tag with you. When the system
is armed, you hear one beep every second to remind
you to leave. The beep rhythm speeds up during the last
10 seconds. If an intruder is detected, the alarm will be
delayed accordingly.
Time is calculated in seconds. The Entry and Exit Delay can
be set from 0 to 300 seconds.
The entry and exit delays only
work for sensors connected as
Delay Zone accessories (see
"Wireless" on page 8).
The Entry Delay gives you time
to disarm the system on the
control panel without triggering
an alarm.
The Exit Delay gives you time to
arm the system on the control
panel and leave your home
without triggering an alarm.
Exit Delay 000-300
System Setting Auto Arm / Disarm
Auto Arm Time <00:00>
You can set up the system to arm and disarm
automatically at a dened time every day.
Setting Auto Arm and Auto Disarm
to the exact same time will
deactivate the function.
Auto Disarm Time <00:00>
ON or OFF?
System Setting Control by Phone ON or OFF? -
You can activate or deactivate the control of your system
by phone call. Activating the control by phone call enables
you to arm and disarm the system and monitor your home
by phone call.
See instructions on page 14 for
more information on the control
of the system by phone call.
System Setting GSM Fail Alarm ON or OFF?
Notication of SIM/ GSM signal problem.
System Setting Keypad tones ON or OFF? -
Activate or deactivate the sound when typing on the
keyboard of the control panel.
System Setting Access code
Admin Code 123456
Your admin code enables you to enter the setup menu.
Default admin code: 123456
It is recommended to change all
codes before using your system
for the rst time and to keep
your codes secret
User Code 1234
Your user code enables you to disarm the system on
the control panel. The user code is the access code
requested when you call the control panel.
Default user code: 1234
Duress Code 1111
In case of emergency, when you are requested to disarm
the system by force, it is recommended to disarm your
system with your Duress Code. The panel will silently
dial the stored phone numbers.
Default duress code: 1111
Open Door Code 8888
You can open electronic doors using this code. The door
must be wired to the [LOCK] interface on the back of the
control panel.

EN
DE ITFR
11
www.techly.com
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3
Comments Note
System Setting Date and Time YYYY-MM-DD TIME
(e.g. 2014-06-20 14H30)
System Setting Date Format
System Setting Entry Exit Delay
Entry Delay 000-300
This function can be used if you do not want to bring a
remote control or RFID tag with you. When the system
is armed, you hear one beep every second to remind
you to leave. The beep rhythm speeds up during the last
10 seconds. If an intruder is detected, the alarm will be
delayed accordingly.
Time is calculated in seconds. The Entry and Exit Delay can
be set from 0 to 300 seconds.
The entry and exit delays only
work for sensors connected as
Delay Zone accessories (see
"Wireless" on page 8).
The Entry Delay gives you time
to disarm the system on the
control panel without triggering
an alarm.
The Exit Delay gives you time to
arm the system on the control
panel and leave your home
without triggering an alarm.
Exit Delay 000-300
System Setting Auto Arm / Disarm
Auto Arm Time <00:00>
You can set up the system to arm and disarm
automatically at a dened time every day.
Setting Auto Arm and Auto Disarm
to the exact same time will
deactivate the function.
Auto Disarm Time <00:00>
ON or OFF?
System Setting Control by Phone ON or OFF? -
You can activate or deactivate the control of your system
by phone call. Activating the control by phone call enables
you to arm and disarm the system and monitor your home
by phone call.
See instructions on page 14 for
more information on the control
of the system by phone call.
System Setting GSM Fail Alarm ON or OFF?
Notication of SIM/ GSM signal problem.
System Setting Keypad tones ON or OFF? -
Activate or deactivate the sound when typing on the
keyboard of the control panel.
System Setting Access code
Admin Code 123456
Your admin code enables you to enter the setup menu.
Default admin code: 123456
It is recommended to change all
codes before using your system
for the rst time and to keep
your codes secret
User Code 1234
Your user code enables you to disarm the system on
the control panel. The user code is the access code
requested when you call the control panel.
Default user code: 1234
Duress Code 1111
In case of emergency, when you are requested to disarm
the system by force, it is recommended to disarm your
system with your Duress Code. The panel will silently
dial the stored phone numbers.
Default duress code: 1111
Open Door Code 8888
You can open electronic doors using this code. The door
must be wired to the [LOCK] interface on the back of the
control panel.

EN
DE ITFR
12
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3
Comments Note
System Settings Ring Times <1-9>: 5 -
Enter the value (from 1 to 9) and conrm with "Enter".
This function enables you to determine the number of times
the control panel will ring before taking your call (for control
by phone call).
System Settings Siren Alert Time <1-9Min>: 3
Enter the value (from 1 to 9) and conrm with "Enter".
This function enables you to determine for how long the siren
rings out in case of alarm.
System Settings Backlight Time <0-120s>: 30 -
Enter the value (from 0 to 120) and conrm with "Enter".
Default setting is 30 seconds.
System Settings Siren Setup
Wired Siren
Siren Switch
ON/OFF
Enable / Disable the siren.
Default setting: On Wired siren refers to a siren
connected to the control panel
by wire.
Arm/Disarm Tone
ON/OFF
Arm / Disarm silently.
Default setting: On
Built-in Siren
Siren Switch
ON/OFF
Enable / Disable the siren.
Default setting: On Built-in siren refers to the
siren featured in the control
panel.
Arm/Disarm Tone
ON/OFF
Arm / Disarm silently.
Default setting: On
Wireless Siren
Siren Switch
ON/OFF
Enable / Disable the siren.
Default setting: On Wireless siren refers to a siren
connected to the control panel
by radio-frequency.
Arm/Disarm Tone
ON/OFF
Arm / Disarm silently.
Default setting: On
System Settings User ID On / O -
When Disarm Upload is on, the system will upload the history
of arm/disarm events to the to the CMS.
Disarm Upload On / O -
System Settings Call Recycle <1-9>: 3
W hen the alarm is triggered, the control panel dials the numbers
you have stored. If you do not disarm the system, the control
panel will call you again (up to 9 times). The “Call Recycle”
function enables you to dene the number of times the control
panel attempts to call you. Default setting:
3 times.
System Settings Language - -
Select the language you wish to choose and conrm with
"Enter".
Languages available may vary
depending on the version of
your product.
System Settings Reset 1=YES 0=NO -
All system settings will be restored to default setting.
Stored phone numbers and connected accessories will be
cleared.
System Settings About About Jun 4 2014 -
History -- -
Choose the event log you need to track, press “Enter”. The control panel keeps in record the latest 150 event
logs.

EN
DE ITFR
13
www.techly.com
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3
Comments Note
System Settings Ring Times <1-9>: 5 -
Enter the value (from 1 to 9) and conrm with "Enter".
This function enables you to determine the number of times
the control panel will ring before taking your call (for control
by phone call).
System Settings Siren Alert Time <1-9Min>: 3
Enter the value (from 1 to 9) and conrm with "Enter".
This function enables you to determine for how long the siren
rings out in case of alarm.
System Settings Backlight Time <0-120s>: 30 -
Enter the value (from 0 to 120) and conrm with "Enter".
Default setting is 30 seconds.
System Settings Siren Setup
Wired Siren
Siren Switch
ON/OFF
Enable / Disable the siren.
Default setting: On Wired siren refers to a siren
connected to the control panel
by wire.
Arm/Disarm Tone
ON/OFF
Arm / Disarm silently.
Default setting: On
Built-in Siren
Siren Switch
ON/OFF
Enable / Disable the siren.
Default setting: On Built-in siren refers to the
siren featured in the control
panel.
Arm/Disarm Tone
ON/OFF
Arm / Disarm silently.
Default setting: On
Wireless Siren
Siren Switch
ON/OFF
Enable / Disable the siren.
Default setting: On Wireless siren refers to a siren
connected to the control panel
by radio-frequency.
Arm/Disarm Tone
ON/OFF
Arm / Disarm silently.
Default setting: On
System Settings User ID On / O -
When Disarm Upload is on, the system will upload the history
of arm/disarm events to the to the CMS.
Disarm Upload On / O -
System Settings Call Recycle <1-9>: 3
W hen the alarm is triggered, the control panel dials the numbers
you have stored. If you do not disarm the system, the control
panel will call you again (up to 9 times). The “Call Recycle”
function enables you to dene the number of times the control
panel attempts to call you. Default setting:
3 times.
System Settings Language - -
Select the language you wish to choose and conrm with
"Enter".
Languages available may vary
depending on the version of
your product.
System Settings Reset 1=YES 0=NO -
All system settings will be restored to default setting.
Stored phone numbers and connected accessories will be
cleared.
System Settings About About Jun 4 2014 -
History -- -
Choose the event log you need to track, press “Enter”. The control panel keeps in record the latest 150 event
logs.

EN
DE ITFR
14
Zone setup of accessories
Every detector can be assigned to 4 dierent categories of zones: Home Zone,
Delay Zone, Normal Zone and 24-H Zone. To assign a detector to a zone, follow the
instructions on page 8 of this manual (the zone will be assigned at the time
of connection of the accessory).
Normal zone
When the system is armed, if a sensor is triggered, the siren rings out. When the
system is disarmed, sensors do not trigger an alarm.
24h zone
Regardless the system is armed or disarmed, sensors assigned to the 24h zone can
trigger an alarm. It is recommended to assign smoke detectors, gas detectors and
outdoor beam sensors to the 24-H zone.
Delay zone
If you want to set up the entry and exit delay functions, corresponding sensors
must be assigned to the Delay zone. Once the delay time has been set up, the
sensors will not trigger the alarm during the delay set. Refer to the instructions
“Entry and Exit Delay” on page 10 of this manual. It is recommended to assign
the Door / Window Contact to the Delay zone.
Home zone
When the system is armed in Home Mode, the sensors assigned to the Home zone
do not trigger an alarm. It is recommend to assign motion dectors to the Home
zone so that you can have your system armed in Home Mode when you are home
and move inside your home without triggering any alarm.
Control by phone call
This feature is available only after having enabled it from the control panel, as
explained on page 10 of this manual.
Method 1
When an alarm has been triggered, the control panel dials the stored phone
numbers. When you pick up the phone, follow the voice instructions to control the
panel from distance (refer to the instructions in the table below).
Method 2
1. Dial the telephone number of your control panel (either the number of the SIM
card in your control panel or the number of the landline to which your panel is
connected). After getting through, the voice instructions will guide you to enter
your access code.
2. Enter your user code, followed by “#”.
3. A voice gives you the options you can select.
4. Select the operations to control the panel (see instructions in the table below).

EN
DE ITFR
15
www.techly.com
Note
The call will end automatically if you do not send any command within 30 seconds.
Table of commands for control by phone call
Command Function
Press “1” Arms the system
Press “0”
- Disarms the system and turns the
siren o
- Stops monitoring without hanging
up
- Stops the phone call function
without hanging up
Press “3” Phone call with control panel
Press “”
- Starts audio monitoring mode (not
limited in time)
- Stops the built-in siren and the
wireless siren (if connected to the
control panel)
Press “6” Turns all sirens o
Press “9”
- Turns the built-in siren on (whether
the siren ringing settings is ON or
OFF)
- Turns the wireless siren on (if
connected to the control panel)
Press “#”
- Turns all sirens o
- Exits control by phone call
- Stops call recycles
Note
In GSM mode, the audio monitoring is not limited in time.

EN
DE ITFR
16
Setup by SMS
IMPORTANT: BEFORE USING FOR THE FIRST TIME
Insert a SIM card in the control panel before starting SMS operations.
Make sure the SIM card does not require any PIN code.
SAVE A SMS NUMBER IN THE CONTROL PANEL (using the control panel).
Only stored numbers can control and congure the system.
(Refer to the instructions page 8)
Each SMS operation dened in this user manual will be illustrated as follows:
You send:
SMS Command
The control panel replies:
Control panel’s reply
The rst green speech bubble is the
SMS command sent by the user.
The rst grey speech bubble is the
reply sent by the control panel.
The speech bubbles that follow are the
dialogue between the user and the
control panel (SMS sent by the user are
in green SMS sent by the control panel
are in grey).
The system is in English by default. To change the system language, refer to the
instructions on page 22 of this manual.
Important
When replying to the control panel by SMS, make sure no space follows
punctuation marks like "." or ":". For examples, to store SMS numbers, your SMS
must be formatted as follows:
SMS numbers:
1.067890033
2.067890022
3.067890011
4.067890000
5.
No space after "1."

EN
DE ITFR
17
www.techly.com
Disarm the System
Send:
0
System disarmed.
Arm the System
Send:
1
System armed.
Home Mode
Send:
2
System in home mode.
Setting Enquiry
Send:
00
System:Disarmed
AC power:on
Note
The values indicated hereinabove
will change after having set up the
system.

EN
DE ITFR
18
Store Phone Numbers
Send:
5
Phone numbers:
1.
2.
3.
4.
5.
Copy, paste, then edit
(case sensitive):
Phone numbers:
1. 067890033
2. 067890022
3. 067890011
4. 067890000
5.
Ok
Store Phone Numbers for SMS
Notications
Send:
6
SMS numbers:
1.
2.
3.
4.
5.
Copy, paste, then edit
(case sensitive):
SMS numbers:
1. 067890033
2. 067890022
3. 067890011
4. 067890000
5.
Ok
Note
The rst SMS number will receive
SMS notications when the system
is disarmed by RFID tag. To start
receiving these notications, you
must rename the RFID tags. Up to 4
RFID tags can be renamed. Other tags
will be attributed a number based on
the order of registration to the control
panel. Refer to the instructions on
page 8 to learn how to register an
RFID tag in the control panel.

EN
DE ITFR
19
www.techly.com
Rename Zones
Send "91~99". For example for zone 1,
send:
91
Zones names:
1.
Copy, paste, then edit
(case sensitive):
Zones names:
1. Entrance door sensor
Ok
Note
Zones 1 to 9 can be renamed. The
name of the zone cannot consist of
more than 30 Latin characters. Zones
10 to 99 cannot be renamed.
SMS Alert for Accessory Low
Battery
(available for two-way acessories such
as Motion Detectors)
For accessories assigned to zones
that have been renamed, an SMS will
be sent under the format “Zone name
+ low battery”.
Bedroom PIR low battery
For accessories assigned to zones
that have not been renamed, an SMS
will be sent under the format “Zone
number + low battery”.
Zone 10 low battery.
SMS Alert for Accessory
Tamper Alarm
(available for two-way acessories such
as Motion Detectors)
For accessories assigned to zones
that have been renamed, an SMS will
be sent under the format “Zone name
+ tamper alarm”.
Bedroom PIR tamper alarm.
For accessories assigned to zones
that have not been renamed, an SMS
will be sent under the format “Zone
number + tamper alarm”.
Zone 10 tamper alarm.

EN
DE ITFR
20
Rename RFID Tag
Send:
10
Rename RFID tag names:
1.
2.
3.
4.
Copy, paste, then edit
(case sensitive):
Rename RFID tag names:
1. Tom
2. Nurse
3. Nancy
4. David
Ok
Note
The rst SMS number will receive
SMS notications when the system
is disarmed by RFID tag. To start
receiving these notications, you
must rename the RFID tags. Up to 4
RFID tags can be renamed. Other tags
will be attributed a number based on
the order of registration to the control
panel. Refer to the instructions on
page 8 to learn how to register an
RFID tag in the control panel.
Entry and Exit Delay Time
Send:
11
Entry delay time(0-300sec):0
Exit delay time(0-300sec):0
Copy, paste, then edit
(case sensitive):
Entry delay time(0-300sec):10
Exit delay time(0-300sec):20
Ok
Note
This function can be used if you do not
want to bring a remote control or a RFID
tag with you.
When you arm the system, the system
will be armed after the delay set.
When you disarm the system, the
system will be disarmed after the
delay set.
When arming the system, you hear
one beep every second to remind you
to leave. The beep rhythm speeds
up during the last 10 seconds. If an
intruder is detected, the alarm will be
delayed accordingly.
