Technaxx® * User Manual
FMT1000BT DAB+ Transmitter
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device,
to which this user manual belongs, complies with the essential requirements of the
standards referred to the Directive R&TTE 2014/53/EU. The Declaration of Conformity you
find here: www.technaxx.de/(in bar at the bottom “Konformitätserklärung”). Before using
the device the first time, read the user manual carefully. Turn OFF nearby Bluetooth
devices to avoid signal interference! Service phone No. for technical support: 01805
012643 (14 cent/minute from German fixed-line and 42 cent/minute from mobile networks).
Free Email: [email protected]
Features
4-in-1 Function: DAB+ receiver, portable DAB+ radio/MP3 player, Bluetooth Car Kit, FM
transmitter Wireless transfer for DAB+/DAB radio frequencies by FM transmission
technology Portable FM unit is usable as DAB+ radio & MP3 player Bluetooth function
for streaming music from mobile phones to the vehicle’s radio Handsfree function via
Bluetooth 2.1A output supports charging of almost all Smartphones and other mobile
devices AUX jack for stereo sound via AUX–IN of your vehicle Line–IN function
supports other external devices Quick Scan to search the available free FM frequency
Supports music playing from MicroSD card Built-in 800mAh rechargable battery
(charging the battery directly: put the FM unit to the charging dock in the car Flexible
goose neck easy to adjust the angle of the devices Easy handling and installation
Technical specifications
Power Input
12V–24V (cigarette lighter socket of a vehicle)
Bluetooth module
Actions 4.2
Frequency range
DAB+/DAB Band III 174-240MHz
FM frequency range
87.6–107.9MHz
Transmitter charging output
5V/2.1A
Transmittig distance
~3m maximum (depending on the electromagnetic
shielding of your car antenna)
LCD display
3.84 x 1.44cm (1.61“)
Input / Output connectors
AUX-IN / AUX-OUT 3.5mm
Earphone impedance
32 Ω
Storage
MicroSD card up to 32GB
Power supply
Built-in rechargable 800mAh lithium battery 3.7V
Charging time
~2 hours
Playing time
~10 hours (medium volume)
Playing time (portable use)
~7 hours
Weight / Dimensions FM unit
57g / (L) 5.0 x (W) 2.5 x (H) 6.5cm
Weight / Dimensions holder
59g / (L) 11.5cm; flexible.goose neck 4cm
Package Contents
FMT1000BT DAB+ Transmitter, Micro USB cable,
Audio cable, Antenna, Earphone, User Manual

Charging (there are 2 ways)
(1) Charging the battery of the FM unit: In the car put the FM unit into the docking
station (look for correct placement of the contacts, it easily clicks into the docking station of
the holder by a magnet). Insert the power supply plug into the cigarette lighter socket of a
vehicle. The battery will be charged automatically, no matter if the FM unit is switched ON
or OFF. At home, plug the Micro USB cable* (*included) into the FM unit and connect it to
a power adaptor** (**not included). The battery is charged regardless of whether the FM
unit is on or off. The output of adapter must be 5V 500mAh. Note: To check the charging
status of the battery when it is switched off, remove the charging cable and switch the
device on. The battery indicator at the top right of the screen shows the status: 3 bars
100%–70%, 2 bars 70%–40%, 1 bar 40%–10%, no bar 10%-0%.
(2) Charging other devices on the way in a car with charger unit: When the Docking
Station is powered from cigarette lighter socket of a vehicle, connect your mobile phone
with a USB cable*** (***not included) to the Docking Station. This unit will serve as mobile
phone charger. The output is 5V/2.1A with 10W.
View of the device
(1)
Front view (FM unit)
(2)
Metall contact
(docking station, fixed on holder)
(3)
Rear view (FM unit)
Charging contact
MicroSD Slot
Aux-in/Out Jack
Micro USB Charging port
ON/OFF Switch
Antenal Jack

Buttons of the panel (FM unit)
1.
Spin Button
Control
Press to Play/Pause under music mode, confirm
the selected sub-menu or pick up/hang off the
phone calls when get phone calls
Rotate clockwise or anticlockwise to go forwards
or backwards to a music title.
2.
Info / Menu
Button
Info: Under DAB mode, short press this button to see the DAB+ radio
info: DAB+ Channel name, Channels, Format, Bit rate, type, date, SNR
and signal strength
Menu: Press and hold this button to enter into the sub-menu below.
Rotate and short press the “Spin Button Control”to choose and
confirm the sub-menu. Press the Info/Menu button once to exit the
selected.
DAB Menu: Scan the DAB+ channel manually, Volume, Language
(English/German), System reset, Version
3.
Mode Button
Switch modes between DAB+/BT/MicroSD card and AUX–IN/AUX–
OUT
4.
Button
Auto scan the DAB+ radio
Auto scan the clear FM frequency after press the TX button
5. Tx Button
Set FM frequency for transmitting to the radio

Mounting
This devices contain two parts: The docking
station (fixed on the holder) and FM unit (you
can remove from the docking station easily).
When you put the FM unit into the Docking
Station the device will be charged. Then it
becomes a In-Car DAB+ receiver.
Installation
1. Put the FM unit into the docking, insert the
Power supply Plug into the car cigarette
lighter socket of a vehicle. Switch on the FM
unit with “ON/OFF” switch
2. Install the external antenna as seen in the
picture below.
3. Press TX button the screen will show the current FM transmitting frequency. Press
to scan the clear and unoccupied frequency. By pressing again and again the device
will show you more clear and unoccupied frequencies. Turn the spin button control to
adjust the frequencies manually.
4. Switch the car radio’s FM frequency to match the frequency you just set on the device.
All the sound will transmit to the car's radio and come out from the car Stereo.

DAB+ Receiver
1. Press the Mode button to switch to the DAB mode
2. Press button to perform a full scan of DAB stations since showing “scanning..” on
the screen. Once finished the totally DAB+ channel scanned will be displayed on the
top right corner, and then play the first DAB+ channel automatically. Start to enjoy the
DAB+ radio on the way.
3. Rotate the "Spin Button Control" to choose you desired DAB+ channels.
4. Use the Info/Menu button to check the DAB+ info or adjust the menu.
Bluetooth
1. Press the Mode button to switch to BT (Bluetooth) mode.
2. The first time the devices display "unconnected". Activate your mobile phone's
Bluetooth function, then search new device. When the mobile phone detects this unit,
which is named "FMT1000BT DAB+", then press this name to connect.
3. After successful connection the screen of the mobile phone and the FMT1000BT DAB+
will display "connected". Now can stream the music from the mobile phone.
4. Operate the Spin Button Control to play/pause or adjust previous/next songs.
5. In any mode, as long as the mobile phone is connected via Bluetooth with the FM unit
and there is an incoming call, this unit will automatically switch to telephone mode. The
screen displays "Calling". Press the Spin Button Control to pick up the call, then screen
display "In Call" (not in the Bluetooth mode).
MicroSD Card
Note: Format the MicroSD card in FAT32
1. Press the Mode button to switch the mode to SD (MicroSD).
2. Plug in the MicroSD card which contain MP3 files into the card slot, then enjoy the
music
3. Operate the Spin Button Control to play/pause or adjust previous/next songs.
AUX–IN
This device supports other external devices. Use the provided audio cable to connect
another external device to the AUX input of this unit. Press the Mode button to switch to
the Aux mode.
AUX–OUT
To get better sound quality, you can connect this device to car audio via the provided
audio cable directly. Connect the AUX cable from the AUX–IN/AUX–OUT jack to the AUX
input jack of your car (if available). Then the good quality sound would be come out from
the car stereo directly.

How to use portable device: This device has a built-in battery so it can be
used away from docking (if charged). Plug the provided earphone to the AUX–IN port of
this devices. The earphone will be treat as antennal under DAB+ mode. All the function
and operation are exactly same as mentioned above.
Replacing the fuse: As shown below, unscrew the screw cap, replace the fuse
and then reassemble the parts in the correct order.
1. Tip, 2. Screw Cap, 3. Silicon Ring, 4. Seal, 5. Fuse
Warnings
To prolong the life of this device, pull it out when starting the engine of the car. Do not
remove any cover to avoid the risk of an electric shock or other damages. Do not
attempt to disassemble the device, it may result in short-circuit or even damage. Do not
drop or shake the device, it may break internal circuit boards or mechanics. Keep the
device in dry and ventilated environment. Avoid high humidity and high temperature.
Do not expose this unit to rain or moisture to reduce the risk of fire or electrical shock.
The device should not be exposed to dripping or splashing. Do not place any objects
filled with liquids (such as vases) shall be placed on or near by the device. Do not install
the device near any heat source, such as radiators, or other equipment that produces heat.
Keep the device away from little children.
Security and Disposal Hints for Batteries: Hold children off batteries. When a
child swallowed a battery go to a doctors place or bring the child into a hospital
promptly! Look for the right polarity (+) and (–) of batteries! Always change all
batteries. Never use old and new batteries or batteries of different types together.
Never short, open, deform or load up batteries! Risk of injury! Never throw
batteries into fire! Risk of explosion!
Hints for Environment Protection: Packages materials are raw materials and
can be recycled. Do not disposal old devices or batteries into the domestic waste.
Cleaning: Protect the device from contamination and pollution. Avoid using rough,
coarse-grained materials or solvents/aggressive cleaner. Wipe the cleaned
device accurately. Important Notice: Should battery fluid leak from a battery,
wipe the battery case with a soft cloth dry. Distributor: Technaxx Deutschland
GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany
