3 Overview
3.1 Product Description
The RF Forward Path Amplifier - Enhanced (FPAE) is designed to plug into Technetix latest generation Advanced Intelligent
Multi-services Access platform - the AIMA3000. The FPAE accepts forward-path RF signals from 45 MHz to 1218 MHz
through the RF input port. The module provides an adjustable gain of 20 dB a single output port. Electronic gain and slope
control allows for the module to be customised for many situations. The forward-path version provides Automatic Gain
Control (AGC). The FPAE can also be conveniently monitored and controlled through a computer connected to one of the
Ethernet ports via the ASMM module.
All module settings are retained in non-volatile memory to ensure trouble-free operation. Bulk updating, automatic uploading
and downloading of configuration files can be done when using Technetix NMSE web-based management system.
3.2 Product Key Features
• DOCSIS 3.1 Compatible with operating bandwidth up to 1218 MHz
• Plug-and-play with the AIMA3000 platform
• Forward-path version (45 MHz to 1218 MHz) supports PAL, CENELEC, and NTSC with up to 127 channels
• Supports both analogue and digital transmissions
• High linearity, superior low noise profile and minimal distortion
• Automatic gain control (AGC) or manual gain control (MGC)
• Electronic gain and slope control
• Configurable alarm thresholds at a customer’s request
• Alarm monitoring through Technetix NMSE and the ASMM’s Web Interface
• Broadband GaAs amplifier technology
• Remote firmware upgrade and auto upload/download of configuration files through ASMM web interface or
using Technetix NMSE
• Bulk firmware updates through Technetix NMSE
• FCC, CE and RCM(1) compliant
(1) See Declaration of Conformity for current status.

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 9
3.3 Specifications
RF Performance
RF bandwidth 45 ~ 1218 MHz
RF flatness ± 0.5 dB
Noise Figure (NF) ≤ 8 dB
RF Input level 10 dBmV per channel (nominal) (1)
RF Output level 40 dBmV per channel (rating) (1)
Gain range NC: 0~20 dB
BC: 10~30 dB
NC individual: 0~10 dB
Gain Adjustment range BC individual: 0~10 dB
0 dB to 10 dB (output gain control)
Slope adjustment range 0 dB to 9 dB
AGC range (input variation) 10 dB
AGC accuracy ±0.5 dB over AGC range
RF impedance 75 Ω
RF return loss >18 dB
RF test point relative to RF output port -20 ± 1 dB
Isolation between NC and BC inputs > 50 dB
Back isolation > 60 dB
RF connectors 3 × GSK-type female
RF test points 1 x mini-SMB
Alarms and status Front-panel LEDS, SNMP traps
Link Performance (1)
NTSC (1) CENELEC (42ch) (2)
CNR > 60 dB > 60 dB
CSO > 75 dB > 75 dB
CTB > 75 dB > 85 dB
Notes:
(1) Loaded with 77ch NTSC, RF input=10 dBmV (70 dBuV) / ch, Gain=30 dB
(2). Loaded with 42ch CENELEC, RF input=10 dBmV (70 dBuV) / ch, Gain=30 dB
General
Power supply Powered via AIMA3000 backplane
Power consumption < 13 W
Operating temperature -5 ~ 55 °C
Operating humidity 90 % (Non-condensing)
Storage temperature -40 ~ 70 °C
Storage humidity 90 % (Non-condensing)
Dimensions (W*D*H) 24.6 * 410 * 152.5 mm
Weight Single: 0.88 kg
Supported network Technetix NMSE or through ASMM’s Web Interface
management options

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 10
3.3.1 Block Diagram
Table 3-1 FT5P Block Diagram Glossary
Figure 3 1 Block diagram FPAE
Parameters Glossary
RF INPUT RF Input
ATT Attenuator
TP RF IN -20 dB RF -20 dB Input Test point
SLOPE Slope Control
RF OUTPUT RF Output
TP RF OUT -20 dB RF -20 dB Output Test point
Input Gain Input Gain
Output Gain Output Gain
TO BACK PLANE AND COMMS Data Bus
CPU Central Processing Unit

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 11
3.4 Order Details
A-FPAE-[Y]-[Z] RF Forward-Path Amplifier - Enhanced
Options:
Y Ports
S Single
Z Bandwidth
1G 45 ~ 1000 MHz
12 45 ~ 1218 MHz

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 12
4 Module Characteristics
4.1 Module Appearance and Port Layout
4.1.1 Overview
Front Panel
Rear Panel
Figure 4-1 Module Appearance

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 13
4.1.2 Front Panel Layout
Figure 4-2 FPAE Front Panel Layout

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 14
Table 4-1 FPAE Front Panel Functions
Item Number Item Description
1 MODE LED
Module Gain Control Mode Indicator
MGC: Green Light Blinking
AGC: Green
2 STATUS LED
Module Alarm Indicator
Normal: Green
Minor Alarm: Amber
Major Alarm: Red
3 RF OUT LED
RF Output Indicator
Normal: Green
Minor Alarm: Amber
Major Alarm: Red
4 RF OUT TP RF Output Test Point
5 Orange tab-retaining clip Used to plug and anchor the module. The tab-retaining clip will pop-
up after pressing the release and plug module.
6 Mounting Screw Module fastening screw

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 15
4.1.3 Rear Panel Layout
Figure 4-3 Rear Panel Layout
Table 4-2 FT5P Rear Panel Functions
Serial Number Item Description
1 RF IN RF Input
2 RF OUT RF Output
3 Air Vent Air vent allowing air to flow out of the module
4 Multi-pin connector Power and communication port
5 Placement Pin Used to position the module in the chassis

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 16
5 Installation
5.1 Preparatory Work for Installation
Before installing this device, you must ensure that the unit is intact and ready for installation.
Unpack and check the unit: Open the box to check for any damage that may have occurred during shipment.
If damage is found, please contact a Technetix customer support representative.
Necessary equipment and tools for installation:
Table 5.1 Necessary equipment and tools for installation
Tools/Modules Description
Phillips screwdriver PH1/PH2 For use with the AIMA3000 chassis
FPAE Module The module to install into the AIMA3000 chassis
No. Description Qty
1 FPAE module 1
2 Individual test sheet (Certificate of Performance) 1
5.2 Unpacking
Unpack the module. Keep the packaging materials for future transport needs.
Check the package manifest, record the product module type, serial number, purchase date, and any other relevant
information to facilitate later management and maintenance.
Table 5.2 Packing Manifest

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 17
5.3 Module Installation
1. Gently depress the orange retaining clip and release the hinged tab
Hinged tab
Module fastening screw
AIMA Module
Orange retaining clip
2. Hold the AIMA module casing upright, align it with the AIMA3000 slide rails for the correct slot, and insert the
module until it reaches the multi-pin connector.
DO NOT use excessive force when inserting the module, but ensure the RF connectors at the rear of the module
are securely connected with the chassis's RF connectors.
CAUTION!
The module MUST be installed correctly to ensure a proper connection of the module’s multi-pin connector and
the backplane.
Tip:
When inserting the module into the guide rails, vertically tilt the module slightly to check that the guides are properly
seated on the rails. The module is guided to the correct position using the large metal fastening screw on the lower
part of the front panel.

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 18
3. After the module is inserted, gently push the hinged tab until it snaps into the orange retaining clip. While
pushing down on the hinged tab, the AIMA module will mate with the power bus and will lock into the chassis
CAUTION!
If force is required to insert a module, then it may not be correctly seated on the slide rails, or the mounting screw may
be misaligned.
4. When the module is fully seated within the chassis, on the bottom of the AIMA module, fasten the spring-loaded
mounting screw. Only use fingers to fasten the mounting screw. DO NOT use a screwdriver.
5.4 Check Module LEDs
When the module has been installed, if the chassis is powered, all LED indicators on the front panel will show a blinking
green light, indicating the module is initiating.
If the input signal and output signal are normal, the “STAT” LED indicator will cease to blink in about 5 seconds and remain
constant green afterwards. At the same time, “RF IN” and “RF OUT” LED indicators will also remain constant green when
the signals are normal.
If the input signal is out of the expected range, the “STAT” and “RF IN” LED indicators will show constant orange or red. If
the output signal is out of the expected range, the “STAT” and “RF OUT” LED indicators will show constant orange or red.
5.5 Test the RF Input Signal
When setting up the transmitter for final deployment, the RF input levels must not exceed 20 dB.

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 19
6 Module Configuration & Alarm setup
The module configuration settings can be configured using the web interface and Technetix NMSE (network management
software). This manual only provides details on the web interface. For login details and network setup, please refer to the
AIMA-ASMM user manual. If the same module is reinserted in the same slot, the ASMM will restore the previous settings if
the module is set to “Auto Download” the configuration.
6.1 Port Configuration screen
After logging in to the AIMA ASMM controller, select the “Modules” tab and then the “FPAE” to configure one of the FPAE
modules. After selecting the “FPAE”, the “Port” option will appear.

AIMA3000.FPAE Product User Manual
Technetix Group Limited
[email protected] •technetix.comMay/2016 - Version 1.0 20
Figure 6-1
After selecting “Port”, the RF configuration screen will appear for the designated transmitter.
In the FPAE “Port” configuration screen “Gain Control Type”, “Slope Control”, “Broadcast MGC”, “Narrowcast MGC”,
and “Alarm Settings” become available.
Total Gain is calculated by adding the Input Gain Level and the Output Gain Level with 10 dB.
