Techni Mobili RTA-739DL User manual

Thank you for purchasing our product.
MODEL RTA-739DL
ASSEMBLY INSTRUCTIONS
REV.PFT-6839-0822
Please note that this
product comes packaged
in 2 separate boxes. Scan QR code to
view assembly video
L-SHAPE HOME OFFICE TWO-TONE DESK WITH STORAGE

P.1 RTA-739DL P.1
•The product comes packaged in 2 separate boxes.
•Please read carefully the assembly instructions
before the installation.
•Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require of two people for the assembly.
•Scan the above QR code to view the complete
assembly video online.
•For individual Step videos –please use the QR code
found on the corresponding step within the manual.

P.2 RTA-739DL P.2
Do a quick inventory
of all the parts and
hardware listed in the
following pages.
Missing, damaged and defective
parts can be replaced at no cost
to you. Please refer to the last
pages on this manual.
The replacement parts service is limited to the
48 contiguous United States. If you reside in
AK, HI, PR, U.S. territories or other countries,
please contact the supplier from where the
unit was purchased.
1
x1 2
x1 3
x1 4
x1
Right frame Left frame Center-left leg Center-right leg
MAIN PARTS LIST
5
x1 6
x1
Left-top-back tube Left-bottom-back tube
14
x1
Left tabletop
12
x4
15
x1
Corner top
7
x1 8
x1
Left-top-front tube Right-top-back tube
9
x1
10
x1
Right-bottom-back tube Right-top-front tube
Corner-bottom-back tube Foot
11
x1 13
x1
Earphones
hook

P.3 RTA-739DL P.3
MAIN PARTS LIST (Continue)
16
x1
Right tabletop 17
x2
Right shelf panel
18
x1
Left panel 19
x1 Right panel 20
x1
Back panel 21
x1 Bottom panel
22
x3
Drawer front panel 23
x3
Drawer left panel 24
x3
Drawer right panel 25
x3
Drawer back panel
26
x3
Drawer bottom
board 27
x3
Sets
Sliders*, each set of 4 pcs
“Flat”: 2 pcs, go inside the cabinet “L shaped”: 2 pcs, go on the drawers
* 24 pcs of
screws D come
packaged
together with
these pieces.

P.4 RTA-739DL P.4
MAIN PARTS LAYOUT (FOR REFERENCE):
