Techni Mobili RTA-B018 User manual

Thank you for purchasing our product.
MODEL RTA-B018
ASSEMBLY INSTRUCTIONS
REV.CS-092021-3

•Please read carefully the assembly instructions
before the installation.
•Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require two people.
P. 1 RTA-B018 P. 1

P. 2 RTA-B018 P. 2
8
x1
5
x2
4
x1
1
x1
2
x1
3
x1
Top panel Left frame Right frame Back panel
MAIN PARTS LIST
6
x1
Shelf Drawer front panel Drawer left panel Drawer right panel
10
x1
Drawer back panel Drawer bottom
panel
7
x1
9
x1
MAIN PARTS LAYOUT
(FOR REFERENCE):
1
5
4
H
I
5
2
3
x1
x1
6

P. 3 RTA-B018 P. 3
LIST OF HARDWARE
PART
QTY ITEM
A4M6x50
B8M6x30
C4Cam Bolt
D8ST4x12
E4ST4x35
F4M6x12
G4Cam Lock
H2
Non-
Locking
caster
I2Locking
caster
J2Sliders
1Allen key
1Wrench
(Spanner)
You will also need a Phillips screwdriver
(not included)

P. 4 RTA-B018 P. 4
☛This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
assembly using this kind of hardware.
Cam Bolt
Cam Lock
1. Screw the bolt into the corresponding hole
on panel “A”.
3. Insert the cam lock on panel “B” making
sure it goes aligned to receive the bolt’s head.
4. Turn the cam lock clockwise. This will lock the
parts together and will close any gaps.
Alignment: The cross points
towards the panel “A” with the bolt.
2. Join panel “B” to panel “A”. If panel “B” comes
with the cam lock pre-installed, make sure it is
aligned to receive the bolt’s head (refer to point
3). There might be a very small gap between the
panels which is normal.
Panel “B”
Panel “B”
Panel “B”
Panel “B”
Panel
“B”

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do aquick inventory
to make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost
to you. Please refer to
the last pages on this
manual.
❹If during assembly
you find an issue or
need clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read the
instructions and analyze
the illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which
hardware will be used on
each step.Using the
wrong size of screw, bolt
or pin might strip the
threads or cause damage
to the part in which it is
being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾Sometimes the laminate might cover
partially or entirely the hole on apanel.If there
is no visible hole for the screw, pass and press
the tip of your finger over the area where the
hole should be located to feel the indentation,
and once found, carefully pierce the laminate to
reveal the hole underneath.
❿If the hole seems too small for the screw,
first make sure you are using the correct size of
screw and that it’s been installed in the correct
hole.If the hole still appears to be too small,
carefully pierce the laminate to reveal the
hole’s actual size.
P. 5 RTA-B018 P. 5
❸The replacement parts
service is limited to the
48 contiguous United States.
If you reside in Alaska,
Hawaii, Puerto Rico,
U.S. territories or other
countries, please contact the
supplier from where the unit
was purchased.

ASSEMBLY STEPS
Grab and extend each of the sliders Jtowards your RIGHT and separate
the small track from the rest by pressing UP firmly the locking lever, at
the same time that you pull the small track out. The big pieces J-1 will be
used in the next step, while the small tracks J-2 will be used until step
11, so please set them aside.
P. 6 RTA-B018 P. 6
Open the big sliders J-1 and attach them to the top bar on the left frame
2and the right frame 3with screws Dusing a screwdriver (not included).
Screw at the back hole first (last hole), then it will be easier to find the
front hole through the openings.
(Front)
(Top)
(Front)
STEP 2
Hardware:
D
M6x20
4
Pcs
J-1 2
Pcs
(NOT INCLUDED)
J-1
Big pieces: Use on next step Small tracks: Used until step 11
(Front)
(Front)
23
J-1
Flush
pieces
(Top)
J
used in the next step, while the small tracks
J-2
will be used until step
J-1 J-2
Open slider
towards the right
Push lever UP
Separate smaller rail
STEP 1
Hardware:
J2
Pcs
Attach at
back first

P. 7 RTA-B018 P. 7
Attach the casters Hand Ito the bottom of the frames 2and 3using the
wrench, and following this order:
•The Non-Locking casters Hgo at the back of the frame.
•The Locking casters Igo at the front of the frame.
Assemble the back panel 4to the frames 2and 3with screws Fbut do
not tighten yet. The screws go through the tabs on the frames and into
the panel.
STEP 3
Hardware:
H
Non-
Locking
2
Pcs
I
Locking
2
Pcs
STEP 4
Hardware:
F
M6x30
4
Pcs
Locking
I
H
3
2
H
I
Locking
at front
Locking
at front
3
24
DO NOT TIGHTEN
THE SCREWS, leave
them all loose to allow
flexibility for the next
steps.

P. 8 RTA-B018 P. 8
•Place the tabletop 1upside-down on the floor over a towel or rug to
protect its surface, and place the frames 2and 3over it making the
holes coincide, then insert the screws Abut do not tighten yet.
•Turn the unit over its back side to have it ready for the next step.
STEP 5
Hardware:
A
M6x50
4
Pcs
3
2
1
DO NOT TIGHTEN THE
SCREWS, leave them all
loose to allow flexibility for
the next step.
•Assemble the shelf panels 5to the middle and bottom bars on the
frames 2and 3with screws Bfrom underneath as shown, but do not
tighten any screws until finished with this step.
•Afterwards, you can proceed to tighten all the screws left loose from
steps 4, 5and 6, and turn the unit upright.
STEP 6
Hardware:
B
M6x30
8
Pcs
5
5
2
3

P. 9 RTA-B018 P. 9
Assemble the drawer side panels 7and 8to the drawer back panel 9
with screws Efrom the side.
STEP 7
Hardware:
E
ST4x35
4
Pcs
Use a screwdriver (not included) to attach the bolts Cto the drawer front
panel 6.
STEP 9
Hardware:
C
Cam Bolt
4
Pcs
(NOT INCLUDED)
8
7
9
Make sure all the
grooves match at the
bottom of the panels
Slide the drawer bottom panel 10 through the grooves of the side panels
7and 8, and into the groove of panel 9.
STEP 8
7
8
9
10
6

P. 1 0 RTA-B018 P. 1 0
Use a screwdriver (not included) to assemble the drawer front panel 6to
the side panels 7and 8with cam locks Gas shown and as explained in
page 4.
Attach the sliders J-2 to the side panels 7and 8with screws D.
(Left)
STEP 10
Hardware:
G
Cam lock
4
Pcs
(NOT INCLUDED)
STEP 11
Hardware:
J-2 2
Pcs
D
ST4x12
4
Pcs
(NOT INCLUDED)
(Right)
J-2
7
8
6
Cam lock
alignment
J-2
(Front)
8
7
J-2
J-2

P. 11 RTA-B018 P. 11
•On the frame first make sure that the piece with the ball bearing is all
the way to the front.
•Insert the drawer making sure that simultaneously on both sides, the
tracks J-2 on the drawer go through the black plastic guides and the
ball bearing pieces on the sliders J-1.
•Push in the drawer slowly into the unit.
STEP 12
1. Make sure the piece
with the ball bearings is
all the way to the front
J-1 J-1
J-2
2. The track must go through
the plastic guide and engage
into the ball bearing piece
3. Push in very slowly.

ALL DONE!
Give yourself a nice pat on the back. You did a
great job!
P. 1 2 RTA-B018 P. 1 2

WEIGHT LIMITS
P. 1 3 RTA-B018 P. 1 3
10 Lbs.
(4.53 Kg)
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the drawer.
•Do not sit on the unit or lean against it.
•Do not allow small children to play with the unit or use it as a moving vehicle.
•Do not allow small children to reach inside the drawer without your supervision.
•Before moving the unit, make sure to unlock the front casters.
•Before moving the unit, make sure to secure any object that might fall off.
•When transporting the unit to places far away, lock the front casters and protect and
secure the unit to avoid damage in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts
might be available to you at no charge. Please refer to the last pages on this manual.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes
liability for damages or consequences due to accidents, incorrect assembly, negligence,
improper use, modifications, or not heeding the above warnings.
CARE, MAINTENANCE AND SAFETY WARNINGS:
50 Lbs.
(22.68 Kg)
70 Lbs.
(31.75 Kg)
90 Lbs.
(40.82 Kg)

RTA Products, LLC warrants to the Original Purchaser who acquired anew product from
RTA Products or its authorized resellers that this product will be free from defects in its
workmanship and materials, under normal use and service conditions, as described
herein."Defects" as used in this warranty, is defined as any imperfections that impair the
use of the furniture or product.RTA Products LLC will replace any defective part, at its
discretion, and without charge to the original purchaser other than the freight from the end
consumer to RTA Products.
Replacement parts can only be supplied if parts are available.Items out of production
may be unavailable.This warranty will be effective for the applicable time period
beginning the date of purchase on your original sales receipt.RTA product’s obligation
under this warranty is limited to repairing or replacing products or parts as provided
herein.This product has been designed for and is intended for office and home-office use
only.This warranty is Original Purchaser’s sole remedy for product defects, and this
warranty does not extend to any product, or damage to any product, caused by or
attributed to abuse or misuse, products used for commercial or rental purposes, use
modifications of, or attachments to the product, and products or parts not used,
maintained, or extended hereunder is in lieu of any and all other warranties, express or
implied, including without limitations any implied warranty or merchantability or of fitness
for aparticular purpose.Please note, all desks made with PVC Laminate surface should
not be exposed to direct sunlight, as it may damage the material.Damage of this nature
is not covered under this warranty.
RTA Products will not be responsible for indirect, special, incidental or consequential
damages.This warranty is limited to merchandise purchased in the Continental United
States.Some States do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.This warranty
gives you specific legal rights.You may also have other rights that may vary from state to
state.
RTA Products will advise you of the procedure to follow in making warranty claims.The
following are the procedures for warranty claims:
a. Call us Monday –Friday, from 9am-5pm (Eastern Time) at [phone] to explain
the defect and give your name, address and phone number.Please have ready the
model number of our product, date and place of purchase.You can also write to us by
e-mail to [e-mail] and include the same information.
b. If we determine that replacement will remedy the situation, and in order to determine
the extent or the cause of the defect, purchaser will need to send the part in question
at purchaser’s expense.Once we receive the part, we will examine it and determine
whether the claim is valid (or not), and then proceed to send the replacement.We will
ship the replacement at our expense.
P. 1 4 RTA-B018 P. 1 4
TECHNI MOBILI WARRANTY
DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY
TV Stand/Entertainment Center: 2 YEAR WARRANTY

FOR SEVERAL HELP OPTIONS
INCLUDING REPLACEMENT PARTS ORDERS
_________________________________________________________________
VISIT: WWW.TECHNIMOBILI.COM
CLICK ON SUPPORT TAB
Scan QR Code to order replacement parts
OR EMAIL US: [e-mail]
P. 1 5 RTA-B018 P. 1 5
