Techni Mobili RTA-482BC User manual

Thank you for purchasing our product.
MODEL RTA-482BC
ASSEMBLY INSTRUCTIONS
REV.072021-0

•Please read carefully the assembly instructions
before the installation.
•Do not discard this manual or any of the packaging
material until the unit has been completely
assembled.
•Might require two people.
P. 1 RTA-482BC P. 1

P. 2 RTA-482BC P. 2
1
x1
2
x1
3
x4
4
x1
Front structure Back structure Glide Studs Top panel
MAIN PARTS LIST
5
x1
6
x1
7
x1
8
x1
Upper left shelf Upper left
divider
Upper right shelf Middle left shelf
10
x1
11
x1
Middle right shelf Lower left panel
9
x1
12
x1
Middle divider
Lower right panel
13
x1
14
x1
Lower shelf Lower back panel 15
x1
Lower panel
16
x1
17
x1
Left door Right door 18
x4
19
x2
set
Hinges Door Spring kit 20
x2
Strips
Covers
Lower right panel

MAIN PARTS LAYOUT (FOR REFERENCE):
P. 3 RTA-482BC P. 3
LIST OF HARDWARE, SCREWS AND FITTINGS
PART QTY ITEM
A18 M6x45 Bolt
B24 M6x40 Bolt
C8M6x25
D4M6x30
E4ST3x15
F24 ST4x16
G2
Sets Anchor Kit
1Allen Key
1Screwdrive
r

P. 4 RTA-482BC P. 4
☛
☛
This unit uses cam bolts and locks. The following explains how to use them.
☛
☛
This unit uses cam bolts and locks. The following explains how to use them.
This unit uses cam bolts and locks. The following explains how to use them.
This is not an assembly step; it is a guide for when you are actually doing the
This is not an assembly step; it is a guide for when you are actually doing t
assembly using this kind of hardware.
Cam Bolt
Cam Lock
1. Screw the bolt into the corresponding hole
on panel “A”.
3. Insert the cam lock on panel “B”, making
sure it goes aligned to receive the bolt’s head.
4. Turn the cam lock clockwise. This will lock
the parts together and will close any gaps.
Alignment: The cross
points towards the
panel with the bolt.
2. Join panel “B” to panel “A”. There might be a
very small gap between the panels which is
normal.
CORRECT
Panel “B”
Panel “B”
Panel “B”
INCORRECT
Panel “B”
Alignment: The cross
points towards the
panel with the bolt.
Panel “B”

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
❶Do aquick inventory
to make sure the package
contains all the parts and
hardware listed in the
assembly instructions.
❷Missing, damaged
and defective parts can
be replaced at no cost
to you. Please refer to
the last pages on this
manual.
❹If during assembly
you find an issue or
need clarification, please
contact our Customer
Service for assistance.
Please refer to the last
pages on this manual.
❺On each step read the
instructions and analyze
the illustrations thoroughly
before proceeding to do the
assembly.
❽Do not overtighten
or force the screws as
they might break, strip,
damage the threads of
the holes or get stuck
inside the part.
❻Make sure you
understand which
hardware will be used on
each step.Using the
wrong size of screw, bolt
or pin might strip the
threads or cause damage
to the part in which it is
being used.
❼To avoid
misalignments, always
leave the screws loose
and tighten them until
all pieces are
positioned correctly.
❾Sometimes the laminate might cover
partially or entirely the hole on apanel.If there
is no visible hole for the screw, pass and press
the tip of your finger over the area where the
hole should be located to feel the indentation,
and once found, carefully pierce the laminate to
reveal the hole underneath.
❿If the hole seems too small for the screw,
first make sure you are using the correct size of
screw and that it’s been installed in the correct
hole.If the hole still appears to be too small,
carefully pierce the laminate to reveal the
hole’s actual size.
P. 5 RTA-482BC P. 5
❸The replacement parts
service is limited to the
48 contiguous United States.
If you reside in Alaska,
Hawaii, Puerto Rico,
U.S. territories or other
countries, please contact the
supplier from where the unit
was purchased.

P. 8 RTA-482BC P. 8
ASSEMBLY STEPS
Assemble the shelves 5and 7to the Upper left divider 6with bolts Aas
shown and as explained in page 4.
Assemble the shelves 8and 10 to the Middle divider 9with bolts Aas
shown and as explained in page 4.
5
6
5
6
STEP 1
Hardware:
AM6x45
Bolt
2
Pcs
Cam lock
alignment
7
Cam lock
alignment
STEP 2
Hardware:
AM6x45
Bolt
2
Pcs
Cam lock
alignment
Cam lock
alignment
10
9
8
Assemble the shelf 7from step 1to the Middle divider 9from step 2with
a bolt Aas shown and as explained in page 4.
STEP 3
Hardware:
AM6x45
Bolt
1
Pc
Cam lock
alignment
Cam lock
Cam lock
7
9

P. 9 RTA-482BC P. 9
With the help of another person, assemble the Back structure 2to all the
panels assembled in step 7with bolts Bas shown and as explained in
page 4.
STEP 5
Hardware:
BM6x40
Bolt
12
Pcs
Install the glide studs 3into the bottom of the structures 1and 2.
STEP 4
Hardware:
34
Pcs
1
2
Cam locks
alignment
Cam locks
(Front)
2
10
7
6
5
8
9
(Back)

ASSEMBLY STEPS
P. 6 RTA-482BC P. 6
Assemble the Lower side panels 11 and 12 to the Lower panel 15 with
bolts Aas shown and as explained in page 4.
(Back)
(Back)
15
12
11
STEP 7
Hardware:
AM6x45
Bolt
4
Pcs
(Front)
(Front)
(Back)
Assemble the Lower back panel 14 to the Lower panel 15 with bolts Aas
shown and as explained in page 4.
STEP 6
Hardware:
AM6x45
Bolt
2
Pcs
Cam locks
alignment
Cam locks
alignment
14
15
(Holes for
hinges in
step 16)

P. 7 RTA-482BC P. 7
Assemble the Lower shelf 13 to the panels 11, 12 and 14 with bolts Aas
shown and as explained in page 4.
13
11
12
STEP 9
Hardware:
AM6x45
Bolt
6
Pcs
Cam locks
alignment
14
•Attach the piece 19B from the Door spring kit 19 to the lower shelf 13
with screws F, making sure the little stopper faces towards the front.
STEP 8
Hardware:
19
A
2
Pcs
19
B
2
Pcs
FST4x16
4
Pcs
13
•Slide the spring piece 19A from the Door spring kit 19 through the
piece 19B until it locks inside, making sure the spring button faces
towards the front.
13
19B
F
19A 19B

P. 1 0 RTA-482BC P. 1 0
With the help of another person, turn over the frame built in step 5 and
place the box built in step 9over the lower section of the structure 2.
The side panels 11 and 12 will engage inside the frame, while the
bottom panel 15 will stay on top of it as shown.
With the help of another person, assemble the front structure 1 to all the
panels on the upper section of the frame with bolts Bas shown and as
explained in page 4.
11
STEP 10
Cam locks
alignment
Cam locks
11
2
12
15
FLIP
FLIP
STEP 11
Hardware:
BM6x40
Bolt
12
Pcs
1
6
5
8
7
910

P. 1 0 RTA-482BC P. 1 0
With the help of another person, turn over the frame built in step 5 and
place the box built in step 9over the lower section of the structure 2.
The side panels 11 and 12 will engage inside the frame, while the
bottom panel 15 will stay on top of it as shown.
With the help of another person, assemble the front structure 1 to all the
panels on the upper section of the frame with bolts Bas shown and as
explained in page 4.
11
STEP 10
Cam locks
alignment
Cam locks
11
2
12
15
FLIP
FLIP
STEP 11
Hardware:
BM6x40
Bolt
12
Pcs
1
6
5
8
7
910

P. 11 RTA-482BC P. 11
Secure the side panels 11 and 12 to the structure 1with screws Cfrom
the inside.
•With the help of another person bring the frame upright.
•Secure the side panels 11 and 12 to the back structure 2with screws
Cfrom the inside.
11
1112
STEP 12
Hardware:
C
M6x25
4
Pcs
11
1
12
STEP 13
Hardware:
C
M6x25
4
Pcs
12
2
(Front)
(Back)

P. 1 2 RTA-482BC P. 1 2
•Attach the remaining bolt Ato the top panel 4on the center hole.
•Assemble panel 4to the Upper left divider 6as shown and as
explained in page 4.
•Secure panel 4to structures 1and 2with screws D from underneath.
•Attach the metal disk 19C from the Spring kit 19 to the doors 16 and
17 with the screws 19D.
•Attach the Hinges 18 to the doors with screws F.
4
16
19C
STEP 14
Hardware:
AM6x45
Bolt
1
Pcs
D
M6x30
4
Pcs
STEP 15
Hardware:
F
M6x45
8
Pcs
18 2
Pcs
19
C
19
D
4
2
1
A
16
19C19C
17
19C 19D
19D
17
18
F
18
F
16
D
6

P. 1 3 RTA-482BC P. 1 3
•With the help of another person, install the Door 16 to the Lower left
panel 11 by attaching the Hinges 18 with screws Fonly on the oval
holes.
•Install the Door 17 to the Lower right panel 12 by attaching the Hinges
18 with screws Fonly on the oval holes.
STEP 16
Hardware:
F
ST4x16
16
Pcs
11 17
16
11
17
16
12
18
F
•If the doors are not closing properly or need alignment,
proceed to do the following adjustments:
A. Loosen these screws to adjust the height of the door.
B. Loosen this screw to adjust the depth of the door.
C. Turn this screw either way to adjust the door side-to-
side.
•After the adjustments are done, you can secure the
hinges to the side panels with the rest of screws Fon
the round holes.

P. 1 4 RTA-482BC P. 1 4
•Once you have selected the place against the wall where the unit will
go, with the help of another person bring the unit closer to the wall,
and calculate the 2 points on the wall where the anchor device Gwill
be installed, which should be no more than 1 inch away from the top
corners of the unit.
•Mark the points on the wall and with the appropriate tools make a hole
to install the anchors from the kit G.
•Attach the bracketsfrom the kit Gto the anchors with the screws that
come in the same kit.
•Use the tie downs from the kit Gto secure the frame to the brackets.
Securing the unit to the wall prevents accidents from tip-overs.
•Cover all the cam locks on panels 6and 9with stickers 20.
(Wall)
20
STEP 17
Hardware:
G1
Set
20 2
Pcs
(Wall)
Hardware:
G
G
(Wall)
6
6
9
9
20

ALL DONE!
Give yourself a nice pat on the back. You did a
great job!
P. 1 5 RTA-482BC P. 1 5
IT IS EXTREMELY IMPORTANT
THAT YOU READ ALL THE
WARNINGS ON THE NEXT PAGE!

TIP-OVER WARNING!
P. 1 6 RTA-482BC P. 1 6
Please keep your children and yourself safe. Tip-over accidents can
result in serious injuries or be fatal to small children.
PREVENT TIP-OVER ACCIDENTS BY FOLLOWING THESE RECOMMENDATIONS:
1. Secure the unit by anchoring it to the wall. The anchoring device has
been provided with the unit, and must be installed by following the
instructions shown in PAGE 14 of this manual.
2. Once the unit has been anchored, load the heavier objects onto the
lower shelves, and the lighter objects to the upper shelves.
3. Never reach the objects on the upper shelves by climbing on the lower
shelves.
4. Do not let children climb on the shelves to reach objects located on the
upper shelves, an adult should always grab the objects for them.
5. Do not let children play on any empty shelf or inside the lower cabinet.

WEIGHT LIMITS
P. 1 7 RTA-482BC P. 1 7
22 Lbs.
(10 Kg)
•For the safety of small children and your own, secure the unit to the wall with the anchor
device provided.
•Do not exceed the indicated weight limits.
•Always load the heavy objects on the lower shelves.
•Do not allow small children to climb or play on the shelves or inside the lower cabinet.
•Do not allow small children to reach objects located on the upper shelves by themselves.
•Do not climb on the lower shelves to reach objects on the upper shelves.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and
water, then dry with a clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as
underneath the tabletop.
•If you have to move the unit, detach it from the anchoring device first.
•Before moving the unit, make sure to secure or remove any object that is heavy or might
fall off. It is recommended to remove all objects from the top shelves.
•Have a second adult person help you move the unit, and please be very careful when
doing so as to avoid tipping-over accidents.
•If you lift the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid damage
in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts
might be available to you at no charge. Please refer to the last pages on this manual.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes
liability for damages or consequences due to accidents, incorrect assembly, negligence,
improper use, modifications, or not heeding the above warnings.
CARE, MAINTENANCE AND SAFETY WARNINGS:
66 Lbs.
(30 Kg)
22 Lbs.
(10 Kg)
22 Lbs.
(10 Kg) 22 Lbs.
(10 Kg)
22 Lbs.
(10 Kg)
66 Lbs.
(30 Kg)

RTA Products, LLC warrants to the Original Purchaser who acquired anew product from
RTA Products or its authorized resellers that this product will be free from defects in its
workmanship and materials, under normal use and service conditions, as described
herein."Defects" as used in this warranty, is defined as any imperfections that impair the
use of the furniture or product.RTA Products LLC will replace any defective part, at its
discretion, and without charge to the original purchaser other than the freight from the end
consumer to RTA Products.
Replacement parts can only be supplied if parts are available.Items out of production
may be unavailable.This warranty will be effective for the applicable time period
beginning the date of purchase on your original sales receipt.RTA product’s obligation
under this warranty is limited to repairing or replacing products or parts as provided
herein.This product has been designed for and is intended for office and home-office use
only.This warranty is Original Purchaser’s sole remedy for product defects, and this
warranty does not extend to any product, or damage to any product, caused by or
attributed to abuse or misuse, products used for commercial or rental purposes, use
modifications of, or attachments to the product, and products or parts not used,
maintained, or extended hereunder is in lieu of any and all other warranties, express or
implied, including without limitations any implied warranty or merchantability or of fitness
for aparticular purpose.Please note, all desks made with PVC Laminate surface should
not be exposed to direct sunlight, as it may damage the material.Damage of this nature
is not covered under this warranty.
RTA Products will not be responsible for indirect, special, incidental or consequential
damages.This warranty is limited to merchandise purchased in the Continental United
States.Some States do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.This warranty
gives you specific legal rights.You may also have other rights that may vary from state to
state.
RTA Products will advise you of the procedure to follow in making warranty claims.The
following are the procedures for warranty claims:
a. Call us Monday –Friday, from 9am-5pm (Eastern Time) at [phone] to explain
the defect and give your name, address and phone number.Please have ready the
model number of our product, date and place of purchase.You can also write to us by
e-mail to [e-mail] and include the same information.
b. If we determine that replacement will remedy the situation, and in order to determine
the extent or the cause of the defect, purchaser will need to send the part in question
at purchaser’s expense.Once we receive the part, we will examine it and determine
whether the claim is valid (or not), and then proceed to send the replacement.We will
ship the replacement at our expense.
P. 1 8 RTA-482BC P. 1 8
TECHNI MOBILI WARRANTY
DESKS/LAPTOP CARTS/FILE CABINETS: LIMITED 5-YEAR WARRANTY
TV Stand/Entertainment Center: 2 YEAR WARRANTY
