TECHNICAL & SERVICE MANUAL
SPLIT SYSTEM AIR CONDITIONER
CA250X5TAA - GR250X5TAA
CA250X5TAA - GR250X7TAA
CA360X5TAA - GR360X7TAA
CA480X5TAA - GR480X7TAA
0.8180.112.1 05/01

−
2
−
Table of Contents
1.SPECIFICATIONS…………………………………………………………………………… 3
1-1 Unit Specifications…………………………………………………………………….. 3
1-2 Major Component Specifications……………………………………………………. 7
(A) Indoor Unit……………………………………………………………………….... 7
(B) Outdoor Unit………………………………………………………………………. 9
1-3 Other Component Specifications……………………………………………………. 12
(A) Indoor Unit……………………………………………………………………….... 12
(B) Outdoor Unit………………………………………………………………………. 13
1-4 Dimensional Data……………………………………………………………………... 14
(A) Indoor Unit……………………………………………………………………….... 14
(B) Outdoor Unit………………………………………………………………………. 16
1-5 Refrigerant Flow Diagram……………………………………………………………. 18
1-6 Operating Range……………………………………………………………………… 20
1-7 Cooling Capacity………………………………………………………………………. 21
1-8 Noise Criterion Curves……………………………………………………………….. 25
1-9 Air Throw Distance Chart…………………………………………………………….. 27
2. PROCESSES AND FUNCTIONS……………………………………………………….… 28
2-1 Room Temperature Control………………………………………………………….. 28
2-2 Freeze Prevention (Cooling)……………………………………………………….… 29
2-3 Drain Pump Control…………………………………………………………………… 29
2-4 Outdoor Fan Control………………………………………………………………….. 30
3. ELECTRICAL DATA………………………………………………………………………... 31
3-1 Electrical Characteristics……………………………………………………………... 31
3-2 Electric Wiring Diagrams / Schematic Diagrams…………………………………... 33
(A) Indoor Unit……………………………………………………………………….... 33
(B) Outdoor Unit………………………………………………………………………. 35
4. SERVICE PROCEDURES………………………………………………………………….. 43
4-1 Troubleshooting……………………………………………………………………….. 43
4-2 A Sensor is Defective…………………………………………………………………. 54
4-3 Operation of Major Electrical parts………………………………………………….. 54
4-4 Checking the Electrical Components……………………………………………….. 55

– 3–
1.SPECIFICATIONS
MODEL No. Indoor Unit CA250X5TAA
Outdoor Unit GR250X5TAA
POWER SOURCE 220 - 230 - 240 V / 1 Phase / 50 Hz
PERFORMANCE Cooling
Capacity kW 7.3
BTU / h 25,000
Air circulation (Hi/Me/Lo) m3 / h1,140/1,020/840
Moisture removal(High) Liters/ h3.6
ELECTRICAL RATINGS
Voltage rating V 220230240
Available voltage range V 198 - 264
Running amperes* A14.5 14.6 14.7
Max. running amperes** A20.2 19.6 19.4
Power input kW 3.01 3.07 3.16
Power factor %94.4 91.4 89.6
C.O.P W / W 2.43 2.38 2.31
Max. starting amperes A 69 72 75
FEATURES
Controls Microprocessor
Timer ON/OFF 24-hours & Program
Fan speeds Indoor/Outdoor 3 and Automatic control/ 2 (Auto)
Airflow direction (Indoor) Automatic (Remote control)
Air filter Washable, easy access
Remote controller (Accessory) RCS-5PN3E
Refrigerant control Capillary tube
Drain pump (drain connection) Max. head 25cm above drain connection (25A,OD32mm)
Compressor Rotary
Operation sound Indoor - Hi/Me/Lo dB - A 37 / 35 / 31
Outdoor - Hi dB - A 53
REFRIGERANT TUBING
Limit of tubing length m (ft.) 40 (131)
Limit of tubing length at shipment m (ft.) 15 (49)
Limit of elevation difference m (ft.) Outdoor unit is higher than indoor unit: 40 (131)
between the two units Outdoor unit is lower than indoor unit: 25 (82)
Refrigerant tube Narrow tube mm (in) 6.35 (1 / 4)
outer diameter Wide tube mm (in) 15.88 (5 / 8)
Refrigerant amount at shipment kg R22 - 2.4
DIMENSIONS & WEIGHT Indoor unit Outdoor unit
Unit dimensions Height mm (in) 328(12-29/32) 735(28-30/32)
Width mm (in) 860(33-27/32) 940(37)
Depth mm (in) 860(33-27/32) 340(13-12/32)
Package dimensions Height mm (in) 410(16-5/32) 826(32-17/32)
Width mm (in) 988(38-29/32) 1,016(40)
Depth mm (in) 988(38-29/32) 416(16-12/32)
Net weight kg (lb) 30(66) 68(150)
Shipping weight kg (lb) 47(104) 74(163)
Shipping volume m
3
(Cu. ft.) 0.4(14.1) 0.349(12.3)
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Cooling :
Rating conditions(*) :Indoor air temperature 27 °C DB / 19 °C WB, Outdoor air temperature 35 °C DB
1-1 Unit Specifications

– 4–
1.SPECIFICATIONS
MODEL No. Indoor Unit CA250X5TAA
Outdoor Unit GR250X7TAA
POWER SOURCE 380 - 400 - 415 V / 3N / 50 Hz
PERFORMANCE Cooling
Capacity kW 7.3
BTU / h 25,000
Air circulation (Hi/Me/Lo) m3 / h1,140/1,020/840
Moisture removal(High) Liters/ h3.6
ELECTRICAL RATINGS
Voltage rating V 380400415
Available voltage range V 342- 456
Running amperes* A 4.74.74.6
Max. running amperes** A 65.85.7
Power input kW 2.76 2.82.81
Power factor %89.2 86 85
C.O.P W / W 2.64 2.61 2.6
Max. starting amperes A 27 29 30
FEATURES
Controls Microprocessor
Timer ON/OFF 24-hours & Program
Fan speeds Indoor/Outdoor 3 and Automatic control/ 2 (Auto)
Airflow direction (Indoor) Automatic (Remote control)
Air filter Washable, easy access
Remote controller (Accessory) RCS-5PN3E
Refrigerant control Capillary tube
Drain pump (drain connection) Max. head 25cm above drain connection (25A,OD32mm)
Compressor Rotary
Operation sound Indoor - Hi/Me/Lo dB - A 37 / 35 / 31
Outdoor - Hi dB - A 53
REFRIGERANT TUBING
Limit of tubing length m (ft.) 40 (131)
Limit of tubing length at shipment m (ft.) 15 (49)
Limit of elevation difference m (ft.) Outdoor unit is higher than indoor unit: 40 (131)
between the two units Outdoor unit is lower than indoor unit: 25 (82)
Refrigerant tube Narrow tube mm (in) 6.35 (1 / 4)
outer diameter Wide tube mm (in) 15.88 (5 / 8)
Refrigerant amount at shipment kg R22 - 2.4
DIMENSIONS & WEIGHT Indoor unit Outdoor unit
Unit dimensions Height mm (in) 328(12-29/32) 735(28-30/32)
Width mm (in) 860(33-27/32) 940(37)
Depth mm (in) 860(33-27/32) 340(13-12/32)
Package dimensions Height mm (in) 410(16-5/32) 826(32-17/32)
Width mm (in) 988(38-29/32) 1,016(40)
Depth mm (in) 988(38-29/32) 416(16-12/32)
Net weight kg (lb) 30(66) 68(150)
Shipping weight kg (lb) 47(104) 74(163)
Shipping volume m3(Cu. ft.) 0.4(14.1) 0.349(12.3)
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Cooling :
Rating conditions(*) :Indoor air temperature 27 °C DB / 19 °C WB, Outdoor air temperature 35 °C DB
1-1 Unit Specifications

– 5–
1.SPECIFICATIONS
MODEL No. Indoor Unit CA360X5TAA
Outdoor Unit GR360X7TAA
POWER SOURCE 380 - 400 - 415 V / 3N / 50 Hz
PERFORMANCE Cooling
Capacity kW 10.6
BTU / h 36,000
Air circulation (Hi/Me/Lo) m3 / h1,920/1,680/1,320
Moisture removal(High) Liters/ h4.7
ELECTRICAL RATINGS
Voltage rating V 380400415
Available voltage range V 342 - 456
Running amperes* A 5.25.15.1
Max. running amperes** A 6.76.56.4
Power input kW 3.07 3.11 3.15
Power factor %89.7 88 85.9
C.O.P W / W 3.45 3.41 3.37
Max. starting amperes A 31 33 34
FEATURES
Controls Microprocessor
Timer ON/OFF 24-hours & Program
Fan speeds Indoor/Outdoor 3 and Automatic control/ 2 (Auto)
Airflow direction (Indoor) Automatic (Remote control)
Air filter Washable, easy access
Remote controller (Accessory) RCS-5PN3E
Refrigerant control Capillary tube
Drain pump (drain connection) Max. head 25cm above drain connection (25A,OD32mm)
Compressor Rotary
Operation sound Indoor - Hi/Me/Lo dB - A 43 / 40 / 36
Outdoor - Hi dB - A 54
REFRIGERANT TUBING
Limit of tubing length m (ft.) 50 (164)
Limit of tubing length at shipment m (ft.) 15 (49)
Limit of elevation difference m (ft.) Outdoor unit is higher than indoor unit: 50 (164)
between the two units Outdoor unit is lower than indoor unit: 30 (98)
Refrigerant tube Narrow tube mm (in) 9.52 (3 / 8)
outer diameter Wide tube mm (in) 19.05 (3 / 4)
Refrigerant amount at shipment kg R22 - 4.0
DIMENSIONS & WEIGHT Indoor unit Outdoor unit
Unit dimensions Height mm (in) 358(14-3/32) 1,235(48-20/32)
Width mm (in) 1,150(45-9/32) 940(37)
Depth mm (in) 860(33-27/32) 340(13-12/32)
Package dimensions Height mm (in) 440(17-10/32) 1,326(52-7/32)
Width mm (in) 1,278(50-10/32) 1,016(40)
Depth mm (in) 988(38-29/32) 416(16-12/32)
Net weight kg (lb) 38(84) 94(207)
Shipping weight kg (lb) 62(137) 101(223)
Shipping volume m
3
(Cu. ft.) 0.556(19.6) 0.56(19.8)
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Cooling :
Rating conditions(*) :Indoor air temperature 27 °C DB / 19 °C WB, Outdoor air temperature 35 °C DB
1-1 Unit Specifications

– 6–
1.SPECIFICATIONS
MODEL No. Indoor Unit CA480X5TAA
Outdoor Unit GR480X7TAA
POWER SOURCE 380 - 400 - 415 V / 3N / 50 Hz
PERFORMANCE Cooling
Capacity kW 14
BTU / h 47,800
Air circulation (Hi/Me/Lo) m3 / h1,920/1,680/1,320
Moisture removal(High) Liters/ h7.4
ELECTRICAL RATINGS
Voltage rating V 380400415
Available voltage range V 342 - 456
Running amperes* A 8.48.58.9
Max. running amperes** A10.3 9.99.5
Power input kW 4.74.76 4.86
Power factor %85 80.8 76
C.O.P W / W 2.98 2.94 2.88
Max. starting amperes A 71 73 75
FEATURES
Controls Microprocessor
Timer ON/OFF 24-hours & Program
Fan speeds Indoor/Outdoor 3 and Automatic control/ 2 (Auto)
Airflow direction (Indoor) Automatic (Remote control)
Air filter Washable, easy access
Remote controller (Accessory) RCS-5PN3E
Refrigerant control Capillary tube
Drain pump (drain connection) Max. head 25cm above drain connection (25A,OD32mm)
Compressor Rotary
Operation sound Indoor - Hi/Me/Lo dB - A 43 / 40 / 36
Outdoor - Hi dB - A 56
REFRIGERANT TUBING
Limit of tubing length m (ft.) 50 (164)
Limit of tubing length at shipment m (ft.) 15 (49)
Limit of elevation difference m (ft.) Outdoor unit is higher than indoor unit: 50 (164)
between the two units Outdoor unit is lower than indoor unit: 30 (98)
Refrigerant tube Narrow tube mm (in) 9.52 (3 / 8)
outer diameter Wide tube mm (in) 19.05 (3 / 4)
Refrigerant amount at shipment kg R22 - 4.3
DIMENSIONS & WEIGHT Indoor unit Outdoor unit
Unit dimensions Height mm (in) 358(14-3/32) 1,235(48-20/32)
Width mm (in) 1,150(45-9/32) 940(37)
Depth mm (in) 860(33-27/32) 340(13-12/32)
Package dimensions Height mm (in) 440(17-10/32) 1,326(52-7/32)
Width mm (in) 1,278(50-10/32) 1,016(40)
Depth mm (in) 988(38-29/32) 416(16-12/32)
Net weight kg (lb) 38(84) 106(234)
Shipping weight kg (lb) 62(137) 113(249)
Shipping volume m3(Cu. ft.) 0.556(19.6) 0.56(19.8)
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Cooling :
Rating conditions(*) :Indoor air temperature 27 °C DB / 19 °C WB, Outdoor air temperature 35 °C DB
1-1 Unit Specifications

– 7–
1.SPECIFICATIONS
(A)Indoor Unit
MODEL No.CA250X5TAA
Source 220 - 230 - 240 V / 1 phase / 50 Hz
Remote controller (Accessory) RCS- 5PN3E
Controller P. C. B Ass'y CR - X363GS
Switch Ass'y SW - X363GS
Fan (Number … diameter) mm Turbo (1… ø 490)
Fan motor
Model … Nominal output WSFG6X - 41A5P … 40 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole … r.p.m. (230 V, High) rpm 6 … 470
Coil resistance ΩBRN–WHT :114.0 ,ORG–YEL :66.4
(Ambient temperature 20 °C) WHT–VLT :23.9 ,WHT–PNK : 77.4
VLT –ORG :12.4 ,YEL–BLK : 82.1
Safety device
Operating temperature Open°C130±8 °C
Close°C79±15 °C
Run capacitor VAC , µF440 V , 4 µF
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … fin pitch mm 2 … 1.7
Face area m20.295
Panel
Model No. PNR - X253GS
Indicator Lamp Ass'y IND - X253GS
Dew proof heater 240 V , 26 W
Auto louver motor M2LB24ZA12
Auto louver motor … Rated V, W, rpm. 240 VAC , 3 W , 2.5 rpm
Coil resistance (at 25 °C) Ω15,620 Ω±15 %
1-2 Major Component Specifications

– 8–
1.SPECIFICATIONS
(A) Indoor Unit
MODEL No.CA360X5TAA CA480X5TAA
Source 220 - 230 - 240 V / 1 phase / 50 Hz
Remote controller (Accessory) RCS - 5PN3E
Controller P. C. B Ass'y CR - X363GS
Switch ass'y SW - X363GS
Fan (Number … diameter) mm Turbo (1… ø 490)
Fan motor
Model … Nominal output WSFG6X - 61A3P … 60 W
Source 220 - 230 - 240 V / 1 phase / 50 Hz
No. of pole … r.p.m. (230 V, High) rpm 6 … 530
Coil resistance ΩBRN –WHT :71.1 ,ORG–YEL :22.7
(Ambient temperature 20 °C) WHT–VLT :8.7 ,VLT –PNK :43.2
VLT –ORG :13.3 ,YEL–BLK :54.32
Safety device
Operating temperature Open°C130±8 °C
Close°C79±15 °C
Run capacitor VAC , µF440 V , 6 µF
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … fin pitch mm 2 … 1.7
Face area m20.479
Panel
Model No. PNR - X483GS
Indicator Lamp ass'y IND - X483GS
Dew proof heater 240 V , 31 W
Auto louver motor M2LB24ZA12
Auto louver motor … Rated V, W, rpm 240 VAC , 3 W , 2.5 rpm
Coil resistance (at 25 °C) Ω15,620Ω±15 %

– 9–
1.SPECIFICATIONS
(B) Outdoor Unit
MODEL No. GR250X5TAA
Source 220 - 230 - 240 V / 1 phase / 50 Hz
Compressor Rotary (Hermetic)
Model ... Code No. C -R221H5V
Nominal output W2,200
Compressor oil cc 1,350
Coil resistance (at 25°C) Ω C - R : 0.76, C - S :2.76
Refrigerant amount at shipment kg R22 - 2.4
Safety device Internal/OL - D24
Operating temperature Open °C 160±5/150±10
Close °C 87±9/63±10
Run capacitor V,µF400V, 40
High pressure switch ACB -1TB07
Set pressure OFF kg/cm230
ON kg/cm224 ±2.0
Fan (Number…diameter (mm)) Propeller (1…ø 460)
Fan motor
Model…Nominal output WKFC6S - 91C5P…100 W
No. of pole ... rpm (230V, High) rpm 6...868
Coil resistance ΩBRN–WHT :61.0
(Ambient temperature 20°C) YEL–PNK :17.7
WHT–YEL :64.3
Safety device Internal type
Operating temperature Open °C130±8
Close °C79±15
Run capacitor VAC, µF440 V, 5 µF
Heat exchanger
Coil Aluminium plate fin / Copper tube
Rows ... fin pitch mm 2...2.0
Face area m20.616
+ 2.0
+ 0.5
1-2 Major Component Specifications

– 10–
1.SPECIFICATIONS
(B) Outdoor Unit
MODEL No.GR250X7TAA
Source 380 - 400 - 415 V / 3 phase / 50 Hz
Compressor Rotary (Hermetic)
Model … Code No. C - R224H8S
Nominal output W2,200
Compressor oil CC 1,350
Coil resistance (at 25°C) ΩR - S:5.54,S - T:5.54,T - R:5.54
Refrigerant amount at shipment kg R22 - 2.4
Safety device Internal type External type
Overload relay models —FMSA - 1SZ607A
Operating temperature Open °C120±5—
Close °C98±11 —
Operating ampere (at 25°C) A—6A, 110 %
Run capacitor V, µF—
High pressure switch ACB - 1TB07
Set pressure OFFkg/cm230
ON kg/cm224 ±2.0
Fan Number … diameter mm Propeller (1 … ø 460)
Fan motor
Model … Nominal output WKFC6S - 91C5P … 100 W
No. of pole … rpm (230 V, High) rpm 6 … 868
Coil resistance ΩBRN–WHT :61.0 ,YEL–PNK :17.7
(Ambient temperature 20°C) WHT–YEL :64.3
Safety device
Operating temperature Open °C130±8
Close °C79±15
Run capacitor VAC, µF440V, 5 µF
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … fin pitch mm 2 … 2.0
Face area m20.616
+ 2.0
+ 0.5

– 11–
1.SPECIFICATIONS
(B) Outdoor Unit
MODEL No. GR360X7TAA GR480X7TAA
Source 380-400- 415 V / 3 phase / 50 Hz
Compressor Rotary (Hermetic) Scroll (Hermetic)
Model...Code No. C - R243H8T ZR61KC - TFD - 522
Nominal output W2,400 3,750
Compressor oil cc 1,350 2,130
Coil resistance ΩT – R:5.54,R – S:5.54 T1 – T2:2.72,T2 – T3:2.72
(Ambient temperature 25°C ) S – T:5.54 T3 – T1:2.72
Refrigerant amount at shipment kg R 22 - 4.0 R 22 - 4.3
Safety devices Internal type External type Internal type External type
Overload relay models — FMSA -1SZ607A — FMSA -1SZ607A
Operating temperature Open °C120 ±5— 130—
Close °C98 ±11 —61 —
Operating ampere (at 25°C) A—6 A, 110 % —10 A, 110 %
Run capacitor V, µF—
High pressure switch ACB - 1TB07
Set pressure OFF kg/cm230
ON kg/cm224 ±2.0
Fan (Number...diameter) mm Propeller (2...ø460)
Fan motor
Model...Nominal output WKFC6S - 91C5PX2...100WX2
No. of pole...rpm (230 V, High) rpm 6...871
Coil resistance ΩBRN–WHT :61.0
(Ambient temperature 20°C) WHT–YEL :64.3
YEL–PNK :17.7
Safety device
Operating temperature Open °C130±8
Close °C79±15
Run capacitor VAC, µF440V,5 µF/440 V,5 µF
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows...fin pitch mm22...2.0
Face area m21.08
+ 2.0
+ 0.5

– 12 –
1
1-3 Other Component Specifications
(A) Indoor Unit
CA250X5TAA CA360X5TAA CA480X5TAA
Power Transformer ATR – I75A
Rated Primary AC 230 V, 50 Hz
Secondary 10.6 V, 0.93 A
Capacity 9.85 VAC
Coil resistance WHT - WHT : 96.5 , BRN - BRN : 0.8 (at 20 °C)
Thermistor cut off temperature °C 150
Thermistor (Coil sensor) PBC - 41E - S26 PBC - 41E - S36
Coil resistance k –10 °C : 23.7 , 5 °C : 12.1
–5 °C : 18.8 , 10 °C : 9.7
0 °C : 15.0 , 15 °C : 8.0
Thermistor (Room or coil sensor) KTEC - 35 - S6
Coil resistance k 0 °C : 16.5 , 40 °C : 2.7
5 °C : 12.8 , 45 °C : 2.2
10 °C : 10.0 , 50 °C : 1.8
20 °C : 6.3 , 55 °C : 1.5
30 °C : 4.0 ,
Drain pump WP20SL - 21
Rated AC 230 V, 14.7 W
Float switch FS - 0218 - 103
Rated (Contact rated) AC 230 V, 50 W
Switch Ass'y SW - X363GS
Indicator Lamp Ass' IND - X253GS
Synchronized Motor M2LB24ZA12
1.SPECIFICATIONS

– 13 –
1
(B) Outdoor Unit
MODEL No GR250X7TAA GR360X7TAA GR480X7TAA
Compressor Motor Magnetic Contactor FMSA - 1SZ607A
Coil rated AC 220 - 240 V, 50 Hz
Coil resistance (at 20°C) 828 (at 20 °C)
Contact rated V, A AC 440 V, 13 A
Thermal Relay
Contact rated V, A AC 220 V, 2.25 A
Rated ampere (90 / 120%) A 6 A, 110 % 6 A, 110 % 10 A, 110 %
Auxiliary relay HH62S / 085
Coil rated A AC 240 V, 50 Hz
Coil resistance kW 15.5 ± 20 %
Contact rated A AC 250 V, 10A
Relay RDR - S400
Rated voltage V AC 380 - 415 V, 3 phase, 50 Hz
Resistance (at 20°C) k R - T : 76.3
Thermostat (Coil sensor) YTB - S377
Operating Temperature °C 27.5 ± 1.5 OFF (High)
25.5 ON (Low)
Contact ratedAC 250 V, 1 A
MODEL No GR250X5TAA
Compressor Motor Mgnetic ContactorFMCA - 1SZ607
Coil rated AC 220 - 240 V, 50 Hz
Coil resistance (at 20°C) 828 ± 15 %
Contact rated V, A AC 440 V, 13 A
Auxiliary relay HH62S / 085
Coil rated AC 240 V, 50 Hz
Coil resistance (at 20°C) k 17.2
Contact rated V, A AC 220 V, 5 A
Thermostat (Coil sensor) YTB - S377
Operating Temperature °C 27.5 ± 1.5 OFF (High)
25.5 ON (Low)
Contact rated A AC 250 V, 1 A
+ 1.5
– 0.5
+ 1.5
– 0.5
1.SPECIFICATIONS

– 14–
(A)Indoor Unit:CA250X5TAA
860
100
760
500
500
298 30
205
125
12
12
48
860
820 (Ceiling opening)
820 (Ceiling opening)
61
730 (Suspention bolt pitch)
Panel center
590 (Suspention bolt pitch)
345 35
Air intake grille
Air outlet
Refrigerant liquid line (ø 6.35)
Refrigerant gas line (ø 15.88)
Drain connection
Power supply entry
For discharge duct
Suspention bolt mounting
342 15
X-view
0410_X_S
207
100
205 61
760
50 150
255
207
8
8
1.SPECIFICATIONS
1-4Dimensional Data

– 15–
(A)Indoor Unit:CA360X5TAA, CA480X5TAA
1150
1050
790
500
328 30
218
125
860
1110 (Ceiling opening)
820 (Ceiling opening)
61
1020 (Suspention bolt pitch)
Panel center
590 (Suspention bolt pitch)
490 40
Air intake grille
Air outlet
Refrigerant liquid line (ø9.52)
(SPW-X303G56, SPW-X303GS56 ø6.35)
Refrigerant gas line (ø19.05)
(SPW-X303G56, SPW-X303GS56 ø15.88)
Drain connection
Power supply entry
For discharge duct
Suspension bolt mounting
X-view
0603_X_S
218
14535
210 60
760
70 165
285
210
100 100
8
8
342 15
12
48
12
1.SPECIFICATIONS

– 16–
(B)Outdoor Unit :GR250X5TAA
GR250X7TAA
400 380
20
340
20
110660170
735
280
307
940
Dimension : mm
Hole for anchor bolt (4-ø13)
Refrigerant tube joint (narrow tube)
Flare connection 1/4 in (6.35 mm)
Refrigerant tube joint (wide tube)
Flare connection 5/8 in (15.88 mm)
Refrigerant tubing inlet
Power supply inlet
0411_C_S
1.SPECIFICATIONS
1-4Dimensional Data

– 17–
(B)Outdoor Unit :GR360X7TAA
GR480X7TAA
400 380
20
340
20
110660170
1235
580
607
940
Dimension : mm
Hole for anchor bolt (4-ø13)
Refrigerant tube joint (narrow tube)
Flare connection 3/8 in (9.52 mm)
Refrigerant tube joint (wide tube)
Flare connection 3/4 in (19.05 mm)
Refrigerant tubing inlet
Power supply inlet 0412_C_S
1.SPECIFICATIONS

– 18 –
Indoor Unit :CA250X5TAA
Outdoor Unit:GR250X5TAA
GR250X7TAA
Indoor Unit :CA360X5TAA Outdoor Unit:GR360X7TAA
O. D.
15.88 mm
(5/8")
Evaporator
Capillary
O. D.
6.35 mm
(1/4")
Condenser Compressor
Accumulator
Capillary
Sub-condenser
Wide tube
service valve
Narrow tube
service valve
0664_X_S
Strainer
Strainer
HP
High
pressure
switch
O. D.
19.05 mm
(3/4")
Evaporator
Capillary
O. D.
9.52 mm
(3/8")
Condenser
HP
High pressure switch
Compressor
Accumulator
Capillary
Sub-condenser
Wide tube
service valve
0605_X_S
Narrow tube
service valveStrainer
Strainer
1.SPECIFICATIONS
1-5Refrigerant Flow Diagram

– 19 –
Indoor Unit :CA480X5TAA
Outdoor Unit:GR480X7TAA
Insulation of Regrigerant Tubing
IMPORTANT
To prevent heat loss and wet floors due to
dripping of condensation, both the wide and
narrow tubes must be well insulated with a
proper insulation material. The thickness of
the insulation should be a min. 8 mm.
After a tube has been
insulated, never try to bend
it into a narrow curve
because it can casue the
tube to break or crack.
Insulator
Thickness:
Min. 8mm
Narrow tube
Wide tube
0133_C_I
O. D.
19.05 mm
(3/4")
Evaporator
Capillary
O. D.
9.52 mm
(3/8")
Condenser
HP
High pressure switch
Compressor
Accumulator
Sub-condenser
Wide tube
service valve
0606_X_S
Narrow tube
service valveStrainer
1.SPECIFICATIONS

– 20–
Temperature Indoor air intake temp. Outdoor air intake temp.
Maximum 35°C DB / 22.5°C WB 52°C DB
Minimum 18°C DB / 14°C WB 19°C DB
1.SPECIFICATIONS
1-6Operating Range
