Technibel GRV72C5TA Series Manual

TECHNICAL DATA
& SERVICE MANUAL
OUTDOOR UNIT: GRV72C5TA-
GRV92C5TA-
GRV122C5TA-
SPLIT SYSTEM AIR CONDITIONER
0.8180.273.0 05/2002
Model No. Product Code No.
GRV72C5TA- 387107047
GRV92C5TA- 387107048
GRV122C5TA- 387107049

IMPORTANT!
Please read before installation
This air conditioning system meets strict safety and operating
standards.
For the installer or service person, it is important to install or
service the system so that it operates safely and efficiently.
For safe installation and trouble-free operation, you must:
• Carefully read this instruction booklet before beginning.
• Follow each installation or repair step exactly as shown.
• Observe all local, state and national electrical codes.
• Pay close attention to all warning and caution notices given in
this manual.
•The unit must be supplied with a dedicated electrical line.
This symbol refers to a hazard or unsafe practice which can result
in severe personal injury or death.
This symbol refers to a hazard or unsafe practice which can result
in personal injury or product or property damage.
If necessary, get help
These instructions are all you need for most installation sites and
maintenance conditions.
If you require help for a special problem, contact our sale/service
outlet or your certified dealer for additional instructions.
In case of improper installation
The manufacturer shall in no way be responsible for improper
installation or maintenance service, including failure to follow the
instructions in this document.
SPECIAL PRECAUTIONS
• During installation, connect before the refrigerant system and
then the wiring one; proceed in the reverse orden when removing
the units.
When wiring
ELECTRICAL SHOCK CAN CAUSE SEVERE
PERSONAL INJURY OR DEATH. ONLY A QUALIFIED,
EXPERIENCED ELECTRICIANS SHOULD ATTEMPT
TO WIRE THIS SYSTEM.
• Do not supply power to the unit until all wiring and tubing are
completed or reconnected and checked, to ensure the grounding.
• Highly dangerous electrical voltages are used in this system.
Carefully refer to the wiring diagram and these instructions when
wiring.
Improper connections and inadequate grounding can cause
accidental injury and death.
•Ground the unit following local electrical codes.
• The Yellow/Green wire cannot be used for any connection
different from the ground connection.
• Connect all wiring tightly. Loose wiring may cause overheating
at connection points and a possible fire hazard.
• Do not allow wiring to touch the refrigerant tubing, compressor,
or any moving parts of the fan.
• Do not use multi-core cable when wiring the power supply and
control lines. Use separate cables for each type of line.
When transporting
Be careful when picking up and moving the indoor and outdoor
units. Get a partner to help, and bend your knees when lifting to
reduce strain on your back. Sharp edges or thin aluminium fins on
the air conditioner can cut your fingers.
When installing...
... In a ceiling or wall
Make sure the ceiling/wall is strong enough to hold the unit-weight.
It may be necessary to build a strong wooden or metal frame to
provide added support.
... In a room
Properly insulate any tubing run inside a room to prevent
"sweating", which can cause dripping and water damage to walls
and floors.
... In moist or uneven locations
Use a raised concrete base to provide a solid level foundation for
the outdoor unit.
This prevents damage and abnormal vibrations.
... In area with strong winds
Securely anchor the outdoor unit down with bolts and a metal
frame. Provide a suitable air baffle.
... In a snowy area (for heat pump-type systems)
Install the outdoor unit on a raised platform that is higher than
drifting snow. Provide snow vents.
When connecting refrigerant tubing
• Keep all tubing runs as short as possible.
• Use the flare method for connecting tubing.
• Apply refrigerant lubricant to the matching surfaces of the flare
and union tubes before connecting them; screw by hand and
then tighten the nut with a torque wrench for a leak-free
connection.
• Check carefully for leaks before starting the test run.
NOTE:
Depending on the system type, liquid and gas lines may be either
narrow or wide. Therefore, to avoid confusion, the refrigerant
tubing for your particular model is specified as narrow tube for
liquid, wide tube for gas.
When servicing
• Turn the power OFF at the main power board before opening
the unit to check or repair electrical parts and wiring.
• Keep your fingers and clothing away from any moving parts.
• Clean up the site after the work, remembering to check that no
metal scraps or bits of wiring have been left inside the unit being
serviced.
• Ventilate the room during the installation or testng the refrigeration
system; make sure that, after the installation, no gas leaks are
present, because this could produce toxic gas and dangerous
if in contact with flames or heat-sources.
WARNING
CAUTION
WARNING
2

Pa
g
e
1. OPERATING RANGE 4
2. SPECIFICATIONS 5
2-1 Unit specifications 5
2-2 Major Component specifications 8
3. DIMENSIONAL DATA 11
4. REFRIGERANT FLOW DIAGRAM 12
5. PERFORMANCE DATA 13
5-1 Performance Charts 13
5-2 Cooling Capacity 16
6. ELECTRICAL DATA 19
6-1 Electrical characteristics 19
6-2 Electric Wiring Diagram 20
6-3 System Wiring Diagram 20
Table of Contents
3

1. OPERATING RANGE
Temperature Indoor Air Intake Temp. Outdoor Air Intake Temp.
Cooling Maximum
Minimum
43°C D.B.
19°C D.B.
32°C D.B. / 23°C W.B.
19°C D.B. / 14°C W.B.
4

2. SPECIFICATIONS
2-1 Unit Specifications
GRV72C5TA-
Power source
V
olta
g
e ratin
g
Performance * MCAV72C5TA
-
Capacity kW
BTU/h
Air circulation (High) m³/h
Moisture removal (High) Liters/h
Electrical Ratin
g
Available voltage range V
Running amperes A
Power input W
Power factor %
C.O.P. W/W
Compressor locked rotor amperes A
Features
Fan speed
Compressor
Refrigerant / Amount charged at shipment g
Refrigerant control
Operation Sound Hi dB-A
Refrigerant tubing connections
Max. allowable tubing length at shipment m
Refrigerant Narrow tube mm(in.)
tube diameter Wide tube mm(in.)
Dimensions & Wei
g
ht
Unit dimensions Height mm
Width mm
Depth mm
Package dimensions Height mm
Width mm
Depth mm
Weight Net kg
Shipping kg
Shipping volume m3
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Remarks:
Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
*For other INDOOR UNITS' MODELS, please refer to catalogue
92
2,8
17
57
1(Hi)
198 ~ 264
Cooling
3,20
1,90
6485
430
0,40
0,16
230 V
815
343
34
37
6,35 (1/4)
700
265
568
220 - 240 V ~ 50 H
z
Cooling
540
Rotary (Hermetic)
R407C / 730
9,52 (3/8)
Flare type
Capillary tub
e
7.5
680
5

GRV92C5TA-
Power source
V
olta
g
e ratin
g
Performance * MCAV92C5TA
-
Capacity kW
BTU/h
Air circulation (High) m³/h
Moisture removal (High) Liters/h
Electrical Ratin
g
Available voltage range V
Running amperes A
Power input W
Power factor %
C.O.P. W/W
Compressor locked rotor amperes A
Features
Fan speed
Compressor
Refrigerant / Amount charged at shipment g
Refrigerant control
Operation Sound Hi dB-A
Refrigerant tubing connections
Max. allowable tubing length at shipment m
Refrigerant Narrow tube mm(in.)
tube diameter Wide tube mm(in.)
Dimensions & Wei
g
ht
Unit dimensions Height mm
Width mm
Depth mm
Package dimensions Height mm
Width mm
Depth mm
Weight Net kg
Shipping kg
Shipping volume m3
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Remarks:
Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
*For other INDOOR UNITS' MODELS, please refer to catalogue
23
57
540
700
6,35 (1/4)
9,52 (3/8)
Flare type
7.5
1(Hi)
Rotary (Hermetic)
R407C / 800
Capillary tub
e
198 ~ 264
450
0,80
Cooling
4,40
990
98
2,6
36
39
0,16
265
568
815
343
8874
220 - 240 V ~ 50 H
z
230 V
Cooling
2,60
6

GRV122C5TA-
Power source
V
olta
g
e ratin
g
Performance * MCAV122C5TA
-
Capacity kW
BTU/h
Air circulation (High) m³/h
Moisture removal (High) Liters/h
Electrical Ratin
g
Available voltage range V
Running amperes A
Power input W
Power factor %
C.O.P. W/W
Compressor locked rotor amperes A
Features
Fan speed
Compressor
Refrigerant / Amount charged at shipment g
Refrigerant control
Operation Sound Hi dB-A
Refrigerant tubing connections
Max. allowable tubing length at shipment m
Refrigerant Narrow tube mm(in.)
tube diameter Wide tube mm(in.)
Dimensions & Wei
g
ht
Unit dimensions Height mm
Width mm
Depth mm
Package dimensions Height mm
Width mm
Depth mm
Weight Net kg
Shipping kg
Shipping volume m3
DATA SUBJECT TO CHANGE WITHOUT NOTICE
Remarks:
Rating conditions are:
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
*For other INDOOR UNITS' MODELS, please refer to catalogue
6,30
1380
95
2,5
11604
470
1,50
Cooling
6,35 (1/4)
12,7 (1/2)
540
700
0,16
198 ~ 264
815
343
37
40
Flare type
7.5
59
1(Hi)
220 - 240 V ~ 50 H
z
230 V
265
568
33
Cooling
3,40
Rotary (Hermetic)
R407C / 750
Capillary tub
e
7

2-2 Major Component Specifications
Outdoor Unit: GRV72C5TA-
Compressor
Type
Compressor model
Nominal output W
Compressor oil…Amount cc
Coil resistance (Ambient temp. 25°C) Ω
Overload relay
Safety devices Type
Operating Temp. Open °C
Close °C
Operating amp. (Ambient temp. 25°C)
Run capacitor µF
VAC
Fan & Fan Motor
Type
Q'ty ……. Dia.
Fan motor model…Q'ty
No. Of poles…rpm (230 V, High)
Nominal output W
Coil resistance (Ambient temp. 25 °C ) Ω
Safety devices Type
Operating temp. Off °C
On °C
Run capacitor µF
VAC
Heat Exch. Coil
Coil
Rows
Fin pitch mm
Face area m2
External Finish
DATA SUBJECT TO CHANGE WITHOUT NOTICE
WHT-YEL: 408,1
1…. Ø 370
115 ± 3
FV68S…350
C-R: 4,66
145 ± 5
69 ± 11
CS-7C115
6…832
25,05
BRN-WHT: 242,4
802 060 35B C-1RN60H5C
600
95 ± 5
17,5
450
//
A
crylic baked-on enamel finish
Thermal protector
130 ± 5
1
1,3
0,353
1,5
A
luminium plate fin / Copper tube
450
Rotary (Hermetic)
83 ± 15
C-S: 8,89
Propelle
r
UE6-21ST5P…1
External (OLR T)External (OLR A)
MRA 38072-3229
Trip in 6 to 16 s at 13
A
8

Outdoor Unit: GRV92C5TA-
Compressor
Type
Compressor model
Nominal output W
Compressor oil…Amount cc.
Coil resistance (Ambient temp. 25°C) Ω
Overload relay
Safety devices Type
Operating Temp. Open °C
Close °C
Run capacitor µF
VAC
Fan & Fan Motor
Type
Q'ty ……. Dia.
Fan motor model…Q'ty
No. Of poles…rpm (230 V, High)
Nominal output W
Coil resistance (Ambient temp. 25 °C ) Ω
Safety devices Type
Operating temp. Off °C
On °C
Run capacitor µF
VAC
Heat Exch. Coil
Coil
Rows
Fin pitch mm
Face area m2
External Finish
22,5
800
FV68S…470
C-R: 3,07
C-S: 7,97
External (OLR A) External (OLR T)
MRA 38066-3229 CS-7C115
145 ± 5
Rotary (Hermetic)
802 282 45G C-RN80H5
A
450
Propelle
r
1…. Ø 370
UE6-21ST5P…1
6…832
83 ± 15
1,5
450
25,05
BRN-WHT: 242,4
WHT-YEL: 408,1
Thermal protector
130 ± 5
A
crylic baked-on enamel finish
A
luminium plate fin / Copper tube
1
1,3
0,353
115 ± 3
69 ± 11 95 ± 5
Trip in 6 to 16 s at 18
A
//
9

Outdoor Unit: GRV122C5TA-
Compressor
Type
Compressor model
Nominal output W
Compressor oil…Amount cc.
Coil resistance (Ambient temp. 25°C) Ω
Overload relay
Safety devices Type
Operating Temp. Open °C
Close °C
Run capacitor µF
VAC
Fan & Fan Motor
Type
Q'ty ……. Dia.
Fan motor model…Q'ty
No. Of poles…rpm (230 V, High)
Nominal output W
Coil resistance (Ambient temp. 25 °C ) Ω
Safety devices Type
Operating temp. Open °C
Close °C
Run capacitor µF
VAC
Heat Exch. Coil
Coil
Rows
Fin pitch mm
Face area m2
External Finish
A
crylic baked-on enamel finish
A
luminium plate fin / Copper tube
1
1,3
0,353
145 ± 5 115 ± 3
69 ± 11 95 ± 5
External (OLR A) External (OLR T)
MRA 38065-3229 CS-7C115
1100
FV68S…520
C-R: 1,962
C-S: 5,38
Rotary (Hermetic)
802 356 45B C-RN110H5B
Propelle
r
1…. Ø 370
UE6-21ST5P…1
6…832
25,05
BRN-WHT: 242,4
WHT-YEL: 408,1
450
Thermal protector
130 ± 5
83 ± 15
1,5
Trip in 6 to 16 s at 21
A
//
25
450
10

3. DIMENSIONAL DATA
700
540
15
470
4 – ø12 holes 116
320
294
Air intake
Air discharge
25510
170
103 57
Narrow tube service valve
ø6.35 (1/4")
Wide tube service valve
ø9.52 (3/8")
ø12.7 (1/2") 7000/9000 BTU/h
12000 BTU/h
Unit : mm
11

4. REFRIGERANT FLOW DIAGRAM
Indoor Unit: Outdoor Unit: GRV72C5TA-
GRV92C5TA-
Indoor Unit: Outdoor Unit: GRV122C5TA-
Compressor
Accumulator
Wide tube
service
valve
Wide tube
O.D.
ø9.52 mm
(3/8 ")
Narrow
tube
service
valve
Narrow tube
O.D.
ø6.35 mm
(1/4")
Condenser
Capillary tube
Indoor Unit Outdoor Unit
Evaporator
Muffler
Compressor
Accumulator
Wide tube
service
valve
Wide tube
Narrow
tube
service
valve
Narrow tube
O.D.
ø6.35 mm
(1/4")
Condenser
Capillary tube
Indoor Unit Outdoor Unit
Evaporator
Muffler
O.D.
ø12.7 mm
(1/2 ")
Insulation of Refrigerant Tubing
Because capillary tubing is used in the outdoor unit, both the
wide and narrow tubes of this air conditioner become cold. To
prevent heat loss and wet floors due to dripping of
condensation, both tubes must be well insulated with a
proper insulation material. The thickness of the insulation
should be a min. 8 mm.
After a tube has been insulated,
never try to bend it into a narrow
curve because it can cause the tube
to break or crack.
IMPORTANT
CAUTION
Wide tube
Thickness:
Min. 8 mm
Insulation
Narrow tube
Thickness:
Min. 8 mm
12

5. PERFORMANCE DATA
5-1 Performance charts
GRV72C5TA-
 Coolin
g
Characteristics
Notes:
Points of Rating condition
Data referred to indoor unit MCAV72C5TA-
0,00
0,10
0,20
0,30
0,40
0,50
0,60
0,70
0,80
0,90
20 25 30 35 40 45
Outdoor inlet air D.B. (°C)
Low pressure at wide tube service valve MPa
1
2
3
4
5
6
20 25 30 35 40 45
Outdoor inlet air D.B. temp. (°C)
Operating current (A)
Indoor inlet air
D.B. (°C)
Indoor inlet air
D.B. (°C)
27
1
9
32
27
19
32
13

GRV92C5TA-
 Coolin
g
Characteristics
Notes:
Points of Rating condition
Data referred to indoor unit MCAV92C5TA-
0,00
0,10
0,20
0,30
0,40
0,50
0,60
0,70
0,80
0,90
20 25 30 35 40 45
Outdoor inlet air D.B. (°C)
Low pressure at wide tube service valve MPa
1
2
3
4
5
6
20 25 30 35 40 45
Outdoor inlet air D.B. temp. (°C)
Operating current (A)
Indoor inlet air
D.B.
(
°C
)
Indoor inlet air
D.B. (°C)
27
1
9
32
27
19
3
2
14

GRV122C5TA-
 Coolin
g
Characteristics
Notes:
Points of Rating condition
Data referred to indoor unit MCAV122C5TA-
1
2
3
4
5
6
7
8
9
10
20 25 30 35 40 45
Outdoor inlet air D.B. temp. (°C)
Operating current (A)
Indoor inlet air
D.B.
(
°C
)
27
1
9
3
2
0,00
0,10
0,20
0,30
0,40
0,50
0,60
0,70
0,80
0,90
20 25 30 35 40 45
Outdoor inlet air D.B. (°C)
Low pressure at wide tube service valve MPa
Indoor inlet air
D.B. (°C)
27
1
9
3
2
15

5-2 Cooling Capacity
OUTDOOR UNIT: GRV72C5TA-
220 - 240 V ~ 50 Hz
RATING CAPACITY 1,90 kW moisture removal 0,4 l/h
COMP. POWER INPUT 0,592 kW max comp input 0,672 kW
AIR FLOW RATE m³/h
EVAPORATOR
ENT.TEMP. °C
W.B. D.B. 20 25 30 35 40 43
TC 1,92 1,80 1,75 1,66 1,56 1,44
CM 0,49 0,51 0,53 0,56 0,58 0,60
21 SHC 1,33 1,23 1,21 1,17 1,12 1,06
23 SHC 1,51 1,40 1,37 1,33 1,28 1,22
15 25 SHC 1,67 1,56 1,53 1,49 1,44 1,38
27 SHC 1,84 1,72 1,69 1,65 1,56 1,44
29 SHC 1,92 1,80 1,75 1,66 1,56 1,44
31 SHC 1,92 1,80 1,75 1,66 1,56 1,44
TC 2,06 1,95 1,88 1,78 1,68 1,54
CM 0,51 0,53 0,55 0,57 0,60 0,62
21 SHC 1,15 1,08 1,05 1,01 0,96 0,90
23 SHC 1,32 1,24 1,21 1,16 1,12 1,06
17 25 SHC 1,49 1,41 1,37 1,33 1,28 1,21
27 SHC 1,67 1,57 1,52 1,48 1,43 1,38
29 SHC 1,84 1,73 1,69 1,64 1,59 1,53
31 SHC 2,01 1,90 1,84 1,78 1,68 1,54
TC 2,19 2,07 2,00 1,90 1,78 1,64
CM 0,53 0,55 0,57 0,59 0,61 0,64
21 SHC 0,96 0,90 0,88 0,83 0,78 0,73
23 SHC 1,14 1,06 1,04 1,00 0,95 0,89
19 25 SHC 1,31 1,22 1,19 1,15 1,11 1,05
27 SHC 1,48 1,38 1,35 1,62 1,26 1,21
29 SHC 1,65 1,53 1,51 1,47 1,43 1,36
31 SHC 1,82 1,69 1,67 1,63 1,58 1,52
TC 2,30 2,19 2,11 2,02 1,89 1,74
CM 0,55 0,57 0,59 0,61 0,63 0,65
23 SHC 0,94 0,89 0,86 0,82 0,77 0,71
21 25 SHC 1,12 1,05 1,02 0,98 0,93 0,88
27 SHC 1,29 1,20 1,18 1,14 1,09 1,03
29 SHC 1,46 1,36 1,34 1,30 1,25 1,19
31 SHC 1,63 1,52 1,50 1,46 1,41 1,35
TC 2,45 2,31 2,24 2,11 1,98 1,84
CM 0,57 0,59 0,61 0,63 0,65 0,67
23 25 SHC 0,92 0,87 0,84 0,79 0,74 0,69
27 SHC 1,09 1,02 1,00 0,95 0,90 0,85
29 SHC 1,27 1,17 1,16 1,11 1,06 1,01
31 SHC 1,44 1,33 1,32 1,27 1,22 1,17
TC: TOTAL COOLING CAPACITY kW
SHC: SENSIBLE HEAT CAPACITY kW
CM: COMPRESSOR INPUT kW
RATING CONDITIONS
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
NOTE: Data referred to indoor unit MCAV72C5TA-
CONDENSER
OUTDOOR AMBIENT TEMP. °C
430
16

OUTDOOR UNIT: GRV92C5TA-
220 - 240 V ~ 50 Hz
RATING CAPACITY 2,60 kW moisture removal 0,8 l/h
COMP. POWER INPUT 0,90 kW max comp input 1,03 kW
AIR FLOW RATE m³/h
EVAPORATOR
ENT.TEMP. °C
W.B. D.B. 20 25 30 35 40 43
TC 2,63 2,46 2,39 2,28 2,14 1,97
CM 0,74 0,77 0,80 0,84 0,87 0,90
21 SHC 1,82 1,69 1,66 1,60 1,53 1,45
23 SHC 2,06 1,91 1,88 1,82 1,75 1,67
15 25 SHC 2,29 2,13 2,09 2,03 1,97 1,89
27 SHC 2,52 2,36 2,31 2,26 2,14 1,97
29 SHC 2,63 2,46 2,39 2,28 2,14 1,97
31 SHC 2,63 2,46 2,39 2,28 2,14 1,97
TC 2,81 2,67 2,57 2,44 2,29 2,11
CM 0,77 0,80 0,84 0,87 0,90 0,93
21 SHC 1,57 1,48 1,44 1,38 1,31 1,23
23 SHC 1,81 1,70 1,65 1,59 1,53 1,45
17 25 SHC 2,04 1,93 1,87 1,81 1,75 1,66
27 SHC 2,28 2,15 2,09 2,03 1,96 1,88
29 SHC 2,52 2,37 2,31 2,25 2,18 2,10
31 SHC 2,75 2,59 2,52 2,44 2,29 2,11
TC 2,99 2,83 2,73 2,60 2,44 2,25
CM 0,80 0,84 0,87 0,90 0,93 0,97
21 SHC 1,32 1,24 1,20 1,14 1,07 0,99
23 SHC 1,56 1,46 1,42 1,36 1,29 1,22
19 25 SHC 1,79 1,67 1,63 1,58 1,51 1,43
27 SHC 2,02 1,88 1,85 2,04 1,73 1,65
29 SHC 2,26 2,09 2,07 2,01 1,95 1,87
31 SHC 2,49 2,31 2,29 2,23 2,16 2,09
TC 3,15 3,00 2,89 2,76 2,59 2,39
CM 0,84 0,87 0,90 0,93 0,97 1,00
23 SHC 1,29 1,22 1,18 1,12 1,06 0,98
21 25 SHC 1,53 1,43 1,40 1,35 1,28 1,20
27 SHC 1,76 1,65 1,62 1,56 1,50 1,41
29 SHC 2,00 1,86 1,83 1,78 1,71 1,63
31 SHC 2,22 2,08 2,05 2,00 1,93 1,85
TC 3,35 3,16 3,06 2,89 2,71 2,52
CM 0,87 0,90 0,93 0,97 1,00 1,03
23 25 SHC 1,26 1,19 1,15 1,09 1,02 0,95
27 SHC 1,50 1,39 1,36 1,30 1,23 1,16
29 SHC 1,73 1,60 1,58 1,52 1,45 1,38
31 SHC 1,97 1,83 1,80 1,74 1,67 1,61
TC: TOTAL COOLING CAPACITY kW
SHC: SENSIBLE HEAT CAPACITY kW
CM: COMPRESSOR INPUT kW
RATING CONDITIONS
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
NOTE: Data referred to indoor unit MCAV92C5TA-
CONDENSER
OUTDOOR AMBIENT TEMP. °C
450
17

OUTDOOR UNIT: GRV122C5TA-
220 - 240 V ~ 50 Hz
RATING CAPACITY 3,40 kW moisture removal 1,5 l/h
COMP. POWER INPUT 1,286 kW max comp input 1,506 kW
AIR FLOW RATE m³/h
EVAPORATOR
ENT.TEMP. °C
W.B. D.B. 20 25 30 35 40 43
TC 3,43 3,22 3,13 2,98 2,79 2,58
CM 0,99 1,07 1,14 1,21 1,28 1,35
21 SHC 2,38 2,21 2,17 2,09 2,00 1,90
23 SHC 2,69 2,50 2,45 2,38 2,29 2,19
15 25 SHC 2,99 2,79 2,73 2,66 2,57 2,47
27 SHC 3,30 3,08 3,02 2,95 2,79 2,58
29 SHC 3,43 3,22 3,13 2,98 2,79 2,58
31 SHC 3,43 3,22 3,13 2,98 2,79 2,58
TC 3,68 3,49 3,36 3,19 3,00 2,76
CM 1,03 1,10 1,18 1,25 1,32 1,39
21 SHC 2,05 1,93 1,88 1,80 1,71 1,60
23 SHC 2,36 2,22 2,16 2,08 2,00 1,89
17 25 SHC 2,67 2,52 2,45 2,37 2,28 2,17
27 SHC 2,98 2,81 2,73 2,65 2,56 2,46
29 SHC 3,29 3,10 3,02 2,94 2,85 2,74
31 SHC 3,59 3,39 3,30 3,19 3,00 2,76
TC 3,91 3,70 3,57 3,40 3,19 2,94
CM 1,07 1,14 1,21 1,29 1,36 1,43
21 SHC 1,73 1,62 1,57 1,49 1,40 1,30
23 SHC 2,04 1,90 1,86 1,78 1,69 1,59
19 25 SHC 2,35 2,18 2,14 2,06 1,98 1,87
27 SHC 2,64 2,46 2,42 2,35 2,26 2,16
29 SHC 2,95 2,73 2,71 2,63 2,55 2,44
31 SHC 3,26 3,02 2,99 2,92 2,83 2,73
TC 4,11 3,92 3,78 3,61 3,39 3,12
CM 1,10 1,17 1,24 1,32 1,39 1,47
23 SHC 1,69 1,60 1,54 1,47 1,38 1,28
21 25 SHC 2,00 1,87 1,83 1,76 1,67 1,57
27 SHC 2,31 2,15 2,11 2,04 1,96 1,85
29 SHC 2,62 2,43 2,39 2,33 2,24 2,14
31 SHC 2,91 2,71 2,68 2,61 2,53 2,42
TC 4,39 4,14 4,01 3,78 3,54 3,30
CM 1,12 1,20 1,27 1,35 1,43 1,51
23 25 SHC 1,65 1,55 1,50 1,42 1,33 1,24
27 SHC 1,96 1,82 1,78 1,70 1,61 1,52
29 SHC 2,27 2,09 2,07 1,99 1,90 1,81
31 SHC 2,58 2,39 2,36 2,27 2,18 2,10
TC: TOTAL COOLING CAPACITY kW
SHC: SENSIBLE HEAT CAPACITY kW
CM: COMPRESSOR INPUT kW
RATING CONDITIONS
Cooling: Indoor air temperature 27°C D.B. / 19°C W.B.
Outdoor air temperature 35°C D.B. / 24°C W.B.
NOTE: Data referred to indoor unit MCAV122C5TA-
CONDENSER
OUTDOOR AMBIENT TEMP. °C
470
18

6. ELECTRICAL DATA
6-1 Electrical characteristics
OUTDOOR UNIT: GRV72C5TA-
Indoor Unit Complete Unit
Fan Motor Fan Motor Compressor
Performance at
Rating conditions Running Amps. A 0,110 0,280 2,810 3,200
Power input kW 0,025 0,063 0,592 0,680
Full load conditions Running Amps. A 0,110 0,280 3,110 3,500
Power input kW 0,025 0,063 0,672 0,760
NOTE: Data referred to indoor unit MCAV72C5TA-
For other indoor unit models there could be some differences.
OUTDOOR UNIT: GRV92C5TA-
Indoor Unit Complete Unit
Fan Motor Fan Motor Compressor
Performance at
Rating conditions Running Amps. A 0,120 0,280 4,000 4,400
Power input kW 0,027 0,063 0,900 0,990
Full load conditions Running Amps. A 0,120 0,280 4,500 4,900
Power input kW 0,027 0,063 1,030 1,120
NOTE: Data referred to indoor unit MCAV92C5TA-
For other indoor unit models there could be some differences.
OUTDOOR UNIT: GRV122C5TA-
Indoor Unit Complete Unit
Fan Motor Fan Motor Compressor
Performance at
Rating conditions Running Amps. A 0,130 0,280 5,890 6,300
Power input kW 0,031 0,063 1,286 1,380
Full load conditions Running Amps. A 0,130 0,280 7,090 7,500
Power input kW 0,031 0,063 1,506 1,600
NOTE: Data referred to indoor unit MCAV122C5TA-
For other indoor unit models there could be some differences.
Rating Conditions: Indoor Air Temperature 27°C D.B. / 19°C W.B.
Outdoor Air Temperature 35°C D.B.
Full Load Conditions: Indoor Air Temperature 32°C D.B. / 23°C W.B.
Outdoor Air Temperature 43°C D.B.
Outdoor uni
t
230 V 1-Phase 50 H
z
Outdoor uni
t
230 V 1-Phase 50 H
z
Outdoor uni
t
230 V 1-Phase 50 H
z
19

6-2 Electric Wiring Diagram
6-3 System Wiring Diagram
20
