TechniSat DigiCorder HD series Manual

Your unit carries the CE symbol and complies with all relevant EU standards.
Subject to change and printing errors. Correct as at 02/09
TechniSat and DigiCorder HD S2X Plus are registered tradehighlights of
TechniSat Digital GmbH Postfach 560 54541 Daun www.technisat.de
TechniSat DVB-S
DigiCorder HD series
Short instructions
ENENENFRENESENITENNOENDAENSVENFIENPLENCZENSK

2
Automatic Search
Satellite
Channel searching Transponder
Manual Search
Country
Protection of minors Time zone
Program journal Date/Time
Standby clock
Basic settings
Settings IRC code
Screen format
Quickstart
Picture settings HDMI resolution
Audio language
HDMI colour space
Sound settings Subtitle language
TV SCART mode
Antenna configuration Dolby Digital
Zoom
Special functions AV synchronism
OSD
Main Menu HDMI audio format
PVR
System configuration
Media Player
Service settings Restore factory set-
tings Network
Timer overview Delete all programs
Remote access
Hard disk timer Update software
Miscellaneous
Timer organising
Video rec. timer Copy settings
TV-Lists organising Channel change timer
Record organising
Timer settings
Radio lists organising Music copying
Picture copying
Hard disk organising
Record copying
CI Slot 1
Hard disk information
CI Slot 2
Conditional access Hard disk mainte-
nance
Smartcard 1
Smartcard 2
Menu language

3
ENEN
Contents:
Safety advice................................................................................................... 4
When not in operation .....................................................................................5
Help ................................................................................................................ 7
Initial installation.............................................................................................. 8
Switching on and off........................................................................................9
Channel selection............................................................................................9
Optional features ........................................................................................... 10
Additional channel information ...................................................................... 10
Volume control .............................................................................................. 11
TV/Radio switching........................................................................................ 11
Access Electronic Channel Guide (EPG)...................................................... 11
Hard disk operation ....................................................................................... 11
Recording............................................................................................ 11
Playback.............................................................................................. 18
Pause/Still picture................................................................................ 18
Fast Forward and Rewind ................................................................... 19
Slow motion......................................................................................... 19
Single frame progress ......................................................................... 20
MP3 Playback .....................................................................................20
Playback/reproduction of pictures.......................................................22
Manage hard disk................................................................................23
Sort Channels / Configure Favourites List ....................................................29
Exit Menus.....................................................................................................32

4
Disposal advice
The packaging for your unit consists entirely of recyclable material. Please
sort the items appropriately, and sort them for disposal via your local waste
“Disposal system”. Please note that spent batteries (from the remote control)
as well as electronic components should not be disposed of in your household
refuse, but in accordance with your local regulations (special waste, handing
back to the outlet where purchased).
Safety advice
For your own protection, please read the safety instructions carefully before
commencing operation of your new unit.
The manufacturer accepts no responsibility for damage caused by inappropri-
ate operation, or by non-compliance with safety precautions.
> To ensure sufficient ventilation, position the device on a flat, even sur-
face and do not place any objects on the lid of the device. This surface
has ventilation slots that ensure heat can escape from inside the unit.
> Do not place any burning objects, such as burning candles, on top of the
unit.
> Do not subject the unit to water spray or droplets, and do not place any
objects filled with liquid, e.g. vases, on top of the unit.
> The unit may only be operated in a temperate climate.
> Never open the unit housing! You are in danger of receiving an electric
shock. Any necessary repairs should be carried out only by qualified
service personnel.
In the following cases, you should disconnect the unit from the mains power
supply, and consult a qualified technician:
> the mains cable or the mains plug is damaged
> the unit was exposed to liquid, or liquid has run into the unit
> in case of significant malfunction
> in case of severe external damage

5
ENEN
When not in operation
During an electrical storm, or when the unit will not be used for a lengthy pe-
riod of time (e.g. while you are on holiday), disconnect the unit from the mains
power supply.
Connecting the DVB receiver
Card reader for the smartcard:
> Slide the smartcard (with the gold chip facing
down and in the intendet direction of insertion)
carefully until it is fitted into the card reader
Inserting the CI module:
> Follow the instructions of the manufac-
turer of the CI module and card.
> Slide the desired smartcard into the
relevant CI module.
> Now carefully slide the CI module into
the appropriate slot.
Video recorder
a. Mains connection
b. Connecting LNB 1 with
LNB Input 1 of the DVB receiver.
(Please note: When operating with
an antenna signal, the LNB must
be connected with the LNB Input 1.)
c. Connecting LNB 2 with LNB Input 2
of the DVB receiver.
d. Scart connection between the DVB
receiver and the television set.
e. Connecting from the component
socket of the DVB Receiver to the
component socket of the TV.
f. Scart connection between the DVB
receiver and the television set.
g. Scart connection from a video player
to the VCR Scart socket of the DVB
receiver.
h. Connecting the Audio outputs with a
HiFi-/Surround system.

6
Operating with 2 antenna signals
To ensure the full functional scope of the digital receiver is usable, the receiver
should be operated with two separate antenna signals / antenna connections,
which are fitted identically.
b, cConnect LNB Inputs 1 and 2 of the digital receiver via a suitable coaxial
cable with your external unit.
Operating with 1 antenna signal
In exceptional cases, you may also operate the receiver with just one antenna
signal. In this case, however, the recording and PIP functions will only be func-
tional to a limited extent. bConnect the LNB Input 1 of the digital receiver via a
suitable coaxial cable with your external unit.
Operation with a rotating antenna
b
During operation with a rotating antenna, connect the DiSEqC engine (Level
1.2) with the LNB input 1.
Connection to a television set
dConnect the receiver (HDMI output) and TV (HDMI input) via an HDMI cable.
If your TV is suitably equipped, it will automatically switch to the HDMI input
when the digital receiver is switched on.
Or: e Connect the receiver (component output) and TV (component input) via a
component cable.
Alternatively: f Use a SCART cable to connect the receiver (SCART socket
TV) with the television set (SCART socket). If your television set is appropri-
ately equipped, it will automatically switch to AV, and thus to satellite operation,
when the digital receiver is switched on. Where applicable, it may be neces-
sary to adapt the type of signal for your television set.
Important operating instructions
The operation of the digital receiver is simplified by the use of the “On Screen
Displays”, which also serves to reduce the number of keys required on the
remote control unit. All functions are displayed on the screen, and can be
operated with a few keys. Related functions are combined in a “MENU”. The
function selected is highlighted in colour. The “function keys” red, yellow, green
and blue are indicated by colour bars in the bottom line. These colour bars
represent different functions in the various menus, which will be activated by
pressing the appropriate coloured key (multifunction key) on the remote control.
The “Function keys” are only active when a brief description is displayed in the
appropriate field.

7
ENEN
Remote control option:
By switching the remote control option, this remote control unit can be used to
control two TechniSat receivers and one TechniSat television set with the same
coding. While the button is pressed, the currently set remote control code is
indicated by flashing of the relevant LED.
> To implement the remote control option, press and hold the remote con-
trol code buton and subsequently press the OK button as often it takes
for the LED of the desired remote control options (SAT1, SAT2 or TV) to
briefly flash.
Help:
Where available in the menus, pressing the blue function key will cause
a help text to be displayed, pressing again will remove the text from the
screen.
Mute
Remote control option
Numeric keys
0 / AV
EPG
Multifunctional keys
Back
Rewind
Stop
Program -
Video text on/Mix/off
Menu On/Off
TV/Radio
Channel list On/Off
Info
Record
Fast forward
Pause / Play
Program +
Volume +
Still picture
Jog-shuttle on/off
Sleep timer
Sleep timer
On/Standby
OK
Arrow keys
Volume -

8
Initial installation
When switching on the unit for the first time, a start window will be displayed,
with the installation assistant AutoInstall. Please follow the instructions dis-
played on screen. If you do not implement the initial installation, or if it is not
completed, the receiver will commence operation with a standard pre-channeld
configuration.
Antenna configuration
In this installation step you can adjust the digital receiver to the configuration of
your antenna.
> If you wish to accept the standard antenna setting, use the arrow keys
up/down to highlight the field Standard and confirm by pressing OK.
> If the configuration of your receiving installation does not correspond
with the standard setting, highlight the field Manual and confirm by
pressing OK.
DiSEqC
> If you have DiSEqC components in your receiving installation, highlight
the field Activate and confirm by pressing OK
Position A/Option A
> Use the arrow keys up/down to highlight the satellite you wish to receive
at the DiSEqC setting Position A/Option A and confirm by pressing OK.
Position B/Option A
> Use the arrow keys up/down to highlight the satellite you wish to receive
at the DiSEqC setting Position B/Option A and confirm by pressing OK.
Position A/Option B
> Use the arrow keys up/down to highlight the satellite you wish to receive
at the DiSEqC setting Position A/Option B and confirm by pressing OK.
Position B/Option B
> Use the arrow keys up/down to highlight the satellite you wish to receive
at the DiSEqC setting Position B/Option B and confirm by pressing OK.
In the next step, you should check on the correct configuration of your
antenna.
> If you wish to accept the settings entered, use the arrow keys up/down
to highlight the field Yes, and confirm by pressing OK.

9
ENEN
Position A/Option B
> Use the arrow keys up/down to highlight the satellite you wish to receive
at the DiSEqC setting Position A/Option B and confirm by pressing OK.
Position B/Option B
> Use the arrow keys up/down to highlight the satellite you wish to receive
at the DiSEqC setting Position B/Option B and confirm by pressing OK.
In the next step, you should check on the correct configuration of your
antenna.
> If you wish to accept the settings entered, use the arrow keys up/down
to highlight the field Yes, and confirm by pressing OK.
You can abort the initial installation at any time simply by pressing the red func-
tion key. Press the green function key to go back to the previous step in the
installation procedure. Thus any entries made incorrectly can be quickly cor-
rected. If you do not implement the initial installation, or if it is not completed,
the receiver will commence operation with a standard pre-channeld configura-
tion.
For daily use
Switching on and off
> Press the On/Standby key either on the digital receiver or the remote
control to switch the receiver on.
> Press the same key again to switch the receiver off.
Channel selection
Using the channel up/down keys
> Use the channel up/down keys on the remote control or on the receiver
to move up or down the list one channel slot at a time.
Using the numeric keys
> You may use the numeric keys to enter the desired channel number. For
example: 1 for channel 1
1, then 4 for channel 14
2, then 3, then 4 for channel 234
When entering a channel number consisting of several digits, you have ap-
prox. 3 seconds after pressing each number to complete the entry. If you wish
to enter a number consisting of only one or two digits, you can speed up the
switching procedure by holding the key down on the last digit.

10
Using the channel list:
> Press the OK key.
> Now use the arrow keys up/down to highlight the desired channel.
> Press the OK key to display the highlighted channel.
> Use the arrow keys up/down to move the highlighter in the list by one
line at a time.
> Use the arrow keys left/right to move back and forth in the list one page
at a time.
Return to the last channel selected
> Pressing the Back key on the remote control will take you back to the
last channel selected.
> Press the key again to return to the channel previously selected.
Optional features
Certain channels offer the possibility of optional channels. This function makes
it possible for you, e.g. during a sports broadcast, to freely select from various
camera perspectives (Form 1) or to select from a range of different sporting
broadcasts (Bundesliga football).
If a programme includes optional features, this will be indicated by a notifica-
tion.
> To select one of the possible options, press the option button. A selec-
tion window showing the available options will be displayed.
> Use the arrow keys up/down to highlight the desired option, and confirm
by pressing OK.
Select start time
On certain channels, you can select individual films with different start times.
With this in mind, these films are available on a round the clock basis at differ-
ent start times. If a channel features selectable start time, this will be indicated.
> To select one of the possible start times, press the option button.
A selection window showing the start times offered will be displayed.
> Use the arrow keys up/down to select the desired start time.
> Confirm by pressing OK.
Provided the broadcast for the selected start time is available, you can view
this at the desired time.
Additional channel information
Each time you change channels, an information box will be displayed briefly,
showing the channel slot and the channel name of the channel selected.
In addition, other channel properties will be indicated, such as for Video text,

11
ENEN
widescreen broadcasts and for encrypted channels. If a TV broadcast is avail-
able in multiple languages or with multiple sound channels, or if multiple
radio channels are available on a single radio station slot, this will be displayed
on screen. You may then proceed as follows to select a different language or a
different audio channel:
> Press the Option key. A list will now be displayed on screen, indicating
the languages currently available.
> Use the arrow keys up/down to highlight the desired language or the
desired radio station and confirm by pressing OK. You may now listen
to the channel in the language selected. Your digital receiver is also
equipped to receive monaural channels.
> Use the arrow keys left/right to choose between Mono channel 1 ( ),
Mono channel 2 ( ) and Stereo ( ).
Volume control
> Adjust the volume of your digital receiver using the Volume + key to
increase the volume, and Volume – to decrease the volume.
> Press the mute key to switch the sound on or off.
TV/Radio switching
> By pressing the TV/Radio button, you can switch between TV and Radio
operation.
Access Electronic Channel Guide (EPG):
> Press the SFI/EPG key on the remote control of the digital receiver.
The Electronic Channel Guide then appears on the screen. The chan-
nels you have selected, or those of the factory default settings, will be
shown with their current channels. You can now also use the EPG func-
tion to obtain information on various channels. In addition, you may use
the EPG functions to select a particular channel, to pre-select a channel,
or to set a timer for a channel.
Exit EPG
> Press either the Menu or the TV/Radio key to return to normal operation.
Hard disk operation
Recording
Warning!!!
Simultaneous receiving of two encrypted channels
Your receiver also allows you to receive two different encrypted channels
simultaneously, using only one CI module and only a single valid Smartcard.

12
However, this is only possible if you use a CI module with the “Dual-Decrypt”
function (see details of the CI module manufacturer), both the desired channels
are located on the same transmitter and the CI dual decryption function has
been correctly selected.
Please ensure that the receiver has acquired the time. During operation, this is
displayed in the Infobox and during standby operation on the display. If this is
not the case, leave the receiver switched on to a selected channel for approxi-
mately 30 seconds, so that the receiver can acquire the current time.
1. Immediate recording
Select this recording type, to record the broadcast currently showing immedi-
ately with the touch of a button.
2. Time-controlled recording
This function can be used to switch your digital receiver on and off for the se-
lected broadcast, in order to record onto the hard disk when you are away. The
time can be channeld either manually or automatically via the EPG function.
3. Timeshift recording
The timeshift recording function makes delayed TV viewing possible. With this
function, even while the recording continues, you can use a time-delayed play
back.
Manually start recording
Option 1
> Switch on the program, which is showing the broadcast which you would
like to record.
> Press the record button to record the current broadcast. While the re-
cording continues, the broadcast is still displayed on the screen.
> To stop the playback of the current broadcast at a specific point, press
the yellow function key Play/Pause. While the recording continues in the
background, a still picture appears on the screen.
> T
o continue the playback of this broadcast from this point, press the yel-
low function key Play/Pause again. You will now view the broadcast with
a time delay relative to the live transmission (Timeshift), while the current
broadcast is continually recorded in the background.
Option 2
> If you have to interrupt the viewing of a broadcast e.g. due to a tel-
ephone call etc., you can halt the playback of this broadcast by press-
ing the yellow function key Play/Pause and start recording the current

13
ENEN
broadcast at the same time. While the recording starts in the back-
ground, a still picture appears on the screen.
>
To continue the playback of this broadcast from this point, press the yel-
low function key Play/Pause again. You will now view the broadcast with
a time delay relative to the live transmission (Timeshift), while the current
broadcast is continually recorded in the background.
Manually end recording
> First press the OK button to end the recording.
> Press the green function key to access the PVR navigator.
> Use the arrow keys up/down to highlight the current recording and con-
firm by pressing OK.
> Press the green function key Stop and a selection window appears.
> Use the arrow keys up/down to select Save, to save the recording onto
the hard disk, or Cancel, to cancel saving of the broadcast and confirm
by pressing OK.
Automatically end recording
Option 1
> Press the On/Standby key. Now a selection window appears, which
should show the details of the current recording.
> Use the arrow keys up/down to highlight the line with the desired action.
> Confirm by pressing OK. The receiver completes recording of the broad-
cast and subsequently reverts to standby mode.
> When you switch on the receiver before recording is over, a selection
window appears, select whether you wish to view the current broadcast
from the start, revert to live mode or switch to the current channel.
> Use the arrow keys up/down to highlight the desired line and confirm
by pressing OK. When Start is selected, the recording will continue in
Timeshift operation.
Option 2
> By pressing the Record button, a selection window appears.
> Use the arrow keys up/down to highlight the line with the desired action,
e.g. +1 hour, and confirm by pressing OK. The receiver will now record
the channel(s) being broadcast on the channel selected for the time
period selected, and will then automatically stop recording.
Timer recordings
With the help of the hard disk timer, you can record broadcasts on the inte-
grated hard disk even when you are away. Your receiver is also equipped with

14
video recorder timers as well as channel switching timers. In terms of their
programming, these timers differ only in that the relevant type of timer is speci-
fied. In Standby operation, the hard disk and video recorder timers are shown
by a clock symbol on the display. As described in this chapter, you can either
program the timer manually or with the help of the EPG function.
1. Hard disk timer
This function can be used to switch your digital receiver on and off for the
selected broadcast, in order to record onto the hard disk when you are away.
If the receiver was switched on by means of the hard disk timer, this will be
indicated by the message “_ PVR Timer” shown in the display. Some functions
of the remote control (e.g. Accessing the main menu) are not operational.
2. Video recorder timer
When you use a video recorder timer, your digital receiver will be switched on
and off for the channel selected, so that it may be recorded, e.g. on a video re-
corder, in your absence. If the receiver was switched on by means of the video
recorder timer, this will be indicated by the message “_ VCR Timer” shown in
the display. Some functions of the remote control are not operational.
Be careful to note that the relevant recorder must also be channeld.
3. Channel change timer
If your receiver is in normal operating mode, it will switch to the programmed
channel at the time selected. In contrast to the setting for a hard disk or video
recorder timer, the remote controls remain fully functional, and the receiver will
not be switched off at the end of the channel.
Manual timer programming
> Press the Menu key to display the Main menu.
> Use the arrow keys up/down to highlight the line Manage timer.
> Confirm with the OK button, to access the Timer Menu
> Use the arrow keys up/down to select the desired timer type.
> Press the OK key to go to the entry window in order to channel a new
timer event.
Channel
> Use the arrow keys to highlight the upper line of the menu.
> Press the OK key.
> In the selection window use the arrow keys up/down to select the de-
sired source (TV or Radio) and confirm by pressing OK. Depending on
the previous setting, either the TV or the radio channel list will now be
displayed.

15
ENEN
> Now highlight the desired channel with the help of the numeric keys
(channel input) and/or with the help of the arrow keys. Use the arrow
keys up/down to move the highlighter around the list one line at a time
and the arrow keys left/right to move the highlighter forwards or back-
wards one page at a time.
> Press the OK key to accept a channel into the timer memory.
Date
> Use the arrow keys to highlight the column Date.
> Use the numeric keys to enter the date (in 4-digit format) on which the
timer event is to take place.
Start
> Use the arrow keys to highlight the column Start.
> In this line, use the numeric keys to enter the starting time for the timer.
Stop
> Repeat the steps as for “Start” in order to enter the stopping, or ending
time (except in the case of channel change timers).
Repeat
> Use the arrow keys to highlight the column Rep.
> Press the OK key.
A selection window will be displayed, presenting various repeat options:
1x Timer once
T Daily repeat
1 W Repeat once per week
1-5 Repeat only on weekdays
6-7 Repeat only on weekends
> Use the arrow keys up/down to select the desired function.
> Press OK to accept the setting.
Accepting data into memory
> When you have completed the programming, press the green function
key Accept, to transfer the data to memory. After the data have been
saved into memory, the timer overview appears.
Timer overview
The timer overview function gives you an overview of all timer events already
channeld.

16
> To access the timer overview, first call up the main menu by pressing
the Menu button.
> Use the arrow keys up/down to select the entry Manage timer and con-
firm by pressing OK. The sub-menu Manage timer will be displayed.
> Use the arrow keys up/down to highlight the line Set highlighter, confirm
by pressing OK.
If, when programming, multiple timer events clash, meaning the timer
cannot be correctly set, the overlaps are highlighted in red.
Change timer programming
> To change an existing timer setting, access the timer overview function.
> Subsequently, use the arrow keys up/down to highlight the timer event
you wish to change.
> Press the green function key Change to go to the settings of the high-
lighted timer. Make the changes as described.
> Use the arrow keys up/down to highlight the additional window dis-
played: Type, before you save to the timer.
> By pressing the OK key a window with the available timer types will
open.
> Now use the arrow keys up/down to select the desired timer type.
> To accept the timer type, confirm by pressing OK.
> Press the green function key Save, to save the data in storage.
Delete timer programming
> To delete an existing timer setting, access the timer overview function.
> Subsequently, use the arrow keys up/down to select the timer to be
deleted.
> Press the yellow function key Delete. A message will be displayed: “Do
you really want to delete this timer?”
> Use the arrow keys left/right to select Yes.
> To delete the timer, confirm by pressing OK.
Channel new timer event
> To channel a new timer event, use the arrow keys up/down to highlight a
blank line in the menu Timer overview.
> Press the green function key New to call up the input window to channel
a new timer event.
> Use the arrow keys up/down to highlight the additional window dis-
played: Type.
>
By pressing the OK key a window with the available timer types will open.

17
ENEN
> Now use the arrow keys up/down to select the desired timer type.
> To accept the timer type, confirm by pressing OK.
> When you have completed the programming, press the green function
key Accept, to transfer the data to memory.
Timer settings (Preliminary or Follow-up time)
During the EPG timer programming, the receiver receives the data of the
selected broadcast automatically from the EPG data. This allows the start and
end time of the broadcast being recorded to be saved precise to the minute.
However, there are often cases where the selected broadcast starts somewhat
earlier or later than is specified. In this case, the recorded broadcast will miss
out either the start or the end. To solve this problem, you can set preliminary or
follow-up time in one minute steps. The timer now starts earlier at the specified
preliminary time and ends at the set follow-up time later than specified in the
EPG data.
> Press the red function key Timer to open a selection window.
> Use the arrow keys up/down to highlight the line Timer settings.
> Confirm by pressing OK. A menu appears for adjusting the preliminary
or follow-up time.
> Use the arrow keys up/down to highlight the line Timer preliminary time
or Timer follow-up time..
> Use the numeric keys to enter the desired preliminary or follow-up time
in minutes.
> Press the green function key Save, to save the setting and to return to
the timer overview.
Timeshift function
The timeshift function allows you the possibility to activate both playback and
recording at the same time. This allows time-delayed TV viewing and allows
you to view the start of the recording and thus jump throughsections that have
already been recorded. At the same time, the recording of the live signal of the
broadcast continues.
> To access a specific section of a current recording, the functions Play
and Pause are available, as well as Fast Forward and the jog shuttle.
> Pressing the Info button causes the Infobox to appear with a status bar
displayed, which shows the playback and recording duration.
Setting highlighters while recording
> Press the Record key to open a window showing the functions available.
> Use the arrow keys up/down to highlight the line Set highlighter, confirm
by pressing OK. A highlighter will now be set at the current position.
Continue in this manner to set highlighters at all desired places. high-

18
lighters can also be placed even during a recording and in the Manage
hard disk menu.
Playback
You can access hard disk recordings via the hard disk (PVR-) navigator. These
can be accessed in several ways. Depending on whether you are operating
the TV or radio, a list appears with all the TV or radio recordings contained on
the hard disk. After access via the navigator, the playback of the highlighted
recording already starts.
Accessing the PVR navigator:
The PVR navigator can be accessed in the following ways:
During normal operation
> Press the OK key to open the channel list navigator.
> Press the green function key PVR to switch to the PVR navigator.
or
> Press the green function key directly to open the PVR navigator.
During recording/playback of a recording
> During a recording/playback of a hard disk recording, you can access
the PVR navigator by pressing the OK button.
Play back hard disk recordings
> First access the PVR navigator.
> Use the arrow keys up/down to select the recording you wish to play
back. Completed as well as current recordings can be selected.
> To start the playback, confirm by pressing OK. The indication “Play-
back_” will be displayed.
Recording information
> First access the PVR navigator.
> Use the arrow keys to highlight the recording for which you would like to
see further information.
> Pressing the yellow function key Status allows information on the high-
lighted recording to be displayed.
> Press the Back button to return to the PVR navigator.
Pause/Still picture
> To halt the playback of a recording (still picture), during playback, press
the yellow function key or the Still picture button. The symbol "Pause _II"

19
ENEN
will be displayed.
> Press the relevant key again to restart the playback from the same posi-
tion.
Fast Forward and Rewind
To access a specific section of a recording, your PVR includes variable speed
Fast Forward and Rewind functions.
> During playback, press the blue function key for Fast Forward or the red
function key for Rewind. The display indicates “Fast Forward ___” or
“Rewind ___”. The recording will now be run at 4x normal speed in the
desired direction.
> Press the blue or red function key again and the speed increases to 16x.
The display indicates “Fast Forward ___” or “Rewind ___”.
> Press the blue or red function key again and the speed increases to 64x.
The display indicates “Fast Forward ___” or “Rewind ___”.
> By pressing the blue or red function key again, you can jump forward or
backward in 10 minute segments.
> Once the desired portion of the recording has been reached, you can
access normal playback by pressing the yellow function key.
Jogshuttle function
In addition, your receiver features a jog-shuttle function, which allows you to
go to a specific place in your recording very quickly and precisely. This can be
used as follows:
> While in playback mode, press the key Jogshuttle on/off (Freeze frame)
to go to the jog-shuttle mode. The playback of the recording will be
stopped (freeze frame/pause). The symbol “_II“ will be displayed.
Fast Forward and Rewind
> By pressing the arrow keys right/left, you can adjust both the speed and
direction of playback. In the process, the respective playback mode will
be displayed.
> While this is displayed, press the arrow keys ____ or ____, right or left,
to jump forwards or backwards in 10 minute steps.
Slow motion
> By pressing the right arrow key once, the recording is played back at
slow motion speed and the indication “I_” appears on the display.

20
Single frame progress
> Press the arrow key up to display the next frame in a forwards direction
and press down for display the previous frame in the backward/reverse
direction.
Create image
> By pressing the Record button, an individual image is transferred onto
the hard disk. In this way, you can access and manage created images.
Setting highlighters
> As described before, go to the place in your recording at which you wish
to insert a highlighter.
> Press the record button to set a highlighter at the actual position. Con-
tinue in this manner to set highlighters at all desired places. Highlighters
can also be set during Record mode as well as in the menu Manage
hard disk.
Jump to highlighters
During the playback, it is possible to jump directly to specific sections of the
recording, where you have positioned highlighters.
> Pressing the key Option will open a window with the existing highlight-
ers. In addition, the indication “Current” appears. This highlights the
actual playback position on the recording.
> As soon you use the arrow keys up/down to highlight a highlighter, the
playback begins at this point.
> By pressing the OK button, the window is closed and you switch to nor-
mal playback.
End playback
> To exit playback, press the green function key. The playback will be
ended and your receiver will revert to normal operation. In the process,
the receiver logs the position on the recording at which playback was
ended. When you restart playback of this recording, it will automatically
revert to the point at which you previously stopped it.
MP3 playback
You can use your receiver to display created images, as well as files, which are
saved in MP3 format on the hard disk or on a device connected via the USB
socket. The USB device should be formatted using the file system FAT 32.
> During normal operation, open the PVR navigator with the green func-
tion key.
