TEFAL InfinyMix+ BLD ATHENA 1 ACC BL91H User manual

EN
F
1
2
3
4
5
N
J
G
H
2
3
1
1
2
3
2
3
1
D**
A
B*
C*
M
I
E*
L
K
EN p. 1 – 7
ZH p. 8 – 13
VI p. 14 – 21
MS p. 22 – 29
KO p. 30 – 37
8020004637
EN
ZH ZH
VI VI
MS MS
KO KO
* Depending on model ; 視乎型號 ; Tùy theo mẫu
máy ; Bergantung kepada model ; 모델에 따라 다름
** The shape can be different from model ; 形狀可因應型號各異 ; Hình dẫng có thẫ khác so
vẫi mẫu máy ; Bentuk mungkin berbeza daripada model ; 모델에 따라 모양이 다를 수 있음

1
1
2
MAX
600 ml
Clic
1
2
11
2
1 2 3
4 5 6
7 8 9

1
ENDESCRIPTION
A1 Middle cap
2 Lid
3 Plastic Tritan Jar
B* 1 Seal
2 Powelix blades unit
3 Locking ring
C* 1 Seal
2 Powelix life blades unit with
titanium coating
3 Locking ring
DMotor unit
E* 1 On the go bottle lid
2 On the go bottle
3 Seal
4 Powelix life blades unit with
titanium coating
5 Locking ring
FTamper
GStart/Stop button
HScreen
IBlender jar lock indicator
JOn the go bottle lock indicator
KControl display
LSetting button
MBlend button
NClean button
CAUTION:
The safety precautions are part of the appliance. Read them carefully
before using your new appliance for the first time. Keep them in a place
where you can find and refer to them later on. The appliance will only
start if the jar or the bottle is correctly positioned on the motor unit (D)
and the lid locked on the jar.
BEFORE USING YOUR APPLIANCE FOR THE FIRST TIME
Before using your appliance for the first time, rinse the parts that come
into contact with food (jar, bottle, lids and middle cap) with soapy water.
CAUTION: Do not immerse the appliance in water (neither the motor
unit nor the jar base). Never put the motor unit (D) under running
water. Clean it with a damp cloth and dry it carefully. The blades are
extremely sharp.

2
ASSEMBLING AND FITTING THE JAR
Moisten the seal (B1, C1) (even if already fitted on the blade unit (B2,
C2)). Be careful to correctly fit the seal (B1, C1) back onto the blades unit
(B2, C2) the correct way up.
Check the seal is in place on the blades unit. Place the blades (B2 or C2)
on the locking ring (B3 or C3) (Fig 1). Turn the jar upside down and fit the
locking ring with blades on the base of the jar (Fig 2). Lock it by rotating
to lock notch in the clockwise direction (Fig. 2). Make sure the locking ring
is locked correctly : the arrow on the jar must be aligned with the arrow
on the locking ring.
Add the ingredients into the assembled jar without exceeding the
maximum level indicated:
* 1.75 L for thick mixtures
* 1.5 L for liquid preparations
Warning : Do not pour boiling liquids (over 80°C/176°F) into the jar
Lock the lid on the jar and lock in the clockwise direction (Fig 5). Make
sure the lid is locked correctly : the point on the lid should be aligned with
point on the handle. Lock the middle cap in position on the lid and lock it
by rotating it in the clockwise direction. If the lid is not correctly locked,
your appliance will not start; Position the jar correctly on the motor unit :
the point on the jar should aligned with the lock on the motor unit. A jar
logo will appear on the screen and a bip signal will sound.
ASSEMBLING AND FITTING THE ON THE GO BOTTLE
Moisten the seal (E3) (even if already fitted on the blades unit (E4)). Be
careful to correctly fit the seal back onto the blades unit (E4) the correct
way up (Fig 9).
Check the seal is in place on the blades unit.
Make sure all the packaging has been removed before operating the
appliance.

3
EN
Add the ingredients into the bottle without exceeding the maximum level
indicated:
* 400ml for thick mixtures
* 600ml for liquid preparations
Warning : Do not pour boiling liquids (over 80°C/176°F) into the bottle.
Place the blades unit (E4) on the top of the bottle, fit the locking ring (E5),
and lock it by rotating to lock notch in the clockwise direction (Fig. 8).
Make sure the blades unit is locked correctly : the arrow on the locking
ring should be aligned with the arrow on the bottle.
Turn the bottle upside down and position it correctly on the motor unit.
Lock it by rotating it in the clockwise direction. A bottle logo will appear
on the screen and a bip signal will sound .
USING YOUR APPLIANCE
Put the appliance on a flat, stable, heat-resistant surface away from heat
sources or water splashes
Plug your appliance and select your program or manual settings (time
and speed) and press the start/ stop button : with the Jar (A) you can
change the blending speed from 1 to 9 by pressing the setting +/- buttons
(L). « H »is the maximum speed. You can also set up the working time by
pressing the setting +/- buttons (L) between 5 seconds and 3 minutes.
With the On The Go bottle (E) you can manage the blending speed from
1 to 7 by pressing the setting +/- buttons (L). You can also set up the
working time by pressing the setting +/- buttons (L) beteen 5 seconds and
90 seconds.
Wait for the blender to stop automatically. If you want to stop the blender
before the automatic end of the program, press on the start / stop button.
Do not shake the motor unit or the jar when the blender is in use.
When you use the pusher or the middle cap, hold the jar by its handle to
avoid it falling.
When the blender is in use, do not use any other accessory than the
pusher to avoid damaging the jar.

4
Less than 3 minutes of mixing are enough to blend liquids for most of
the recipes
For adding ingredients while blending, remove the middle cap from the
lid and add the ingredients through the feeder hole. Beware of the risk
of spatter.
CAUTION: After running one cycle in the blender for the maximum
processing time, let the blender rest for 1 minute before operating it
again.
After using the blender for a maximum of three cycles, stop the appliance
and leave to cool to ambient temperature (takes about 2 hours).
The appliance is equipped with overload protection. This prevents the
motor from being damaged by overloading.
If the appliance switches off during operation, proceed as follows :
unplug and leave to cool down for approx.15-20 minutes.
Reconnect the appliance to the power supply and resume blending.
After approx 3 minutes without use, your appliance will start a stand by
mode. To switch on you appliance, press the Start/ Stop button (G)
ROUGH CHOPPING SMALL QUANTITIES
Accessories used : assembled chopper
Chop in a few seconds by pulsing: peanuts, almonds etc.
Model 1600w : quantity / max time: 140g peanuts/8s or 150g almonds/8s

5
EN
Programs available with the Jar (A)
Auto-programs Description Example of recipe Time
Use this program
to make smoothie:
blending fresh fruits/
vegetables with milk
or yogurt
200g of carrots + 100g of
celeriac + 100g of bananas
+ 500g of orange juice
Default time :
60 sec
Adjustable from
30 seconds to
80 seconds
Use this program
to make ice cream:
blending frozen fruits
with fresh cream or
yogurt
Sorbet: 450g frozen
raspberries + 240g milk +
75g custar sugar. Tamper
must be use to help the
flow
Default time :
1min10s
Use this program to
crush ice cubes into
ice snow
8 ices cubes max Default time :
40 sec
Adjustable from
10 seconds to
50 seconds
Use this program
to make some light
dough like waffle,
cake, pancake,
clafoutis, brownie…
You can not make
heavy dough like
bread, brioche, pizza…
Yoghourt cake : Add
ingredients in this order
on the jar. 120g yoghurt +
210g custar sugar + 7.5g
vanilla sugar + 3 eggs +
125g sunflower oil + 85g
Corn flour + 65g almonds
powder + 140g flour + 11g
baking powder. Put the
mix in a mold and bake for
50min to 180°C
Default time :
1min15s
Adjustable from
30 seconds to
2minutes
Use this program to
clean your blender
200ml of water + 1 drop of
washing-up liquid.
30 seconds
Programs available with the On The Go bottle (E)
Auto-programs Description Example of recipe Time
Use this program
to make smoothie:
blending fresh fruits/
vegetables with milk
or yogurt
100g of carrots + 50g of
banana + 50g of celeriac +
250g of orange juice.
Default time :
45 sec
Adjustable from
30 seconds to
60 seconds

6
Unplug the appliance.
Empty the preparation, the jar is not meant for storing food in the
refrigerator or freezer.
To clean the motor unit, use a damp cloth. Dry it carefully.
Never immerse the motor unit in water.
For easy cleaning, wash the removable parts in water with few drops of
washing-up liquid, immediately after use.
The lid (A2), on the go bottle (E2), on the go bottle lid (E1), and middle
cap (A1) can be cleaned in the dishwasher, but the jar (A3), Powelix
blades unit (B or E3), Powelix life blades unit with titanium coating
(C) don’t go in the dishwasher. Don’t immerse the blades (B, C or E3)
completely and for a long time.
For easy cleaning in both jars, you can use the “Clean program” :
Put 200ml of water. You can add 1 drop of washing-up liquid only in the
Jar (A) The appliance works at various alternating speeds for approx.
30sec.
AFTER USING YOUR APPLIANCE
Auto-programs Description Example of recipe Time
Use this program to
crush ice cubes into
ice snow
4 ices cubes max Default time :
40 sec
Adjustable from
10 seconds to
50 seconds
Use this program to
clean your blender
200ml of water 30 seconds
The pulse button can still be used when no program is running.
CAUTION: Hard food may mark the inside of the jar but this does not
affect the efficiency of the appliance. Frozen food must be smaller
than a walnut.
Do not add hot liquid above 80°C as it can be ejected out of the
appliance due to a sudden build up of steam.

7
EN
WHAT TO DO IF YOUR APPLIANCE DOES NOT WORK ?
Problems Causes Solutions
Appliance does not work
The plug is not connected.
Connect the appliance to a
socket with the same voltage as
indicated on the rating plate of
the appliance.
The blender jug is not positioned
correctly on the motor unit.
Check that the blender jug
is positioned properly on the
motor unit as explained in the
instructions.
The power switch is on OFF
position.
Follow the instructions for
starting your appliance.
In case of software bug. Unplug the appliance, wait few
minutes and plug in again.
The appliance stopped
while in use Overload Follow the instructions in section Overload.
Excessive vibrations
The product is not placed on a
flat surface.
Place the appliance on a flat
surface.
Volume of ingredients is too high. Reduce the quantity of
ingredients processed.
Leak from the lid
Volume of ingredients is too high. Reduce the quantity of
ingredients processed.
The lid is not correctly positioned Place the lid correctly on the
blender jug.
Leak from the bottom of
the blender jug
The blades are not correctly
positionned
Fit the locking ring (B3, C3)
(Fig.2) and lock it by rotating
to lock notch in the clockwise
direction (Fig. 2).
Make sure the locking ring is
locked correctly : the point on
the jar must be aligned with the
lock (Fig 9)
The blades do not turn
easily
Pieces of food too large or too
hard.
Reduce the size or quantity of
ingredients processed.
The blended liquid is too hot and
distorted the silicone gasket.
Replace the gasket with a new
one.
Leak from the bottom
of the OTG bottle The blades are not correctly
positionned
Place the blades unit on the
top of the bottle and lock it by
rotating to lock notch in the
clockwise direction (Fig. 9).

8
描述
A 1頂部中心圓蓋
2攪拌瓶蓋
3聚酯攪拌瓶
B* 1密封膠邊
2Powelix刀頭組件
3鎖定環
C* 1密封膠邊
2 Powelix life鈦金屬塗層刀頭
組件
3鎖定環
D 摩打座
E* 1隨行杯蓋
2隨行杯
3密封膠圈
4 Powelix life鈦金屬塗層刀頭
組件
5鎖定環
F 攪拌棒
G 「Start/Stop」(開始/停止) 鍵
H 螢幕
I 攪拌瓶鎖定指示燈
J 隨行杯鎖定指示燈
K 控制螢幕
L 設定鍵
M 攪拌鍵
N 清潔鍵
注意：
使用本產品時請遵照安全指示。首次使用本產品前請先仔細閱讀安全
措施說明。並妥為保存，留待日後參考。攪拌瓶或隨行杯必須正確安
裝在摩打組(D)上，且杯蓋已鎖好，本產品才會啟動。
初次使用本產品前
初次使用本產品前，請用肥皂水沖洗所有與食物接觸的部分（攪拌
瓶、隨身杯、蓋子、頂部中心圓蓋）。
注意事項：請勿將本產品浸在水裏（包括摩打組及攪拌瓶座）。切勿
用水沖洗摩打組（D）。用濕布清潔然後小心抹乾。刀頭配件非常鋒
利。
使用本產品前請確定已移除所有包裝物。
