TEFAL RK705 User manual

EN
www.tefal.com
10-in-1 Rice & Multi-Cooker

15
6
7
9
2
3
4
17
14
13 11
12
15
16
10
8
4567
12 13 14 15
16
a
b
17
a
b
18 19
1 2 3b3a
MAX.
10 cups
8 9 1110
10 cups
MAX.

15
6
7
9
2
3
4
17
14
13 11
12
15
16
10
8
4567
12 13 14 15
16
a
b
17
a
b
18 19
1 2 3b3a
MAX.
10 cups
8 9 1110
10 cups
MAX.

1
CONTROL PANEL
13a
14a
14b
14c
14d
14e
14f
14g
14h
13b
13c
13d
13e
13f
13g

2
EN
IMPORTANT SAFEGUARDS
SAFETY INSTRUCTIONS
Read and follow the instructions for use. Keep
them safe.
• This appliance is not intended to be operated by
means of an external timer or a separate remote-
control system.*
• This appliance shall not be used by children from
0 year to 8 years.*
• This appliance can be used by children aged
from 8 years and above if they have been
given supervision or instruction concerning
use of the appliance in a safe way and if they
understand the hazards involved. Cleaning and
user maintenance shall not be made by children
unless they are older than 8 years and supervised.
Keep the appliance and its cord out of reach of
children aged less than 8 years.
• Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use of
the appliance in a safe way and understand the
hazards involved.
• Children shall not play with the appliance.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
* model with the FRY (frying) function

3
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they
do not play with the appliance.
• As this appliance is for household use only, it is
not intended for use in the following applications
and the guarantee will not apply for:
–Staff kitchen areas in shops, offices and other
working environments
–Farm houses
–By clients in hotels, motels and other residential
type environments
–Bed and breakfast type environments
• If your appliance is fitted with a removable
power cord: if the power cord is damaged, it must
be replaced by a special cord or unit available
from a authorised service centre.
• If your appliance is fitted with fixed power cord:
a if the power supply cord is damage, it must be
replaced by the manufacturer, the manufacturer’s
after-sales servicedepartment orsimilarly qualified
person in order to avoid any danger.
• The appliance must not be immersed in water or
any other liquid.
• Use a damp cloth or sponge with diswashing
liquid to clean the accessories and parts in
contact with the aliments. Rince with a damp

4
EN
cloth or sponge. Drying accessories and parts in
contact with food with a dry cloth.
• If the symbol is marked on the appliance, this
symbol means “Caution: surfaces may become
hot during use”.
• Caution: the surface of heating element is subject
to residual heat after use.
• Caution: risk of injury due to improper use of the
appliance.
• Caution: if your appliance has a removable power
cord, do not spill liquid on the connector.
• Always unplug the appliance:
–immediately after use
–when moving it
–prior to any cleaning or maintenance
–if it fails to function correctly
• Burns can occur by touching the hot surface of
the appliance, the hot water, steam or the food.
• During cooking, the appliance gives out heat and
steam. Keep face and hands away.
• Cooking appliances should be positioned in
a stable situation with the handles (if any)
positioned to avoid spillage of the hot liquids.*
• Do not get face and hands close to the steam
outlet. Do not obstruct the steam outlet.
• For any problems or queries please contact our
Customer Relations Team or consult our web site.
• The appliance can be used up to an altitude of
4000 m.

5
• For your safety, this appliance complies with the safety regulations and
directives in effect at the time of manufacture (Low-voltage Directive,
Electromagnetic Compatibility, Food Contact Materials Regulations,
Environment…).
• Check that the power supply voltage corresponds to that shown on the
appliance (alternating current).
• Given the diverse standards in effect, if the appliance is used in a country
other than that in which it is purchased, have it checked by an approved
service centre.
Connecting to the power supply
• Do not use the appliance if:
− the appliance or the cord is damaged
− the appliance has fallen or shows visible damage or does not work
properly
− In the event of the above, the appliance must be sent to an approved
Service Centre. Do not take the appliance apart yourself.
• Do not leave the cord hanging.
• Always plug the appliance into an earthed socket.
• Do not use an extension lead. If you accept liability for doing so, only
use an extension lead which is in good condition, has an earthed plug
and is suited to the power of the appliance.
• Do not unplug the appliance by pulling on the cord.
Using
• Use a flat, stable, heat-resistant work surface away from any water
splashes.
• Do not allow the base of the appliance to come into contact with water.
• Never try to operate the appliance when the bowl is empty or without
the bowl.
• The cooking function/knob must be allowed to operate freely. Do not
prevent or obstruct the function from automatically changing to the
keep warm function.
• Do not remove the bowl while the appliance is working.
• Do not put the appliance directly onto a hot surface, or any other source
of heat or flame, as it will cause a failure or danger.
• The bowl and the heating plate should be in direct contact. Any object or
food inserted between these two parts would with the correct operation.
• Do not place the appliance near a heat source or in a hot oven, as
serious damage could result.

6
EN
Environment protection first!
Your appliance contains valuable materials which can be
recovered or recycled.
Leave it at a local civic waste collection point.
• Do not put any food or water into the appliance until the bowl is in
place.
• Respect the levels indicated in the recipes.
• Should any part of your appliance catch fire, do not attempt to put it
out with water. To smother the flames use a damp teatowel.
• Any intervention should only be made by a service centre with original
spare parts.
Protect the environment
• Your appliance has been designed to run for many years. However,
when you decide to replace it, remember to think about how you can
contribute to protecting the environment.
• Before discarding your appliance you should remove the battery from
the timer and dispose of it at a local civic waste collection centre
(according to model).

7
DESCRIPTION
BEFORE THE FIRST USE
1 Steam basket
2 Measurements for water and rice
3 Removable ceramic bowl
4 Measuring cup
5 Rice spoon
6 Soup spoon
7 Lid
8 Removable inner steam shield
9 Micro pressure valve
10 Lid opening button
11 Handle
12 Rice spoon holder
13 Control panel
a “KEEP WARM/CANCEL” key
b “BROWNING” key
c “–” key - time decrease
d “START” key
e “MENU” key
f “+” key - time increase
g “DELAYED START” key
14 Function indicators
a “RICE” function
b “RISOTTO” function
c “REHEAT” function
d “OATMEAL” function
e “SLOW COOK” function
f “STEAM/SOUP” function
g “YOGURT” function
h “BAKING” function
15 Housing
16 Heating element
17 Power cord
Unpack the appliance
• Remove the appliance from the packaging and unpack all the accessories
and printed documents.
• Open the lid by pushing the opening button located on the housing –
fig.1.
Read the instructions and carefully follow the operating method.
Clean the appliance
• Remove the ceramic bowl – fig.2, the steam shield and the pressure
valve – fig.3a and 3b.
• Clean the bowl, the valve and the steam shield with a sponge and
dishwashing liquid.
• Wipe the outside of the appliance and the lid with a damp cloth.
• Dry off carefully.
• Put all the elements back in their original position. Install the steam
shield in the right positions on the top lid of machine. Then, put the
steam shield behind the 2 ribs and push it on the top until it’s fixed.
Install the detachable cord into the socket on the cooker base.
• Insert the spoon holder on the base of the appliance – fig.4.
