Tektronix AFG1022 Manual

AFG1000 Series
Arbitrary/Function Generator
Quick Start User Manual
*P077113001*
077-1130-01

AFG1000 Series
Arbitrary/Function Generator
Quick Start User Manual
www.tektronix.com
077-1130-01

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Warranty
Tektronix warrants that the product will be free from defects in materials and workmanship for a period of three (3)
years from the date of original purchase from an authorized Tektronix distributor. If the product proves defective
during this warranty period, Tektronix, at its option, either will repair the defective product without charge for parts
and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement
products used by Tektronix for warranty work may be new or
reconditioned to like new performance. All replaced
parts, modules and products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration
of the warranty period and make suitable arrangements for the performance of service. Customer shall be
responsible for packaging and shipping the defective product to the service center designated by Tektronix,
shipping charges prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for the return of the
product to Customer if the shipment is to a location within the country in which the Tektronix service center is
located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for
products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty of
servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W16 – 15AUG04]

AFG1000 Series Quick Start User Manual
i
Table of contents
Preface .......................................................................................................................................................iii
Where to find more information..........................................................................................................iii
Conventions used in this manual.........................................................................................................iii
Service offerings .................................................................................................................................iv
Getting started ............................................................................................................................................ 1
General features.................................................................................................................................... 1
Before installation ................................................................................................................................ 1
Standard accessories............................................................................................................................. 2
Operating requirements........................................................................................................................ 3
Power the instrument on and off .......................................................................................................... 4
Change instrument settings at power-on .............................................................................................. 5
Erase waveforms from memory ........................................................................................................... 6
Select a local language ......................................................................................................................... 7
Protect your instrument from misuse ................................................................................................... 8
General care ......................................................................................................................................... 9
Update your instrument firmware ...................................................................................................... 10
Equivalent output circuits................................................................................................................... 13
Instrument front panel, interface, and rear panel ....................................................................................... 14
Front panel overview.......................................................................................................................... 14
Parts of the screen interface ............................................................................................................... 15
Default setup ...................................................................................................................................... 16
Select waveform................................................................................................................................. 18
Select run mode.................................................................................................................................. 20
Adjust waveform parameters ............................................................................................................. 21
Channel select .................................................................................................................................... 22
Channel output On/Off....................................................................................................................... 22
Display both channels ........................................................................................................................... 22
Rear panel........................................................................................................................................... 23
Operating basics........................................................................................................................................ 24
Quick tutorial: How to select a waveform and adjust parameters...................................................... 24
Quick tutorial: How to generate a sine waveform.............................................................................. 25
Quick tutorial: Instrument help system .............................................................................................. 26
Generate a pulse waveform................................................................................................................ 27
Generate a built-in waveform............................................................................................................. 28
Create/save a user-defined waveform ................................................................................................ 30
Recall a user-defined waveform......................................................................................................... 32
Generate noise.................................................................................................................................... 34
Generate DC....................................................................................................................................... 34

Table of contents
ii
AFG1000 Series Quick Start User Manual
Sweep a waveform .............................................................................................................................35
Modulate a waveform.........................................................................................................................37
Generate a burst waveform.................................................................................................................45
Copy channel setting ..........................................................................................................................47
USB memory device ..........................................................................................................................48
Utility menu........................................................................................................................................49
Save/recall instrument setup...............................................................................................................52
Application examples ...............................................................................................................................54
Output the waveform created with ArbExpress..................................................................................54
Appendix A: Line fuse replacement..........................................................................................................56
Index .........................................................................................................................................................57

AFG1000 Series Quick Start User Manual
iii
Preface
This manual describes the installation and operation of Tektronix AFG1000
Series
Arbitrary/Function Generator along with basic operations and concepts.
The following instruments are supported by this manual:
AFG1022 Arbitrary/Function Generator:
2-CH, 25 MHz bandwidth, 125 MS/s sampling rate, 14-bit vertical resolution
AFG1062 Arbitrary/Function Generator:
2-CH with two equal strong functionality, 60 MHz bandwidth, 300 MS/s sampling rate
Where to find more information
The following table lists related documentation available for your instrument.
The documentation is available on the Product Documentation CD and on the
Tektronix Web site (www.tektronix.com/manuals).
Item
Purpose
Location
Important
safety
and
compliance
instructions
Compliance and safety
instructions
Built-in Help
UI Help and Operation
Quick Start
User Manual
Unpacking, Installation,
Tutorials, Operation,
and Overviews
Programmer
Manual
Programming
Information
Technical
Reference
Specifications and
performance
verification procedures
Conventions used in this manual
The following icons are used throughout this manual.
Front panel power Connect power USB
The soft keypad along the right side of the display are called bezel buttons in this
manual.

iv
AFG1000 Series Quick Start User Manual
Preface
Service offerings
Tektronix provides service to cover repair under warranty and other services
that are designed to meet your specific service needs.
Tektronix warrants this product as describe in the warranty statement at the
front of this manual. Tektronix technicians provide warranty service at most
Tektronix service locations worldwide.
Please contact your local Tektronix representative for more information on
any repair or adjustment service.

AFG1000 Series Quick Start User Manual
1
Getting started
General features
Each AFG1000 Series Arbitrary/Function Generator offers the functionality
of three
generators in one, and a frequency counter:
25 MHz / 60 MHz Function Generator
12.5 MHz / 30 MHz Pulse Generator
14-bit Arbitrary Waveform Generator
200 MHz Frequency Counter
The following table describes some of the general features of your instrument.
Feature
AFG1022
AFG1062
Channel
2
2
Sine
25 MHz
60 MHz
Pulse
12.5 MHz
30 MHz
Arbitrary waveform
2 to 8,192 points, 14-bit
2 to 1 M points, 14-bit
Sampling Rate
125 MS/s
300 MS/s
Amplitude
High Z 2 mV
p-p
- 20 V
p-p
50
Ω1 mVp-p - 10 Vp-p
High Z ≤ 25 MHz: 2 mVp-p to 20 Vp-p
> 25 MHz: 2 mVp-p to 10 Vp-p
50 Ω
≤ 25 MHz: 1 mVp-p to 10 Vp-p
> 25 MHz: 1 mVp-p to 5 Vp-p
Display
Color TFT LCD
Color TFT LCD
Interface
USB
USB
Help system
Instrument help available in multiple languages
Instrument help available in multiple languages
Before installation
Inspect the instrument carton for external damage. If the carton is damaged,
notify the carrier.
Remove the instrument from its package and check that it has not been damaged in
transit. Verify that the carton contains the instrument and its standard accessories.

Getting started
2
AFG1000 Series Quick Start User Manual
Standard accessories
Unpack the instrument and check that you received all items listed as Standard
Accessories. Check the Tektronix Web site (www.tektronix.com) for the most
current information.
Standard accessories
Description
Tektronix part
number
AFG1000 Series Arbitrary/Function Generator Safety and
Compliance Instructions
071-3434-xx
AFG1000 Series Documentation CD containing the following
PDF documents:
063-4562-xx
AFG1000 Series Arbitrary/Function
Generators Quick Start User Manual
English
077-1130-xx
Simplified Chinese
077-1131-xx
Russian*
077-1135-xx
Japanese*
077-1166-xx
AFG1000 Series Arbitrary/Function
Generators Programmer Manual
077-1129-xx
AFG1000 Series Arbitrary/Function
Generators Specif
ications and
Performance Verification Manual
077-1132-xx
Packing list
Power cord (220 V, 50 Hz, China)
161-0390-xx
Certificate of calibration
001-1657-xx
USB cable x 1
174-6604-xx
BNC cable x 2
161-0389-xx
*
Russian and Japanese Quick Start User Manuals are only available for download by part number at
www.tektronix.com.

Getting started
AFG1000 Series Quick Start User Manual
3
Operating requirements
The following information and figure describe temperature, clearance, and power
supply operating requirements of the instrument.
229.16 mm
(9.02 in)
306.36 mm
(12.06 in)
111.16 mm
(4.38 in)
Figure 1: Instrument dimensions
Environmental
requirements
Clearance. When placing the instrument on a cart or bench, observing the
following clearance requirements:
Sides: 50 mm (2 in)
Rear: 50 mm (2 in)
Temperature. Before operating the instrument, ensure the ambient temperature is
between 0 °C to +40 °C (+32 °F to +104 °F).
CAUTION. To ensure proper cooling, keep both sides of the instrument clear of
obstructions.
Power supply
requirements
Source voltage and frequency. 220 - 240 VAC, 100 - 120 VA C , 50/60 Hz, CAT Ⅱ.
Power Consumption. AFG1022: Less than 28 W
AFG1062: Less than 35 W
WARNING. To reduce the risk of fire and shock, ensure that the mains supply
voltage fluctuations do not exceed 10% of the operating voltage range.

Getting started
4
AFG1000 Series Quick Start User Manual
Power the instrument on and off
The following procedures show you how to apply power to the instrument and
turn it on and off.
Power on To turn apply power to the instrument and turn it on, do the following:
CAUTION. The instrument can be damaged if the line selector switch on the rear
panel is in the incorrect position when power is applied to the instrument. To avoid
damaging the instrument, verify that the line selector switch is in the correct
position for your area before connecting the power cord.
1. Switch the line selector
to the correct position.
2. Peel off the label on the
power receptacle and if
needed, replace the fuse
according to the line
setting (refer to
Appendix A for the steps
of fuse replacement)
before inserting the AC
power cord. Insert the
AC power cord into the
power receptacle on the
rear panel and the other
end into a properly
grounded power outlet.
3. Push the front-panel
power button to power
on the instrument.
Power off To turn the instrument off, do the following:
1. Push the
front-panel
power
button to power
off
the instrument.

Getting started
AFG1000 Series Quick Start User Manual
5
Change instrument settings at power-on
The default settings are restored when you power on the instrument. You can
change the power-on settings to the last powered-off settings from the Utility
menu using the following procedure.
1. Push the front-panel
Utility button.
2. Press System.
3. Press Power On to select
from the following the
power on settings.
Default restores the
default settings when
the instrument is
powered on.
Last restores the
same settings as when
the instrument was
last powered off.

Getting started
6
AFG1000 Series Quick Start User Manual
Erase waveforms from memory
You can erase all waveforms from the instrument internal memory using the
following procedure.
1. Push the Arb panel button.
2. Press Others.
3. Press File browse to
enter the file system.
4. Use the general purpose
knob to select INTER, and
then press Enter.
5. Press Secure.
6. Press Select to erase all
waveforms stored in
internal memory, or press
Cancel to cancel the
operation.

Getting started
AFG1000 Series Quick Start User Manual
7
Select a local language
When you power on the instrument for the first time, English is selected by
default.
After you select a desired language, all the bezel menus, pop-up
messages, and
built-in help are displayed in the specified language.
1. Push the front-panel Utility
button.
2. Press System.
3. Press Language to select
the desired language.
You can select from English,
and Simplified Chinese.

Getting started
8
AFG1000 Series Quick Start User Manual
Protect your instrument from misuse
Check input and output
connectors
When connecting a cable, be sure to distinguish the input connector from the
output connectors to avoid making wrong connection.
1. Locate the channel output
on the front panel. Out1
means CH1 output and
Out2 means CH2 output.
2. Locate the Ref Clk Out
on the rear panel.
3. Locate the Ref
Clk/Counter In, Fsk/Ext
Trig In and Ext Mod In
connectors on the rear
panel.
CAUTION. The instrument can be damaged when applying external voltages or
shorting the output pins. To avoid damaging the instrument, do not short the output
pins or apply external signals to the output connectors.
CAUTION. The instrument can be damaged when applying excessive inputs over
+5 V to Trigger Input connector. To avoid damaging the instrument, do not apply
excessive inputs over +5 V to Trigger Input connector.

Getting started
AFG1000 Series Quick Start User Manual
9
General care
Protect the instrument from adverse weather conditions. The instrument is not
waterproof. Do not store or leave the instrument where the display will be exposed
to direct sunlight for long periods of time.
CAUTION. To avoid damage to the instrument, do not expose it to sprays,
liquids, or solvents.
Preventive maintenance Preventive maintenance mainly consists of periodic cleaning. Periodic cleaning
reduces instrument breakdown and increases reliability. Clean the instrument as
needed, based on the operating environment. Dirty conditions might require more
frequent cleaning than computer room conditions.
Clean the flat panel display surface by gently rubbing the display with a cleanroom
wipe. If the display is very dirty, moisten the wipe with distilled water or a 75%
isopropyl alcohol solution and gently rub the digital surface. Avoid excess force or
you might damage the display surface.
Clean the exterior surfaces with a dry, lint-free cloth or a soft bristle brush. If dirt
remains, use a cloth dampened with a 75% isopropyl alcohol solution. A swab is
useful for cleaning in narrow spaces around the controls and connectors. Do not
use abrasive compounds on any part of the instrument.
To avoid damaging the instrument, follow these precautions:
Avoid getting moisture inside the instrument during external cleaning and use
only enough to dampen the cloth or swab.
Do not wash the front-panel power switch. Cover the switch while washing the
instrument.
Use only deionized water when cleaning. Use a 75% isopropyl alcohol
solution as a cleanser and rinse with deionized water.
Do not use chemical cleaning agents; they can damage the instrument. Avoid
chemicals that contain benzene, toluene, xylene, acetone, or similar solvents.

Getting started
10
AFG1000 Series Quick Start User Manual
Update your instrument firmware
Use the front-panel USB connector to update your instrument firmware using a
USB memory device.
USB memory device requirements: This instrument supports a USB memory
device with a FAT32 or FAT16 file system. If the USB memory device doesn't
work properly, format it into the FAT32 or FAT16 format and try again; or try
another USB memory device.
CAUTION. Updating your instrument firmware is a sensitive operation which
might damage your instrument if you do not follow all instructions carefully. To
prevent
damage to the instrument, do not remove the USB memory device or power
off the
instrument during the update process.
NOTE: The screen images of the following procedure are provided as an example.
The actual screen display might be different depending on your instrument
configuration.
1. Push the front-panel
Utility button to display
the Utility menu and view
the currently installed
firmware version on the
display screen.
2. From a PC, visit
www.tektronix.com and
check if Tektronix offers a
newer firmware version.
Download and unzip the
compressed zip file. Copy
the designated firmware
file onto a USB memory
device.
3. Insert the USB memory
device into the front-panel
USB connector on your
instrument.
