Introduction
These instructions provide the installation procedure for the generator and special
function modules for the TG700 mainframe. These instructions also provide the
firmware upgrade procedure for the TG700 mainframe.
These instructions are composed of the following sections:
Firmware Upgrade describes how to upgrade the firmware of the TG700
mainframe.
Installation Instructions describes how to install and remove modules from
the TG700 mainframe.
Entering the Option Key (SDI7 OPtion 3G only) describes how to enter the
option key that is required to enable Option 3G on the SDI7 module.
For detailed information about module features and specifications, refer to the
TG700 TV Signal Generator Platform User Manual and the TG700 TV Signal
Generator Platform Specifications and Performance Verification Technical
Reference included on the TG700 CD-ROM.
Standard Accessories
The following accessories are shipped with each module:
TG700 TV Signal Generator Platform Module Installation Instructions,
Tektronix part number: 075-0986-XX
TG700 Signal Generator Platform Software Library CD-ROM, Tektronix
part number: 020-2721-XX
TG700 Module Installation 1

Firmware Upgrade
Firmware Upgrade
This section describes how to upgrade the firmware of the TG700 mainframe.
You do not need to upgrade the instrument firmware if the firmware version
ontheCD-ROMprovidedwiththiskitisthesameasthefirmware version
already installed on your TG700 mainframe. In this case, proceed to Installation
Instructions. (Seepage10.)
CAUTION. If the firmware version of the CD-ROM provided with this kit is later
than the firmware version installed on your TG700 mainframe, be sure to upgrade
the firmware of the mainframe before installing the module.
Equipment Required
The following equipment is required to upgrade the firmware:
PC with Windows 2000/Vista/XP/7 and Ethernet interface installed
10 BASE-T Ethernet cable (crossover or straight)
TG700 Signal Generator Platform Software Library CD-ROM provided with
the new module
2TG700 Module Installation

Firmware Upgrade
Mainframe Memory Requirements
With software version 5.6, the TG700 mainframe must have at least 32 MB of
memory installed. If you intend to install frame picture files (*.pic), created by the
Frame Picture Generator application for the DVG7, HDVG7, AVG7, or AWVG7
modules, or if you intend to install bitmap frame picture files (*.bmp) for the SDI7
module, then the mainframe must have 64 MB of memory installed.
Software Upgrades If your existing mainframe has 32 MB of memory and you have loaded the TG700
memory with frame picture files, you may not be able to upgrade the instrument to
software version 5.6.
If you receive a memory error while attempting to upgrade the software version,
you need to either delete some of the frame picture files or upgrade your
instrument to 64 MB of memory.
Memory Upgrades Option FP provided extra memory, which allowed the TG700 mainframe to
support the Frame Picture Generator application. This option is no longer
necessary for new TG700 mainframes.
If you have an older mainframe with less than 64 MB of memory, you can increase
the memory in your mainframe to 64 MB by ordering the following upgrade kit:
040-1698-xx. Contact your local Tektronix representative for more information.
TG700 Module Installation 3

Firmware Upgrade
Upgrade Procedures
NOTE. Refer to Mainframe Memory Requirements before you perform the
upgrade procedures. (See page 3.)
Perform the following procedure to upgrade the firmware. It is not necessary to
uninstall the earlier version.
1. If you are connecting the TG700 directly to a PC:
a. Using a crossover Ethernet cable, connect between the 10 BASE-T port
on the TG700 and the Ethernet port or NIC on the PC.
b. Power on the TG700 and the PC.
c. Identify the PC’s IP address and subnet mask.
NOTE. You can find the PC’s IP address and subnet mask by bringing up the
“Command Prompt”, using the “Startup” menu under “Accessories” and
typing “ipconfig” at the prompt.
d. Set the IP address of the TG700 such that all the digits are the same except
for the last digit, which should be changed by 1.
e. Set the subnet mask of the TG700 to the same subnet as the PC.
f. Proceedtostep4.
4TG700 Module Installation

Firmware Upgrade
2. If you are connecting the TG700 to your local Ethernet network using a
static IP address:
CAUTION. Using an IP address that is already in use can cause network conflicts,
resulting in system instability and/or the system locking up. Ensure that the IP
address is not already in use before connecting to the network. Contact the
network administrator for assistance.
a. Power on the TG700.
b. Set the IP address of the TG700 as specified by the network administrator.
c. Set the subnet mask of the TG700 as specified by the network
administrator.
d. Using a straight Ethernet cable, connect between the 10 BASE-T port
on the TG700 and the Ethernet hub port of your local network. By
connecting to an Ethernet network, you can access the TG700 using any
PC on the network.
e. PoweronaPCconnectedtothenetworkandproceedtostep4.
3. If you are connecting the TG700 to your local Ethernet network using a
DHCP server (dynamically allocated IP addresses):
a. Power on the TG700.
b. Set the NET SETUP:DHCP setting to Enable on the TG700.
c. Power off the TG700.
d. Using a straight Ethernet cable, connect the 10 BASE-T port on the
TG700 to the Ethernet hub port of your local network. By connecting to
an Ethernet network, you can access the TG700 using any PC on the
network.
e. Power on the TG700 and a PC connected to the network.
f. Identify the IP address assigned to the TG700 by the DHCP server.
g. Proceed to step 4.
TG700 Module Installation 5

Firmware Upgrade
4. Insert the TG700 Signal Generator Platform SW Library and Documentation
CD−ROM provided with the new module into the CD drive on your PC.
5. When the Product Software and Documentation Browser window appears,
select the Mainframe and Module Software link.
6. Select one of the following upgrade options:
SelectUpgrade to V5.X if your mainframe has 32 MB or more of memory.
Select Upgrade to V4.1 if your mainframe has 16 MB of memory.
The PC will open a Windows Explorer window displaying the contents of
the selected upgrade folder.
NOTE. With software version 5.6 and later, it is strongly recommended that
the TG700 mainframe have 64 MB of memory if you intend to install logo
and/or frame picture files into a DVG7, HDVG7, or SDI7 module. (See page 3,
MainframeMemoryRequirements.)
6TG700 Module Installation

Firmware Upgrade
7. Double-click the tgUpgrade.exe icon in the folder. The TG700 Upgrade
dialog box appears as shown in the following figure.
Figure 1: TG700 Upgrade dialog box
NOTE. In the following cases, an error message appears when you double-click
the tgUpgrade.exe icon. If this happens, copy all of the files in the Upgrade folder
to the hard disk, and then repeat the operation.
■When you upgrade the TG700 with firmware version 1.3 or earlier and use the
ATG7, AVG7, or AWVG7 module in it.
■When you upgrade the TG700 with firmware version 2.1 or earlier and use the
AVG7 or AWVG7 module in it.
TG700 Module Installation 7

Firmware Upgrade
8. In the dialog box, enter the IP address that you assigned to your TG700.
9. If you want to download the signals for the specified module(s), use the check
boxes at the bottom of the dialog box. Normally, you do not need to select
any check boxes. Select the appropriate check box(es) in the following cases:
ATG7 check box: when you upgrade the TG700 mainframe with firmware
version 1.3 or earlier and use the ATG7 module in the mainframe.
AVG7 check box: when you upgrade the TG700 mainframe with firmware
version 2.1 or earlier and use the AVG7 module in the mainframe.
AWVG7 check box: when you upgrade the TG700 mainframe with
firmware version 2.1 or earlier and use the AWVG7 module in the
mainframe.
10. Click the Copy button. The PC will start transferring the files in the Upgrade
folder to the TG700.
CAUTION. Do not power off the TG700 until the file transfer is complete. Doing
so will prevent the instrument from starting up normally.
11. When the file transfer is complete, the message box shown below appears.
Figure 2: Message box appearing after the file transfer is complete
12. Click the OK button in the message box.
13. Disconnect the power cable from the power cord connector on the TG700 rear
panel, and then connect it again to restart the instrument.
8TG700 Module Installation

Firmware Upgrade
14. If your TG700 includes an HDLG7 module, proceed with the following steps
to complete the upgrade:
CAUTION. While upgrading, do not press the front panel buttons or cycle the
instrument power. Doing so can corrupt the module memory and FPGA image.
a. Power on the TG700.
b. Press theMODULE button until the name of the module you are
upgrading appears.
c. Press and hold the ENTER button until “Upgrade FPGA” appears .
d. Press the ENTER button to upgrade the module.
e. The upgrade will take approximately three minutes. After it is complete,
remove power from the TG700 and then reapply power to reboot the
system.
NOTE. If you are upgrading the FPGA of multiple modules, you need to upgrade
them separately and reboot the instrument after each upgrade. For example, if
you have three HDLG7s, the FPGA upgrade process sequence will be: select and
upgrade a module, then reboot, then select and upgrade another module, then
reboot, select and upgrade the final module, then reboot. You do not need to
upgrade the modules in any particular order.
Firmware Version Check
Perform the following procedure to verify that the new firmware version was
properly installed:
1. Press the front-panel MODULE button to display the TG700 main menu.
2. Use the up (▲)ordown(▼) arrow button to select UTILITY, and then press
the ENTER button.
3. Use the up (▲) or down (▼) arrow button to select VERSION INFO (F/W).
4. Use the left (◄)orright(►) arrow button to select CPU[0].
5. Check that the new firmware version number is displayed in the menu.
Refer to the Release Notes included on the CD-ROM for information about the
new firmware version.
TG700 Module Installation 9

Installation Instructions
Installation Instructions
This section provides procedures for installing and removing modules from the
TG700 mainframe. A screwdriver with a #1 Phillips tip is the only tool you need
to install or remove a module.
CAUTION. To prevent damage to the mainframe and module, always remove the
power cord before installing or removing a module.
If the software version of the provided CD-ROM is later than the firmware version
of your TG700 mainframe, be sure to upgrade the firmware of the mainframe
before installing the module. (See page 2, Firmware Upgrade.)
Preventing Component Damage
CAUTION. Electrostatic discharge (ESD) can damage components on this module
and mainframe. To prevent ESD or other component damage, follow the steps
below when installing, removing, or handling modules:
Wear a grounded antistatic wrist strap to discharge the static voltage from
your body while installing or removing modules from the TG700 mainframe.
Transport and store modules in a static-protected bag or container.
Do not slide the module over any surface.
Handle modules as little as possible.
Do not touch module components or connector pins.
Do not use any devices capable of generating or holding a static charge in the
work area where you remove, install, or handle modules.
Avoid handling modules in areas that have a floor or work-surface covering
capable of generating a static charge.
10 TG700 Module Installation

Installation Instructions
Installing a Module
To install a module into an empty slot in the mainframe, perform the following
procedure:
1. Unplug the power cord from the power connector on the rear panel of the
mainframe.
2. Use the following guidelines to select the slot where you will install the
module. The following figure shows a sample module configuration with
the associated slot numbers.
For AGL7 and GPS7 modules, only one of these modules can be installed
in the TG700 mainframe at a time, and it must be installed only in slot 1.
All other modules may be installed in any slot location.
CAUTION.When installing a GPS7 module into an existing mainframe, you
must perform the TG700 mainframe oven calibration procedures. Refer to
the Configure the GPS7 Module section in the TG700 TV Signal Generator
Platform User Manual for instructions.
For AG7, ATG7, AVG7, BG7, DVG7, HDLG7, and SDI7 modules, up to
four of the modules can be installed in the TG700 mainframe.
The HD3G7, AWVG7, and HDVG7 modules consume higher power
than most of the TG700 modules. Because of this, there can only be
a maximum of three of these modules installed at one time. If an
HDVG7 module that has a rear-panel fan is installed, then only one other
high-power module may be installed with it.
When the maximum number of these high-power modules are installed
the lower-power modules (AG7, ATG7, AVG7, BG7, DVG7, HDLG7, or
SDI7) may be installed in any of the remaining available slots.
Figure 3: TG700 slot numbering
3. Use a screwdriver with a #1 Phillips tip to loosen the two screws of the blank
panel attached to the slot you want to use, and then pull it away from the
instrument. Save the blank panel for future use. (See Figure 4.)
If you are installing a new module into a slot that already contains a module,
remove the existing module. (See page 15, Removing a Module.)
TG700 Module Installation 11

Installation Instructions
Figure 4: Removing the blank panel
CAUTION. Be careful not to damage the parts and cables inside of the module
when you insert the module into the mainframe.
4. Insert the module into the slot, paying attention to the module orientation.
(See Figure 5.) Push the module into the slot until the connector board of the
module is firmly engaged with the Main board of the mainframe.
Figure 5: Installing the module
12 TG700 Module Installation

Installation Instructions
5. Tighten the two screws to secure the module to the mainframe. (See Figure 6.)
Figure 6: Securing the module
Entering the Option Key (SDI7 Option 3G only)
If you ordered Option 3G with the SDI7 module, you must enter the option key
that was supplied with the module in order to enable the 3G software option.
Each option key applies to only one SDI7 module. You will need to enter the
option key only once. After the option key is entered, the option key stays with
that SDI7 module, enabling Option 3G even when the module is moved to another
TG700 platform that is running software version 5.6 or above.
Locate the option key document, and then perform the following steps to enter
the option key:
1. Press the front-panel MODULE button until the mainframe main menu is
displayed as shown below.
2. Press the up (▲)ordown(▼) arrow button until TG700 : UTILITY is
displayed, and then press the ENTER button.
TG700 Module Installation 13

Installation Instructions
3. Press the up (▲)or down (▼) arrow button until TG700 : UTILITY :
OPTIONS ENABLED is displayed. The bottom line of the display will
list the slot number in which the SDI7 module is installed and will indicate
whether option 3G is enabled: None is displayed when the option is not
enabled, 3G is displayed when the option is enabled.
4. If more than one SDI7 module is installed in the mainframe, use the left
(◄)orright(►) arrow button to select the desired module, and then press
the ENTER button.
5. Press the up (▲)ordown(▼) arrow button until TG700 : UTILITY :
MODULE ID is displayed.
6. Verify that the displayed module ID matches the module ID listed on the
option key document.
7. Enter the option key:
a. Press the up (▲)ordown(▼) arrow button until TG700 : UTILITY :
OPTION KEY is displayed. When Option 3G is not enabled, the option
key string is blank as shown below.
b. Press the ENTER button to enter the option key edit mode. The
underscore character (_) appears under the first character of the option key.
c. Use the up (▲) or down (▼)arrowbuttontoselectthefirst character of
the option key.
d.Use the left (◄)orright(►) arrow button to move the underscore
character to the next character in the option key.
e. Enter all of the option key characters, and then press ENTER button to
confirm the selection.
f. Press the CANCEL button twice to exit the UTILITY submenu. This
returns to the top of the UTILITY submenu.
14 TG700 Module Installation

Installation Instructions
8. Verify that Option 3G is enabled:
a. Press theENTER button to enter the UTILITY submenu.
b. Press the up (▲)ordown(▼) arrow button until TG700 : UTILITY :
OPTIONS ENABLED is displayed.
c. Verify that SDI7[ slot number ]3Gis displayed. This indicates that
Option 3G has been enabled.
d. Press the CANCEL button to exit the UTILITY submenu. This returns to
the mainframe main menu.
Removing a Module
To remove a module from the mainframe, perform the following procedure:
CAUTION. To facilitate module removal, attach terminations or BNC cables to the
module connectors. The connector may be damaged if too much force is applied
to it during module removal.
1. Unplug the power cord from the power connector on the mainframe rear panel.
2. Attach 75 Ωterminations or BNC cables to the BNC connectors on the
module to be removed. Module removal becomes easier if the terminations or
cables are attached to the connectors at the left and right ends.
3. Use a screwdriver with a #1 Phillips tip to loosen the two screws securing
the module to the mainframe.
CAUTION. Be careful not to damage the parts and cables inside of the module
when you remove the module from the mainframe.
TG700 Module Installation 15

Installation Instructions
4. Pull the module slowly toward you while supporting the terminations or BNC
cables attached to the connectors. (See Figure 7.)
Figure 7: Removing the module
5. If this empty slot will not be used, you must attach a blank panel to the
mainframe to control instrument cooling and EMI emissions.
a. Align the blank panel with the open slot of the mainframe.
b. Tighten the two screws to secure the blank panel to the mainframe.
A blank panel is available as an optional accessory for the
TG700 mainframe. Refer to the TG700 TV Signal Generator Platform
User Manual.
6. If you want to install another module into the slot from which the module is
removed, perform Installing a Module. (Seepage11.)
16 TG700 Module Installation
