Tektronix B020000 User manual

User Manual
SPG422
Component Digital Sync Generator
S/N B020000 and above
071-0034-02
This document supports firmware version 1.5.0
and above.
www.tektronix.com

Copyright ©Tektronix, Inc. All rights reserved.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supercedes
that in all previously published material. Specifications and price change privileges reserved.
Tektronix, Inc., P.O. Box 500, Beaverton, OR 97077
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.

WARRANTY
Tektronix warrants that the products that it manufactures and sells will be free from defects in materials and workmanship
for a period of one (1) year from the date of shipment. If a product proves defective during this warranty period, Tektronix,
at its option, either will repair the defective product without charge for parts and labor, or will provide a replacement in
exchange for the defective product.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the
warranty period and make suitable arrangements for the performance of service. Customer shall be responsible for
packaging and shipping the defective product to the service center designated by Tektronix, with shipping charges prepaid.
Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the
Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any
other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting
from attempts by personnel other than Tektronix representatives to install, repair or service the product; b) to repair
damage resulting from improper use or connection to incompatible equipment; c) to repair any damage or malfunction
caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or integrated with other
products when the effect of such modification or integration increases the time or difficulty of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR
IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TEKTRONIX’ RESPONSIBILITY TO
REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO
THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL NOT BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE
OF WHETHER TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH
DAMAGES.

SPG422 Component Digital Sync Generator User Manual i
Table of Contents
General Safety Summary vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Preface ix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
About This Manual ix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Related Manuals ix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contacting Tektronix x. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Getting Started
Getting Started 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Packaging 1–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Product Description 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front-Panel Controls 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear-Panel Connectors 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Basics
Operating Basics 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Genlock 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Genlock Video Standard 2–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Genlock Input Configuration 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Genlock Timing 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Black Signals 2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bars Signals 2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial Black 2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Signals 2–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Serial Signals (Option 2 only) 2–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reference
Reference 3–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Front Panel Buttons and Menu Displays 3–1. . . . . . . . . . . . . . . . . . . . . . .
Main Menu 3–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Menus Available from the Select Buttons 3–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the RS-232 Remote 3–31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
RS-232 Command Summary 3–33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Command Information 3–38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Explanation of the Parser Commands 3–39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DIAGNOSTIC Commands 3–40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISPLAY Commands 3–42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INPUT Commands 3–42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OUTPUT Commands 3–44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STATUS Commands 3–52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SYSTEM Commands 3–54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Ground-Closure Remote 3–56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appendix
Appendix A: Specifications A–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents
ii SPG422 Component Digital Sync Generator User Manual
Performance Conditions A–1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Characteristics Tables A–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Signal Illustrations A–27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents
SPG422 Component Digital Sync Generator User Manual iii
List of Figures
Figure 1–1: Front and rear panels of the SPG 422 1–1. . . . . . . . . . . . . . . .
Figure 1–2: Illustration of the SPG 422 front panel 1–2. . . . . . . . . . . . . . .
Figure 1–3: Illustration of the SPG 422 rear panel 1–3. . . . . . . . . . . . . . .
Figure 1–4: Front rail mount 1–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 1–5: Deep rackmount and shallow rackmount 1–7. . . . . . . . . . . . .
Figure 1–6:Assembly of rackmounting hardware 1–7. . . . . . . . . . . . . . . .
Figure 1–7: Installing the instrument in the rack slides 1–8. . . . . . . . . . .
Figure 2–1: Front panel of the SPG 422 2–1. . . . . . . . . . . . . . . . . . . . . . . .
Figure 2–2: Various ways to configure the Genlock input 2–2. . . . . . . . . .
Figure 2–3: Illustration of the SPG 422 timing 2–5. . . . . . . . . . . . . . . . . .
Figure 3–1: Illustration of the SPG 422 main menu 3–2. . . . . . . . . . . . . .
Figure 3–2: How to access menus with the Select buttons 3–13. . . . . . . . . .
Figure 3–3: The Genlock menu structure 3–15. . . . . . . . . . . . . . . . . . . . . . .
Figure 3–4: The Serial bars menu structure 3–16. . . . . . . . . . . . . . . . . . . . .
Figure 3–5: The Serial Audio menu 3–19. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 3–6: Black 1 and 2 menu structure 3–25. . . . . . . . . . . . . . . . . . . . . .
Figure 3–7: Black 3 through 6 menu structure 3–26. . . . . . . . . . . . . . . . . . .
Figure 3–8: The Serial Signals menu structure 3–27. . . . . . . . . . . . . . . . . .
Figure 3–1: How to connect the terminal 3–31. . . . . . . . . . . . . . . . . . . . . . .
Figure 3–2: Pinout for ground-closure control using the Remote
connector 3–56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–1: Timing Relationship between the digital video data
and the analog line synchronization
(reference for line scanning) in the 525/60 system A–4. . . . . . . . . . . . .
Figure A–2: Timing relationship between the digital video data
and the analog line synchronization
(reference for line scanning) in the 625/50 system A–5. . . . . . . . . . . . .
Figure A–3: Relationship between the digital and analog fields, showing
also the position of the digital field-blanking interval in the
625 system A–6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–4: Relationship of video data/vertical sync in the
525 system A–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–5: 60 Hz Black burst with 7.5 IRE setup A–12. . . . . . . . . . . . . . .
Figure A–6: 60 Hz Black burst with no setup A–13. . . . . . . . . . . . . . . . . . . .
Figure A–7: 50 Hz black burst A–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–8: 75% Color Bars —Y channel A–27. . . . . . . . . . . . . . . . . . . . . .

Table of Contents
iv SPG422 Component Digital Sync Generator User Manual
Figure A–9: 75% Color Bars —CB channel A–27. . . . . . . . . . . . . . . . . . . .
Figure A–10: 75% Color Bars —CR channel A–28. . . . . . . . . . . . . . . . . . .
Figure A–11: 100% Color Bars —Y channel A–28. . . . . . . . . . . . . . . . . . . .
Figure A–12: 100% Color Bars —CB channel A–29. . . . . . . . . . . . . . . . . .
Figure A–13: 100% Color Bars —CR channel A–29. . . . . . . . . . . . . . . . . .
Figure A–14: 75% Red —Y channel A–30. . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–15: 75% Red —CB channel A–30. . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–16: 75% Red —CR channel A–31. . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–17: 100% Red —Y channel A–31. . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–18: 100% Red —CB channel A–32. . . . . . . . . . . . . . . . . . . . . . . .
Figure A–19: 100% Red —CR channel A–32. . . . . . . . . . . . . . . . . . . . . . . .
Figure A–20: EIA Bars (part of SMPTE Bars) —Y channel A–33. . . . . . .
Figure A–21: EIA Bars (part of SMPTE Bars) —CB channel A–33. . . . .
Figure A–22: EIA Bars (part of SMPTE Bars) —CR channel A–34. . . . .
Figure A–23: IWQ Bars (part of SMPTE Bars) —Y channel A–34. . . . . .
Figure A–24: IWQ Bars (part of SMPTE Bars) —CB channel A–35. . . . .
Figure A–25: IWQ Bars (part of SMPTE Bars) —CR channel A–35. . . . .
Figure A–26: Reverse Bars (part of SMPTE Bars) —Y channel A–36. . . .
Figure A–27: Reverse Bars (part of SMPTE Bars) —CB channel A–36. .
Figure A–28: Reverse Bars (Part of SMPTE Bars) —CR Channel A–37.
Figure A–29: Multiburst —Y channel A–37. . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–30: Multiburst —CB and CR channels A–38. . . . . . . . . . . . . . . .
Figure A–31: Modulated Pulse and Bar —Y channel A–38. . . . . . . . . . . . .
Figure A–32: Modulated Pulse and Bar —CB channel A–39. . . . . . . . . . .
Figure A–33: Modulated Pulse and Bar —CR channel A–39. . . . . . . . . . .
Figure A–34: Convergence (horizontal) —Y channel A–40. . . . . . . . . . . . .
Figure A–35: Convergence (horizontal) —CB and CR Channels A–40. . .
Figure A–36: Convergence (vertical) —Y channel A–41. . . . . . . . . . . . . . .
Figure A–37: Convergence (vertical) —CB and CR channels A–41. . . . . .
Figure A–38:Active Picture Markers (part of Active Picture
Timing Test Signal) —Y channel A–42. . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–39:Active Picture Markers (part of Active Picture
Timing Test Signal) —CB A–42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–40:Active Picture Markers (part of Active Picture
Timing Test Signal) —CR A–43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–41: White Bar (part of Active Picture
Timing Test Signal) —Y channel A–43. . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–42: White Bar (part of Active Picture
Timing Test Signal) —CB and CR channels A–44. . . . . . . . . . . . . . . . .

Table of Contents
SPG422 Component Digital Sync Generator User Manual v
Figure A–43: Bowtie Sweep —Y channel A–44. . . . . . . . . . . . . . . . . . . . . . .
Figure A–44: Bowtie —CB and CR channels A–45. . . . . . . . . . . . . . . . . . .
Figure A–45: Bowtie Markers —Y channel A–45. . . . . . . . . . . . . . . . . . . . .
Figure A–46: Ramp —Y channel A–46. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–47: Ramp —CB channel A–46. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–48: Ramp —CR channel A–47. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–49: Pluge —Y channel A–47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–50: Pluge —CB and CR channels A–48. . . . . . . . . . . . . . . . . . . .
Figure A–51: 40% Gray —Y channel A–48. . . . . . . . . . . . . . . . . . . . . . . . .
Figure A–52: 40% Gray —CB and CR channels A–49. . . . . . . . . . . . . . . .

Table of Contents
vi SPG422 Component Digital Sync Generator User Manual
List of Tables
Table 1–1: Front panel control, J13 1–5. . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 1–2: Front panel timeout, S1–2 1–5. . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–1: Audio sets output for each channel 3–24. . . . . . . . . . . . . . . . . .
Table A–1: Encoding parameters for serial digital video outputs A–2. . .
Table A–2: Timing relationships for serial digital video outputs A–3. . . .
Table A–3: Output Characteristics for serial digital video signals A–8. .
Table A–4: Signal Characteristics for analog black outputs
(in base instrument only) A–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table A–5: Signal Characteristics for analog black outputs
(in Option 1 only) A–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table A–6: Signal characteristics for serial bars output A–14. . . . . . . . . .
Table A–7: Signal characteristics for serial test signal
(Option 2 only) A–15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table A–8: Signal Characteristics for AES/EBU serial
digital audio outputs (XLR connectors) A–16. . . . . . . . . . . . . . . . . . . . .
Table A–9: Signal Characteristics for AES/EBU serial
digital audio outputs (BNC outputs) A–17. . . . . . . . . . . . . . . . . . . . . . .
Table A–10: Signal characteristics for embedded serial audio A–18. . . . .
Table A–11: 20-bit audio signal sample distribution for
embedded serial audio on 525/59.94 signals A–19. . . . . . . . . . . . . . . . .
Table A–12: 20-bit audio signal sample distribution for
embedded serial audio on 625/50 signals A–20. . . . . . . . . . . . . . . . . . . .
Table A–13: Audio channel status bits (serial and embedded
audio data streams) A–21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table A–14: Genlock function A–22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table A–15: Power supply A–23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table A–16: Mechanical (physical) characteristics A–24. . . . . . . . . . . . . . .
Table A–17: Environmental characteristics A–24. . . . . . . . . . . . . . . . . . . . .
Table A–18: Certifications and compliances A–25. . . . . . . . . . . . . . . . . . . .

SPG422 Component Digital Sync Generator User Manual vii
General Safety Summary
Review the following safety precautions to avoid injury and prevent damage to
this product or any products connected to it. To avoid potential hazards, use this
product only as specified.
Only qualified personnel should perform service procedures.
Use Proper Power Cord. Use only the power cord specified for this product and
certified for the country of use.
Connect and Disconnect Properly. Do not connect or disconnect probes or test
leads while they are connected to a voltage source.
Ground the Product. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, ensure that the product is properly grounded.
Observe All Terminal Ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that
exceeds the maximum rating of that terminal.
Do Not Operate Without Covers. Do not operate this product with covers or panels
removed.
Use Proper Fuse. Use only the fuse type and rating specified for this product.
Avoid Exposed Circuitry. Do not touch exposed connections and components
when power is present.
Wear Eye Protection. Wear eye protection if exposure to high-intensity rays or
laser radiation exists.
Do Not Operate With SuspectedFailures. If you suspect there is damage to this
product, have it inspected by qualified service personnel.
Do Not Operate in Wet/DampConditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Provide Proper Ventilation. Refer to the manual’s installation instructions for
details on installing the product so it has proper ventilation.
To Avoid Fire or
Personal Injury

General Safety Summary
viii SPG422 Component Digital Sync Generator User Manual
Terms in this Manual. These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Terms on the Product. These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read the
marking.
WARNING indicates an injury hazard not immediately accessible as you read the
marking.
CAUTION indicates a hazard to property including the product.
Symbols on the Product. The following symbols may appear on the product:
ProtectiveGround
(Earth)Terminal CAUTION Refer to Manual Double Insulated
WARNING
High Voltage
Symbols and Terms

SPG422 Component Digital Sync Generator User Manual ix
Preface
This manual describes the cabilities of the SPG 422 Component Sync Pulse
Generator, and its features and specifications.
To begin, refer to the first section, Getting Started. This section shows you how
to install and configure the SPG 422 for use in your operating system. For
detailed information about a feature or menu, refer to the third section,
Reference.
About This Manual
This manual is composed of the following sections:
HGetting Started provides a product description, installation instructions, and
a functional check procedure. Standard and optional accessories are also
listed.
HOperating Basics briefly describes the front panel controls and rear panel
connections.
HReference provides a detailed reference for all front panel menus and remote
control interfaces of the SPG 422.
HAppendices provide additional information, such as specifications.
Related Manuals
The following related document is also available.
HThe SPG 422 Service Manual (071–0035–XX) describes how to service the
SPG 422. This optional manual must be ordered separately.

Preface
xSPG422 Component Digital Sync Generator User Manual
Contacting Tektronix
Product
Support For questions about using Tektronix measurement products, call toll free in North America:
1-800-833-9200
6:00 a.m. –5:00 p.m. Pacific time
Or contact us by e-mail:
[email protected]
For product support outside of North America, contact your
local Tektronix distributor or sales office.
Service
support Tektronix offers a range of services, including Extended Warranty Repair and Calibration services. Contact your local
Tektronix distributor or sales office for details.
For a listing of worldwide service centers, visit our web site.
Toll-free
Number In North America: 1-800-833-9200
An operator can direct your call.
Postal
Address Tektronix, Inc.
Department or name (if known)
P.O. Box 500
Beaverton, OR 97077
USA
Web site www.tektronix.com

Getting Started

SPG422 Component Digital Sync Generator User Manual 1–1
Getting Started
This section provides the information necessary to install and become familiar
with the SPG 422 Component Digital Sync Generator in its operating environ-
ment. It includes a discussion of the rear-panel connectors, electrical and
mechanical installation, setting for the internal jumpers, and a tutorial to become
familiar with the menu and front panel operation. Figure 1–1 shows the front and
rear panel features.
Packaging
The shipping carton and pads provide protection for the instrument during
transit. Retain the shipping cartons in case subsequent shipment becomes
necessary. The Service section of this manual contains the repackaging instruc-
tions.
Front
Rear
Figure 1–1: Front and rear panels of the SPG 422

Getting Started
1–2SPG422 Component Digital Sync Generator User Manual
Product Description
The SPG 422 is a component digital, sync pulse generator (SPG). The SPG 422
provides basic setup and timing signals for component digital tape recorders and
processing equipment systems. It provides audio tones and a few simple video
test signals needed to adjust equipment and stripe video tapes. Analog black
signals are the timing reference signals of choice and the SPG 422 provides up to
six analog black signals, each with separate timing controls. Because the
SPG 422 has good frequency stability, it can perform as a stand-alone generator
or genlock to an external PAL or NTSC signal.
Some installations use 525/59.94 and 625/50 Component signals simultaneously
or switch between standards regularly. The SPG 422 architecture supports
dual-standard operation. Also important for dual-standard operation, is the ability
of the SPG 422 to output audio tones locked to the video standard(s) in use.
The SPG 422 has a front-panel interface that controls all instrument functions.
Also, you can control the SPG 422 with either a parallel ground-closure remote
or RS-232. The ground-closure remote provides simple control of a few major
instrument functions, while the RS-232 implementation is a SCPI (Standard
Commands for Programmable Instruments) command language interface, with
most of the front-panel interface capabilities.
Front-Panel Controls
Menu display Menu control buttons Select buttons Reference LEDs
Figure 1–2: Illustration of the SPG 422 front panel
The front panel has four sections: the Menu Display, the Menu Control buttons,
the Select buttons, and the Reference LEDs. (See Figure 1–2.)
This section of the front panel displays the current state of the SPG 422. Also
used in conjunction with the Select and Menu Control buttons to change the
configuration of the outputs.
This section of the front panel controls the Menu Display. The direction arrows
control scrolling through the menu, while the Enter and Exit buttons accept
Menu Display
Menu Control Buttons

Getting Started
SPG422 Component Digital Sync Generator User Manual 1–3
changes or allow you to return to your original starting point. The LOCKOUT
button is included in this group. See Installation in this section of the manual for
details on the LOCKOUT button.
Use the select button to select a specific menu.
The reference LEDs indicate whether the SPG 422 is externally genlocked or is
using its internal oscillator.
More information on these controls is available in the Operating Basics and
Reference sections of this manual.
Rear-Panel Connectors
Power Remote Serial signals
Analog black
Serial audio
Genlock
Serial
black Serial bars
Figure 1–3: Illustration of the SPG 422 rear panel
The SPG 422 rear panel contains all of the connectors for the instrument. (See
Figure 1–3.)
Power Connector. This instrument operates from a single-phase power source
with one current-carrying conductor at or near earth-ground (the neutral
conductor). Only the line conductor is fused for over current protection. Mains
frequency is 50 or 60 Hz. The operating voltage range is continuous from 90 to
250 VAC.
WARNING. To avoid dangerous electical shock, do not connect power to the
SPG 422 when the top cover is off. Dangerous potentials are present on the
Power Supply board.
Serial Bars. Serial digital color bars output. Set from the Serial Bars menu.
Serial Black. Serial Digital Black signal output. All its parameters are set by the
Serial Bars menu.
Select Buttons
Reference LEDs

Getting Started
1–4SPG422 Component Digital Sync Generator User Manual
Genlock 1 and 2. Accepts analog black burst or CW as the genlock input. Burst
locks to NTSC and PAL Composite signals, sync locks to monochrome 525 and
626 signals, and CW lock to 1, 5, 10, 4.43, and 3.58 MHz. There are two
termination options: loopthrough or single-ended. The loopthrough option
requires external termination. When using the single-ended option, both inputs
are internally terminated and you may select either as the genlock source.
Black 1. Analog black output 1. Set from the Black 1 menu.
Black 2. Analog black output 2. Set from the Black 2 menu.
Black 3. Analog black output 3 (option 1 only). Set from the Black 3 menu. (This
connector is plugged in the standard instrument.)
Black 4. Analog black output 4 (option 1 only). Set from the Black 4 menu. (This
connector is plugged in the standard instrument.)
Black 5. Analog black output 5 (option 1 only). Set from the Black 5 menu. (This
connector is plugged in the standard instrument.)
Black 6. Analog black output 6 (option 1 only). Set from the Black 6 menu. (This
connector is plugged in the standard instrument.)
Serial Signals (2). Serial Digital Test signal outputs (option 2 only). (These
connectors are plugged in the standard instrument.) Select the outputs from the
Serial signals menu.
Remote. A 9-pin D-connector. Configure it as either a 9-pin ground-closure or a
9-pin RS-232 serial remote control. Select the configuration by moving the cable
connector within the instrument.
Serial Audio 1+2 and Serial Audio 3+4 (BNC connector). AES/EBU serial digital
audio output for channels 1 & 2 and 3 & 4 respectively. Set from the Serial
Audio menu.
Serial Audio 1+2 and Serial Audio 3+4 (XLR connector). AES/EBU serial digital
audio output for channels 1 & 2 and 3 & 4 respectively. Set from the Serial
Audio menu.
