Tektronix AWG70002A Manual

AWG70001A and AWG70002A
Arbitrary Waveform Generators
Installation and Safety Instructions
*P071311004*
071-3110-04

AWG70001A and AWG70002A
Arbitrary Waveform Generators
Installation and Safety Instructions
www.tek.com
071-3110-04

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are
protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued
and pending. Information in this publication supersedes that in all previously published material. Specifications and price change privileges
reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
■In North America, call 1-800-833-9200.
■Worldwide, visit www.tek.com to find contacts in your area.

Warranty
Tektronix warrants that this product will be free from defects in materials and workmanship for a period of one (1) year from the date of
shipment. If any such product proves defective during this warranty period, Tektronix, at its option, either will repair the defective product
without charge for parts and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement
products used by Tektronix for warranty work may be new or reconditioned to like new performance. All replaced parts, modules and
products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of the warranty period and
make suitable arrangements for the performance of service. Customer shall be responsible for packaging and shipping the defective
product to the service center designated by Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to
Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible
for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care.
Tektronix shall not be obligated to furnish service under this warranty a) to repair damage resulting from attempts by personnel other than
Tektronix representatives to install, repair or service the product; b) to repair damage resulting from improper use or connection to
incompatible equipment; c) to repair any damage or malfunction caused by the use of non-Tektronix supplies; or d) to service a product
that has been modified or integrated with other products when the effect of such modification or integration increases the time or difficulty
of servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY OTHER WARRANTIES, EXPRESS
OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY. TEKTRONIX AND ITS VENDORS WILL
NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER
TEKTRONIX OR THE VENDOR HAS ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]

Table of Contents
Important safety information ................................................................................................................................ iii
General safety summary ................................................................................................................................ iii
Terms in the manual ...................................................................................................................................... iv
Terms on the product ..................................................................................................................................... v
Symbols on the product .................................................................................................................................. v
Preface ............................................................................................................................................................... vii
Key features .................................................................................................................................................. vii
Documentation .............................................................................................................................................. vii
Conventions used in this manual ................................................................................................................. viii
Install the instrument
Standard accessories ..................................................................................................................................... 1
Product options .............................................................................................................................................. 2
Product upgrades ........................................................................................................................................... 3
ReplaceableParts ........................................................................................................................................... 3
Operating requirements ................................................................................................................................. 4
Environmental requirements .................................................................................................................... 4
Power supply requirements ...................................................................................................................... 4
Cleaning ................................................................................................................................................... 4
Power on the instrument ................................................................................................................................ 5
Power off the instrument ................................................................................................................................ 6
Inspect the instrument .................................................................................................................................... 6
Self calibration ................................................................................................................................................ 7
Connecting to the instrument ......................................................................................................................... 8
Connecting to a network ........................................................................................................................... 8
Connecting peripheral devices ................................................................................................................. 9
Controlling the instrument using a remote PC ............................................................................................... 9
Preventing instrument damage ...................................................................................................................... 9
Overheat protection .................................................................................................................................. 9
Connectors ............................................................................................................................................... 9
Options and upgrades .................................................................................................................................. 10
View installed options ............................................................................................................................. 10
Install a new option key .......................................................................................................................... 11
Windows interface guidelines ....................................................................................................................... 11
AWG70000A Series Installation and Safety Instructions i

Operating basics
Front-panel connectors ................................................................................................................................ 13
Rear-panel connectors ................................................................................................................................. 15
Getting acquainted with your instrument ...................................................................................................... 16
Touchscreen interface ............................................................................................................................ 16
Front-panel controls ............................................................................................................................... 16
AWG mode general overview ................................................................................................................ 18
Functions mode general overview .......................................................................................................... 20
Run state control .................................................................................................................................... 21
Run mode ............................................................................................................................................... 22
Changing control settings ....................................................................................................................... 22
Preferences .................................................................................................................................................. 23
Basic guidelines to play a waveform ............................................................................................................ 23
Restoring instrument operating system and product software ..................................................................... 24
Operating system restore ....................................................................................................................... 24
Internal recovery utility ........................................................................................................................... 24
AWG7000A Series product software and TekVISA installation ................................................................... 24
Specifications
General characteristics ................................................................................................................................ 25
Sample clock generator characteristics ....................................................................................................... 26
Analog output characteristics ....................................................................................................................... 26
Analog AC output (AWG70001A with Option AC) ........................................................................................ 27
Marker outputs ............................................................................................................................................. 28
Flag outputs ................................................................................................................................................. 28
Auxillary outputs ........................................................................................................................................... 29
Auxiliary inputs ............................................................................................................................................ 29
Computer outputs ......................................................................................................................................... 30
Power characteristics ................................................................................................................................... 30
EMC, environment, and safety ..................................................................................................................... 30
Compliance Information
EMC compliance .......................................................................................................................................... 31
Safety compliance ........................................................................................................................................ 32
Environmental compliance ........................................................................................................................... 33
Table of Contents
ii AWG70000A Series Installation and Safety Instructions

Important safety information
This manual contains information and warnings that must be followed by the user for safe operation and to keep the product in a
safe condition.
To safely perform service on this product, see the Service safety summary that follows the General safety summary.
General safety summary
Use the product only as specified. Review the following safety precautions to avoid injury and prevent damage to this product or
any products connected to it. Carefully read all instructions. Retain these instructions for future reference.
Comply with local and national safety codes.
For correct and safe operation of the product, it is essential that you follow generally accepted safety procedures in addition to
the safety precautions specified in this manual.
The product is designed to be used by trained personnel only.
Only qualified personnel who are aware of the hazards involved should remove the cover for repair, maintenance, or adjustment.
This product is not intended for detection of hazardous voltages.
Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed.
While using this product, you may need to access other parts of a larger system. Read the safety sections of the other
component manuals for warnings and cautions related to operating the system.
When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the system.
To avoid fire or personal injury
Use proper power cord. Use only the power cord specified for this product and certified for the country of use.
Ground the product. This product is grounded through the grounding conductor of the power cord. To avoid electric shock, the
grounding conductor must be connected to earth ground. Before making connections to the input or output terminals of the
product, ensure that the product is properly grounded. Do not disable the power cord grounding connection.
Power disconnect. The power cord disconnects the product from the power source. See instructions for the location. Do not
position the equipment so that it is difficult to disconnect the power cord; it must remain accessible to the user at all times to allow
for quick disconnection if needed.
Connect and disconnect properly. Do not connect or disconnect probes or test leads while they are connected to a voltage
source. Use only insulated voltage probes, test leads, and adapters supplied with the product, or indicated by Tektronix to be
suitable for the product.
Observe all terminal ratings. To avoid fire or shock hazard, observe all rating and markings on the product. Consult the product
manual for further ratings information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal.
Do not float the common terminal above the rated voltage for that terminal.
Do not operate without covers. Do not operate this product with covers or panels removed, or with the case open. Hazardous
voltage exposure is possible.
Avoid exposed circuitry. Do not touch exposed connections and components when power is present.
Do not operate with suspected failures. If you suspect that there is damage to this product, have it inspected by qualified
service personnel.
AWG70000A Series Installation and Safety Instructions iii

Disable the product if it is damaged. Do not use the product if it is damaged or operates incorrectly. If in doubt about safety of the
product, turn it off and disconnect the power cord. Clearly mark the product to prevent its further operation.
Before use, inspect voltage probes, test leads, and accessories for mechanical damage and replace when damaged. Do not use
probes or test leads if they are damaged, if there is exposed metal, or if a wear indicator shows.
Examine the exterior of the product before you use it. Look for cracks or missing pieces.
Use only specified replacement parts.
Do not operate in wet/damp conditions. Be aware that condensation may occur if a unit is moved from a cold to a warm
environment.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry. Remove the input signals before you clean the product.
Provide proper ventilation. Refer to the manual's installation instructions for details on installing the product so it has proper
ventilation.
Slots and openings are provided for ventilation and should never be covered or otherwise obstructed. Do not push objects into
any of the openings.
Provide a safe working environment. Always place the product in a location convenient for viewing the display and indicators.
Avoid improper or prolonged use of keyboards, pointers, and button pads. Improper or prolonged keyboard or pointer use may
result in serious injury.
Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries.
Use care when lifting and carrying the product. This product is provided with handles for lifting and carrying.
WARNING. The product is heavy. To reduce the risk of personal injury or damage to the device get help when lifting or carrying
the product.
Use only the Tektronix rackmount hardware specified for this product.
Terms in the manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property.
Important safety information
iv AWG70000A Series Installation and Safety Instructions

Terms on the product
These terms may appear on the product:
■DANGER indicates an injury hazard immediately accessible as you read the marking.
■WARNING indicates an injury hazard not immediately accessible as you read the marking.
■CAUTION indicates a hazard to property including the product.
Symbols on the product
When this symbol is marked on the product, be sure to consult the manual to find out the nature of the potential
hazards and any actions which have to be taken to avoid them. (This symbol may also be used to refer the user to
ratings in the manual.)
The following symbols may appear on the product:
Important safety information
AWG70000A Series Installation and Safety Instructions v

Important safety information
vi AWG70000A Series Installation and Safety Instructions

Preface
This manual describes the installation and basic operation of AWG70000A series instruments. For additional operating
information, refer to the instrument help on your instrument. The following instruments are supported by this document:
■AWG70001A single channel Arbitrary Waveform Generators
■AWG70002A two channel Arbitrary Waveform Generators
Key features
The following list describes some of the key features of the AWG70000A series instruments:
■Two modes of operation:
■AWG mode (Arbitrary Waveform Generator) to play any waveshape from a file
■Functions mode to play basic waveshapes
■Sample rates:
■Up to 50 GS/s for one channel instruments
■Up to 25 GS/s for two channel instruments
■Waveform memory
■Up to 16 GSamples for one channel instruments
■Up to 8 GSamples for two channel instruments
■Sequencing with Option 03
■–80 dBc Spurious Free Dynamic Range
■10 bit vertical resolution
■An intuitive, graphical user interface
■Removable hard disk drive
■Supports USB 2.0 interface
■LAN (1000/100/10 Base-T)
■Capacitive touchscreen user interface
■Microsoft Windows 7 Ultimate 64-bit operating system
Documentation
Review the following table to locate more information about this product.
AWG70000A Series Installation and Safety Instructions vii

To read about Use these documents
Installation and operation (overviews) Safety and Installation manual.
Operation and user interface Instrument help from the Help menu.
Programmer commands Programmer manual. This manual is available on the Tektronix
Web site (www.tektronix.com/manuals).
Specifications and performance verification procedures Specifications and Performance Verification Technical
Reference. This manual is available on the Tektronix Web site
(www.tektronix.com/manuals).
Conventions used in this manual
The following icons are used throughout this manual.
Step Front panel power Connect power Network SVGA USB
Preface
viii AWG70000A Series Installation and Safety Instructions

Install the instrument
Unpack the instrument and check that you received all items listed as Standard Accessories. Check the Tektronix Web site
(www.tektronix.com) for the most current information.
Standard accessories
Accessory Tektronix part number
AWG70000A Series Installation and Safety Manual
English (Option L0) 071-3110-xx
Japanese (Option L5) 071-3111-xx
Simplified Chinese (Option L7) 071-3112-xx
Traditional Chinese (Option L8) 071-3113-xx
Russian (Option L10) 071-3114-xx
Windows compatible keyboard 119-7083-xx
Windows compatible mouse 119-7054-xx
Capacitive touch stylus 119-8131-xx
Analog output SMA adapters
(Pre-installed on outputs)
131-8689-xx
Two with the AWG70001A (Three with Option AC)
Four with the AWG70002A
50 Ω SMA Termination, Male, DC to 18 GHz 015-1022-xx
One with the AWG70001A
Two with the AWG70002A
Power cord – one of the following:
North America (Option A0)
Universal Euro (Option A1)
United Kingdom (Option A2)
Australia (Option A3)
Switzerland (Option A5)
Japan (Option A6)
China (Option A10)
India (Option A11)
No power cord or AC adapter (Option A99)
AWG70000A Series Installation and Safety Instructions 1

Product options
Option Description
Opt. 01 Waveform record length expansion
AWG70001A: from 2 GSamples to 16 GSamples
AWG70002A: from 2 GSamples to 8 GSamples for each channel
Opt. 03 Adds sequencing
Opt. 150 Adds 50 GS/s sampling rate (AWG70001A only)
Opt. 208 Adds 8 GS/s sampling rate (AWG70002A only)
Opt. 216 Adds 16 GS/s sampling rate (AWG70002A only)
Opt. 225 Adds 25 GS/s sampling rate (AWG70002A only)
Opt. AC Adds a single-ended AC coupled output connector with additional amplification and attenuation
(AWG70001A only)
Opt. RFX Adds RFXpress (RFX100) software to the AWG
Opt. RDR 1Adds radar signal generation to RFXpress
Opt. SPARA1Adds S-parameter emulation to RFXpress
Opt. OFDM1Adds OFDM signal generation to RFXpress
Opt. ENV1Adds environment signal generation to RFXpress
Opt. ENV011Bundling option - Opt. ENV + Opt. RDR
Opt. ENV021Bundling option - Opt. ENV + Opt. RDR + Opt. OFDM
Opt. ENV031Bundling option - Opt. ENV + Opt. RDR + Opt. OFDM + Opt. SPARA
Opt. ENV041Bundling option - Opt. ENV + Opt. RDR + Opt. OFDM + Opt. SPARA + Opt. UWBCT
Opt. UWBCF1Adds UWB-WiMedia conformance signal generation to RFXpress
Opt. UWBCT1Adds UWB-WiMedia custom and conformance signal generation to RFXpress (includes Opt.
UWBCF)
1Requires Opt. RFX
Install the instrument
2 AWG70000A Series Installation and Safety Instructions

Product upgrades
AWG70001A ugrades Description
AWG701AUP Opt. 01 Increases the waveform record length to 16 Gsamples
AWG701AUP Opt. 03 Adds sequencing
AWG701AUP Opt. SSD Provides an additional (or replacement) preprogrammed solid state drive
AWG701AUP Opt. AC Adds a single-ended AC coupled output connector with additional amplification and attenuation
AWG70002A upgrades Description
AWG702AUP Opt. 01 Increases the waveform record length to 8 GSamples for each channel
AWG702AUP Opt. 03 Adds sequencing
AWG702AUP Opt. 0816 Increases the sampling rate from 8 GS/s to 16 GS/s
AWG702AUP Opt. 0825 Increases the sampling rate from 8 GS/s to 25 GS/s
AWG702AUP Opt. 1625 Increases the sampling rate from 16 GS/s to 25 GS/s
AWG702AUP Opt. SSD Provides an additional (or replacement) preprogrammed solid state drive
ReplaceableParts
Item Tektronix part number
Rear panel foot (four per instrument) 348-2037-xx
Screw 211-1459-xx
Front bottom flip-foot (two per instrument) 348-1950-xx
Screw 211-1459-xx
Foot cushion 348-1947-xx
Rear bottom foot (two per instrument) 348-1948-xx
Screw 211-1459-xx
Foot cushion 348-1947-xx
Handle (two per instrument) 367-0570-xx
Foam 348-2067-xx
Screw (two per handle) 211-1459-xx
Install the instrument
AWG70000A Series Installation and Safety Instructions 3

Operating requirements
Place the instrument on a cart or bench, observing clearance requirements:
■Top and bottom: 0 cm (0 in)
■Left and right side: 5.08 cm (2 in)
■Rear: 0 cm (0 in)
CAUTION. To ensure proper cooling, keep sides of the instrument clear of obstructions.
Environmental requirements
The environmental requirements for your instrument are listed in the following table. For instrument accuracy, ensure that the
instrument has warmed up for 20 minutes and meets the environmental requirements listed in the following table.
Requirement Description
Temperature (operating) 0 °C to 50 °C (+32 °F to +122 °F)
Humidity (operating) 5% to 90% relative humidity at up to 30 °C (86 °F)
5% to 45% relative humidity above 30 °C (86 °F) up to +50 °C
(122 °F) noncondensing
Altitude (operating) Up to 3,000 m (9,843 feet)
Power supply requirements
The power supply requirements for your instrument are listed in the following table.
WARNING. To reduce the risk of fire and shock, ensure that the mains supply voltage fluctuations do not exceed 10% of the
operating voltage range.
Source Voltage and Frequency Power Consumption
100 VAC to 240 VAC, 50/60 Hz 500 W
Cleaning
Inspect the arbitrary waveform generator as often as operating conditions require. Follow these steps to clean the exterior
surface.
WARNING. To avoid personal injury, power off the instrument and disconnect it from line voltage before performing any of the
following procedures.
CAUTION. To avoid damage to the surface of the instrument, do not use any abrasive or chemical cleaning agents.
Use extreme care when cleaning the surface of the display. The display is easily scratched if excessive force is used.
1. Remove loose dust on the outside the instrument with a lint-free cloth. Use care to avoid scratching the front-panel display.
2. Use a soft cloth dampened with water to clean the instrument. If needed, use a 75% isopropyl alcohol solution as a cleaner.
Do not spay liquids directly on the instrument.
Install the instrument
4 AWG70000A Series Installation and Safety Instructions

Power on the instrument
1. Connect the AC power cord to the rear of the instrument.
2. Use the front-panel power button to switch the instrument on.
The power button indicates four instrument power states:
■No light – no power applied
■Yellow – standby mode
■Green – powered on
■Flashing Red – over heat condition (instrument shuts down and cannot restart until internal temperature returns to a
safe level)
Install the instrument
AWG70000A Series Installation and Safety Instructions 5

Power off the instrument
1. Press the front-panel power button to shut down the instrument.
The shutdown process takes approximately 30 seconds to complete, placing the instrument in standby mode. Alternatively,
use the Windows Shutdown menu.
NOTE. You can force an immediate shutdown by pressing and holding the power button for four seconds. Unsaved data is
lost.
2. To completely remove power to the instrument, perform the shutdown just described, and then remove the power cord from
the instrument.
Inspect the instrument
Two types of diagnostics are provided to verify the functionality of your instrument:
■Power-on self test (POST) – Every time you power on the instrument, the instrument automatically performs the POST
internal diagnostics.
■Diagnostics from the System menu – You can run the internal diagnostics from the System menu. Use the following
procedure:
1. Select Utilities from the workspace tabs, then select Diag & Cal.
2. Click Diagnostics & Calibration.
3. In the Diagnostics and Calibration screen, click Diagnostics.
4. Choose the set of diagnostics you want to run.
Install the instrument
6 AWG70000A Series Installation and Safety Instructions
