Tektronix AFG1022 Use and care manual

AFG1000 Series
ArbitraryFunction Generator
Specifications and PerformanceVerification
TechnicalReference
www.tektronix.com
*P077113202*
077-1132-02

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
ContactingTektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tektronix.com to find contacts in your area.

Warranty
Tektronix warrants that the product will be free from defects in materials and workmanship for a period of three (3)
years from the date of original purchase from an authorized Tektronix distributor. If the product proves defective
during this warranty period, Tektronix, at its
option, either will repair the defective product without charge for parts
and labor, or will provide a replacement in exchange for the defective product. Parts, modules and replacement
products used by Tektronix for warranty work may be new or reconditioned to like new performance. All replaced
parts, modules and products become the property of Tektronix.
In order to obtain service under this warranty, Customer must notify Tektronix of the defect before the expiration of
the warranty period and make suitable arrangements for the performance of service. Customer shall be responsible
for packaging and shipping the defective product to the service center designated by Tektronix, shipping charges
prepaid, and with a copy of customer proof of purchase. Tektronix shall pay for the return of the product to Customer
if the shipment is to a location within
the country in which the Tektronix service center is located. Customer shall be
responsible for paying all shipping
charges, duties, taxes, and any other charges for products returned to any other
locations.
This warranty shall not apply to any defect, failure or damage caused by improper use or improper or inadequate
maintenance and care. Tektronix shall not be obligated to furnish service under this warranty a) to repair damage
resulting from attempts by personnel other than Tektronix representatives to install, repair or service the product;
b) to repair damage resulting from improper use or connection to incompatible equipment; c) to repair any damage
or malfunction caused by the use of non-Tektronix supplies; or d) to service a product that has been modified or
integrated with other products when the effect of such modification or integration increases the time or difficulty of
servicing the product.
THIS WARRANTY IS GIVEN BY TEKTRONIX WITH RESPECT TO THE PRODUCT IN LIEU OF ANY
OTHER WARRANTIES, EXPRESS OR IMPLIED. TEKTRONIX AND ITS VENDORS DISCLAIM ANY
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
TEKTRONIX' RESPONSIBILITY TO REPAIR OR REPLACE DEFECTIVE PRODUCTS IS THE SOLE AND
EXCLUSIVE REMEDY PROVIDED TO THE CUSTOMER FOR BREACH OF THIS WARRANTY.
TEKTRONIX AND ITS VENDORS WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL,
OR CONSEQUENTIAL DAMAGES IRRESPECTIVE OF WHETHER TEKTRONIX OR THE VENDOR HAS
ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
[W2 – 15AUG04]

AFG1000 SeriesSpecifications and Performance Verification
i
Table of contents
Important safety information ........................................................................................................................iii
Preface ...........................................................................................................................................................1
Finding other information......................................................................................................................2
Manual conventions ................................................................................................................................2
Specifications.................................................................................................................................................3
Electricalspecifications...........................................................................................................................3
Input and output specifications..............................................................................................................9
Generalspecifications............................................................................................................................10
Performance tests........................................................................................................................................12
Test record............................................................................................................................................14
Frequency/Periodtest ............................................................................................................................20
Amplitude test ......................................................................................................................................21
DC offset test ........................................................................................................................................23
Counter test ...........................................................................................................................................24
AC flatness test .....................................................................................................................................26
Harmonics distortion test.......................................................................................................................28
Total harmonic distortion test..............................................................................................................30

Table of contents
ii
AFG1000 Series Specifications and PerformanceVerification
List of figures
Figure 1: AFG1000 Series dimensions ........................................................................................................11
Figure 2: Frequency/Period tests..................................................................................................................20
Figure 3: 50 Ω terminator accuracy .............................................................................................................21
Figure 4: Amplitude tests.............................................................................................................................22
Figure 5: 50 Ω terminator accuracy .............................................................................................................23
Figure 6: DC offset tests...............................................................................................................................23
Figure 7: Counter tests.................................................................................................................................24
Figure 8: AC flatness tests for 1 kHz...........................................................................................................26
Figure 9: AC flatness tests for the frequency greater than 100 kHz ............................................................26
Figure 10: Harmonic distortion tests............................................................................................................28
Figure 11: Total harmonic distortion tests ...................................................................................................30
List of tables
Table 1: Supported products ..........................................................................................................................1
Table 2: Operating mode................................................................................................................................3
Table 3: Waveforms.......................................................................................................................................3
Table 4: Frequency/Period.............................................................................................................................4
Table 5: Channel Coupling, Channel Copy....................................................................................................4
Table 6: Amplitude.........................................................................................................................................5
Table 7: DC offset..........................................................................................................................................5
Table 8: Counter Specification.......................................................................................................................5
Table 9: Output characteristics.......................................................................................................................6
Table 10: Modulation.....................................................................................................................................7
Table 11: Front panel .....................................................................................................................................9
Table 12: Rear panel ......................................................................................................................................9
Table 13: Power ...........................................................................................................................................10
Table 14: Export control..............................................................................................................................10
Table 15: Environmental..............................................................................................................................10
Table 16: System characteristics..................................................................................................................10
Table 17: Performance test items.................................................................................................................12
Table 18: Test equipment.............................................................................................................................13
Table 19: Series Performance Test Record..................................................................................................15

AFG1000 Series Specifications and Performance Verification
iii
Important safety information
This manual contains information and warnings that must be followed by the
user for safe operation and to keep the product in a safe condition.
To safely perform service on this product, additional information is provided at
the end of this section. (See page v, Service safety summary.)
General safety summary
Use the product only as specified. Review the following safety precautions to
avoid injury and prevent damage to this product or any products connected to
it. Carefully read all instructions. Retain these instructions for future
reference.
Comply with local and national safety codes.
For correct and safe operation of the product, it is essential that you follow
generally accepted safety procedures in addition to the safety precautions
specified in this manual.
The product is designed to be used by trained personnel only. Only
qualified personnel who are aware of the hazards involved should remove
the cover for repair, maintenance, or adjustment.
Before use, always check the product with a known source to be sure it is
operating correctly.
This product is not intended for detection of hazardous voltages. Use
personal protective equipment to prevent shock and arc blast injury where
hazardous live conductors are exposed.
While using this product, you may need to access other parts of a larger
system. Read the safety sections of the other component manuals for
warnings and cautions related to operating the system. When incorporating
this equipment into a system, the safety of that system is the responsibility of
the assembler of the system.
To avoid fire or personal injury
Use proper power cord. Use only the power cord specified for this product
and certified for the country of use.
Use proper voltage setting. Before applying power, make sure that the line
selector is in the proper position for the source being used.
Ground the product. This product is grounded through the grounding conductor
of the power cord. To avoid electric shock, the grounding conductor must be
connected to earth ground. Before making connections to the input or output
terminals of the product, make sure that the product is properly grounded.

Important safety information
iv
AFG1000 Series Specifications and PerformanceVerification
Power disconnect. The power cord disconnects the product from the power
source. See instructions for the location. Do not position the equipment so that it
is difficult to operate the power cord; it must remain accessible to the user at all
times to allow for quick disconnection if needed.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not operate without covers. Do not operate this product with covers or panels
removed, or with the case open. Hazardous voltage exposure is possible.
Avoid exposed circuitry. Do not touch exposed connections and components
when power is present.
Do not operate with suspected failures.If you suspect that there is damage to
this product, have it inspected by qualified service personnel.
Disable the product if it is damaged. Do not use the product if it is damaged or
operates incorrectly. If in doubt about safety of the product, turn it off and
disconnect the power cord. Clearly mark the product to prevent its further
operation.
Before use, inspect voltage probes, test leads, and accessories for mechanical
damage and replace when damaged. Do not use probes or test leads if they are
damaged, if there is exposed metal, or if a wear indicator shows.
Examine the exterior of the product before you use it. Look for cracks or
missing pieces.
Use only specified replacement parts.
Use proper fuse. Use only the fuse type and rating specified for this product.
Do not operate in wet/damp conditions.Be aware that condensation may occur if
a unit is moved from a cold to a warm environment.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry.Remove the input signals before you clean
the product.
Provide proper ventilation. Refer to the installation instructions in the manual
for details on installing the product so it has proper ventilation.
Slots and openings are provided for ventilation and should never be covered or
otherwise obstructed. Do not push objects into any of the openings.

AFG1000 Series Specifications and Performance Verification
v
Important safety information
Provide a safe working environment. Always place the product in a location
convenient for viewing the display and indicators.
Avoid improper or prolonged use of keyboards, pointers, and button pads.
Improper or prolonged keyboard or pointer use may result in serious injury.
Be sure your work area meets applicable ergonomic standards. Consult with
an ergonomics professional to avoid stress injuries. Use care when lifting and
carrying the product.
Use only the Tektronix rackmount hardware specified for this product.
Service safety summary
The Service safety summary section contains additional information required to
safely perform service on the product. Only qualified personnel should perform
service procedures. Read this Service safety summary and the General safety
summary before performing any service procedures.
To avoid electric shock. Do not touch exposed connections.
Do not service alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect power. To avoid electric shock, switch off the product power and
disconnect the power cord from the mains power before removing any covers
or panels, or opening the case for servicing.
Use care when servicing with power on.Dangerous voltages or currents may
exist in this product. Disconnect power, remove battery (if applicable), and
disconnect test leads before removing protective panels, soldering, or replacing
components.
Verify safety after repair. Always recheck ground continuity and mains
dielectric strength after performing a repair.

Important safety information
vi
AFG1000 Series Specifications and PerformanceVerification
Terms in this manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices
that could result in injury or loss of life.
CAUTION. Caution statements identify conditions or practices
that could result in damage to this product or other property.
Symbols and terms on the product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible
as you read the marking.
WARNING indicates an injury hazard not immediately
accessible as you read the marking.
CAUTION indicates a hazard to property including the product.
When this symbol is marked on the product, be sure to consult the manual to
find out the nature of the potential hazards and any actions which have to be
taken to avoid them. (This symbol may also be used to refer the user to ratings
in the manual.)
The following symbol(s) may appear on the product:

AFG1000 Series Specifications and Performance Verification
1
Preface
This manual provides instructions to verify the performance of the AFG1000
Series
Arbitrary Function Generator to the module level.
Unless noted otherwise, the term “AFG3000 Series” refers to the models in the
following table.
Table 1: Supported products
AFG1022
AFG1062
To prevent personal injury or damage to the arbitrary function generator, consider
the following before attempting service:
The procedures in this manual should be performed only by a qualified service
person.
Read the General Safety Summary and the Service Safety Summary at the
beginning of this document.
When using this manual for servicing, be sure to follow all warnings, cautions and
notes.
The manual consists of the following sections:
Specifications contains a description of the arbitrary function generator and
the characteristics that apply to it.
Performance tests contains procedures for confirming that the arbitrary
function generator functions properly and meets warranted limits.
The procedures described in this document should be performed every
12 months or after module replacement.
If the instruments do not meet performance criteria, repair is necessary.

Important safety information
2
AFG1000 Series Specifications and PerformanceVerification
Finding other information
This manual focuses on the performance verification of the arbitrary function
generator. See the following list for other documents supporting the instrument.
All documents except the Online Help are on the AFG1000 Series Arbitrary
Function
Generator Documentation CD-ROM that ship with instrument.
Document
Description
AFG1000 Series Quick Start A quick reference to major features of theinstrument and how they operate. It also provides
User Manual several tutorials to familiarize you with basic instrument features.
AFG1000 SeriesProgrammerManual Anencyclopediaoftopicsthatdescribethearbitraryfunctiongeneratorinterfaceandfeatures,
and gives background information on how to use them. It provides Menu Structures, User
Interface and Programming Information.
AFG1000 Series Compliance and This document contains compliance and safety information.
Safety Instructions
AFG1000 Series Online Help A online help system, integrated with the User Interface application that ships with this
product. The help is preinstalled in the instrument.
Manual conventions
This manual uses certain conventions that you should become familiar with.
Modules Throughout this manual, any replaceable component, assembly, or part of the
arbitrary function generator is referred to generically as a module. In general, a
module is an assembly (such as a circuit board). Sometimes a single component is
a module; for example, the chassis of the arbitrary function generator is a module.
Safety Symbols and terms related to safety appear in the Safety Summary near the
beginning of this manual.

AFG1000 Series Specifications and Performance Verification
3
Specifications
These specifications apply to the AFG1000 Series Arbitrary Function Generator.
All
specifications are guaranteed unless labeled "typical". Typical specifications
are
provided for your convenience but are not guaranteed.
Specifications that are check marked with the symbol are checked directly (or
indirectly) in the Performance tests section.
All specifications apply to the arbitrary function generator unless noted otherwise.
These specifications are valid under the following conditions:
The instrument must have been calibrated/adjusted at an ambient temperature
between +20 °C and +30 °C.
The instrument must be operating at an ambient temperature between 0 °C
and +40 °C.
The instrument must have had a warm-up period of at least 30 minutes.
The instrument must be in an environment with temperature, altitude and
humidity within the operating limits described in these specifications.
Electricalspecifications
Table 2: Operating mode
Characteristic Description
Run mode Continuous,Modulation, Sweep, and Burst
Table 3: Waveforms
Characteristic Description
Standard Sine, Square, Ramp, Pulse, Noise
Numbers of channel 2
Arbitrarywaveform Exponential rise, Exponential fall, Sin(x)/x, Staircase, DC, etc. 45 built-in waveforms, User Defined
Waveformlength
AFG1022 2 to 8,192
AFG1062 2 to 1M
Samplingrate
AFG1022 125 MS/s
AFG1062 300 MS/s
Resolution 14 bits
Number of non-volatile 256
waveformmemories
Memory size 64 Mbyte for waveform storage

4
AFG1000 Series Specifications and PerformanceVerification
Specifications
Table 4: Frequency/Period
Characteristic Description PV ref page
Frequency range
Sine
AFG1022
Range 1 μHz to 25 MHz
Sine wave in burst mode 2 mHz to 25 MHz
AFG1062
Range 1 μHz to 60 MHz
Sine wave in burst mode 2 mHz to 30 MHz
Square
AFG1022
Range 1 μHz to 12.5 MHz
Square wave in burst mode2 mHz to 12.5 MHz
AFG1062
Range 1 μHz to 30 MHz
Square wave in burst mode2 mHz to 15 MHz
Pulse
AFG1022
Range 1 μHz to 12.5 MHz
Pulse wave in burst mode 2 mHz to 12.5 MHz
AFG1062
Range 1 μHz to 30 MHz
Pulse wave in burst mode 2 mHz to 15 MHz
Ramp
AFG1022
Range 1 μHz to 1 MHz
Ramp wave in burst mode 2 mHz to 1 MHz
AFG1062
Range 1 μHz to 2 MHz
Ramp wave in burst mode 2 mHz to 2 MHz
Arbitrary
AFG1022
Range 1 μHz to 10 MHz
Sine wave in burst mode 2 mHz to 10 MHz
AFG1062
Range 1 μHz to 30 MHz
Arb wave in burst mode 2 mHz to 30 MHz 1
Noise bandwidth (-3 dB), typical
AFG1022 25 MHz
AFG1062 50 MHz
Resolution
1 μHz or 12 digits
Accuracy(stability) ±1 ppm, 0 °C to 40 °C
Accuracy (aging) ±1 ppm/year
(See page 20,
Frequency/Period test.)
Table 5: Channel Coupling, Channel Copy
Characteristics Description
Phase Deviation 1 0.0° to +360.0° (Frequency CH1 = CH2)
Support frequency/amplitude/phase copying
1 Resolution: 0.1°

AFG1000 Series Specifications and Performance Verification
5
Specifications
Table 6: Amplitude
Characteristic Description PV ref page
Range
AFG1022 1 mVp-p to 10 Vp-p (into 50 Ω load)
2 mVp-p to 20 Vp-p (into Open circuit or High-Z)
AFG1062 ≤25 MHz: 1 mVp-p to 10 Vp-p
> 25 MHz: 1 mVp-p to 5 Vp-p
(into 50 Ω load)
≤25 MHz: 2 mVp-p to 20 Vp-p
> 25 MHz: 2 mVp-p to 10 Vp-p
(into Open circuit or High-Z)
Accuracy
±(1% of setting +1 m Vp-p ) (at 1 kHz sine waveform), 0 V offset
Resolution 1
mV
p-p
or 4 digits
Units
1
V
p-p
, V
rms,
and Volt (High level and Low level)
Outputimpedance 50 Ω
1 Vrms is not available for Pulse, Noise, and Arb waveforms.
(See page 21,
Amplitudetest.)
Table 7: DC offset
Characteristic
Description
PV ref page
Range
±
(5 V
pk
– Amplitude V
p-p
/2) into 50 Ωload
±
(10 V
pk
– Amplitude V
p-p
/2)
into Open circuit or High-Z
Accuracy
±(1 % of |setting| + 1 mV + amplitude Vp-p * 0.5%)
(See page 23,
DCoffsettest.)
Resolution
1 mV
Outputimpedance
50 Ω(typical)
Table 8: Counter Specification
Characteristic
Description
PV ref page
Function
Frequency, period, positive Pulse width, Dutycycle
Frequency Range
100 mHz to 200 MHz
Frequency Resolution
6 digits (See page 24,
Counter test.)
Coupling mode
AC, DC
Voltage Range and Sensitivity, DC coupled (non-modulation signal)
100 mHz to 100 MHz
250 mVp-p to 5 Vp-p (AC+DC)
100 MHz to 200 MHz
450 mV
p-p
to 3 V
p-p
(AC+DC)
Voltage Range and Sensitivity, AC coupled (non-modulation signal)
1 Hz to 100 MHz
250 mVp-p to 5 Vp-p
100 MHz to 200 MHz
450 mVp-p to 4 Vp-p
Pulse width and Duty cycle
Measure
1 Hz to 10 MHz
Input impedance
1 MΩ with 100 pF parallel
High frequency noise
restraint (HFR)
On / Off (HFR frequency = 500 kHz)
Sensitivity
Low, Middle, High
Trigger level range
± 2.5 V

6
AFG1000 Series Specifications and PerformanceVerification
Specifications
Table 9: Output characteristics
Characteristic Description PV ref page
Sine wave
Flatness (at 1.0 Vp-p amplitude, relative to 1 kHz)
AFG1022 < 10 MHz: ±0.4 dB
10 MHz ≤frq ≤25 MHz: ±0.7 dB
AFG1062 < 10 MHz: ±0.5 dB
10 MHz ≤frq ≤60 MHz: ±0.9 dB
Harmonicdistortion (at 1.0 Vp-p amplitude)
AFG1022 1 μHz to 25 MHz : < –50 dBc
AFG1062 Typical (0 dBm) DC to 10 MHz (included): <-60 dBc
10 MHz to 60 MHz (included): <-47 dBc
(See page 26,
AC flatness
test.)
(See page 28,
Harmonics
distortiontest.)
Total harmonic
distortion (THD)
(at 1 Vp-p amplitude)
10 Hz to 20 kHz: < 0.2%
(See page 30,
Total harmonic
distortion test.)
Phase noise, typical (at 1 Vp-p amplitude)
1 MHz: < –110 dBc/Hz at 10 kHz offset
Spurious (nonharmonic) (at 1 Vp-p amplitude)
Typical (0 dBm): <-45 dBc
Residual clocknoise, typical –57 dBm
Square wave
Risetime/falltime (at 1 Vp-p amplitude), typical
AFG1022 < 12 ns
AFG1062
< 10 ns
Jitter (rms), typical
AFG1022 < 1 ns
AFG1062 < 500 ps
Overshoot < 5%
Duty Cycle 50% fixed
Pulse
Pulse width
AFG1022 40 ns to 999 ks
AFG1062
17 ns to 999 ks
Resolution 1 ns or 4 digits
Duty Cycle
AFG1022
< 1 MHz: Adjustable Duty
1 MHz ≤frq ≤12.5 MHz: 50%
(limitations of pulse duty width apply)
AFG1062 < 1 MHz: Adjustable Duty
1 MHz ≤frq ≤30 MHz: 50%
(limitations of pulse duty width apply)

AFG1000 Series Specifications and Performance Verification
7
Specifications
Table 9: Output characteristics (cont.)
Characteristic Description
PV ref page
Rising/Falling Edge Time, typical
AFG1022 < 12 ns (Fixed)
AFG1062
< 10 ns (Fixed)
Overshoot,typical < 5%
Jitter (rms), typical
AFG1022 < 1 ns
AFG1062 < 500 ps
Ramp
Linearity, typical (at frequency: 1 kHz, amplitude: 1 Vp-p, symmetry: 50%)
< 0.1% of peak output
Symmetry 0% to 100%
Noise
Type White Gaussian
Arbitrary
Risetime/falltime, typical
AFG1022 < 10 ns
AFG1062
< 8 ns
Jitter (rms), typical < 6 ns
Table 10: Modulation
Characteristic Description
AM (Amplitude Modulation)
Carrierwaveforms Sine, Square, Ramp, and Arbitrary
Modulation source Internal or External
Internal modulating
waveforms Sine, Square, Ramp, Noise, and Arbitrary
Internal modulating frequency 2 mHz to 20.0 kHz
Depth 0.0% to 100.0%
FM (Frequency Modulation)
Carrier waveforms Sine, Square, Ramp, and Arbitrary
Modulationsource Internal or External
Internal modulating
waveforms
Sine, Square, Ramp, Noise, and Arbitrary
Internal modulating frequency 2 mHz to 20.0 kHz
Frequency Deviation Deviation ≤ Highest frequency of carrier waveform - Carrier waveform frequency
AFG1022 2 mHz to 12.5 MHz
AFG1062
2 mHz to 30 MHz

8
AFG1000 Series Specifications and PerformanceVerification
Specifications
Table 10: Modulation (cont.)
Characteristic Description
PM (Phase Modulation)
Carrierwaveforms Sine, Square, Ramp, and Arbitrary
Modulationsource Internal or External
Internal modulating
waveforms Sine, Square, Ramp, Noise, and Arbitrary
Internalmodulatingfrequency 2 mHz to 20.0 kHz
Phase deviation range 0.0° to 180.0°
PWM (Pulse Width Modulation) (AFG1062 only)
Carrierwaveforms Pulse, ≤1 MHz
Modulationsource Internal or External
Internal modulating
waveforms Sine, Square, Ramp, and Arbitrary
Internalmodulatingfrequency 2 mHz to 20.0 kHz
Deviation range 0.0% to 50.0% of pulse period
FSK (Frequency Shift Keying)
Carrierwaveforms Sine, Square, Ramp, and Arbitrary
Modulationsource Internal or External
Internal key rate 2 mHz to 100.0 kHz
Internal Modulating Waveforms 50% duty cycle square
ASK (Amplitude Shift Keying) (AFG1062 only)
Carrierwaveforms Sine, Square, Ramp, andArbitrary
Modulationsource Internal or External
Internal key rate 2 mHz to 100.0 kHz
Internal Modulating Waveforms 50% duty cycle square
PSK (Phase Shift Keying) (AFG1062 only)
Carrierwaveforms Sine, Square, Ramp, andArbitrary
Modulationsource Internal or External
Internal key rate 2 mHz to 100.0 kHz
Internal Modulating Waveforms 50% duty cycle square
Sweep
Carrierwaveforms Sine, Square, Ramp and Arb
Type Linear or Logarithmic
Min start/stopfrequency 1 μHz
Max start/stop frequency
AFG1022 Sine: 25 MHz
Square: 12.5 MHz
Ramp: 1 MHz
AFG1062
Sine: 60 MHz
Square: 30 MHz
Ramp: 2 MHz

Specifications
AFG1000 SeriesSpecifications and Performance Verification
9
Table 10: Modulation (cont.)
Characteristic Description
Sweeptime 1 ms to 500 s ± 0.1%
Direction Up / Down
TriggerSource
Internal, External, or Manual
Burst
Waveforms Sine, Square, Ramp, Pulse, and Arbitrary
Burst count
AFG1022 1 to 50,000 cycles, infinite or gated
AFG1062
1 to 1,000,000 cycles, infinite or gated
Start Phase -360° to +360°
Trigger Sources Internal, External, or Manual
Internal trigger interval (40 ns - 500 s) ±1%
Min = Cycles * Period
Gate Source External Trigger
Input and output specifications
Table 11: Front panel
Characteristic Description
External Reference Clock Output
Frequency 10 MHz
Impedance 50 Ω, DC coupled
Amplitude 1.6 V
p-p
into 50 Ω load
ExternalTrigger input
Level TTL compatible
Pulse width >100 ns
Slope Rising or falling (selectable)
Table 12: Rear panel
Characteristic Description
External modulation input
Input range ±1.0 V full scale (except FSK)
3.3 V logic level (FSK)
Impedance 12 kΩ(typical)
Frequency range DC to 20 kHz
External Reference Clock Input (shared with Counter input)
Impedance 400 Ω,ACcoupled
Required input voltage
swing 100 mVp-p to 5 Vp-p
Lock range 10 MHz ± 9 kHz

Specifications
10
AFG1000 Series Specifications and PerformanceVerification
Generalspecifications
Table 13: Power
Characteristic Description
Sourcevoltageand frequency 220 - 240 VAC, 100 - 120 VAC, 50/60 Hz, CATⅡ
Powerconsumption
AFG1022 Less than 28 W
AFG1062 Less than 35 W
Fuse 110 V: 250 V, F1AL
220 V: 250 V, F0.5AL
Table 14: Export control
Characteristic Description
Effectiveanalogbandwidth,typical (Arbitrary waveform at 1 Vp-p amplitude)
30 MHz
Effectivemaximumfrequencyout 10 MHz
Phase noise (At 1 Vp-p amplitude)
At 20 MHz: < –110 dBc/Hz at 10 kHz offset
Table 15: Environmental
Characteristic Description
Temperaturerange
Operating 0 °C to 40 °C
Non operating -20 °C to 60 °C
Humidity
Operating ≤80%, non-condensing
Altitude
Operating Up to 3,000 meters ( apx. 9843 feet)
Non operating Up to 12,000 meters (apx. 39,370 feet)
Cooling Method Fan cooling
Table 16: System characteristics
Characteristic Description
Warm-up time, typical 30 minutes minimum
Communication Interface USB host (front panel) and device (rear panel)
Net weight 3.4 kg (7.5 lbs), approximate
Dimensions(overall)
Height
111.16 mm (4.38 in)
Width 229.16 mm (9.02 in)
Depth 306.36 mm (12.06 in), including rear boot
