60 V Common Mode Probes User Manual
© 2023 Teledyne LeCroy, Inc. All rights reserved.
Unauthorized duplication of Teledyne LeCroy documentation materials other than for internal
sales and distribution purposes is strictly prohibited. However, clients are encouraged to
duplicate and distribute Teledyne LeCroy documentation for their own internal educational
purposes.
Teledyne LeCroy is a trademark of Teledyne LeCroy, Inc. Other product or brand names are
trademarks or requested trademarks of their respective holders. Information in this publication
supersedes all earlier versions. Specifications are subject to change without notice.
dlxx-hcm-user-manual-eng_05apr23.pdf
April, 2023

User Manual
i
Contents
Introduction...................................................................................................................................................1
Compatibility.............................................................................................................................................1
Required Firmware ..................................................................................................................................1
Probe Components..................................................................................................................................2
Specifications ...........................................................................................................................................5
Safety ...........................................................................................................................................................16
Precautions.............................................................................................................................................16
Safe Operating Environment................................................................................................................17
Probe Handling.......................................................................................................................................17
Operation .....................................................................................................................................................18
Amplifier ..................................................................................................................................................18
Freehand Probe Holder.........................................................................................................................19
Connecting Tips .....................................................................................................................................20
Using the PCF-200 Deskew Fixture ....................................................................................................25
Operating from the Oscilloscope ........................................................................................................26
Maintenance ...............................................................................................................................................29
Cleaning ...................................................................................................................................................29
Calibration Interval.................................................................................................................................29
Service Strategy .....................................................................................................................................29
Replacement Parts ................................................................................................................................29
Returning a Product for Service ..........................................................................................................30
Performance Verification Procedure......................................................................................................31
Required Equipment..............................................................................................................................31
Preliminary Set Up .................................................................................................................................33
Functional Check ...................................................................................................................................33
Verification Procedure ..........................................................................................................................33
DL_____-HCM Test Record ...................................................................................................................38
Reference.....................................................................................................................................................39

60 V Common Mode Probes
ii
Certifications .......................................................................................................................................... 39
Technical Support ................................................................................................................................. 40
Warranty.................................................................................................................................................. 40

User Manual
1
Introduction
The 60 V Common Mode Differential Probes (DLxx-HCM) offer 60 V of common mode and
80 V differential input range with up to 1 GHz of bandwidth, making them the ideal probe for
lower voltage GaN power conversion measurements.
The Common Mode Rejection Ratio (CMRR) for the probes is exceptional to very high
frequencies. This provides for the best measurement performance when measuring very
fast slew rate (high dV/dt) PWM signals typical of GaN devices and systems. Exceptional
CMRR, combined with low probe noise and high offset capability, makes the probes capable
of measuring very small control signals floating on high common mode voltages.
The DLxx-HCM probes are calibrated for high-precision measurements to within 0.5% at DC
and 0.1 dB flatness from DC to 100 MHz. This ensures high accuracy top and base voltage
level measurement of pulse-width modulated signals. The Precision Gain Calibration
capability furthers measurement precision by improving the gain accuracy and removing
small offset drifts from the measurement configuration.
Equipped with a wide variety of standard tips, the 60 V Common Mode Differential Probes
provide the perfect combination of high performance and flexibility for connecting to any
device under test. An optional accessory kit and high temperature solder-in tip are available
for further connectivity options.
Compatibility
DLxx-HCM probes are compatible with Teledyne LeCroy oscilloscopes equipped with the
ProBus interface running Windows® 10 Pro, Windows 7 Pro or Windows CE operating
systems. See our website for all compatible oscilloscope models.
Required Firmware
Proper functioning of the probes requires these minimum versions of MAUI®firmware to be
installed on the oscilloscope:
•Version 9.3.x.x for DL05-HCM and DL10-HCM
•Version 10.3.x.x for DL02-HCM

60 V Common Mode Differential Probes
2
Probe Components
The 60 V Common Mode Differential Probes consist of an amplifier and a selection of
standard leads and tips. Optional accessories are available for purchase separately.

User Manual
3
Standard Accessories
The probes are delivered with the following standard accessories.
Item
Description
QTY
DL05
DL10
QTY
DL02
Browser Tip
Attaches to the amplifier for hand-held browsing. Combines
high performance with quick access to many probing points.
1
1
2” Solder-in Tip
Can be soldered directly to the test points for a secure probe
connection. Two-inch long leads give more flexibility in
connecting to hard-to-reach test points.
1
0
High Performance
Solder-in Tip
Because of their small size, these tips provide the maximum
signal fidelity at the highest frequency response. They are
soldered to the test points like the 2” solder-in tips.
2
0
2” Y-lead Socket
Used to probe differential signals that are far apart on the
board. Can be connected directly over pins, used with single
pins inserted, or with grabbers attached to connect to very
tightly spaced points.
1
0
5” Y-lead Socket
Same as above with five-inch long leads. Could be used to
extend into spaces where it is difficult to place the amplifier.
1
1
Mini-Grabbers
Can be used to connect to very tightly spaced pins. Always
attach grabbers to a Y-lead socket.
3
0
Straight Pin Header
Used to connect to female receptacles. Pins have a fixed
spacing of 2.54 mm (0.1 inch).
2
2
Single Pin
Fits into either socket of the Y-leads or the ground lead to
make contact where there is no pin on the board.
6
6
Ground Lead
Bendable, socket-tipped ground lead can be used alone, or
with the single pin or grabbers inserted for probing ground
planes.
1
1
Storage Case
Soft storage case.
1
1
Accessory Tray
Plastic insert for storage case.
1
1
Certificate of
Calibration
1
1

60 V Common Mode Differential Probes
4
Optional Accessories
The following optional accessories may be purchased separately.
Item
Description
Part Number
QTY
High Temperature Lead
Can be used in controlled situations where
the differential amplifier needs to be
removed from an extreme temperature
environment. Ideally suited for testing where
the temperature can fluctuate from -40 °C to
+125 °C, the 1-meter long lead provides an
easy and robust connection to the circuit
under test. It is designed to be soldered to
the test board like the solder-in tips.
DL-HCM-Hi-Temp
1
Deskew Fixture
May be used to determine the effect of probe
input loading on the DUT, for verification of
the probe’s response to the signal being
measured, or as a convenient way to deskew
probes or oscilloscope channels.
PCF-200
1
DL-HCM Accessory Kit
Includes the following items.
DL-HCM-Acc-Kit
Freehand Probe Holder
Designed to keep weight on the probe tip
while securing the position of the amplifier. It
helps prevent loss of contact when the
circuit under test is destabilized. The
amplifier can be mounted horizontally or
vertically in the Freehand.
1
Y-banana Adaptor
Used to connect banana tips delivered with
other probe models to the DLxx-HCM probe.
1
Micro-Grabbers
Ideal for connecting to small IC legs or very
tightly spaced pins. It is always used with a
Y-lead.
2

User Manual
5
Specifications
Full specifications are on the product datasheet. Visit teledynelecroy.com/probes.
Note: Specifications are subject to change without notice.
DL02-HCM
DL05-HCM
DL10-HCM
Guaranteed Specifications
Bandwidth (without leads)
250 MHz
500 MHz
1 GHz
DC Gain Accuracy
± 0.5%
± 0.5%
± 0.5%
Electrical Specifications
Differential Mode Range 1
80 V (DC + Peak AC), 200 mV/div to 20 V/div
Common Mode Range 2
± 60 V (DC + Peak AC)
Max. Input Voltage to Earth
(either input to ground)
80 V (DC + peak AC), max 60 V DC
Max. Safe Input Voltage 3
28.28 Vrms or 60 V DC (referenced to ground)
Vertical Sensitivity (Gain)
200 mV/div to 20 V/div
Measurement Category (CAT) 4
No rated measurement category
Pollution Degree 5
2
This is the maximum voltage that can be applied between the + and - inputs without overloading the amplifier,
which otherwise would result in clipping or distorting of the waveform measured by the oscilloscope.
This is the maximum voltage with respect to earth ground that can be applied to either input. Exceeding the
common mode range can result in unpredictable measurements. Because common mode signal is normally
rejected and not displayed, be careful to avoid accidentally exceeding the common mode range.
This is the maximum safe input voltage with respect to ground for hand-held use.
Per IEC/EN 61010-031:2015, the probe is not intended for measurements on circuits directly connected to the
Mains supply.
Per IEC/EN 61010-031:2015, the probe is to be used only in an operating environment where normally only dry,
non-conductive pollution occurs. Temporary conductivity caused by condensation should be expected.
WARNING: The probe is not intended for hand-held use above 60 VDC. Do not
handle probe tips, leads or any part of the amplifier if there is any question as to
whether DC bus voltages are greater than 60 V. Use stationary setup for
measurements above 60 V.

60 V Common Mode Differential Probes
6
Typical Bandwidth
Typical bandwidth probe only or with named tip.

User Manual
7
Typical Bandwidth (cont’d)

60 V Common Mode Differential Probes
8
Typical Step Response
Typical step response to 1 V input, probe only or with named tip.

User Manual
9
Typical Step Response (cont’d)
Note: Unless full bandwidth is required, we recommend applying a bandwidth filter when
using the Browser to reduce peaking. The plot above shows the results.

60 V Common Mode Differential Probes
10
Typical CMRR Performance
Differential probes sense the voltage difference that appears between the +and – inputs,
referred to as the normal or differential mode voltage. The voltage component that is
referenced to earth and is identical on both inputs is rejected by the amplifier. This is
referred to as the common mode voltage and can be expressed: Vcm = (V+input + V-input)/2
The ideal differential probe/amplifier would sense and amplify only the differential mode
voltage component and reject the entire common mode voltage component. Real
differential amplifiers are not perfect, and a small portion of the common mode voltage
component appears at the output.
Common mode rejection ratio (CMRR) is the measure of how much the amplifier rejects the
common mode voltage component. CMRR is equal to the differential mode gain (or normal
gain) divided by the common mode gain. Common mode gain is equal to the output voltage
divided by the input voltage when both inputs are driven by only the common mode signal.
CMRR can be expressed as a ratio (e.g., 10,000:1) or implicitly in dB (e.g., 80 dB). Higher

User Manual
11
numbers indicate greater rejection (better performance).
The first order term determining the CMRR is the relative gain matching between the + and
– input paths. You can obtain high CMRR values by precisely matching the input
attenuators in a differential amplifier. The matching includes the DC attenuation and the
capacitance which determines the AC attenuation. As the frequency of the common mode
component increases, the effects of stray parasitic capacitance and inductance in
determining the AC component become more pronounced. The CMRR becomes smaller as
the frequency increases. Therefore, the CMRR is usually specified in a graph of CMRR
versus common mode frequency.
The common mode frequency in the previous graph is assumed to be sinusoidal. In real life
applications, the common mode signal is seldom a pure sine wave. Signals with pulse wave
shapes contain frequency components much higher than the repetition rate may suggest.
This makes it very difficult to predict actual performance in the application for CMRR-
versus- frequency graphs.
Differential Input Impedance

60 V Common Mode Differential Probes
12
Voltage vs. Frequency Derating

User Manual
13
Equivalent Circuits (Probe Loading)
PROBE ONLY
BROWSER TIP
2” SOLDER-IN TIP

60 V Common Mode Differential Probes
14
HIGH-PERFORMANCE SOLDER-IN TIP
2” Y-LEAD
5” Y-LEAD

User Manual
15
HI-TEMP LEAD
STRAIGHT PIN HEADER

60 V Common Mode Differential Probes
16
Safety
To maintain the probe in a correct and safe condition, observe generally accepted safety
procedures in addition to the precautions specified in this section. The overall safety of any
system incorporating this product is the responsibility of the assembler of the system.
These symbols appear on the probe and accessories or in this manual to alert you to
important safety considerations.
WARNING, HIGH VOLTAGE. Risk of electric shock or burn.
CAUTION of damage to probe or instrument, or WARNING of hazard to health. Attend
to the accompanying information to protect against personal injury or damage. Do
not proceed until conditions are fully understood and met.
ESD CAUTION. Risk of Electrostatic Discharge (ESD) that can damage the probe or
instrument if anti-static measures are not taken.
Precautions
WARNING. To avoid personal injury or damage due to electric shock orfire:
Do not handle probe tips, leads or any part of the amplifier if DC bus voltages are > 60 V.
Use stationary setup for measurements > 60V. If there is any question as to whether >60 V
voltages are present in the circuit, exercise caution and do not touch these components.
Do not use the probe for measurements on Mains circuits. The probe does not have a CAT
rating for use on circuits in Measurement Categories II, III or IV.
Do not overload; observe all terminal ratings. Do not apply any potential that exceeds the
maximum rating of the probe and/or the probe accessory, whichever is less.
Comply with the Voltage vs. Frequency derating curve.
Connect and disconnect properly. Always connect the probe input lead to the probe
accessories before connecting to a voltage source. Ensure the connections are secure
before applying voltage. Do not disconnect leads or accessories from a live circuit.
Keep the probe body and output cable away from the circuits being measured. Only
accessory tips are intended for contact with electrical sources.
Use only accessories compatible with the probe and rated for the application.Substituting
other accessories than those specified in this manual may create a shock /burn hazard.
Do not remove the probe's casing. Touching exposed connections may result in electric
shock or burn.
