Tellur TLL331121 User manual

WiFi Motion Sensor
TLL331121 User manual

Reset button
Battery
LED Light
Holder
Holder
Sticker Screw
Screw stopper
Inductive area
Product Diagram

Specifications
Power supply: 1 x CR123A 3V (included)
Battery life: Up to 1 year (triggered 7 times/day)
Sensor type: PIR (Passive Infrared Sensor)
Refresh time: 1 per minute
Detection distance: Up to 6 meters
Push notifications: Yes
Tamper notifications: Yes
Low battery notifications: Yes
History record: Yes
WiFi standard: IEEE 802.11b/g/n
Supported WiFi network: 2.4GHz
Dimensions: 5cm x 4.8cm x 4.8cm
Weight: 50gr
Color: White
Operating temperature: 0° - 40°
Operating humidity: 20% - 85%

How to reset?
(1) Press the reset button for 6 seconds until the LED
indicator is flashing rapidly. The device will enter EZ
mode.
(2) Press the reset button again for 6 seconds until
the LED indicator is flashing slowly. The device turns
to AP mode.
Device Status
EZ mode
AP mode
Triggered
Suspend mode
Reset
LED State
Indicator flashes quickly
Indicator flashes slowly
LED indicator will rapidly blink, and it
will turn OFF after the scheduled time
LED indicator is off
LED indicator lights up for 4 seconds
and after 2 seconds, the lights will
turn off; the device goes into
configuration mode
LED State

Product features
Experience the various advanced features of this product
using Tellur Smart app.
Main function
Operate status: alarm/normal (the device can be
triggered only once in 1 minute)
Alarm recording: click “HISTORY”.
Turn Off/On push notification: click “NOTICE”.
Linkage alarm setting
This function allows to connect two Sensors via scene
setting.
Device sharing
It allows other people to control the device.
You can share the device with the added family members.
Push notification
Open/close push notification.
Remove device
Restore default settings. It is necessary to delete and add
the device again, to clear the record by APP.
