Teltonika TRB141 User manual

https://wiki.teltonika.lt/
Quick Start Guide v1.2

FRONT VIEW
Mobile network type LEDs
BACK VIEW
Power socket
Power LED
Mobile signal strength
indication LEDs
Mobile antenna connectorUSB port
Reset button
Input/output connector

1. Unscrew two back panel hex bolts and remove the back panel.
2. Insert your SIM card into the SIM socket.
3. Attach the panel and tighten the hex bolts.
4. Attach the mobile antenna (max torque 0.4 N·m / 3.5 lbf·in).
5. Connect the USB cable.
HARDWARE INSTALLATION
DI1 and DI2 are DRY/WET configurable inputs.
WET: 0-1.9 Visdetected as logical "0",1.9-3.8 Visdetected as logical "1".
DRY: Logical "0" is detected when input is shorted to GND, otherwise
input is detected as logical "1".
Ais ADC input. Analog voltage range 0-30 V. Input can be configured
for 4-20mA sensor protocol as current measurement of 0-30 mA.
Iand are isolated input contacts. 0-7.3 V is detected as logical "0",
7.3-71 V is detected as logical "1".
+is power output connected directly to gateway's power supply input pin.
ThisOutput can beused forpowering external 4-20 mA current sensor.
3.8 is 3.8V power output which can be used to power 1-Wire sensors
when needed.
1W 1-Wire protocol input/output.
is GND contact.
Power pin: +9 ... +30 VDC positive power input.
Ground pin: negative/ground connection from power supply.
I/O pins: programmable Input/Output pins (Open Collector output, max
30 V or Digital input where 0-7.3 V is detected as logical "0", 7.3-30 V is
detected as logical "1").
INPUT/OUTPUT CONNECTOR PINOUT
POWER SOCKET PINOUT
NC*, C* and NO* are respectively Normally Closed, Common and
Normally Open contacts of internal Relays 1 and 2. Maximum Relay 1
(Non-latching) ratings: 0.5 A at 60 VDC/70 VAC, 1 A at 30 VDC/VAC.
Maximum Relay 2 (Latching) ratings: 0.8 A at 70 VDC, 0.9 A at 70 VAC,
2 A at 30 VDC/VAC.

DEVICE CONFIGURATION
TECHNICAL INFORMATION
1. Power on the device and connect the USB cable to your computer.
2. Allow the gateway to boot up. This might take up to 30 seconds.
3. Your computer's OS should detect the USB device and install the driver.
4. To enter the gateway's Web interface (WebUI), type http://192.168.2.1 into the URL field of your Internet browser.
5. Use login information shown in image A when prompted for authentication.
6. After logging in pay attention to the Signal Strength indication displayed in the Mobile widget (image B). To
maximize the cellular performance try adjusting the antennas or changing the location of your device to achieve the
best signal conditions.
*Order code dependent.
**Higher gain antenna can be connected to compensate for cable attenuation when a cable is used. The user is responsible for the compliance with the legal regulations.
Radio specifications
Bundled accessories specifications*
RF technologies
Max RF power
2G, 3G, 4G
33 dBm@GSM, 24 dBm@WCDMA, 23 dBm@LTE
Power adapter Input: 0.4 A@100-240 VAC, Output: 9 VDC, 0.5 A, 4-pin plug
Mobile antenna 698~960 / 1710~2690 MHz, 50 Ω, VSWR<2, gain** 2 dBi, omnidirectional, SMA male connector
A. B.
Bytes received/sent
SIM card slot in use
Data connection
State
-65 dBm
Connected
Registered (home); OPERATOR; 4G (LTE)
Ready
348.7 KB / 223.5 KB
admin
admin01

TRB141 gateway must be used in compliance with any and all applicable national and international laws and with any special restrictions regulating the utilization of the
communication module in prescribed applications and environments.
