Teltonika FMB001 Installation guide

Quick Manual
v1.0
Easy OBDII tracker
FMB001

2
FMB001 | Wiki
Table of Contents
Know your device .......................................................................... 3
Pinout................................................................................................. 4
Set up your device......................................................................... 5
How to insert Micro-SIM card and connect battery ...................... 5
PC Connection (Windows)................................................................ 6
How to install USB drivers (Windows)............................................. 6
Configuration (Windows) ................................................................. 6
LED indications .............................................................................. 8
Characteristics............................................................................... 8
Basic characteristics ......................................................................... 8
Safety information ...................................................................... 10
Certification and Approvals ....................................................... 11

3
FMB001 | Wiki
Know your device
Figure 1 FMB001 device view

4
FMB001 | Wiki
Pinout
Table 1 OBDII pinout
Pinnumber Pinname Description
1 DIN1 Ignition input
2 PWM_BUS+/VPW
4 GND (-) Ground
5 GND (-) Ground
6 CAN_H CAN high
7 K-Line
10 PWM_BUS-
14 CAN_L CAN low
15 L-Line
16 VCC (10 - 30)V DC(+) Power supply (+10-30 V DC)
Figure 2 FMB001 OBDII socket pinout

5
FMB001 | Wiki
Set up your device
How to insert Micro-SIM card and
connect the battery
1. Gently remove FMB001 cover using plastic pry tool from both
sides.
2. Insert Micro-SIM card as shown with PIN request disabled or
read our Wiki how to enter it later in Configurator. Make sure
that Micro-SIM card cut-off corner is pointing forward to slot.
3. Connect battery as shown to device. Position the battery in
place where it does not obstruct other components.
4. Attach device cover back.
Device is ready to be connected.
Figure 3 Cover removal Figure 4 Micro-SIM card insert
Figure 5 Battery connection Figure 6 Attaching cover back

6
FMB001 | Wiki
PC Connection (Windows)
1. Power-up FMB001 with DC voltage (10 – 30 V) power supply
using supplied power cable. LED’s should start blinking, see
“LED indications”.
2. Connect device to computer using Micro-USB cable or Blue-
tooth connection:
•Using Micro-USB cable
▬You will need to install USB drivers, see “How to install
USB drivers (Windows)”
•Using Blue-tooth
▬FMB001 Blue-tooth is enabled by default. Turn on Blue-
tooth on your PC, then select Add Blue-tooth or other
device > Blue-tooth. Choose your device named –
“FMBxxx_last_7_imei_digits”, without LE in the end.
Enter default password 5555, press Connect and then
select Done.
3. You are now ready to use the device on your computer.
How to install USB drivers
(Windows)
1. Please download COM port drivers from here.
2. Extract and run TeltonikaCOMDriver.exe.
3. Click Next in driver installation window.
4. In the following window click Install button.
Setup will continue installing the driver and eventually the
confirmation window will appear. Click Finish to complete the
setup.
Configuration (Windows)
At first FMB001 device will have default factory settings set. These
settings should be changed according to the user's needs. Main
configuration can be performed via Teltonika Configurator
software. Contact sales manager to get the latest Configurator
version or download it from here.Configurator operates on
Microsoft Windows OS and uses prerequisite MS .NET
Framework. Make sure you have the correct version installed.
Table 2 MS .NET requirements
MS.NETrequirements
Operating
system
MS .NET Framework
version Version Links
Windows Vista
Windows 7
Windows 8.1
Windows 10
MS .NET Framework
4.6.2 32 and 64 bit www.microsoft.com
Downloaded Configurator will be in compressed archive. Extract it
and launch Configurator.exe. After launch software language can
be changed by clicking in the right bottom corner (Figure 7
Language selection).

7
FMB001 | Wiki
Configuration process begins by pressing on connected device
(Figure 8 Device connected via USB).
After connection to Configurator Status window will be displayed
(Figure 9 Configurator Status window).
Various Status window tabs display information about GNSS,
GSM,I/O, Maintenance and etc. FMB001 has one user editable
profile, which can be loaded and saved to the device. After any
modification of configuration the changes need to be saved to
device using Save to device button. Main buttons offer following
functionality:
1. Load from device – loads configuration from device.
2. Save to device – saves configuration to device.
3. Load from file – loads configuration from file.
4. Save to file – saves configuration to file.
5. Update firmware – updates firmware on device.
6. Read records – reads records from the device.
7. Reboot device – restarts device.
8. Reset configuration – sets device configuration to
default.
Most important configurator section is GPRS – where all your
server and GPRS settings can be configured and Data Acquisition
–where data acquiring parameters can be configured.
More details about FMB001 configuration using Configurator can
be found in our Wiki.
Figure 8 Device connected via USB
Figure 7 Language selection
Figure 9 Configurator Status window

8
FMB001 | Wiki
LED indications
Table 3 Navigation LED indications
Behaviour Meaning
Permanently switched on GNSS signal is not received
Blinking every second Normal mode, GNSS is working
Off
GNSS is turned off because:
Device is not working or Device is in
sleep mode
Blinking fast constantly Device firmware is being flashed
Table 4 Status LED indications
Behaviour Meaning
Blinking every second Normal mode
Blinking every two seconds Sleep mode
Blinking fast for a short time Modem activity
Off Device is not working or Device is in
boot mode
Characteristics
Basic characteristics
Table 5 Basic characteristics
Module
Name TM2500
Technology GSM, GPRS, GNSS, BLUE-TOOTH
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU,
SBAS, QZSS, DGPS, AGPS
Receiver 33 channel
Tracking sensitivity -165 dBM
Accuracy < 3 m
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s
Cellular
Technology GSM
2G bands Quad-band 850 / 900 / 1800 / 1900
MHz
Data transfer GPRS Multi-Slot Class 12 (up to 240
kbps), GPRS Mobile Station Class B
Data support SMS (text/data)

9
FMB001 | Wiki
Power
Input voltage range 10 - 30 V DC with overvoltage
protection
Power consumption
At 12V < 5 mA (Ultra Deep Sleep)
At 12V < 7 mA (Deep Sleep)
At 12V < 7 mA (Online Deep Sleep)
At 12V < 8 mA (GPS Sleep)
At 12V < 28 mA (nominal)
Blue-tooth
Specification 4.0 + LE
Supported peripherals Temperature and Humidity sensor,
Headset, OBDII dongle
OBDInterface
Data K-Line, CAN Bus data
Data reading Up to 32 vehicle onboard parameters,
10 supported OBD protocols
Interface
Digital Inputs 1
Connection OBDII socket
GNSS antenna Internal High Gain
GSM antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 2 status LED lights
SIM Micro-SIM
Memory 128MB internal flash memory
Physicalspecification
Dimensions 50,7 x 49,6 x 25 mm (L x W x H)
Weight 63 g
Operatingenvironment
Operating temperature -25 °C to +55 °C
Storage temperature -40 °C to +70 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection Rating IP41
Features
Sensors Accelerometer
Scenarios
Green Driving, Over Speeding
detection, Jamming detection, GNSS
Fuel Counter, Excessive Idling
detection, Unplug detection, Towing
detection, Crash detection, Auto
Geofence, Manual Geofence, Trip
Sleep modes GPS Sleep, Online Deep Sleep, Deep
Sleep, Ultra Deep Sleep
Configuration and firmware update
FOTA Web, FOTA, FMB Configurator
(USB, Blue-tooth), FMBT mobile
application (Configuration)
SMS Configuration, Events, Debug
GPRS commands Configuration, Debug
Time Synchronization GPS, NITZ, NTP

10
FMB001 | Wiki
Safety information
This message contains information on how to operate FMB001
safely. By following these requirements and recommendations,
you will avoid dangerous situations. You must read these
instructions carefully and follow them strictly before operating the
device!
•The device uses SELV limited power source. The nominal
voltage is +12 V DC. The allowed voltage range is +10…+30 V DC.
•To avoid mechanical damage, it is advised to transport the
device in an impact-proof package. Before usage, the device
should be placed so that its LED indicators are visible. They
show the status of device operation.
•Before unmounting the device from vehicle, ignition MUST be
OFF.
Do not disassemble the device. If the device is
damaged, the power supply cables are not
isolated or the isolation is damaged, DO NOT
touch the device before unplugging the power
supply.
All wireless data transferring devices produce
interference that may affect other devices which
are placed nearby.
Please consult representatives of your vehicle
model regarding OBDII location on your vehicle. In
case you are not sure about proper connection,
please consult qualified personnel.
The programming must be performed using a PC
with autonomic power supply.
Installation and/or handling during a lightning
storm is prohibited.
The device is susceptible to water and humidity.
Teltonika is not responsible for any harm caused
by wrong cables used for connection between PC
and FMB001
WARNING! Do not use FMB00 device if it distracts
driver or causes inconvenience due to OBDII
placement. Device must not interfere with driver.

11
FMB001 | Wiki
Certification and Approvals
•FMB001 CE / RED
•FMB001 E-Mark
•FMB001 EAC
•FMB001 RoHS
•FMB001 REACH
•FMB001 Declaration of IMEI assignment
This sign on the package means that it is
necessary to read the User‘s Manual before
your start using the device. Full User‘s
Manual version can be found in our Wiki.
This sign on the package means that all used
electronic and electric equipment should not
be mixed with general household waste.
Hereby, Teltonika declare under our sole
responsibility that the above described
product is in conformity with the relevant
Community harmonization: European
Directive 2014/53/EU (RED).
