Teltonika FM1200 User manual

FM1200 User Manual
For Product Codes:
(G33/10-30V/NiMH battery)
V1.7

2
Table of contents
1 INTRODUCTION............................................................................................................ 6
1.1 A TTENTION .............................................................................................................. 6
1.2 I NSTRUCTIONS OF SAFETY ........................................................................................ 6
1.3 L EGAL N OTICE ......................................................................................................... 7
1.4 A BOUT DOCUMENT ................................................................................................... 7
2 BASIC DESCRIPTION................................................................................................... 7
2.1 P ACKAGE CONTENTS ................................................................................................ 7
2.2 B ASIC CHARACTERISTICS .......................................................................................... 8
2.3 T ECHNICAL FEATURES .............................................................................................. 9
2.4 T ECHNICAL I NFORMATION ABOUT INTERNAL BATTERY ............................................... 10
2.5 F USES ................................................................................................................... 10
2.6 E LECTRICAL CHARACTERISTICS .............................................................................. 10
2.7 A BSOLUTE M AXIMUM R ATINGS ............................................................................... 11
3 CONNECTION, PINOUT, ACCESSORIES................................................................. 11
3.1 H OW TO INSERT SIM CARD AND HOW TO CONNECT BATTERY INTO FM1200 DEVICE :. 11
3.2 I NSTALLING FM1200 DRIVERS ................................................................................ 12
3.3 N AVIGATE LED...................................................................................................... 13
3.4 S TATUS LED......................................................................................................... 13
3.5 M AIN CABLE WIRING ............................................................................................... 14
3.6 USB CONNECTION ................................................................................................. 14
3.7 A CCESSORIES ....................................................................................................... 16
4 FIRMWARE.................................................................................................................. 19
4.1 U PDATING FIRMWARE USING USB CABLE ................................................................ 19
5 OPERATIONAL BASICS ............................................................................................ 20
5.1 O PERATIONAL PRINCIPALS ...................................................................................... 20
5.2 S LEEP MODES ........................................................................................................ 20
5.2.1 Sleep mode................................................................................................. 20
5.2.2 Deep Sleep mode....................................................................................... 21
5.3 V IRTUAL ODOMETER ............................................................................................... 22
5.4 F EATURES ............................................................................................................. 22
5.4.1 Scenarios.................................................................................................... 22
5.4.2 Trip.............................................................................................................. 23
5.4.3 Geofencing.................................................................................................. 23
5.4.4 iButton list ................................................................................................... 23
5.5 CONFIGURATION .............................................................................................. 24
5.6 C ONFIGURATOR ..................................................................................................... 24
5.7 R EAD RECORDS ..................................................................................................... 25
5.8 S YSTEM SETTINGS ................................................................................................. 26
5.9 R ECORDS SETTINGS ............................................................................................... 27
5.10 GSM SETTINGS , GPRS PART ................................................................................. 27
5.11 GSM SETTINGS , SMS PART ................................................................................... 28
5.12 GSM SETTINGS , O PERATOR LIST ............................................................................ 29
5.13 D ATA A CQUISITION M ODE SETTINGS ....................................................................... 29
5.14 F EATURES SETTINGS .............................................................................................. 33
5.14.1 Scenarios settings....................................................................................... 33
5.14.2 Trip settings ................................................................................................ 34
5.14.3 Geofencing settings.................................................................................... 35
5.14.4 SMS events................................................................................................. 37
5.14.4.1 SMS events configuration............................................................................... 39
5.15 I/O SETTINGS ......................................................................................................... 41
5.15.1 Monitoring ................................................................................................... 44
5.15.2 Din3/Ain IO element configuration.............................................................. 44
5.15.3 Event Generating........................................................................................ 44
5.15.4 Hysteresis ................................................................................................... 45
6 SMS COMMAND LIST................................................................................................. 46

3
6.1 SMS COMMAND LIST .............................................................................................. 46
6.1.1 getstatus ..................................................................................................... 47
6.1.2 getweektime................................................................................................ 47
6.1.3 getops ......................................................................................................... 47
6.1.4 getcfgtime ................................................................................................... 48
6.1.5 getgps ......................................................................................................... 48
6.1.6 getver.......................................................................................................... 48
6.1.7 getinfo ......................................................................................................... 48
6.1.8 getio ............................................................................................................ 49
6.1.9 readio #....................................................................................................... 49
6.1.10 setdigout ## Y1 Y2...................................................................................... 49
6.1.11 getparam ####............................................................................................ 50
6.1.12 setparam #### #......................................................................................... 50
6.1.13 getparam 1271 #......................................................................................... 50
6.1.14 setparam 1271 #......................................................................................... 50
6.1.15 readops #.................................................................................................... 50
6.1.16 flush #,#,#,#,#,#,# ....................................................................................... 50
6.1.17 sn # ............................................................................................................. 51
6.1.18 banlist.......................................................................................................... 51
6.1.19 crashlog ...................................................................................................... 51
7 DEBUG MODE............................................................................................................. 51
8 PARAMETER LIST...................................................................................................... 52
8.1 P ARAMETERS VALUE TYPES .................................................................................... 52
8.2 S YSTEM PARAMETERS ............................................................................................ 52
8.2.1 Sleep Mode (ID=1000)................................................................................ 52
8.2.2 Sleep timeout (ID=200)............................................................................... 52
8.2.3 Analog Input value range (ID=1001)........................................................... 53
8.2.4 Stop Detection Source (ID=1002)............................................................... 53
8.2.5 Static Navigation (ID=1003)........................................................................ 53
8.2.6 Records (ID=201) ....................................................................................... 53
8.3 R ECORDS PARAMETERS ......................................................................................... 53
8.3.1 Sorting (ID=1010) ....................................................................................... 53
8.3.2 Active Data Link Timeout (ID=1011)........................................................... 53
8.3.3 Server Response Timeout (ID=1012)......................................................... 54
8.4 GSM PARAMETERS ................................................................................................ 54
8.4.1 GPRS content activation (ID=1240) ........................................................... 54
8.4.2 APN Name (ID=1242)................................................................................. 54
8.4.3 APN username (ID=1243) .......................................................................... 55
8.4.4 APN Password (ID=1244)........................................................................... 55
8.4.5 Domain (ID=1245) ...................................................................................... 55
8.4.6 Target Server Port (ID=1246)..................................................................... 55
8.4.7 Protocol (ID=1247)...................................................................................... 55
8.4.8 SMS Login (ID=1252) ................................................................................. 55
8.4.9 SMS Password (ID=1253).......................................................................... 56
8.4.10 SMS data sending settings (ID=1250)........................................................ 56
8.4.11 SMS Data send week time schedule (ID=1273)......................................... 56
8.4.12 Authorized phone numbers (ID=1260-1269).............................................. 56
8.4.13 SMS Event PreDefined Numbers (ID=150-159)......................................... 56
8.4.14 Operator List (ID=1271).............................................................................. 57
8.5 D ATA A CQUISITION M ODES PARAMETERS ................................................................ 57
8.5.1 Home Network GSM operator code “Vehicle on STOP” parameters......... 57
8.5.1.1 Min Period (ID=1540) .......................................................................................... 57
8.5.1.2 Min Saved Records (ID=1543)............................................................................ 57
8.5.1.3 Send Period (ID=1544)........................................................................................ 57
8.5.1.4 GPRS Week Time (ID=1545) .............................................................................. 57
8.5.2 Home Network GSM operator code “Vehicle MOVING” parameters ......... 58
8.5.2.1 Min Period (ID=1550) .......................................................................................... 58
8.5.2.2 Min Distance (ID=1551)....................................................................................... 58
8.5.2.3 Min Angle (ID=1552)............................................................................................ 58
8.5.2.4 Min Saved Records (ID=1553)............................................................................ 58
8.5.2.5 Send Period (ID=1554)........................................................................................ 59

4
8.5.2.6 GPRS Week Time (ID=1555) .............................................................................. 59
8.5.3 Roaming Network GSM operator code “Vehicle on STOP” parameters.... 59
8.5.3.1 Min Period (ID=1560) .......................................................................................... 59
8.5.3.2 Min Saved Records (ID=1563) ............................................................................ 59
8.5.3.3 Send Period (ID=1564)........................................................................................ 59
8.5.3.4 GPRS Week Time (ID=1565) .............................................................................. 59
8.5.4 Roaming Network GSM operator code “Vehicle MOVING” parameters .... 59
8.5.4.1 Min Period (ID=1570) .......................................................................................... 59
8.5.4.2 Min Distance (ID=1571)....................................................................................... 60
8.5.4.3 Min Angle (ID=1572)............................................................................................ 60
8.5.4.4 Min Saved Records (ID=1573)............................................................................ 60
8.5.4.5 Send Period (ID=1574)........................................................................................ 60
8.5.4.6 GPRS Week Time (ID=1575) .............................................................................. 60
8.5.5 Unknown Network GSM operator code “Vehicle on STOP” parameters.... 61
8.5.5.1 Min Period (ID=1580) .......................................................................................... 61
8.5.5.2 Min Saved Records (ID=1583)............................................................................ 61
8.5.5.3 Send Period (ID=1584)........................................................................................ 61
8.5.5.4 GPRS Week Time (ID=1585) .............................................................................. 61
8.5.6 Unknown Network GSM operator code “Vehicle MOVING” parameters.... 61
8.5.6.1 Min Period (ID=1590) .......................................................................................... 61
8.5.6.2 Min Distance (ID=1591)....................................................................................... 61
8.5.6.3 Min Angle (ID=1592)............................................................................................ 62
8.5.6.4 Min Saved Records (ID=1593)............................................................................ 62
8.5.6.5 Send Period (ID=1594)........................................................................................ 62
8.5.6.6 GPRS Week Time (ID=1595) .............................................................................. 62
8.6 F EATURES P ARAMETERS ........................................................................................ 62
8.6.1 Digital Output No.1 usage scenarios (ID=1600)......................................... 62
8.6.2 Max Acceleration Force (ID=1602)............................................................. 62
8.6.3 Max Braking Force (ID=1603)..................................................................... 63
8.6.4 Max Angular Velocity (ID=1604)................................................................. 63
8.6.5 Max allowed Speed (ID=1605) ................................................................... 63
8.6.6 Digital Output No.2 usage scenarios (ID=1601)......................................... 63
8.6.7 Trip (ID=1280)............................................................................................. 63
8.6.8 Start Speed (ID=1281)................................................................................ 63
8.6.9 Ignition Off Timeout (ID=1282) ................................................................... 64
8.6.10 Trip Continuous distance counting (ID=1283)............................................ 64
8.6.11 Geofencing.................................................................................................. 64
8.6.11.1 Frame border (ID=1020).................................................................................... 64
8.6.11.2 Geofence Zone #1 Shape (ID=1030)................................................................. 64
8.6.11.3 Geofence Zone #1 Priority (ID=1031)................................................................ 64
8.6.11.4 Geofence Zone #1 Generate Event (ID=1032).................................................. 64
8.6.11.5 Geofence Zone #1 Longitude (X1) (ID=1033).................................................... 65
8.6.11.6 Geofence Zone #1 Latitude (Y1) (ID=1034) ...................................................... 65
8.6.11.7 Geofence Zone #1 Longitude (X2) (ID=1035).................................................... 65
8.6.11.8 Geofence Zone #1 Latitude (Y2) (ID=1036) ...................................................... 65
8.6.12 AutoGeofencing.......................................................................................... 66
8.6.12.1 Enable/Disable (ID=1101) ................................................................................. 66
8.6.12.2 Activation Timeout (ID=1102)............................................................................ 66
8.6.12.3 Deactivate by (ID=1100).................................................................................... 66
8.6.12.4 AutoGeofence event Priority (ID=1103)............................................................. 66
8.6.12.5 AutoGeofence event generating (ID=1104)....................................................... 66
8.6.12.6 Radius (ID=1105) .............................................................................................. 66
8.6.13 iButton List (ID=1610-1659)........................................................................ 67
8.7 I/O PARAMETERS ................................................................................................... 67
8.7.1 I/O#1 property parameter (ID=1300) .......................................................... 67
8.7.2 I/O#1 priority (ID=1301) .............................................................................. 67
8.7.3 I/O#1 High level (ID=1302)......................................................................... 67
8.7.4 I/O#1 Low level (ID=1303).......................................................................... 68
8.7.5 I/O#1 logic operand (ID=1304) ................................................................... 68
8.7.6 I/O#1 averaging length (ID=1305) .............................................................. 68
8.7.7 I/O#2 exception for a Digital input 3/Analog input option (ID=1320) .......... 70
8.8 SMS EVENT CONFIGURATION ................................................................................. 70
8.8.1 I/O#1 element SMS event configuration (ID=100)...................................... 70
9 MOUNTING RECOMMENDATIONS........................................................................... 72

5
9.1 C ONNECTING W IRES .............................................................................................. 72
9.2 C ONNECTING P OWER S OURCE ............................................................................... 72
9.3 C ONNECTING I GNITION W IRE .................................................................................. 72
9.4 C ONNECTING G ROUND W IRE .................................................................................. 72
9.5 FM1200 INSTALLATION INSTRUCTION ...................................................................... 73
10 DOWNLOADING LOG USING “HERCULES”....................................................... 76
CHANGE LOG.................................................................................................................... 78

6
1 INTRODUCTION
1.1 Attention
Do not disassemble the device. If the device is
damaged, the power supply cables are not isolated
or the isolation is damaged, before unplugging the
power supply, do not touch the device.
All wireless data transferring devices produce
interference that may affect other devices which
are placed nearby.
The device must be connected only by qualified
personnel.
The device must be firmly fastened in the
predefined location.
The programming must be performed using a
second class PC (with autonomic power supply).
The device is susceptible to water and humidity in
environment with IP class greater than IP67.
Any installation and/or handling during a lightning
storm are prohibited.
FM1200 has USB interface;
Please use cables provided with FM1200 device.
Teltonika is not responsible for any harm caused
by using wrong cables for PC <-> FM1200
connection.
1.2 Instructions of safety
This chapter contains information on how to operate FM1200 safely. By following
these requirements and recommendations, you will avoid dangerous situations. You must
read these instructions carefully and follow them strictly before operating the device!
The device uses a 10 V...30 V DC power supply. The nominal voltage is 12 V DC.
The allowed range of voltage is 10 V...30 V DC.
To avoid mechanical damage, it is advised to transport the FM1200 device in an
impact-proof package. Before usage, the device should be placed so that its LED
indicators are visible, which show the status of operation the device is in.
When installing the connection cables to the vehicle, the appropriate jumpers of the
power supply of the vehicle should be disconnected.
Before dismounting the device from the vehicle, the connection cables must be
disconnected.

7
The device is designed to be mounted in a zone of limited access, which is
inaccessible for the operator. All related devices must meet the requirements of standard
EN 60950-1.
The device FM1200 is not designed as a navigational device for boats.
1.3 Legal Notice
Copyright © 2013 Teltonika. All rights reserved. Reproduction, transfer, distribution
or storage of part or all of the contents in this document in any form without the prior
written permission of Teltonika is prohibited.
Other products and company names mentioned here may be trademarks or trade
names of their respective owners.
The manufacturer reserves the right to make changes and/or improvements at any
time in design, functionality, parameters and electrical characteristics without any prior
notice and without incurring obligations.
1.4 About document
This document contains information about the architecture, possibilities, mechanical
characteristics, and configuration of the FM1200 device.
Acronyms and terms used in document
PC – Personal Computer.
GPRS – General Packet Radio Service
GPS – Global Positioning System
GSM – Global System for Mobile Communications
SMS – Short Message Service
AC/DC – Alternating Current/Direct Current
I/O – Input/Output
Record – AVL data stored in FM1200 memory. AVL data contains GPS and I/O
information
AVL packet - data packet that is being sent to server during data transmission. AVL
packet contains from 1 to 50 records.
2 BASIC DESCRIPTION
FM1200 is a terminal with GPS and GSM connectivity, which is able to determine
the object’s coordinates and transfer them via the GSM network. This device is perfectly
suitable for applications, which need location acquirement of remote objects. It is
important to mention that FM1200 has additional inputs and outputs, which let you control
and monitor other devices on remote objects. FM1200 also has a USB port for device
status log output and entering configurations.
2.1 Package contents
1
The FM1200 device is supplied to the customer in a cardboard box containing all
the equipment that is necessary for operation. The package contains:
FM1200 device;
USB cable (optional);
Ni-MH battery 7.2V, 400mAh (optional).
1
Package content depends on Order Code, and can be customized by customer needs.

8
2.2 Basic characteristics
GSM / GPRS features:
•Teltonika TM11Q quad band module (GSM 850 / 900 / 1800 / 1900 MHz);
•GPRS class 10;
•SMS (text, data).
GNSS GGG303 Module features:
•Navigation Systems; GPS/GLONASS/GALILEO/QZSS;
•Protocol NMEA-0183: GGA, GGL, GSA, GSV, RMC, VTG;
•Up to -162 dBm sensitivity.
Hardware features:
•Cortex®-M3 processor;
•16 MB internal Flash memory;
•Built-in accelerometer;
•Ni-MH internal rechargeable battery 7.2V 400mAh (optional).
Interface features:
•Power supply: 10 … 30V;
•USB port;
•2 digital inputs;
•1 digital/analog input (configurable);
•2 open collector digital outputs;
•1Wire® temperature sensor
•1Wire® iButton
•LEDs indicating device status.
Special features:
•Any element event triggers (external sensor, input, speed, temperature, etc.);
•Highly configurable data acquisition and sending;
•Multiple Geo-fence areas;
•Sleep mode;
•Deep sleep mode;
•Configurable scenarios available;
•Real-time process monitoring;
•Authorized number list for remote access;
•Firmware update over GPRS or USB port;
•Configuration update over GPRS, SMS or USB port;
•TCP/IP or UDP/IP protocol support;
•100’000 record storing;

9
2.3 Technical features
Part name Physical specification Technical details
Navigation
LED LED
Modem LED LED
USB Special USB socket, can be connected to PC using special
USB wire (cable is optional)
Power supply 10...30 V DC
2W Max
Energy consumption:
GPRS: average 88 mA r.m.s,
462 mA Max.,
Nominal: average 50 mA r.m.s,
GPS Sleep: average 23 mA,
Deep Sleep: average less than
2 mA
2
Operation temperature:
-25C ... +55C
Storage temperature:
-40C ... +70C
Storage relative humidity 5 ... 95 %
(no condensation)
Table 1. FM1200 specifications
Figure 1. FM1200 view & dimensions (tolerance ±2mm)
2
When in Deep Sleep mode no data storing and sending is activated.

10
2.4 Technical Information about internal battery
Ni-MH rechargeable battery, 7.2V, 400 mA.
FM1200 operating time with internal battery depends on temperature, data sending
frequency (SMS and GPRS), and accumulator age, number of charge/discharge cycles.
2.5 Fuses
1. Internal fuse F1 – rated current 5A DC, necessary for the protection of the entire
product as a whole.
2. Internal fuse F2 (PTC) – rated current 350 mA DC, necessary to protect the
charger circuit and battery.
3. Internal battery pack fuse (PTC) – rated current 2.1A DC, necessary to protect
the battery pack from the load short-circuit.
2.6 Electrical characteristics
VALUE
CHARACTERISTIC DESCRIPTION Min. Typ. Max. Unit
Supply Voltage:
Supply Voltage (Recommended Operating
Conditions) 10 30 V
Digital Output (Open Drain grade):
Drain current (Digital Output OFF) 120 uA
Drain current (Digital Output ON,
Recommended Operating Conditions) 300 mA
Static Drain-Source resistance (Digital
Output ON) 300 mOhm
Digital Input:
Input resistance (DIN1, DIN2, DIN3) 15 kOhm
Input Voltage (Recommended
Operating Conditions) 0 Supply voltage V
Input Voltage threshold (DIN1) 7,5 V
Input Voltage threshold (DIN2, DIN3) 2,5 V
Analog Input:
Input Voltage (Recommended
Operating Conditions), Range1 0 10 V
Input resistance, Range1 120 kOhm
Input Voltage (Recommended
Operating Conditions) Range2 0 30 V
Input resistance, Range2 146,7 kOhm

11
2.7 Absolute Maximum Ratings
VALUE
CHARACTERISTIC DESCRIPTION Min. Typ. Max. Unit
Supply Voltage (Absolute Maximum Ratings) -32 32 V
Drain-
Source clamp threshold voltage (Absolute
Maximum Ratings), ( I
drain
= 2mA ) 36 V
Digital Input Voltage (Absolute Maximum
Ratings) -32 32 V
Analog Input Voltage (Absolute Maximum
Ratings) -32 32 V
3 CONNECTION, PINOUT, ACCESSORIES
3.1 How to insert SIM card and how to connect battery into FM1200 device :

Open FM1200 case using screwdriver

Remove FM1200 case

Insert SIM card as shown

Connect battery connectoras shown

12

Attach case, and screw in the screws

Device is ready
3.2 Installing FM1200 drivers
Software requirements:
• Operating system 32-bit and 64-bit: Windows XP with SP3 or later, Windows Vista,
Windows 7.
• MS .NET Framework V3.5 or later (http://www.microsoft.com or
http://avl1.teltonika.lt/downloads/tavl/Framework/dotnetfx35setupSP1.zip).
Drivers:
Please download Virtual COM Port drivers from Teltonika website:
http://avl1.teltonika.lt/downloads/FM12/vcpdriver_v1.3.1_setup.zip
Installing drivers:
Extract and run VCPDriver_V1.3.1_Setup.exe. This driver is used to detect FM1200
device connected to the computer. Click ‘Next’ in driver installation window (figures
below):
Figure 2. Driver installation window
This will launch device driver installation wizard. In the following window click ‘Next’
button again:

13
Figure 3. Driver installation window
Setup will continue installing drivers and will display a window about successful
process at the end. Click ‘Finish’ to complete setup:
Figure 4. Driver installation window
You have now installed drivers for FM1200 device successfully.
3.3 Navigate LED
Behaviour Meaning
Permanently switched on GPS signal is not received
Blinking every second Normal mode, GPS is working
Off GPS is turned off because:
•Deep sleep mode
Or
•GPS antenna short circuited
3.4 Status LED
Behaviour Meaning
Blinking every second Normal mode
Blinking every 2 seconds Deep sleep mode
Blinking fast for a short
time Modem activity
Blinking fast constantly Boot mode
Off •Device is not working
Or
•Device firmware being flashed

14
3.5 Main cable wiring
Nr. Wire Name Description Wire color
1 VCC (10÷30)V DC
(+) Power supply for module. Power
supply range (10...30) V DC Red
2 OUT 2 Digital output. Channel 2. Open
collector output. Max. 300mA.
Pink
3 OUT 1 Digital output. Channel 1. Open
collector output. Max. 300mA.
White
4 DIN 2 Digital input, channel 2 Gray
5 DIN 1 Digital input, channel 1 DEDICATED FOR IGNITION
INPUT
Yellow
6 GND(VCC(10÷30)V
DC)(-) Ground pin. (10÷30)V DC ( ―) Blue
7 AIN 1 Analog input, channel 1. Input
range: 0-30V/0-10V DC Brown
8 DATA_DALLAS Data channel for Dallas 1-Wire®
devices Green
Table 2. Main cable wires description
Figure 5. FM1200 sticker
3.6 USB connection
For connecting FM1200 device to PC, special USB cable is used. On one side of
the cable there is usual USB plug, which should be connected to PC. Other side of the
cable has connector to connect with FM1200. Cable can be connected after removing
cover of FM1200:

15
Figure 6. USB cable connection to the FM1200 device
Please note that FM1200 device must be connected to the power supply
before it can be connected to the PC!
When FM1200 is connected to PC, it creates an STM Virtual COM Port, which can
be used as a system port (to flash firmware and configure the device):
Figure 7. COM-Ports

16
3.7 Accessories
Note: Teltonika does not provide any additional equipment like panic
buttons, door sensors or others.
1 – Wire devices
One of the realized features FM1200 is 1-Wire® data protocol, which enables
connection of thermometer (DS1820, DS18S20 and DS18B20) and I-Button type:
DS1990A (Figures 8 and 9 show FM1200 and 1-wire® device connection schemes). For
additional information please refer to the 1-Wire Design Guide document.
Note that FM1200 devices supports temperature sensors in parasitic mode! In
this particular mode temperature sensor is connected without use of 1Wire power:
Left row of pins
1W. PWR
must be connected
to GND pin 3 1
Right row of pins
1W. Data
(FM1200 – Green
wire) 2 1
Vpp (+5 Volts DC)
–
power source for
external digital
sensor
GND
(FM1200 – Blue
wire) 3
Digital Input 4
2
Output from
external digital
sensor
Figure 8. Digital thermometer DS1820 and TTJ100 connection scheme

17
Figure 9. I-Button DS1990A connection scheme
Fuel Tank sensors
A fuel tank level sensor exists in most
cars, which shows the approximate fuel level in
the driver’s indicator panel. It is possible to
connect FM1200 Analog input to it (if sensor
returns analogue signal proportional to fuel
level). Figure shows the connection scheme to
the FM1200 and fuel tank sensor. After the
connection to the tank fuel level sensor,
calibration is needed. Calibration is needed
because most fuel tank sensors are not linear.
Calibration is performed by measuring voltage
dependence on volume of fuel in tank.
Alarm buttons, door sensors, etc.
Alarm buttons, door sensors, ignition, etc. return two states: high or low voltage.
Digital inputs are used to read this information. Figure below shows how to connect alarm
button, door sensor, etc.
Figure 10. Panic button connection
In cases when sensor output signal is negative, an additional relay has to be
installed to convert negative signal to positive.

18
Figure 11. Inverting relay connection
Immobilizer relay
When connected as shown below, FM1200 disables engine starter when output is
OFF. More details about relays can be found below.
Figure 12. Immobilizer relay connection
Relays
An ordinary automotive relay is used to invert input signal or to immobilize engine
starter. Note, that they are available as 12 V or 24 V.
Figure 13. Automotive relay pinout

19
4 FIRMWARE
4.1 Updating firmware using USB cable
FM1200 functionality is always improving, new firmware versions are developed.
Current module firmware version can be retrieved from Configurator. See configuration
description for details.
Contact sales manager to get the latest firmware.
Updater is needed to update the firmware. It can be downloaded from:
http://avl1.teltonika.lt/downloads/FM12/
Firmware must to be copied to “Firmware updater” folder. Only one firmware must
be in folder.
Connect FM1200 to PC with the USB cable. Launch “Firmware Updater”, select
COM port to which device is connected, click connect, and when IMEI and Firmware
version fields are filled, start the update. Device needs some time to send IMEI and
Firmware version, so do not be afraid if IMEI will not show up immediately, disconnect
and after 1-2 minutes try to connect again. Update process may take up to several
minutes.
Figure 14. FM1200 firmware updater screen

20
Figure 15. FM1200 firmware updating finished
When you see a table like in Figure 15, it means that the firmware is flashed to
FM1200 successfully. You may now close the update window and start using your
FM1200 device.
5 OPERATIONAL BASICS
5.1 Operational principals
FM1200 module is designed to acquire records and send them to the server.
Records contain GPS data and I/O information. Module uses GPS receiver to acquire
GPS data and is powered with three data acquire methods: time-based, distance-based
and angle-based method. Note, that if FM1200 loses connection to GPS satellites, it
continues to make records, however coordinate in these records remains the same (last
known coordinate). Method’s details are described in section 5.13. All data is stored in
flash memory and later can be sent via GPRS or SMS. GPRS mode is the most preferred
data sending mode. SMS mode is mostly used in areas without GPRS coverage or
GPRS usage is too expensive.
GPRS and SMS settings are described in later sections. FM1200 communicates
with server using special data protocol. Data protocol is described in “FMXXXX
Protocols” document.
FM1200 can be managed by SMS commands. SMS Command list is described in
SMS COMMAND LIST section. Module configuration can be performed over TCP or via
SMS. Configuration parameters and modes are described in “FMXXXX Protocols”
document.
5.2 Sleep modes
5.2.1 Sleep mode
FM1200 is able to go to Sleep mode after configurable Sleep timeout. This timeout
(defined period) starts counting when device is in STOP mode. After timeout is reached
and all conditions for sleep mode are met, device goes to sleep mode. While in sleep
mode, FM1200 turns GPS module off and it is not making new periodic records. Only
event records is being recorded with last known coordinate and sent to AVL server. As a
result power usage decreases allowing saving vehicle battery.
