Tenmars ST-130 User manual

ST-130/ST-130S
User’s Manual
Noise Dose Meter
HB2ST1300000

Contents:
1.SAFETY PRECAUTIONS ......................................................................................................... 3
1.1.Preliminary Description ..................................................................................................... 3
1.2.Note................................................................................................................................... 3
2.PREPARATION FOR USE ....................................................................................................... 4
2.1.Initial.................................................................................................................................. 4
2.2.Calibration ......................................................................................................................... 4
2.3.Storage.............................................................................................................................. 4
3.INSTRUMENT INSTRUCTIONS............................................................................................... 5
3.1.Instrument Description ...................................................................................................... 5
3.1.1.Controls Description ................................................................................................................... 5
3.1.2.Display Description..................................................................................................................... 6
3.1.3.ST-130S Microphone.................................................................................................................. 7
3.1.4.Input interface............................................................................................................................. 7
3.2.Noise Does Measurement Procedures ............................................................................. 8
3.3.Sound Level Measurement Procedures ............................................................................ 8
3.4.Auto Data Record.............................................................................................................. 9
3.5.Single Data Record ......................................................................................................... 10
3.6.Viewing Logged Reading ................................................................................................ 10
3.7.Set Mode......................................................................................................................... 10
3.7.1.Test Mode Set ......................................................................................................................... 11
3.7.2.Auto Power Off Set................................................................................................................... 11
3.7.3.Sampling Time & Auto Record Set........................................................................................... 11
3.7.4.Real Time Clock Set................................................................................................................. 12
3.7.5.94dB Offset Adjust Set ............................................................................................................. 12
3.7.6.Noise Standard Set .................................................................................................................. 12
3.7.7.SLM Function Set .................................................................................................................... 13
4.SOFTWARE............................................................................................................................ 14
4.1.System Requirements ..................................................................................................... 14
4.2.Software Description ....................................................................................................... 14
4.3.Tools Description............................................................................................................. 15
4.4.Open File......................................................................................................................... 15
4.4.1.Zoom Function.......................................................................................................................... 15
4.4.2.Drag function ............................................................................................................................ 15
4.5.Option.............................................................................................................................. 16
4.5.1.PC Setting................................................................................................................................. 16
4.5.2.Meter Setting ............................................................................................................................ 16
4.6.Print Noise Dose Report.................................................................................................. 17
4.7.Sound level chart & Noise dose chart (LN %) ................................................................. 17
4.8.Enable PC data logger .................................................................................................... 18
4.9.Dowload Record data...................................................................................................... 18
4.10.Erase Record data .......................................................................................................... 18
5.EXPLAINATION ...................................................................................................................... 19
5.1.1. Measurement Parameters:.......................................................................................... 19
5.2.A, C, Z Weighting Instruction:.......................................................................................... 20
6.MAINTENANCE ...................................................................................................................... 21
6.1.General Information......................................................................................................... 21
6.2.Battery Replacement....................................................................................................... 21
6.3.Cleaning .......................................................................................................................... 21
6.4.End of Life ....................................................................................................................... 21
7.TECHNICAL SPECIFICATIONS............................................................................................. 22
7.1.Feature............................................................................................................................ 22
7.2.Environment .................................................................................................................... 23
7.2.1.Environmental Conditions......................................................................................................... 23
7.2.2.EMC.......................................................................................................................................... 23
7.3.Accessories.....................................................................................................................23

EN - 2
7.3.1.Standard Accessories............................................................................................................... 23
8.SERVICE ................................................................................................................................ 24
8.1.Warranty Conditions........................................................................................................ 24
8.2.Service ............................................................................................................................ 24

EN - 3
1. SAFETY PRECAUTIONS
When taking measurements:
․ Avoid doing measurements in humid or wet places - make sure that humidity is
within the limits indicated in section “environmental conditions”.
․ Avoid doing measurements in presence of explosive gas, combustible gas,
steam or excessive dust.
The following symbols are used:
Caution: refer to the user’s manual. An incorrect use may damage the
tester or its components
The instrument conforms to the CE standard
1.1. Preliminary Description
The ST-130/ST-130s is designed to test noise exposure in accordance with
OSHA,MSHA,DOS,ACGIH, and ISO standards.
Fast and easy on-site surveys help determine noise reduction requirements.
The meter can also be used in SLM(sound level meter)mode.
The SLM mode has a datalogging feature that can record up to 1000K readings
which can be downloand to PC for analysis.
The built-in USB interface to connect PC.
Applications: Evaluation of environmental noise, Measurements of noise at
workplaces, Assessment of product noise.
1.2. Note
CAUTION
Does not observe the warning and/or operation instruction, it’s
possible to damage the instrument either its components or the
operator
․ Do not operate the instrument at temperature and humidity environment
beyond to reference conditions of chapter 7.2.1.
․ Keep the microphone dry and avoid severe vibration.
․ Wind blowing across the microphone would bring additional extraneous
noise. Once using the instrument in the presence of wind, it must mount the
windscreen to prevent the undesirable signals.

EN - 4
2. PREPARATION FOR USE
2.1. Initial
The instrument has been checked mechanically and electrically prior to shipment.
Take care to ensure the instrument reaches you undamaged.
However, it is wise to carry out a rapid check in order to detect any possible
damage that may cause during transport.
If it’s damage, claims to the dealer immediately.
Check the packaging content according to packing list reported in 7.3.1 chapter .In
case of discrepancies, contact the dealer immediately.
In the event of re-shipment of the instrument please follow the instructions reported
in chapter 7.3.1.
2.2. Calibration
The instrument complies with the technical specifications contained in this manual
and such compliance is guaranteed for 1 year. The instrument is maybe need
recalibration after one year.
2.3. Storage
After a period of storage in extreme environmental conditions exceeding the limits
mentioned in paragraph 7.2.1 let the instrument return to normal measuring
conditions before using it.

EN - 5
3. INSTRUMENT INSTRUCTIONS
3.1. Instrument Description
3.1.1. Controls Description
1. Microphone
2. Microphone Cable
3. Microphone Connector(Male)
4. Microphone Connector(Female)
5. LCD Display
6. record data / Reading record data
button
7. Power ON/OFF Button
8. UP Button
9. Right Button
10. Enter Button
11. Down Button
12. Left Button
13. SET Button
14. Stop Button
15. Start /Pause Button
16. Belt clip
17. Battery Cover
18. USB Interface

EN - 6
3.1.2. Display Description
Battery Status
Auto Power Off
Enable
Pause
115dB
indicator(SPL)
Stop 140 dB
indicator(Peak)
Start USB Interface
SPL High dB Range
(140~70)
dB Display
SPL Middle dB Range
(110~50)
Testing mode
SPL Low dB Range
(90~30) Sound Level Meter mode
Noise Dose % Sound Noise dB
A Weighting Fast Weighting
C Weighting Slow Weighting
Z Weighting Impulse Weighting
dB test data > Hi level dB test data < Low
level
Solid: Auto record
standby: Flashing
recording
Start test time
Visit record data Stop test time
SET mode turn on Test duration

EN - 7
3.1.3. ST-130S Microphone
․ Diameter : 1/2 inch
․ Polarization voltage : 0V
․ Dynamic range : 25dBA ~140dB
․ Sensitivity : -32±3dB (250Hz 0dB=1V/Pa)
․ Free field frequency response : ±2dB(25Hz～12.5kHz)
Frequency (KHz) Deviation of pressure
0.25 0.0
1 -0.1
2 -0.5
3 -0.6
4 -0.9
5 -1.2
6 -1.7
7 -2.2
8 -2.8
9 -3.3
10 -4.1
12.5 -6.0
3.1.4. Input interface
The front is PLT84RFR, the signal input receptacle.
ST-130
Pin 1 GND
Pin 2 Power
Pin 3 NC
Pin 4 NC
ST-130S
Pin 1 GND
Pin 2 Power(+)
Pin 3 N.C
Pin 4 Power(-)

EN - 8
3.2. Noise Does Measurement Procedures
Press turn on meter
LCD do not display symbol.
Press turn on noise dose testing. ，press again pause
testing.
Press select testing information
◎SPL→Dose%→LPMAX→LPMIN→PKMAX→LEQ→SEL→LEP8→TWA8→
LVAG→LN%
Press to observe testing date information. Press change
date display information.
◎Time(hh:mm:ss)→date(YY-DD-MM)
Press stop testing and store all test data
3.3. Sound Level Measurement Procedures
Press turn on meter

EN - 9
LCD show symbol
Press button to select test function.
◎SPL→Leq→SEL→PeakMAX
Press testing , Press again pause testing
If test data bigger than HI test range at the same time, LCD is showing
If test data is smaller than Low test range at the same time, LCD is
showing
Leq integral time setting is along with the same sampling time.
When the sampling time is set to zero, the integration time until the user
exits
Press stop testing
CAUTION
Wind blowing across the microphone would bring additional
extraneous noise. Once using the instrument in the presence of wind
with speed higher than 10m/s, it must mount the windscreen to
prevent the undesirable signals. Keep the microphone dry and avoid
severe vibration.
3.4. Auto Data Record
․ Press enabled Auto record function.
․ LCD symbol will be flash.
․ The bottom left of LCD display ”Write” , this mean the data will be writing to
memory.

EN - 10
․ The bottom left of LCD display “FULL”, this mean the data will be full.
․ Auto record function can not use menu record.
3.5. Single Data Record
․ Press each time to store the display reading and symbol flash.
․ The bottom left of LCD display ”Write” , this mean the data will be writing to
memory.
3.6. Viewing Logged Reading
․ Press button more than 1 sec into the viewing logged reading mode.
․ Press or to scroll through the readings.
․ Press select dose record information. (Nosie Dose Meter mode)
◎Test model→Start time→Test duration time →Total pause time→Test end time
․ Press to change data or date, Press change Time.
(hh:mm:ss→YY-MM-DD)
․ Press more than 1 sec again to exit viewing logged reading mode.
3.7. Set Mode
․ Press into set mode , can set 7 functions in set mode
․ Press exit set mode
◎ Test Mode→Auto Power Off→Sampling Time & Auto Record→Real
Time Clock→94dB Offset Adjust→Noise standard→SLM Fuunction
․ Press again,save set and into next set mode

EN - 11
3.7.1. Test Mode Set
․ Press or , change test mode. (NDM →SLM)
◎ NDM: Noise Dose Meter
◎ SLM:Sound Level Meter
3.7.2. Auto Power Off Set
․ Press or , enable or disable Auto Power Off function
3.7.3. Sampling Time & Auto Record Set
․ Press or , select auto records set or sampling time.
․ Press or enable or disable Auto record, adjust sampling time.
․ Minimum sampling time: 1 second; Maximum sampling time: 23 hours 59
minutes 59 seconds

EN - 12
3.7.4. Real Time Clock Set
․ Press or , select option to adjust.
․ Press or , adjust time digit.
․
3.7.5. 94dB Offset Adjust Set
․ Press , auto run 94dB offset adjust.
․ Press or , change frequency weighted
․ Press or , adjust offset
3.7.6. Noise Standard Set
․ Press or ,select NDM testing law
◎ OSHA→MSHS→DOD→ACGIH→ISO85→ISO90→USER

EN - 13
3.7.7. SLM Function Set
․ Press or , change test function
◎ → →
◎ → →
◎ → →
◎ Peak C →Peak Z
․ Press or ,select test function
◎ Sound level range→Time weighted→Frequency weighted→Peak frequency

EN - 14
4. SOFTWARE
4.1. System Requirements
Operating: Windows® XP/Windows Vista/Windows 7/Windows 8
Storage:200 MB of available hard disk space.
Processor: Intel Pentium® 4
Memory:1 GB RAM (XP), 1.5 GB (Windows Vista/Windows 7/Windows 8)
Other: PL2303 Windows Drive ;Microsoft .NET Framework 3.5 Service Pack 1
4.2. Software Description

EN - 15
4.3. Tools Description
Open file Options
Print noise dose report
(*.ndr) Sound level chart
Noise dose chart (LN%) Start to log sound level (*.csv)
Stop to log sound level Download sound level logs;
Doenload noise does report
Erase measured data that
stored in meter Automatic detect port which connect with meter
4.4. Open File
Sound Level Log List Tool
SPL→LEQ→SEL→PeakMax
Fast→Slow→Impluse
A→C→Z
Calculate LEQ & SEL
Save file as….
Graph
Sound Level Logs Graph
Zoom
Drag
Print
Print Preview
Print Setup
4.4.1. Zoom Function
․ Click the left mouse button to zoom in
․ Click the left mouse button to original size
․ Hold the left mouse button to moving selection range
․ Keyboard '+', '-' can zoom in or zoom out
4.4.2. Drag function
․ Hold the left mouse button can moving view range
․ Hold CTRL+ left mouse button can be change view range and zoom

EN - 16
4.5. Option
PC Setting
Meter Setting
4.5.1. PC Setting
PC data logger sample time.
Click the left mouse button to change
the color box
Graph (Y-axis) sound level range
4.5.2. Meter Setting
Serial number(0~9;A~Z)16 word
Alarm setting
dB Offset setting
MAX:+3.9dB MIN:-3.9dB
Setting meter real time clock
Enable/disable auto Record.
Setting sample time
Enable/disable auto play noise dose
function.
Meter must be turn on and setting in
NDM(noise does meter) mode
Select noise dose standard
Select noise dose play time.
Default standard(8hour),
Other 5；10；15；30min
1；2 ；4；8；10；12；24 hour
Setting information import or export ,file
format(*.ncg)

EN - 17
4.6. Print Noise Dose Report
Select noise dose logger report (*.ndr)
Click or and key in user information , click “ok” ,the output report
4.7. Sound level chart & Noise dose chart (LN %)
Sound level char. X-axis is the time coordinate.Y-axis is the sound coordinate.
Noise does chart. X-axis is the LN%. Y-axis is the sound coordinate.

EN - 18
4.8. Enable PC data logger
Click enable data logger.
Create a new log file (*. csv) in the hard disk.
Click
stop data logger.
4.9. Dowload Record data
Click download sound level logs or noise dose report on the meter memory.
Download 100K record data. it takes about 15 minutes time-consuming, please be
patiently.
4.10. Erase Record data
Click delete all records of the meter.
