CS 5
TECHNICAL SERVICE MANUAL
New & Reconditioned Equipment & Parts - www.southeasternequipment.net

New & Reconditioned Equipment & Parts - www.southeasternequipment.net

PLDC04318
REVISIONE 00
July 31, 2019
UFF. TECNICO
Contents
A1.1 Checking brush motor current draw..............................................................................7
A1.2 Checking and replacing the centre brush motor carbon brushes .................................8
A1.3 Disassembling and replacing the centre brush motor...................................................11
B1.1 Checking suction motor current draw............................................................................15
B1.2 Removing the suction fan..............................................................................................17
B2.1 Testing and/or replacing the solution pump...................................................................19
B3.1 Replacing the suction diverter valve .............................................................................22
B4.1 Replacing the rear squeegee cable ..............................................................................25
B4.2 Adjusting the rear squeegee cable................................................................................27
B4.3 Removing the splitter bracket........................................................................................28
B4.4 Replacing the splitter bracket control cable “A”.............................................................30
B4.5 Adjusting the splitter bracket control cable “A”..............................................................31
B4.6 Replacing the diverter valve control cable “B”...............................................................32
B4.7 Replacing the front squeegee control cable “C”............................................................33
B4.8 Adjusting the front squeegee control cable “C”.............................................................34
C1.1 Replacing the idle wheels.............................................................................................37
C2.1 Replacing the carrying handle ......................................................................................39
C2.2 Replacing rear squeegee activation lever.....................................................................41
C2.3 Disassembling the hand grip.........................................................................................42
C2.4 Disassembling the handle adjustment and squeegee inversion levers..... 43
C2.5 Disassembling and replacing the complete handle ......................................................46
D1.1 Disassembling and replacing hand grip components ...................................................50
D1.2 Checking and replacing the main switch.......................................................................54
D2.1 Disassembling and replacing the power board.............................................................57
D2.2 Checking and replacing the fuses.................................................................................59
D3.1 Wiring diagram..............................................................................................................60
E1.1 Error codes on the instrument panel.............................................................................62
E1.2 FW Version Control.......................................................................................................64
E2.1 Troubleshooting.............................................................................................................65
