Terasic THDB-H2G User manual

TerasicTHDB-H2G
THDB-H2G
Terasic HSMC to GPIO Daughter Board
User Manual
Document Version 1.0 AUG. 15, 2007 by Terasic

Introduction
ii
Page Index
CHAPTER 1 INTRODUCTION...................................................................................................................................1
1-1 FEATURES................................................................................................................................................................1
1-2 GETTING HELP ........................................................................................................................................................1
CHAPTER 2 ARCHITECTURE..................................................................................................................................2
2-1 LAYOUTAND COMPONETS.......................................................................................................................................2
2-2 BLOCK DIAGRAM .....................................................................................................................................................4
CHAPTER 3 BOARD COMPONENTS.....................................................................................................................5
3-1 HSMC EXPANSION CONNECTOR.............................................................................................................................5
3-2 EXPANSION PROTOTYPE CONNECTORS ..................................................................................................................8
3-3 I2C SERIAL EEPROM..........................................................................................................................................13
3-4 POWER SUPPLY.....................................................................................................................................................13
CHAPTER 4 DEMONSTRATION............................................................................................................................14
4-1 CONNECTING THDB-H2G BOARD TO CYCLONE III STARTER BOARD ................................................................14
CHAPTER 5 APPENDIX...........................................................................................................................................15
5-1 REVISION HISTORY................................................................................................................................................15
5-2ALWAYS VISIT THDB-H2G WEBPAGE FOR NEW MAIN BOARD............................................................................15

Introduction
1
Introduction
1
The THDB-H2G board is designed to fan out the High Speed Mezzanine connector (HSMC) I/Os to three
40-pin expansion prototype connectors, which are compatible with Altera DE2/DE1 expansion headers. Users
can connect up to three Altera DE2/DE1 boards (or associated daughter cards) onto a HSMC-interfaced host
board via the THDB-H2G board.
1-1Features
Figure 1.1 shows the photo of the THDB-H2G board. The important functions of the THDB-H2G are listed
below:
•Converts HSMC interface I/O to standard 40-pin expansion connectors.
•Allows users to connectAltera DE2/DE1 boardsto a HSMC-interfaced host board.
•Provides test points for signal measurement.
Figure 1.1. The picture of the THDB-H2G board
1-2Getting Help
Here are some places to get help if you encounter any problem:
9Email to [email protected]
9Taiwan & China: [phone]
9Korea : [phone]
9Japan: [phone]

Architecture
2
Architecture
2
This chapter describes the architecture of the THDB-H2G board including block diagram and components.
1-3Layout and Componets
The picture of the TDRB-H2G is shown in Figure 2.1 and Figure 2.2. It depicts the layout of the board and
indicates the locations of the connectors and key components.
Figure 2.1 The TDRB-H2G board PCB and component diagram

Architecture
3
H
S
M
C Connector(J1)
Figure 2.2 The TDRB-H2G board back side – HSMC connector view
The following components are provided on the THDB-H2G board :
•HSMC expansion connector (J1)
•Expansion prototype connectors (JP1,JP2,JP3)
•I2C serial EEPROM (U2)

Architecture
4
1-4Block Diagram
Figure 2.3 shows the block diagram of the THDB-H2G board.
THDB-H2G
HSMC
Connector 40-Pin Expansion
Prototype Connector 1
36 I/Os
36 I/Os
36 I/Os
I2C Interface
40-Pin Expansion
Prototype Connector 2
40-Pin Expansion
Prototype Connector 3
I2C Serial EEPROM
JP1
J1 JP2
JP3
U2
To
HSMC Interface
Host Board
Figure 2.3. The block diagram of the THDB-H2G board

Board Components
5
Board Components
3
This section will describe the detailed information of the components, connector interfaces,
and the pin mappings on the THDB-H2G board.
1-5HSMC Expansion Connector
This section describes the HSMC connector on the THDB-H2G board
THDB-H2G board contains an Altera standard HSMC connector. All the other interfaces on the THDB-H2G
board are connected to the HSMC connector. Figure 3.1, Figure 3.2, and Figure 3.3 show the pin-outs of the
HSMC connector.
HSMC_TXVR_RXp6
HSMC_TXVR_RXn6
HSMC_TXVR_RXp5
HSMC_TXVR_RXn5
HSMC_TXVR_RXp4
HSMC_TXVR_RXn4
HSMC_TXVR_RXp3
HSMC_TXVR_RXn3
HSMC_TXVR_RXp2
HSMC_TXVR_RXn2
HSMC_TXVR_RXp1
HSMC_TXVR_RXn1
HSMC_TXVR_RXp0
HSMC_TXVR_RXn0
HSMC_SCL
HSMC_TMS
HSMC_TDI
HSMC_CLKIN0
HSMC_TXVR_RXp7
HSMC_TXVR_RXn7
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
2
4
HSMC_TXVR_TXp6
HSMC_TXVR_TXn6
HSMC_TXVR_TXp5
HSMC_TXVR_TXn5
HSMC_TXVR_TXp4
HSMC_TXVR_TXn4
HSMC_TXVR_TXp3
HSMC_TXVR_TXn3
HSMC_TXVR_TXp2
HSMC_TXVR_TXn2
HSMC_TXVR_TXp1
HSMC_TXVR_TXn1
HSMC_TXVR_TXp0
HSMC_TXVR_TXn0
HSMC_SDA
HSMC_TCK
HSMC_TDO
HSMC_CLKOUT0
HSMC_TXVR_TXp7
HSMC_TXVR_TXn7
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
1
3
Figure 3.1 The pin-outs of Bank 1 on the HSMC connector.

Board Components
6
HSMC_D1
HSMC_D3
12V
HSMC_RX_p0
HSMC_RX_n0
12V
HSMC_RX_p1
HSMC_RX_n1
12V
HSMC_RX_p2
HSMC_RX_n2
12V
HSMC_RX_p3
HSMC_RX_n3
12V
HSMC_RX_p4
HSMC_RX_n4
12V
HSMC_RX_p5
HSMC_RX_n5
12V
HSMC_RX_p6
HSMC_RX_n6
12V
HSMC_RX_p7
HSMC_RX_n7
12V
HSMC_CLKINp1
HSMC_CLKINn1
12V
42
44
46
48
50
52
54
56
58
60
62
64
66
68
70
72
74
76
78
80
82
84
86
88
90
92
94
96
98
100
HSMC_D0
HSMC_D2
VCC33
HSMC_TX_p0
HSMC_TX_n0
VCC33
HSMC_TX_p1
HSMC_TX_n1
VCC33
HSMC_TX_p2
HSMC_TX_n2
VCC33
HSMC_TX_p3
HSMC_TX_n3
VCC33
HSMC_TX_p4
HSMC_TX_n4
VCC33
HSMC_TX_p5
HSMC_TX_n5
VCC33
HSMC_TX_p6
HSMC_TX_n6
VCC33
HSMC_TX_p7
HSMC_TX_n7
VCC33
HSMC_CLKOUTp1
HSMC_CLKOUTn1
VCC33
41
43
45
47
49
51
53
55
57
59
61
63
65
67
69
71
73
75
77
79
81
83
85
87
89
91
93
95
97
99
Figure 3.2 The pin-outs of Bank 2 on the HSMC connector

Board Components
7
HSMC_RX_p8
HSMC_RX_n8
12V
HSMC_RX_p9
HSMC_RX_n9
12V
HSMC_RX_p10
HSMC_RX_n10
12V
HSMC_RX_p11
HSMC_RX_n11
12V
HSMC_RX_p12
HSMC_RX_n12
12V
HSMC_RX_p13
HSMC_RX_n13
12V
HSMC_RX_p14
HSMC_RX_n14
12V
HSMC_RX_p15
HSMC_RX_n15
12V
HSMC_RX_p16
HSMC_RX_n16
12V
HSMC_CLKINp2
HSMC_CLKINn2
GND
102
104
106
108
110
112
114
116
118
120
122
124
126
128
130
132
134
136
138
140
142
144
146
148
150
152
154
156
158
160
HSMC_TX_p8
HSMC_TX_n8
VCC33
HSMC_TX_p9
HSMC_TX_n9
VCC33
HSMC_TX_p10
HSMC_TX_n10
VCC33
HSMC_TX_p11
HSMC_TX_n11
VCC33
HSMC_TX_p12
HSMC_TX_n12
VCC33
HSMC_TX_p13
HSMC_TX_n13
VCC33
HSMC_TX_p14
HSMC_TX_n14
VCC33
HSMC_TX_p15
HSMC_TX_n15
VCC33
HSMC_TX_p16
HSMC_TX_n16
VCC33
HSMC_CLKOUTp2
HSMC_CLKOUTn2
VCC33
101
103
105
107
109
111
113
115
117
119
121
123
125
127
129
131
133
135
137
139
141
143
145
147
149
151
153
155
157
159
Figure 3.3 The pin-outs of Bank 3 on the HSMC connector.

Board Components
8
1-6Expansion Prototype Connectors
This section describes the expansion prototype connectors on the THDB-H2G board.
The THDB-H2G board has three expansion prototype connectors (JP1, JP2, and JP3) connected to the
HSMC connector directly. Each of the connectors has 36 prototyping I/Os and 3.3/5 volts power supply from
the HSMC interface and on-board regulator. In addition, the expansion connector is compatible with the
expansion headers of the Altera DE1/DE2 board. With these expansion connectors, users can connect the
Altera DE2/DE1 development kits or custom daughter boards to a HSMC-interfaced host board. Figure 3.4,
Figure 3.5, and Figure 3.6 shows the pin-outs of the expansion prototype connectors. Also, the detailed pin
mappings to HSMC connector are listed in Table 3.1, Table3.2, and Table 3.3.
Figure 3.4 The pin-outs of the expansion prototype connector JP1

Board Components
9
Figure 3.5 The pin-outs of the expansion prototype connector JP2
Figure 3.6 The pin-outs of the expansion prototype connector JP3

Board Components
10
Table 3.1 The pin mappings of the expansion prototype connector JP1
Ex
p
ansion Protot
yp
e Connector 1 - JP1
Pin Numbe
r
Si
g
nal Name HSMC Pin DE2/DE1
1 HSMC_CLKIN0 40 GPIO0
2 HSMC_TXVR_TXp6 5 GPIO1
3 HSMC_TXVR_TXp5 9 GPIO2
4 HSMC_TXVR_TXn6 7 GPIO3
5 HSMC_TXVR_TXn5 11 GPIO4
6 HSMC_TXVR_TXp4 13 GPIO5
7 HSMC_TXVR_TXp3 17 GPIO6
8 HSMC_TXVR_TXn4 15 GPIO7
9 HSMC_TXVR_TXn3 19 GPIO8
10 HSMC_TXVR_TXp2 21 GPIO9
11 5V N/A N/A
12 GND N/A N/A
13 HSMC_TXVR_TXn2 23 GPIO10
14 HSMC_TXVR_TXp1 25 GPIO11
15 HSMC_TXVR_TXp0 29 GPIO12
16 HSMC_TXVR_TXn1 27 GPIO13
17 HSMC_TXVR_TXn0 31 GPIO14
18 HSMC_TXVR_RXp5 10 GPIO15
19 HSMC_CLKOUT0 39 GPIO16
20 HSMC_TXVR_RXn5 12 GPIO17
21 HSMC_TXVR_RXp4 14 GPIO18
22 HSMC_TXVR_RXn4 16 GPIO19
23 HSMC_TXVR_RXp3 18 GPIO20
24 HSMC_TXVR_RXn3 20 GPIO21
25 HSMC_TXVR_RXp2 22 GPIO22
26 HSMC_TXVR_RXn2 24 GPIO23
27 HSMC_TXVR_RXp1 26 GPIO24
28 HSMC_TXVR_RXn1 28 GPIO25
29 VCC33 (3.3 volts) N/A N/A
30 GND N/A N/A
31 HSMC_TXVR_RXn0 32 GPIO26
32 HSMC_TXVR_RXp0 30 GPIO27
33 HSMC_TX_p7 89 GPIO28
34 HSMC_TX_n7 91 GPIO29
35 HSMC_RX_n5 80 GPIO30
36 HSMC_RX_p5 78 GPIO31
37 HSMC_TX_p8 101 GPIO32
38 HSMC_TX_n8 103 GPIO33
39 HSMC_RX_p8 102 GPIO34
40 HSMC_RX_n8 104 GPIO35

Board Components
11
Table 3.2 The pin mappings of the expansion prototype connector JP2
Ex
p
ansion Protot
yp
e Connector 2
–
JP2
Pin Numbe
r
Si
g
nal Name HSMC Pin DE2/DE1
1 HSMC_CLKINp1 96 GPIO0
2 HSMC_D2 43 GPIO1
3 HSMC_CLKINn1 98 GPIO2
4 HSMC_D0 41 GPIO3
5 HSMC_TX_p0 47 GPIO4
6 HSMC_TX_p1 53 GPIO5
7 HSMC_TX_n0 49 GPIO6
8 HSMC_TX_n1 55 GPIO7
9 HSMC_TX_p2 59 GPIO8
10 HSMC_TX_n2 61 GPIO9
11 5V N/A N/A
12 GND N/A N/A
13 HSMC_TX_n3 67 GPIO10
14 HSMC_TX_p3 65 GPIO11
15 HSMC_TX_n4 73 GPIO12
16 HSMC_TX_p4 71 GPIO13
17 HSMC_TX_n5 79 GPIO14
18 HSMC_TX_p5 77 GPIO15
19 HSMC_CLKOUTp1 95 GPIO16
20 HSMC_TX_p6 83 GPIO17
21 HSMC_CLKOUTn1 97 GPIO18
22 HSMC_TX_n6 85 GPIO19
23 HSMC_D1 42 GPIO20
24 HSMC_D3 44 GPIO21
25 HSMC_RX_p0 48 GPIO22
26 HSMC_RX_p1 54 GPIO23
27 HSMC_RX_n0 50 GPIO24
28 HSMC_RX_n1 56 GPIO25
29 VCC33 (3.3 volts) N/A N/A
30 GND N/A N/A
31 HSMC_RX_p2 60 GPIO26
32 HSMC_RX_n2 62 GPIO27
33 HSMC_RX_p3 66 GPIO28
34 HSMC_RX_p4 72 GPIO29
35 HSMC_RX_n3 68 GPIO30
36 HSMC_RX_n4 74 GPIO31
37 HSMC_RX_p6 84 GPIO32
38 HSMC_RX_p7 90 GPIO33
39 HSMC_RX_n6 86 GPIO34
40 HSMC_RX_n7 92 GPIO35

Board Components
12
Table 3.3 The pin mappings of the expansion prototype connector JP3
Ex
p
ansion Protot
yp
e Connector 3
–
JP3
Pin Numbe
r
Si
g
nal Name HSMC Pin DE2/DE1
1 HSMC_CLKINp2 156 GPIO0
2 HSMC_TX_p9 107 GPIO1
3 HSMC_CLKINn2 158 GPIO2
4 HSMC_TX_n9 109 GPIO3
5 HSMC_TX_p10 113 GPIO4
6 HSMC_TX_p11 119 GPIO5
7 HSMC_TX_n10 115 GPIO6
8 HSMC_TX_n11 121 GPIO7
9 HSMC_TX_p12 125 GPIO8
10 HSMC_TX_n12 127 GPIO9
11 5V N/A N/A
12 GND N/A N/A
13 HSMC_TX_p13 131 GPIO10
14 HSMC_TX_p14 137 GPIO11
15 HSMC_TX_n13 133 GPIO12
16 HSMC_TX_n14 139 GPIO13
17 HSMC_TX_p15 143 GPIO14
18 HSMC_TX_n15 145 GPIO15
19 HSMC_CLKOUTp2 155 GPIO16
20 HSMC_TX_p16 149 GPIO17
21 HSMC_CLKOUTn2 157 GPIO18
22 HSMC_TX_n16 151 GPIO19
23 HSMC_RX_p9 108 GPIO20
24 HSMC_RX_n9 110 GPIO21
25 HSMC_RX_p10 114 GPIO22
26 HSMC_RX_p11 120 GPIO23
27 HSMC_RX_n10 116 GPIO24
28 HSMC_RX_n11 122 GPIO25
29 VCC33 (3.3 volts) N/A N/A
30 GND N/A N/A
31 HSMC_RX_p12 126 GPIO26
32 HSMC_RX_n12 128 GPIO27
33 HSMC_RX_p13 132 GPIO28
34 HSMC_RX_p14 138 GPIO29
35 HSMC_RX_n13 134 GPIO30
36 HSMC_RX_n14 140 GPIO31
37 HSMC_RX_p15 144 GPIO32
38 HSMC_RX_p16 150 GPIO33
39 HSMC_RX_n15 146 GPIO34
40 HSMC_RX_n16 152 GPIO35

Board Components
13
1-7I2C Serial EEPROM
This section describes the I2C Serial EEPROM on the THDB-H2G board
The THDB-H2G board provides a Microchip 24LC000 EEPROM (U2) which can be configured by the I2C
interface. The size of the EEPROM is 128-bit that can store the board information or user’s data. The detailed
pin description between EEPROM and HSMC connector is listed in the Table 3.4.
Table 3.4 The pin assignments of the I2C serial EEPROM
EEPROM
Pin Number
EPPROM
Signal Name
HSMC Pin
Number
U2-1 NC N/A
U2-2 NC N/A
U2-3 NC N/A
U2-4 GND N/A
U2-5 HSMC_SDA J1-33
U2-6 HSMC_SCL J1-34
U2-7 NC N/A
U2-8 VCC33 (3.3 volts) N/A
1-8Power Supply
This section describes the power supply on the THDB-H2G board.
The power distribution on the THDB-H2G board is shown in Figure 3.7.
Figure 3.7 THDB-H2G board power distribution diagram.

Demonstration
14
Demonstration
4
This chapter illustrates how to use the THDB-H2G board to a HSMC-interfaced host board.
1-9Connecting THDB-H2G Board to a Cyclone III Starter Board
This section describes how to use the THDB-H2G board with a Cyclone III Starter Board.
Figure 4.1 illustrates how the THDB-H2G board is connected to the Cyclone III starter board. Users need to
pay extra attention to the following two points:
1. Observe the orientation of the HSMC connector when connecting the THDB-H2G to the Cyclone III
Starter Board.
2. Note that there are two LVDS pairs on the HSMC connector: the HSMC_CLK_p1/n1 (form a close
loop via R3) and HSMC_CLKIN_p2/n2 (form a close loop via R4). Therefore, using any one of the
signal in a LVDS pair under single-ended mode will prevent users from using the other signal in the
same pair.
Figure 4.1 Connecting the THDB-H2G board to the Cyclone III starter board

Appendix
15
5
Appendix
1-10Revision History
Date Change Log
AUG 15, 2007 Initial Version
1-11Always Visit THDB-H2G Webpage for New Main board
We will be continuing providing interesting examples and labs on our THDB-H2G
webpage. Please visit www.terasic.com for more information.
