Terasic TR-5 Lite FPGA User manual

TR5 User Manual
www.terasic.com
July 27, 2017
1

TR5 User Manual
www.terasic.com
July 27, 2017
2
CONTENTS
CHAPTER 1 OVERVIEW ........................................................................................................................................4
1.1 GENERAL DESCRIPTION ............................................................................................................................................4
1.2 KEY FEATURES..........................................................................................................................................................4
1.3 BLOCK DIAGRAM......................................................................................................................................................6
CHAPTER 2 BOARD COMPONENTS ....................................................................................................................9
2.1 BOARD OVERVIEW....................................................................................................................................................9
2.2 CONFIGURATION,STATUS AND SETUP .....................................................................................................................11
2.3 GENERAL USER INPUT/OUTPUT ..............................................................................................................................17
2.4 TEMPERATURE SENSOR,FAN CONTROLAND POWER MONITOR ..............................................................................21
2.5 CLOCK CIRCUIT ......................................................................................................................................................22
2.6 FLASHAND SSRAM MEMORY..............................................................................................................................25
2.7 DDR3 SO-DIMM...................................................................................................................................................28
2.8 FMC CONNECTORS.................................................................................................................................................32
2.9 SATA......................................................................................................................................................................39
2.10 GPIO ....................................................................................................................................................................40
2.11 PCI EXPRESS.........................................................................................................................................................43
CHAPTER 3 SYSTEM BUILDER .........................................................................................................................47
3.1 INTRODUCTION .......................................................................................................................................................47
3.2 GENERAL DESIGN FLOW.........................................................................................................................................48
3.3 USING SYSTEM BUILDER ........................................................................................................................................49
CHAPTER 4 FLASH PROGRAMMING .................................................................................................................59
4.1 CFI FLASH MEMORY MAP ......................................................................................................................................59
4.2 FPGACONFIGURE OPERATION ...............................................................................................................................60
4.3 FLASH PROGRAMMING WITH USERS DESIGN ..........................................................................................................61
4.4 RESTORE FACTORY SETTINGS .................................................................................................................................64
CHAPTER 5 PROGRAMMABLE PLL ...................................................................................................................65
5.1 CONFIGURE CDCM6208 AND LMK04096B IN RTL...............................................................................................65

TR5 User Manual
www.terasic.com
July 27, 2017
3
5.2 NIOS II CONTROL FOR PLL/TEMPERATURE/POWER.................................................................................................80
CHAPTER 6 EXAMPLES OF ADVANCED DEMONSTRATION ......................................................................86
6.1 FLASH AND SSRAM TEST ......................................................................................................................................86
6.2 DDR3 SDRAM TEST .............................................................................................................................................89
6.3 DDR3 SDRAM TEST BY NIOS II............................................................................................................................92
6.4 FAN SPEED CONTROL..............................................................................................................................................95
6.5 UART TO USB CONTROL .......................................................................................................................................98
CHAPTER 7 PCI EXPRESS REFERENCE DESIGN .....................................................................................103
7.1 PCI EXPRESS SYSTEM INFRASTRUCTURE..............................................................................................................103
7.2 PC PCI EXPRESS SOFTWARE SDK........................................................................................................................104
7.3 REFERENCE DESIGN -FUNDAMENTAL................................................................................................................... 116
7.4 PCIE REFERENCE DESIGN –DDR3.......................................................................................................................123
CHAPTER 8 TRANSCEIVER VERIFICATION ................................................................................................130
8.1 FUNCTION OF THE TRANSCEIVER TEST CODE .......................................................................................................130
8.2 FUNCTION OF THE TRANSCEIVER TEST CODE .......................................................................................................130
8.1 TESTING................................................................................................................................................................132
CHAPTER 9 FMC CONNECTORS PIN OUT ....................................................................................................135
ADDITIONAL INFORMATION ...................................................................................................................................162

TR5 User Manual
www.terasic.com
July 27, 2017
4
Chapter 1
Overview
This chapter provides an overview of the TR5 Development Board and installation guide.
1.1 General Description
The Terasic TR5 Stratix V GX FPGA Development Kit provides the ideal hardware solution for
designs that demand high capacity and bandwidth interface, ultra-low latency communication, high
pin count and power efficiency. With an iPass PCIe gen3 connector, the TR5 is designed for the most
demanding high-end applications, empowered with the Altera 28 nm Stratix V GX, delivering the
best system-level integration and flexibility in the industry.
The Stratix® V GX FPGA features integrated transceivers that transfer at a maximum of 12.5Gbps,
this allows the TR5 to be fully compliant with version 3.0 of the PCI Express standard. Not relying
on an external PHY will accelerate mainstream development of network applications enabling
customers to deploy designs for a broad range of high-speed connectivity applications. For designs
that demand high capacity and high speed for memory and storage, the TR5 delivers with one
independent bank of DDR3 SO-DIMM RAM, one ZBT SSRAM, and high-speed parallel flash
memory. The feature-set of the TR5 fully supports all high-intensity applications such as ASIC
verification, data acquisition, and signal processing.
1.2 Key Features
The following hardware is implemented on the TR5 board:
FPGA
Altera Stratix® V GX FPGA
5SGXEA7N2F45C2 /5SGXEABN3F45I3YY

TR5 User Manual
www.terasic.com
July 27, 2017
5
FPGA Configuration
On-Board USB Blaster II or JTAG header for FPGA programming
Fast passive parallel (FPPx16) configuration via MAX II CPLD and flash memory
General user input/output:
4 LEDs
4 push-buttons
4 slide switches
Clock System
50MHz Oscillator
CDCM6208 Programmable PLL
LMK04096B Programmable PLL
SMA connector pairs for differential clock input and output
Memory
DDR3 SO-DIMM SDRAM
QDRII+ SRAM
FLASH
SD Card
Communication Ports
PCI Express (PCIe) x4 iPass connector
Serial ATA host and device ports
PCI Express (PCIe) x8 edge connector
One mini Uart to USB connector
System Monitor and Control
Temperature sensor
Fan control
Power monitor
Mechanical Specification
4 FPGA Mezzanine Card (FMC) Connectors
One 40-pin Expansion Header

TR5 User Manual
www.terasic.com
July 27, 2017
6
Power
12V DC Input
1.3 Block Diagram
94H94HFigure 1-1 shows the block diagram of the TR5 board. To provide maximum flexibility for the users,
all key components are connected with the Stratix V GX FPGA device. Thus, users can configure the
FPGA to implement any system design.
Figure 1-1 Block diagram of the TR5 board
Below is more detailed information regarding the blocks in 95H95H Figure 1-1.
Stratix V GX FPGA
5SGXEA7N2F45C2
622K logic elements (LEs)
57.16-Mbits embedded memory

TR5 User Manual
www.terasic.com
July 27, 2017
7
48 transceivers (12.5Gbps)
512 18 x18 multipliers
256 Variable-precision DSP blocks
28 Fractional PLLs and 4DLLs
5SGXEABN3F45I3YY
952K logic elements (LEs)
62.96-Mbits embedded memory
48 transceivers (12.5Gbps)
704 18 x18 multipliers
352 Variable-precision DSP blocks
28 Fractional PLLs and 4DLLs
JTAG Header and FPGA Configuration
On-board USB Blaster II or JTAG header for use with the Quartus II Programmer
MAXII CPLD EPM2210 System Controller and Fast Passive Parallel (FPP) configuration
Memory devices
2MB ZBT SSRAM
Up to 8GB DDR3 SO-DIMM SDRAM
256MB FLASH
General user I/O
4 user controllable LEDs
4 user push buttons
4 user slide switches
On-Board Clock

TR5 User Manual
www.terasic.com
July 27, 2017
8
50MHz oscillator
Programming PLL providing clock for FMC transceivers
Programming PLL providing clock for PCIe transceiver
Programming PLL providing clocks for DDR3 SDRAM
Two Serial ATA ports
SATA 3.0 standard at 6Gbps signaling rate
Four FMC Connectors
2 HPC (high-pin count) FMC connectors up to 172 x2 Single-end I/O
2 LPC (low-pin count) FMC connectors up to 76 x2 Single-end I/O
10 Transceiver Channels for HPC and 1 Transceiver Channel for LPC
FMC VITA 57.1 Compliant
Adjustable VADJ: 1.2V/1.5V/1.8V/2.5V/3.0V
Don’t support bidirectional LVDS due to Stratix V device only support single directional LVDS
One 40-pin GPIO Expansion Header
36 FPGA I/O pins; 4 power and ground lines
I/O standards: 3.3V (with level shift from 2.5V to 3.3V)
External PCI Express x4 iPass Connector
Support for PCIe x4 Gen1/2/3
iPass connector with x4 PCI Express slot
Power Source
DC 12V power adapter

TR5 User Manual
www.terasic.com
July 27, 2017
9
Chapter 2
Board Components
This chapter introduces all the important components on the TR5.
2.1 Board Overview
96H96HFigure 2-1 is the top and bottom view of the TR5 development board. It depicts the layout of the
board and indicates the location of the connectors and key components. Users can refer to this figure
for relative location of the connectors and key components.

TR5 User Manual
www.terasic.com
July 27, 2017
10
Figure 2-1 FPGA Board (Top)

TR5 User Manual
www.terasic.com
July 27, 2017
11
Figure 2-2 FPGA Board (Bottom)
2.2 Configuration, Status and Setup
Configure
The FPGA board supports two configuration methods for the Stratix V FPGA:
Configure the FPGA using the on-board USB-Blaster II.
Flash memory configuration of the FPGAusing stored images from the flash memory on power-
up.
For programming by on-board USB-Blaster II, the following procedures show how to download a
configuration bit stream into the Stratix V GX FPGA:

TR5 User Manual
www.terasic.com
July 27, 2017
12
Make sure that power is provided to the FPGA board.
Connect your PC to the FPGAboard using a mini-USB cable and make sure the USB-Blaster II
driver is installed on PC.
Launch Quartus II programmer and make sure the USB-Blaster II is detected.
In Quartus II Programmer, add the configuration bit stream file (.sof), check the associated
“Program/Configure”item, and click “Start”to start FPGA programming.
Status LED
The FPGA Board development board includes board-specific status LEDs to indicate board status.
Please refer to 97H9HTable 2-1 for the description of the LED indicator.
Table 2-1 Status LED
Board Reference
LED Name
Description
D6
12-V Power
Illuminates when 12-V power is active.
D1
3.3-V Power
Illuminates when 3.3-V power is active.
D21
CONF_DONE
Illuminates when the FPGA is successfully configured.
Driven by the MAX II CPLD EPM2210 System
Controller.
D22
LOAD
Illuminates when the MAX II CPLD EPM2210 System
Controller is actively configuring the FPGA. Driven by
the MAX II CPLD EPM2210 System Controller with the
Embedded Blaster CPLD.
D23
ERROR
Illuminates when the MAX II CPLD EPM2210 System
Controller fails to configure the FPGA. Driven by the
MAX II CPLD EPM2210 System Controller.
D24
BOOT_PAGE
Illuminates when FPGA is configured by the factory
configuration bit stream.
D12~D20,D33~D35
FMC Voltage
Value Indicator
See Section 2.8 FMC Connectors
Setup Configure Mode Control DIP switch
The Configure Mode Control DIP switch (SW5) is provided to specify the configuration mode of the
FPGA. As currently only one mode is supported, please set all positions as shown in 99H99HFigure 2-3.

TR5 User Manual
www.terasic.com
July 27, 2017
13
Figure 2-3 4-Position DIP switch for Configure Mode
Select Flash Image for Configuration
The Image Select DIP switch (SW4) is provided to specify the image for configuration of the FPGA.
Setting SW4 to high (‘0’) specifies the default factory image to be loaded, setting SW4 to low (‘1’)
specifies the TR5 to load a user-defined image, as shown in 101H101H Figure 2-4.

TR5 User Manual
www.terasic.com
July 27, 2017
14
Figure 2-4 2-position DIP switch for Image Select
FMC VCCIO Voltage Setting Header
The I/O voltage of all the four FMC connectors is adjustable within 1.2/1.5/1.8/2.5/3.0V. For example,
user can adjust the I/O voltage to 2.5V to support LVDS differential I/O stand. The user can
independently control the voltage of FMCA~FMCD through JP5, JP6, JP7 and JP9. As shown in
Figure 2-5, make short circuit onto JP5 pin 7 and pin 8, the status of D12, D13 and D14 will be set
as “ON/OFF/ON” for representing the FMCA VCCIO is 2.5V. Table 2-2, Table 2-3, Table 2-4 and
Table 2-5 lists the voltage settings of the FMCA~FMCD VCCIO and their corresponding LED
display status.

TR5 User Manual
www.terasic.com
July 27, 2017
15
Figure 2-5 FMC A VCCIO Voltage Setting to 2.5V
Table 2-2 FMC A VCCIO Voltage Setting
JP5 Setting
LED Status
FMC A VCCIO Voltage
D12
D13
D14
Short Pin 1 & 2
OFF
OFF
ON
1.2V
Short Pin 3 & 4
OFF
ON
OFF
1.5V
Short Pin 5 & 6
OFF
ON
ON
1.8V
Short Pin 7 & 8
ON
OFF
ON
2.5V(Default)
Short Pin 9 & 10
ON
ON
OFF
3.0V
Table 2-3 FMC B VCCIO Voltage Setting
JP6 Setting
LED Status
FMC B VCCIO Voltage
D15
D16
D17
Short Pin 1 & 2
OFF
OFF
ON
1.2V
Short Pin 3 & 4
OFF
ON
OFF
1.5V
Short Pin 5 & 6
OFF
ON
ON
1.8V
Short Pin 7 & 8
ON
OFF
ON
2.5V(Default)
Short Pin 9 & 10
ON
ON
OFF
3.0V

TR5 User Manual
www.terasic.com
July 27, 2017
16
Table 2-4 FMC C VCCIO Voltage Setting
JP7 Setting
LED Status
FMC C VCCIO Voltage
D18
D19
D20
Short Pin 1 & 2
OFF
OFF
ON
1.2V
Short Pin 3 & 4
OFF
ON
OFF
1.5V
Short Pin 5 & 6
OFF
ON
ON
1.8V
Short Pin 7 & 8
ON
OFF
ON
2.5V(Default)
Short Pin 9 & 10
ON
ON
OFF
3.0V
Table 2-5 FMC D VCCIO Voltage Setting
JP9 Setting
LED Status
FMC D VCCIO Voltage
D33
D34
D35
Short Pin 1 & 2
OFF
OFF
ON
1.2V
Short Pin 3 & 4
OFF
ON
OFF
1.5V
Short Pin 5 & 6
OFF
ON
ON
1.8V
Short Pin 7 & 8
ON
OFF
ON
2.5V(Default)
Short Pin 9 & 10
ON
ON
OFF
3.0V
FMC JTAG Header
The TR5 supports individual JTAG interfaces on each FMC connector. This feature allows users to
extend the JTAG chain to FMC daughter cards. The JTAG signals on each FMC connector can be
removed or included in the active JTAG chain via 3-Pin header (See Figure 2-6). Table 2-6 lists the
setting of the headers and their associated interfaces. Note that if the JTAG interface on FMC
connector is enabled, make sure that the active JTAG chain must be a closed loop or the FPGA may
not be detected.

TR5 User Manual
www.terasic.com
July 27, 2017
17
Figure 2-6 FMCC JTAG Header
Table 2-6 FMC JTAG Header Setting
Headers
Setting
Description
JP1
Short Pin 1 & 2
Disable FMCA JTAG
Short Pin 2 & 3
Enable FMCA JTAG
JP2
Short Pin 1 & 2
Disable FMCD JTAG
Short Pin 2 & 3
Enable FMCD JTAG
JP3
Short Pin 1 & 2
Disable FMCB JTAG
Short Pin 2 & 3
Enable FMCB JTAG
JP4
Short Pin 1 & 2
Disable FMCC JTAG
Short Pin 2 & 3
Enable FMCC JTAG
2.3 General User Input/Output
This section describes the user I/O interface to the FPGA.
User Defined Push-buttons
The FPGA board includes four user defined push-buttons that allow users to interact with the Stratix
V GX device. Each push-button provides a high logic level or a low logic level when it is not pressed

TR5 User Manual
www.terasic.com
July 27, 2017
18
or pressed, respectively. 102H 102HTable 2-7 lists the board references, signal names and their corresponding
Stratix V GX device pin numbers.
Table 2-7 Push-button Pin Assignments, Schematic Signal Names, and Functions
Board
Reference
Schematic
Signal Name
Description
I/O
Standard
Stratix V GX
Pin Number
BUTTON0
BUTTON0
High Logic Level when the button is
not pressed
1.5-V
PIN_BC7
BUTTON1
BUTTON1
1.5-V
PIN_BD7
BUTTON 2
BUTTON2
1.5-V
PIN_BB8
BUTTON 3
BUTTON3
1.5-V
PIN_BB9
User-Defined Slide Switch
There are four slide switches on the FPGA board to provide additional FPGA input control. When a
slide switch is in the DOWN position or the UPPER position, it provides a low logic level or a high
logic level to the Stratix V GX FPGA. The down position provides a low logic level and the upper
position provides a high logic level.
104H104HTable 2-8 lists the signal names and their corresponding Stratix V GX device pin numbers.
Table 2-8 Slide Switch Pin Assignments, Schematic Signal Names, and Functions
Board
Reference
Schematic
Signal Name
Description
I/O
Standard
Stratix V GX
Pin Number
SW0
SW0
High logic level when SW in the UPPER
position.
1.5-V
PIN_AT9
SW1
SW1
1.5-V
PIN_AU8
SW2
SW2
1.5-V
PIN_AK9
SW3
SW3
1.5-V
PIN_AL9
User-Defined LEDs
The FPGAboard consists of four user-controllable LEDs to allow status and debugging signals to be
driven to the LEDs from the designs loaded into the Stratix V GX device. Each LED is driven directly
by the Stratix V GX FPGA. The LEDs are turned on or off when the associated pins are driven to a
low or high logic level, respectively. A list of the pin names on the FPGA that are connected to the
LEDs is given in 105H105HTable 2-9.

TR5 User Manual
www.terasic.com
July 27, 2017
19
Table 2-9 User LEDs Pin Assignments, Schematic Signal Names, and Functions
Board
Reference
Schematic
Signal Name
Description
I/O
Standard
Stratix V GX
Pin Number
LED0
LED0
Driving a logic 0 on the I/O port turns the LED
ON.
Driving a logic 1 on the I/O port turns the LED
OFF.
1.5-V
PIN_AT32
LED1
LED1
1.5-V
PIN_BA31
LED2
LED2
1.5-V
PIN_AN27
LED3
LED3
1.5-V
PIN_AH27
UART-To-USB
The UART is designed to perform communication between the board and the PC, allowing a
transmission speed of up to 3Mbps. This interface wouldn’t support HW flow control signals. The
physical interface is done using UART-USB on-board bridge from a FT232R chip and connects to
the host using a USB Type-B connector. For detailed information on how to use the transceiver, please
refer to the datasheet, which is available on the manufacturer’s website, or under the
Datasheets\FT232 folder on the Kit System CD. Figure 2-7 shows the related schematics, and Table
2-10 lists the UART pin assignments, signal names and functions.
Figure 2-7 Connection between UART-To-USB and Stratix V GX FPGA
Table 2-10 UART-To-USB Pin Assignments, Schematic Signal Names, and Functions
Board
Reference
Schematic
Signal
Name
Description
I/O Standard
Stratix V
GX Pin
Number
UART_TX
UART_TX
Uart TX output from FPGA
1.2/1.5/1.8/2.5/3.0-
PIN_T26

TR5 User Manual
www.terasic.com
July 27, 2017
20
V
UART_RX
UART_RX
Uart RX input to FPGA
1.2/1.5/1.8/2.5/3.0-
V
PIN_T25
Micro SD-Card
The development board supports Micro SD card interface using 4 data lines. Figure 2-8 shows the
related signals connections between the SD Card and Stratix V GX FPGA. Table 2-11 lists all the
associated pins
Figure 2-8 Connection between the SD Card Socket and Stratix V GX FPGA
Table 2-11 Micro SD Card Pin Assignments, Schematic Signal Names, and Functions
Schematic
Signal
Name
Description
I/O Standard
Stratix V
GX Pin
Number
SD_CLK
Serial Clock
1.5-V
PIN_BB39
SD_CMD
Command, Response
1.5-V
PIN_BA36
SD_DAT0
Serial Data 0
1.5-V
PIN_AV37
SD_DAT1
Serial Data 1
1.5-V
PIN_AY37
