3 Specifications
7
3Specifications
3.1. Use
The testo 882 is a handy and robust thermal imager. It opens the
door to contactless determination and illustration of the temperature
distribution on surfaces for you.
Typical areas of application are:
•Building inspection (heating, ventilation and air conditioning
trade, company technicians, engineering offices, experts):
Energy evaluation of buildings
•Preventative maintenance (servicing): Mechanical and electrical
inspection of systems and machines
•Production monitoring (quality assurance): Monitoring
production processes
Basic properties:
•High-quality wide-angle lens 32° x 23°, detector 320 x 240,
NETD < 50 mK, 2 GB SD card for approx. 1000 images,
minimum focus distance 20 cm, integrated digital camera with
power LEDs for illumination, dynamic motorfocus, isotherm,
min./max. on area, audio comments, display of surface moisture
distribution (real-time display with optional radio humidity
probe), high-temperature filter (optional)
Export control
Thermal imagers may be subject to the export restrictions of the
European Union.
The testo 882 with 33 Hz in particular can only be exported to
countries outside of the European Union with an export permit from
the authorities.
Please observe the national regulations for export control when
exporting.
[e-mail] www.Testo-Direct.ca

3 Specifications
8
3.2. Technical data
Infrared image output
Characteristic Values
Field of vision/min.
focusing distance
Standard lens: 32° x 23°/0.2 m (0.66 ft)
Thermal sensitivity
(NETD)
<50 mK at 30 °C (86 °F)
Geometric resolution Standard lens: 1.7 mrad
Refresh rate 33 Hz within EU, 9 Hz outside of EU
Focus manual + motorized
Detector type FPA 320 x 240 pixels, a.Si
Spectral range 8 - 14 μm
Visual image output
Characteristic Values
Field of vision/min.
focusing distance
33° x 25°/0.4 m (1.31 ft)
Image size 640 x 480 pixels
Refresh rate 8 to 15 Hz
Image presentation
Characteristic Values
Image display 3.5" LCD with 320 x 240 pixels
Display options Infrared image/real image/infrared and real
Video stream 25 Hz
Colour palettes 9 options
[e-mail] www.Testo-Direct.ca

3 Specifications
9
Measuring
Characteristic Values
Temperature range
(can be changed)
Measuring range 1:
-20 - 100 °C (-4 - 212 °F)
Measuring range 2:
0 - 350 °C (32 - 662 °F)
Measuring range 3:
350 - 550 °C (662 - 1022 °F)
Accuracy With measuring range 1 activated, for
readings within the range of -20 - 100 °C
(-4 - 212 °F):
±2 °C (±3.6 °F)
With measuring range 2 activated, for
readings within the range of 0 - 350 °C
(32 - 662 °F):
±2 °C (±3.6 °F) or ±2 % of reading
(whichever is the greater)
With measuring range 3 activated, for
readings within the range of 350 - 550 °C
(662 - 1022 °F):
±3 % of reading
Reproducibility ±1 °C (±1.8 °F) or ±1 % (whichever is the
greater)
Measuring point
minimum diameter
5 mm at 1 m
On-time (time to
image)
30 s
Humidity and
ambient temperature
measurement with
radio probe (optional)
0…100%rF,
-20…70°C (-4…158°F)
Accuracy of radio
probe (optional)
±2%rF,
±0,5°C (0,9°F)
Measuring functions Standard measurement (1-point), 2-point
measurement, Cold-/Hotspot, isotherm,
min./max. on area, Display of humidity
image via manual entry of the ambient
humidity/temperature (real-time display with
optional radio humidity probe), solar
(manual entry of the radiation intensity)
[e-mail] www.Testo-Direct.ca

3 Specifications
10
Characteristic Values
Compensation for
reflected temperature
manual
Setting emissivity 0.01…1.00
Image storage
Characteristic Values
File format .bmt
Export options in .bmp, .jpg, .csv
Removable memory SD card
Memory capacity Scope of delivery: 2 GB (approx. 1000
images)
Lens
Characteristic Values
Wide-angle lens 32° x 23°
Aperture 0.95
w
Laser measuring spot marking
Characteristic Values
Classification of the
laser
635 nm, Class 2
Audio functions
Characteristic Values
Sound
recording/playback
via headset (included in delivery)
Recording period max. 30 s per image
[e-mail] www.Testo-Direct.ca

3 Specifications
11
Power supply
Characteristic Values
Battery type Fast-charging, Li-ion battery can be
changed on-site
Operating time approx. 4 h at 20 - 30 °C (68 - 86 °F)
Charging option In instrument/in charging station (optional)
Mains operation Yes, with mains unit 0554 8808
Mains unit output
voltage
5 V/4 A
Ambient conditions
Characteristic Values
Operating
temperature
-15 - 40 °C (5 - 113 °F) for measuring
range 1 and 2
0 - 40 °C (32 - 113 °F) for measuring
range 3
Storage
temperature
-30 - 60 °C (-22 - 140 °F)
Air humidity 20 - 80 %RH, not condensing
Enclosure rating of
the housing
IP54 (Interface terminals closed, battery
connected, lens mounted)
Physical features
Characteristic Values
Weight 900 g (including battery)
Dimensions 152 x 108 x 262 mm (5.98 x 4.17 x 10.31")
Tripod mounting Yes, with adapter (included in delivery)
Housing ABS
Enclosure rating of
the housing
IP54 (Interface terminals closed, battery
connected, lens mounted, softcase
mounted)
Vibration max. 2 G
[e-mail] www.Testo-Direct.ca
