TESTO 885 User manual

testo 885 · Thermal imager
Instruction manual

2

1 Contents
3
1 Contents
1Contents .............................................................................................. 3
2Safety and the environment ................................................................ 5
2.1. About this document .................................................................... 5
2.2. Ensure safety .............................................................................. 6
2.3. Protecting the environment .......................................................... 7
3Specifications...................................................................................... 8
3.1. Use ............................................................................................. 8
3.2. Technical data............................................................................. 9
4Product description........................................................................... 19
4.1. Overview ................................................................................... 19
4.1.1. Product components .........................................................................................19
4.1.2. Display interface................................................................................................21
4.1.3. Operating concept.............................................................................................24
4.2. Basic properties......................................................................... 25
4.2.1. Power supply.....................................................................................................25
4.2.2. File formats and file names...............................................................................25
5First steps.......................................................................................... 27
5.1. Commissioning.......................................................................... 27
5.1.1. Connecting the rechargeable battery................................................................27
5.1.2. Performing basic settings..................................................................................27
5.1.3. Initial charging of the rechargeable battery ......................................................29
5.2. Getting to know the product ....................................................... 30
5.2.1. Adjusting the hand strap ...................................................................................30
5.2.2. Attaching the lens cover to the hand strap .......................................................31
5.2.3. Rotating the handle ...........................................................................................31
5.2.4. Attaching a shoulder strap ................................................................................32
5.2.5. Using a lens case..............................................................................................32
5.2.6. Inserting the memory card ................................................................................32
5.2.7. Fitting/removing IR protection glass .................................................................33
5.2.8. Changing the lens .............................................................................................33
5.2.9. Switching the imager on/off...............................................................................34
5.2.10. Manually focusing the image ............................................................................35
5.2.11. Automatically focusing the image .....................................................................35
5.2.12. Recording (freezing/saving) an image ..............................................................35
6Using the product.............................................................................. 37
6.1. Menu bar/tabs ........................................................................... 37
6.1.1. Analysis functions tab.............................................................................37
6.1.2. Scale and correction functions tab .........................................................37

1 Contents
4
6.1.3. Main menu tab........................................................................................38
6.2. Menu functions...........................................................................40
6.2.1. Measurement....................................................................................................40
6.2.2. Display options ................................................................................................. 50
6.2.3. Image gallery ....................................................................................................51
6.2.4. Wizards .............................................................................................................54
6.2.5. Configuration.....................................................................................................65
6.2.6. Audio .................................................................................................................72
6.3. Measuring..................................................................................74
7Maintaining the product.....................................................................75
8Tips and assistance ...........................................................................76
8.1. Questions and answers ..............................................................76
8.2. Accessories and spare parts.......................................................76

2 Safety and the environment
5
2 Safety and the environment
2.1. About this document
Use
> Please read this documentation through carefully and
familiarize yourself with the product before putting it to use. Pay
particular attention to the safety instructions and warning advice
in order to prevent injuries and damage to the products.
> Keep this document to hand so that you can refer to it when
necessary.
> Hand this documentation on to any subsequent users of the
product.
Warnings
Always pay attention to information that is marked by the following
warnings with warning pictograms. Implement the specified
precautionary measures.
Representation
Explanation
CAUTION indicates potential minor injuries
NOTICE indicates circumstances that may lead to
damage to the products
Symbols and writing standards
Represen-
tation
Explanation
Note: Basic or further information.
1. ...
2. ...
Action: more steps, the sequence must be followed.
> ...
Action: a step or an optional step.
- ... Result of an action.
Menu Elements of the instrument, the instrument displays
or the program interface.

2 Safety and the environment
6
[OK] Control keys of the instrument or buttons of the
program interface.
... | ... Functions/paths within a menu.
“...” Example entries
2.2. Ensure safety
> Only operate the product properly, for its intended purpose and
within the parameters specified in the technical data. Do not
use any force.
> Do not operate the instrument if there are signs of damage at
the housing, mains unit or feed lines.
During operation, the imager must not be pointed at the sun or
other intensive sources of radiation (e.g. objects with temperatures
greater than 550°C/1022°F, if using the high-temperature
measurement range 1400°C/2552°F). This can lead to serious
damage to the detector. The manufacturer assumes no liability for
any such damage to the microbolometer detector.
> Dangers may also arise from the systems being measured or
the measuring environment: Note the safety regulations valid in
your area when performing the measurements.
> Do not store the product together with solvents. Do not use any
desiccants.
> Carry out only the maintenance and repair work on this
instrument that is described in the documentation. Follow the
prescribed steps exactly. Use only original spare parts
from Testo.
> Improper use of rechargeable batteries can lead to destruction
or injuries by means of current surges, fire or escaping
chemicals. The following instructions must be observed to avoid
such hazards:
• Only use in accordance with the directions in the instruction
manual.
• Do not short, take apart or modify.
• Do not expose to heavy impacts, water, fire or temperatures
above 60 °C.
• Do not store in the proximity of metal objects.
• Do not use leaky or damaged rechargeable batteries. In the
event of contact with battery acid: Thoroughly wash affected
area with water and consult a doctor, if necessary.
• Only charge in the instrument or the recommended charging
station.

2 Safety and the environment
7
• Immediately stop the charging process if this is not
completed in the given time.
• In the event of improper function or signs of overheating,
immediately remove the rechargeable battery from the
measuring instrument/charging station. Caution:
Rechargeable battery may be hot!
2.3. Protecting the environment
> Dispose of faulty rechargeable batteries/spent batteries in
accordance with the valid legal specifications.
> At the end of its useful life, send the product to the separate
collection for electric and electronic devices (observe local
regulations) or return the product to Testo for disposal.
WEEE Reg. Nr. DE 75334352

3 Specifications
8
3 Specifications
3.1. Use
The testo 885 is a handy and robust thermal imager. It enables you
to carry out contactless determination and display of the
temperature distribution on surfaces.
Typical areas of application are:
• Building inspection: energetic assessment of buildings, and
inspection of heating, ventilation and air conditioning systems.
• Preventative maintenance (servicing): mechanical and electrical
inspection of systems, machines and energy distribution
systems
• Production monitoring (quality assurance): monitoring of
production processes
• Professional energy consultation, leak detection
• Checking of photovoltaic modules
• Additional/different functions/features: telephoto lens (optional),
super-telephoto lens (optional), 25° lenses (optional), display of
surface moisture distribution via manual input of the ambient
conditions (optional: humidity measurement in real time with
radio humidity probe), SiteRecognition (site recognition with
image management), voice recording, high temperature
measurement (optional), process analysis package - sequence
capturing in the camera and video measurement on the PC
(optional)
Export control
Thermal imagers may be subject to the export restrictions of the
European Union.
Please observe the national regulations for export control when
exporting.

3 Specifications
9
3.2. Technical data
Infrared image output
Feature
Values
Detector type FPA 320 x 240 pixels, a.Si
Thermal sensitivity
(NETD)
< 30 mK at 30°C (86°F)
Field of vision/min.
focusing distance
30° x 23°/0.1 m (0.33 ft)
Telephoto lens (optional): 11° x 9°/0.5 m
(1.64 ft)
Super-telephoto lens (optional): 6,6° x 5° /
2 m (6.5 ft)
25° lenses (optional)
25° x 19° / 0,2 m (0,66 ft)
Geometric resolution
(IFOV)
1.7 mrad (standard lens)
0.6 mrad (telephoto lens)
0.18 mrad (super-telephoto lens)
1,36 mrad (25° lenses)
Super-resolution
(pixels/IFOV)
640 x 480 pixels /
1.06 mrad (standard lens)
0.38 mrad (telephoto lens)
0.11 mrad (super-telephoto lens)
0,85 mrad (25° lenses)
Image refresh rate 33 Hz within EU, 9 Hz outside of EU
Focus Automatic/manual
Spectral range 7.5…14 μm
Visual image output
Feature
Values
Image size 3.1 megapixels
Min. focusing
distance
0.5 m (1.64 ft.)
Image presentation

3 Specifications
10
Feature Values
Image display LCD touchscreen, 10.9 cm (4.3") screen
diagonal, 480 x 272 pixels
Digital zoom 1-3x
Display options IR image/real image
Video output
USB 2.0
Video stream Max. 25 Hz within EU, max. 9 Hz outside EU
Colour palettes 10
Measurement
Feature
Values
Temperature ranges
(can be changed)
Measuring range 1, instruments up to serial
number 2862504 (see type plate):
-20 to 100 °C (-4 to 212 °F)
Measuring range 1, instruments from serial
number 2862505 (see type plate):
-30 to 100 °C (-22 to 212 °F)
Measuring range 2:
0 to 350 °C (32 to 662 °F)
• Without high temperature measuring
range up to 1200 °C (2192 °F)
Measuring range 3:
0 to 650 °C (32 to 1202 °F)
• With high temperature measuring range
of 350 to 1200 °C (662 to 2192 °F)
Measuring range 3:
350 to 1200 °C (662 to 2192 °F)
Measuring range 4:
0 to 650 °C (32 to 1202 °F)

3 Specifications
11
Feature Values
Accuracy Measuring range 1 @ -20 to 100 °C
(-4 to 212 °F): ±2 °C (±3.6 °F)
Measuring range 1 @ -30 to -21 °C
(-22 to -5 °F), instruments from serial
number 2862505 (see type plate): ±3 °C
(±5.4 °F)
Measuring range 2:
±2 °C (±3.6 °F) or ±2 % of m.v.
(higher value applies)
• Without high temperature measuring
range up to 1200 °C (2192 °F)
Measuring range 3:
±2°C (±3.6 °F) typically 0 to 100 °C (32
to 212 °F) or +/-2% of m.v.
• With high temperature measuring range
of 350 to 1200 °C (662 to 2192 °F)
Measuring range 3:
±3 % of m.v.
Measuring range 4
±2°C (±3.6 °F) typically 0 to 100 °C (32
to 212 °F) or +/-2% of m.v.
Information valid for values within the
specified measuring range + tolerance
Extended display
range
Values with no guarantee of accuracy,
prefixed with a tilde (~) on the display. Only
for instruments from serial number 2862505
(see type plate):
Measuring range 1:
-50 to -33 °C (-58 to -27.4 °F)
Measuring range 2:
-10 to -2 °C (14 to 28.4 °F)
• Without high temperature measuring
range up to 1200 °C (2192 °F)
Measuring range 3:
-10 to -2 °C (14 to 28.4 °F)
• With high temperature measuring range
of 350 to 1200 °C (662 to 2192 °F)
Measuring range 3:
0 to 343 °C (32 to 649.4 °F)
Measuring range 4:
-10 to -2 °C (14 to 28.4 °F)
Reproducibility ±1°C (±1.8°F) or ±1% (higher value applies)

3 Specifications
12
Feature Values
Emissivity/reflected
temperature settings
0.01 to 1.00
Reflected
temperature/transmis
sion correction
(atmosphere)
settings
Manual
Minimum measuring
point diameter
Standard lens: 5.0 mm at 1 m (3.24 ft.)
distance
Telephoto lens: 1.9 mm at 1 m (3.24 ft.)
distance
Super-telephoto lens: 1.6 mm at 2
m (6.5 ft.)
distance
25° lens: 4.1 mm at 1 m (3.24 ft.) distance
Measurement
Feature Values
Display of surface
moisture distribution
via manual input
Humidity
measurement with
radio humidity probe
(not available in all
countries)
optional:
automatic measurement value transfer in
real time
Solar mode Yes
Analysis functions Up to 10 measuring points, hot/cold spot
detection, area measurement (min/max/
average value), isotherm, alarm values, up
to 5 range selections
ambient temperature
internal sensor
-15 to +50 ° C
Imager equipment
Feature
Values
Digital imager Yes
Standard lens 30° x 23°

3 Specifications
13
Feature Values
25° lens
Optional: 25° x 19°
Telephoto lens Optional: 11° x 9°
Super-telephoto lens Optional: 5° x 3.7°
Image stitching
wizard
Yes
Laser (not available
in USA, Japan,
China)
635 nm, Class 2
Voice recording via Bluetooth (not available in all
countries)/via wired headset
Video measurement
(via USB)
Up to 3 measuring points
Full radiometric video
measurement (via
USB)
(optional)
Acoustic alarm yes
Image storage
Feature
Values
File format .bmt, possible export to .bmp, .jpg, .png,
.csv, .xls
Video file format (via
USB)
.wmv, .mpeg-1, vmt (full radiometric video,
testo format)
Storage device
SD card 2 GB (800 to 1000 images)
Power supply
Feature
Values
Battery type Fast-charging Li-
ion battery can be changed
on site
Operating time Approx. 4.5 h at 20 to 30°C (68 to 86°F)
Charging option
In instrument/in charging station (optional)
Mains operation Yes, with mains unit 0554 8808
Mains unit output
voltage
5 V / 4 A

3 Specifications
14
Ambient conditions
Feature
Values
Operating
temperature range
-15 to 50°C (5 to 122°F)
Storage temperature
range
-30 to 60°C (-22 to 140°F)
Air humidity 20 to 80% non-condensing
Physical features
Feature
Values
Weight 1570 g (including battery)
Dimensions (L x W x
H)
253 x 132 x 111 mm (0.83 x 0.44 x 0.37")
Tripod mounting 1/4" - 20 UNC
Housing protection
class (IEC 60529)
IP54
Vibration
(IEC 60068-2-6)
2G
Bluetooth (not available in all countries)
Approval and Certification
Product testo 885
Mat.-No. 0563 0885
Date 21.01.2019
The use of the wireless module is subject to the regulations and stipulations of the
respective country of use, and the module may only be used in countries for which a
country certification has been granted. The user and every owner has the obligation to
adhere to these regulations and prerequisites for use, and acknowledges that the re-
sale, export, import etc. in particular in countries without wireless permits, is his
responsibility.

3 Specifications
15
Country
Comments
Australia
E 1561
Canada contains IC 5123A-WT11U
See IC Warnings
Europa + EFTA
The EU Declaration of Conformity
can be found on the testo
homepage www.testo.com under
the product specific downloads.
EU countries:
Belgium (BE), Bulgaria (BG), Denmark (DK),
Germany (DE), Estonia (EE), Finland (FI), France
(FR), Greece (GR), Ireland (IE), Italy (IT), Latvia
(LV), Lithuania (LT), Luxembourg (LU), Malta
(MT), Netherlands (NL), Austria (AT), Poland (PL),
Portugal (PT), Romania (RO), Sweden (SE),
Slovakia (SK), Slovenia (SI), Spain (ES), Czech
Republic (CZ), Hungary (HU), United Kingdom
(GB), Republic of Cyprus (CY).
EFTA countries:
Iceland, Liechtenstein, Norway, Switzerland
Japan
See Japan Information
Turkey Authorized

3 Specifications
16
USA
contains FCC ID: QOQWT11U
See FCC Warnings
Radio module
Feature
Values
Bluetooth Range
<10 m (free field)
Bluetooth type Bluegiga WTT11u
Bluetooth Module
Declaration ID
D031190
Bluetooth radio class
Class 1
Bluetooth company Silicon
Laboratories Inc.
RF Band
2402 - 2480 MHz
Nominal output power
17 dBm
IC Warnings
RSS-Gen & RSS-247 statement:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
Caution: Radio Frequency Radiation Exposure
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment and meets the IC radio frequency (RF) Exposure Guidelines. This equipment
should be installed and operated keeping the radiator at least 20 cm or more away from
person´s body in normal use position.

3 Specifications
17
Co-Location:
This transmitter must not be co-located or operated in conjunction with any other antenna
or transmitter.
Attention : exposition au rayonnement de radiofréquences
Cet équipement est conforme aux limites d'exposition aux radiofréquences IC fixées pour
un environnement non contrôlé et aux Lignes directrices relatives à l'exposition aux
radiofréquences (RF). Cet équipement devrait être installé et utilisé à une distance d'au
moins 20 cm d'un radiateur ou à une distance plus grande du corps humain en position
normale d'utilisation.
Co-location
Ce transmetteur ne peut pas être installé en colocation ou être utilisé avec une autre
antenne ou transmetteur, quel qu'en soit le type.
FCC Warnings
Information from the FCC (Federal Communications Commission)
For your own safety
Shielded cables should be used for a composite interface. This is to ensure continued
protection against radio frequency interference.
FCC warning statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is c onnected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. Shielded interface cable must be
used in order to comply with the emission limits.
Warning
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and

3 Specifications
18
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Caution: Radio Frequency Radiation Exposure
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines. This
equipment should be installed and operated keeping the radiator at least 20 cm or more
away from person´s body in normal use position.
Japan Information
当該機器には電波法に基づく、技術基準適合証明等を受けた特定無線設備を装
着している。

4 Product description
19
4 Product description
4.1. Overview
4.1.1. Product components
1 Digital imager lens for taking visual images and two
power -LEDs for illuminating the image.
2 Infrared imager lens for taking thermograms.
3 [Release lens] for releasing the lens lock.
4 Thread (1/4" - 20 UNC) for attaching a tripod (bottom of
imager). Do not use desktop tripods: danger of tipping over!
5 Laser (not available in all countries) for marking the
measurement object.
When using the super-telephoto lens the laser for marking
the measure object is not available.
CAUTION
Laser radiation! Class 2 laser
> Do not look into the beam.

4 Product description
20
6 Focusing ring for adjusting the focus manually.
CAUTION
Auto mechanism may be damaged!
> Only turn
focusing ring
when auto-focus is deactivated ( ).
7 Rotatable handle with adjustable hand strap and fastening loop
for the lens cover.
8 Battery compartment (bottom of imager).
9 Operating buttons (back and top of imager):
Button Functions
[ ]
Switch imager on/off
[●] (5-way
joystick)
Press [●]: open menu, activate selection/setting.
Move [●] up/down/right/left: select functions,
navigate
[Esc] Cancel action.
[A], [B] Shortcut keys for activating various functions. The
current shortcut key assignment is displayed (top
left). For adjustable functions, see Configure key,
page 69.
[Trigger
button]
(round
unmarked
button)
Press button (only when auto-focus is activated):
focus image automatically.
Press button: record image (freeze/save).
10 Two fixing eyelets for carrying/shoulder strap.
11 Interface terminals:
Terminal Assignment
Top Mains socket, headset socket, Battery status LED.
Battery status LED indications (imager on):
• Off (no battery inserted).
•
Flashing (mains unit is connected and battery is
charging).
• On (mains unit is connected and battery is fully
charged).
Bottom USB port, memory card slot, HDMI port type D
