Testrite Visual Charisma Inside-Out Light Box XSIO Series User manual

Page 1 of 5Version: 1
Identify the various Frame Assembly Components as shown below. First start by
assembling corners. There are two (2) at L-brackets per corner. All extrusion sections are
numbered to identify which pieces go together, 1 with 1, 2 with 2, etc.
1. For the Bottom frame section, join the corner sections of the bottom portion of the
frame using the L-brackets and screws. Join the mid sections using the at joiner plates
and screws as shown below.
2. Repeat step 1 for the Top section with eyebolts attached (not shown).
3. Connect the corner supports and fasten to bottom section using the hex key provided.
PROFESSIONAL INSTALLATION
WITH MULTIPLE PEOPLE IS RECOMMENDED
Charisma Inside-Out Light Box™ - XSIO Series
XSIO812 shown
1.
A.
A.
B.
2.
Eyebolts Power
Cords
B.
A.
A.
1A.
1B.
3.
Frame Assembly Components
Frame Top/Bottom
Center Support
Outside Corner
Inside Corner
Corner Support
Corner Support
Top View
If dicult to install, try loosening hex
screws before re-tightening
2
2
2
2
1
1
1
1
1
Frame Bottom
Frame Top

Page 2 of 5Version: 1
Inner and outer extrusions should t into the notches of the top and bottom frame extrusions. If it doesn’t t, carefully jiggle the extrusions until they t in. Don’t force it.
1. Identify the outer corner extrusion, pictured below.
2. Slide outside corner extrusion down channel of upright section as shown below, slowly lowering it into place. The corner of the extrusion will sit into the notched space of
the bottom frame corner. Do not force or drop into place.
3. Slide inside corner extrusion down channel of upright section as shown below, slowly lowering it into place. The corner of the extrusion will sit into the notched space of
the bottom frame corner. Do not force or drop into place.
Charisma Inside-Out Light Box™ - XSIO Series
1.
2.
Outside Corner extrusion
Top View
Outside Corner
extrusion
Inside Corner
extrusion Assembled
View
Inside Corner
extrusiuon
Top View
Outside
Corner
Outside
Corner
extrusion
Outside
Corner
Notch
Notch
Notch
Notch
Inside
Corner
Inside
Corner
Corner Support
Corner
Support

Page 3 of 5Version: 1
1. Attach the Top frame section to the uprights and fasten the screws using the hex key provided. Corners of outside and inside extrusions will
sit in the notches of the top of the frame.
2. Insert the vertical supports into the channel of the Top and Bottom sections, and fasten the ends using the hex key provided. Make sure to
use all vertical supplies provided.
Charisma Inside-Out Light Box™ - XSIO Series
XSIO812 shown
1.
2.
Outside notch
Inside notch
Corner of
extrusion will
sit in notch
If dicult to install, try loosening
hex screws before re-tightening

Page 4 of 5Version: 1
1. At each break in the extrusion, identify the orange or white electrical connector. Then connect the
white female connectors to their matching male connectors and the orange female connector to their
matching male connector. The connectors must fully “click” together.
2. It is normal for the last female white connector to be unconnected to anything else.
3. If there are multiple cables, connect those with matching colors (not shown).
Charisma Inside-Out Light Box™ - XSIO Series
Unconnected last female
connector is normal
2.
Power Supply to Plug
connection
1.1.
Light to Light connection

Page 5 of 5Version: 1
Follow the steps below to install the INSIDE face graphics FIRST, then proceed to installing the outside face graphics.
Outside face graphic is shown in the steps below for clarity.
1. To install the graphic, take the corner with the pull tag on it and press about 6”-10”of silicone into the frame channel corner A.
Repeat for the opposite corner B. Repeat for the next corner C. Lastly, repeat for the nal corner D.
2. After all corners are pressed in, press the silicone into the frame channel at the mid-points on all four sides.
3. Press silicone into frame evenly between the corner and midpoints.
This prevents the graphic from bunching up or stretching too much and will ensure a smooth and tight t.
4. To remove the graphic from the frame, simply pull up on the pull tag.
5. Repeat steps 1 to 4 for the additional graphics. Note: the outside facing graphics are wider than the inside facing graphics.
6. Use eyebolts on frame to hang the assembly.
7. Plug in the power cords. Note: The light box will have multiple power cords.
Charisma Inside-Out Light Box™ - XSIO Series
7.
XSIO812 shown
2.
6.
Pull
tag
4.
3.
1.
A.
D.
Frame
Section view
Section view
Silicone
gasket
Graphic
B.
C.
