Teufel Concept B 20 Manual

gb was
here
Technical description and operating instructions
2.0 PC Speakers
Concept B 20
91789 GB 20110321.indd 191789 GB 20110321.indd 1 22.03.11 09:0122.03.11 09:01

• Concept B 20
2
N
Th
ch
wa
of
N
pr
ed
ly,
wr
G
©
Ve
M
O
If y
rig
lut
W
sp
AG
Em
C
In
low
qu
1.
Ca
wi
fir
e.g
Contents
General notes and information ................................................................................3
Safety notes ............................................................................................................4
Product contents......................................................................................................6
Control elements......................................................................................................7
Connecting and setting up the speakers ...................................................................8
Use .......................................................................................................................10
Protecting the environment .................................................................................... 11
91789 GB 20110321.indd 291789 GB 20110321.indd 2 22.03.11 09:0122.03.11 09:01

3
• Concept B 20
Notice
The information in this document may
change without prior notice and in no
way constitutes any liability on the part
of Lautsprecher Teufel GmbH.
No part of these instructions may be re-
produced in any form or be broadcast-
ed in any way electronically, mechanical-
ly, by photocopy or recording without the
written permission of Lautsprecher Teufel
GmbH.
© Lautsprecher Teufel GmbH
Version 1.0
March 2011
Original packaging
If you wish to exercise your eight-week
right of return, we ask that you be abso-
lutely sure to hold onto the packaging.
We can only accept the return of the
speakers WITH THE ORIGINAL PACK-
AGING.
Empty boxes are not available!
Complaints
In case of complaint we will need the fol-
lowing information to process your en-
quiry:
1. Invoice number
Can be found on the sales slip (enclosed
with the product) or on the order con-
firmation received as a PDF document,
e.g. 4322543.
2. Serial number or batch number
Located on the back side of the unit,
e.g. serial number: TH04....
Many thanks for your support!
Contact
For questions, suggestions or criticism
please contact our customer service de-
partment:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen
Buelowstrasse 66
10783 Berlin (Germany)
Phone: 00800 – 200 300 400 (free of
charge)
Fax +49 (0)30 / 300 930 930
E-mail: [e-mail]
www.teufelaudio.com
Proper use
Only use the product as described in
these operating instructions. Any oth-
er use will be deemed as not in accord-
ance with the instructions and may lead
to damage to property or even persons.
The manufacturer accepts no liability for
damage caused by use not in accord-
ance with the instructions.
The product is intended for private use.
Before operating the speakers
please read the safety notes
and operating instructions care-
fully. This is the only way to use all func-
tions safely and reliably.
Keep the operating instructions safe and
pass them on to anyone who may own
the unit after you.
General notes and information
.3
.4
.6
.7
.8
10
11
91789 GB 20110321.indd 391789 GB 20110321.indd 3 22.03.11 09:0122.03.11 09:01

• Concept B 20
4
Safety notes
Caution icons
You will find the following caution icons
in these instructions:
Danger High risk!
Failure to observe the warning
may result in severe personal
injury or death.
Attention Moderate risk!
Failure to observe the warning
may result in property damage.
Minor risk!
Points which should be ob-
served when handling the unit.
Safety notes
Danger Risk of electric shock!
Faulty installation of electri-
cal equipment or mains volt-
age which is too high can cause electric
shocks.
• Only use the enclosed mains adapter.
When connecting, make sure that the
right voltage is present. More detailed
information is available directly on the
mains adapter.
• The switch in the volume control does
not disconnect the unit from the pow-
er supply. For this reason, connect it
to an easily accessible socket so that
you can quickly disconnect it from the
power supply in the event of faults.
• Immediately pull the mains adapter
out of the socket if the casing is defec-
tive or exhibits other visible damages.
• Set up the unit so that the mains plug is
easily accessible and no vent slots are
blocked.
• If the unit emits smoke or smells of
burning or other unusual odours, dis-
connect it immediately from the power
supply and do not operate it.
• Never open the unit housing.
Repairs may only be carried out by an
authorised specialist workshop, other-
wise any warranty claims are forfeit-
ed. Only use parts which conform with
the original unit specifications. There
are electrical and mechanical parts in
this unit which are essential in order to
avoid exposure to sources of danger.
• Only use accessory products, which
are exclusively specified by the manu-
facturer.
• Do not insert any objects through the
vent slots into the housing.
• Only use the unit in indoor areas, do
not use it in moist areas and protect it
from drops of water or splash water.
Also take care not to stand vases or
other containers filled with liquid on
or near the unit in order to avoid liq-
uid getting into the housing. If water
or other
foreign bodies should enter
the unit, disconnect it immediately from
the mains power supply. Send the unit
to our service address in this case.
• Never touch the mains adapter with
wet hands.
• Check the unit regularly for damage.
D
ing
•
•
Th
qu
ry
ris
•
•
•
D
ma
•
91789 GB 20110321.indd 491789 GB 20110321.indd 4 22.03.11 09:0122.03.11 09:01

5
• Concept B 20
s
e
-
er
h
-
e
o
it
-
m
t
.
Danger Danger to children!
Children can become trapped
in the packing film when play-
ing and suffocate.
• Do not allow children to play with the
unit or the packing film. Danger of
suffocation.
• Ensure that children do not remove
small parts from the unit or take them
off of the unit (e.g. control knobs or
the like). They could swallow the parts
and choke. Never allow children to
operate electrical devices unsuper-
vised.
Danger to hearing!
Loud noise may lead to hear-
ing loss.
This may have psychological conse-
quences and also cause physical inju-
ry. Children and pets are particularly at
risk.
• Set your signal source unit volume
control to a low setting.
• When the volume is set to a high lev-
el, never place your ear directly on
the speaker.
• To avoid damage to health, avoid ex-
tended listening at high volume.
Danger Danger of injury/dam-
age!
Selecting an incorrect location
may result in damages.
• Never use the speakers unmounted
in vehicles, in unstable locations, on
wobbly tripods or furniture, on insuffi-
ciently dimensioned brackets etc. The
speakers could tip or fall down and
cause injury to persons or be dam-
aged.
• Arrange the speakers so that they
cannot be knocked over accidentally
and make sure that the cables do not
pose a trip hazard.
• Do not place open flames such as
burning candles or similar on the
speakers.
• Do not place the speakers near sourc-
es of heat (e.g. heaters, ovens, oth-
er heat generating equipment such as
amplifiers etc.).
Attention Risk of damage!
Power overload due to light-
ning strike may damage or de-
stroy the unit.
• If the unit is to be left unsupervised
for a long period (e.g. during a holi-
day), or if a thunderstorm is forecast,
disconnect the mains adapter from the
power socket.
91789 GB 20110321.indd 591789 GB 20110321.indd 5 22.03.11 09:0122.03.11 09:01

• Concept B 20
6
Explanation of symbols
Safety class II Only use in indoor areas Polarity:
outside (–), inside (+)
Product contents
햲
햳
햴
Check to be sure
• Check that all items have been deliv-
ered and that nothing is damaged:
햲1 speaker right (main speaker)
1 speaker left
햳1 mains adapter
햴1 connector cable with 3.5 mm
stereo jack plugs
• If the delivery is incomplete or you
find damage sustained in transit, do
not operate the speakers, instead
contact our service department (see
page 3).
R
1
2
3
4
5
6
7
8
9
91789 GB 20110321.indd 691789 GB 20110321.indd 6 22.03.11 09:0122.03.11 09:01

7
• Concept B 20
Control elements
Right speaker
Left speaker
1
2
3
4
5
6
7
8
9
1Volume Volume control
2Tone Sound control
3Mic Microphone input jack
4Phones Earphone jack
5Micout Microphone output jack
6 To Left Speaker Connector jack for the left speaker
7 DC 17V 2.3A Input jack for the mains adapter
8 Audio In Audio input jack
9
Connector cable for the right speaker
91789 GB 20110321.indd 791789 GB 20110321.indd 7 22.03.11 09:0122.03.11 09:01

• Concept B 20
8
Connecting and setting up the speakers
Lo
•
•
•
•
•
Th
lef
sib
the
an
ta
er
ro
the
Th
be
the
Us
If y
ca
the
Ph
M
1. Insert the plug of the connector cable (9) in the jack (6) of the right speaker.
2. Connect the jack Audio In (8) with the line-out jack of your PC/notebook or with
the headphone jack of your music source (e.g. MP3 player, mobile etc.). Use the
connector cable 햴for this.
3. Connect the right speaker to the power supply with the mains adapter 햳. Observe
all safety notes on page 4/5 in the process.
4. If you would like to use a headset, connect the jack Mic Out (5) with the micro-
phone input jack of your PC/notebook. For this, you will need a cable with a
3.5 mm stereo jack plug (not included in the product contents).
Right speaker Left speaker
6
9
785
햴
햳
optional
91789 GB 20110321.indd 891789 GB 20110321.indd 8 22.03.11 09:0122.03.11 09:01

9
• Concept B 20
Location tips
• Select a stable, level base.
• Make sure that the environment is
clean and free from dust.
• Avoid placing the unit close to sourc-
es of heat or in direct sunlight.
• Arrange the connector cables so that
they do not pose a trip hazard.
• Do not place any heavy objects on
the cables or the speakers.
The speakers should be situated to the
left and right of the monitor and if pos-
sible, form an equilateral triangle with
the listener – the so-called stereo tri-
angle (distance from the listener = dis-
tance between the speakers). The speak-
ers should project sound directly into the
room or be arranged slightly towards
the listener.
There should be approx. 10 cm of space
between the back of the speakers and
the wall.
Using a headset/headphones
3
4
If you would like to use a headset, you
can connect it to the jacks (3) and (4) of
the right speaker.
Phones = headphones
Mic = microphone
ve
er
Prerequisite for the microphone func-
tion: The jack Mic Out (5) must be con-
nected to the microphone input jack of
the PC/notebook (see step 4 on the pre-
vious page).
Note: If you connect headphones to the
jack Phones (4), the speakers will be au-
tomatically muted. Sound will only be
played back via the headphones.
Danger to hearing!
When using headphones
a high volume may lead to
hearing loss.
• Set the volume control Volume (1) to a
low level.
• To avoid damage to health, avoid ex-
tended listening at high volume.
91789 GB 20110321.indd 991789 GB 20110321.indd 9 22.03.11 09:0122.03.11 09:01

• Concept B 20
10
D
qu
se
Use
Turning the speakers on/off, adjusting
the volume
1
• Turning the speakers on/increasing
the volume:
Turn the dial Volume (1) back.
• Turning the speakers off/decreasing
the volume: Turn the dial Volume (1)
forward.
To turn off the speakers, turn the dial
against the resistance until it locks into
place and the blue light turns off.
Adjusting the sound
2
You can adjust the sound with the dial
Tone (2):
• Turn the dial back for more bass.
• Turn it forward for more treble.
91789 GB 20110321.indd 1091789 GB 20110321.indd 10 22.03.11 09:0122.03.11 09:01

11
• Concept B 20
Disposing of the device
Used units must not be dis-
posed of with household
waste!
If the unit is no longer opera-
tional, every consumer is re-
quired by law to dispose of used devices
separately from household waste, e.g. at
Protecting the environment
a collection point run by the communal
authority borough. In this way it is en-
sured, that used devices are properly re-
cycled and that negative consequences
on the environment are avoided. For this
reason, electrical equipment is labelled
with the displayed symbol.
91789 GB 20110321.indd 1191789 GB 20110321.indd 11 22.03.11 09:0122.03.11 09:01

Instruction No. 91789 GB 20110321
For questions, suggestions or criticism please contact our customer service department:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen - Aufgang D1
Buelowstrasse 66
D-10783 Berlin (Germany)
Phone: 00800 – 200 300 400 (free of charge)
Fax: +49 (0)30 – 300 930 930
www.teufelaudio.com
No responsibility is assumed for the correctness of this information.
Technical changes, typographical errors and other errors reserved.
91789 GB 20110321.indd 1291789 GB 20110321.indd 12 22.03.11 09:0122.03.11 09:01
