Tews Technologies TPCE863 User manual

The Embedded I/O Company
TPCE863
4 Channel High Speed
Sync/Async Serial Interface
Version 1.0
User Manual
Issue 1.0.1
August 2014
TEWS TECHNOLOGIES GmbH
Am Bahnhof 7
25469 Halstenbek, Germany
Phone: [phone]
Fax: [phone]
e-mail: [email protected] www.tews.com

TPCE863-10R
4 Channel High Speed Sync/Async Serial
Interface, HD68 front panel connector
This document contains information, which is
proprietary to TEWS TECHNOLOGIES GmbH. Any
reproduction without written permission is forbidden.
TEWS TECHNOLOGIES GmbH has made any
effort to ensure that this manual is accurate and
complete. However TEWS TECHNOLOGIES GmbH
reserves the right to change the product described
in this document at any time without notice.
TEWS TECHNOLOGIES GmbH is not liable for any
damage arising out of the application or use of the
device described herein.
Style Conventions
Hexadecimal characters are specified with prefix 0x,
i.e. 0x029E (that means hexadecimal value 029E).
For signals on hardware products, an ‚Active Low’ is
represented by the signal name with # following, i.e.
IP_RESET#.
Access terms are described as:
W Write Only
R Read Only
R/W Read/Write
R/C Read/Clear
R/S Read/Set
2014 by TEWS TECHNOLOGIES GmbH
All trademarks mentioned are property of their respective owners.
TPCE863 User Manual Issue 1.0.1 Page 2 of 72

Issue
Description
Date
1.0.0 Initial Issue September 2012
1.0.1 General Revision August 2014
TPCE863 User Manual Issue 1.0.1 Page 3 of 72

Table of Contents
1PRODUCT DESCRIPTION .........................................................................................10
2TECHNICAL SPECIFICATION ...................................................................................11
3HANDLING AND OPERATION INSTRUCTIONS.......................................................12
3.1 ESD Protection..............................................................................................................................12
4ON BOARD DEVICES ................................................................................................13
4.1 Overview ........................................................................................................................................13
4.2 PI7C9X111SL PCIe/PCI Bridge.....................................................................................................13
4.2.1 PI7C9X111SL Register Map...................................................................................................13
4.2.2 PCI Express Configuration Space Register Mapping.............................................................14
4.2.2.1 PCI-Compatible Configuration (Type 1) Registers............................................................14
4.2.2.2 PCI-Compatible Extended Capability Registers................................................................15
4.2.3 Configuration EEPROM..........................................................................................................16
4.3 SCC FPGA......................................................................................................................................16
4.3.1 PCI Configuration Space ........................................................................................................17
5ADDRESS MAP..........................................................................................................18
5.1 Register Space..............................................................................................................................18
5.2 Register Map..................................................................................................................................18
5.3 Global Register Map .....................................................................................................................19
5.4 SCC Register Map.........................................................................................................................20
5.5 Global Registers............................................................................................................................22
5.5.1 GCMDR – Global Command Register....................................................................................22
5.5.2 GSTAR – Global Status Register ...........................................................................................25
5.5.3 GMODE – Global Mode Register ...........................................................................................26
5.5.4 IQLENR0 – Interrupt Queue Length Register 0......................................................................27
5.5.5 IQLENR1 – Interrupt Queue Length Register 1......................................................................27
5.5.6 IQSCCiRXBAR – Interrupt Queue SCCi Receiver Base Address Register...........................28
5.5.7 IQSCCiTXBAR – Interrupt Queue SCCi Transmitter Base Address Register........................28
5.5.8 FIFOCR4 – FIFO Control Register 4......................................................................................29
5.5.9 IQCFGBAR – Interrupt Queue Configuration Base Address Register ...................................30
5.5.10 FIFOCR1 – FIFO Control Register 1......................................................................................30
5.5.11 CHiCFG – Channel i Configuration Register..........................................................................31
5.5.12 CHiBRDA – Channel i Base Receive Descriptor Address Register.......................................33
5.5.13 CHiBTDA – Channel i Base Transmit Descriptor Address Register ......................................33
5.5.14 CHiFRDA – Channel i First (Current) Receive Descriptor Address Register.........................33
5.5.15 CHiFTDA – Channel i First (Current) Transmit Descriptor Address Register ........................33
5.5.16 CHiLRDA – Channel i Last Receive Descriptor Address Register.........................................33
5.5.17 CHiLTDA – Channel i Last Transmit Descriptor Address Register ........................................34
5.5.18 VR – Version Register ............................................................................................................34
5.5.19 ISPR – In-System-Programming Register..............................................................................34
5.5.20 GCTLR – Global Control Register ..........................................................................................35
TPCE863 User Manual Issue 1.0.1 Page 4 of 72

5.6 SCC Channel Specific Registers.................................................................................................36
5.6.1 CMDR – Command Register..................................................................................................36
5.6.2 STAR – Status Register..........................................................................................................37
5.6.3 CCR0 – Channel Configuration Register 0.............................................................................38
5.6.4 CCR1 –Configuration Register 1............................................................................................39
5.6.5 CCR2 – Channel Configuration Register 2.............................................................................41
5.6.6 BRR – Baud Rate Register.....................................................................................................43
5.6.7 TCR – Termination Character Register..................................................................................43
5.6.8 IMR – Interrupt Mask Register................................................................................................44
5.6.9 ISR – Interrupt Status Register...............................................................................................45
5.6.10 ACR – Additional Configuration Register ...............................................................................47
6FUNCTIONAL DESCRIPTION....................................................................................49
6.1 DMA Controller..............................................................................................................................49
6.1.1 DMAC Transmit Descriptor Lists ............................................................................................50
6.1.1.1 Transmit Descriptor ...........................................................................................................50
6.1.2 DMAC Receive Descriptor Lists .............................................................................................52
6.1.2.1 Receive Descriptor ............................................................................................................52
6.1.2.2 Receive Data Section Status Byte (HDLC Mode) .............................................................54
6.1.2.3 Receive Data Section Status Byte (ASYNC Modes).........................................................55
6.2 DMAC Interrupt Controller ...........................................................................................................55
6.2.1 DMA Controller initiated Interrupts..........................................................................................56
6.2.2 Interrupt Vector Description....................................................................................................57
6.2.2.1 Configuration Interrupt Vector ...........................................................................................57
6.2.2.2 DMA Controller Interrupt Vector ........................................................................................57
6.2.2.3 SCC Interrupt Vector .........................................................................................................59
7SERIAL COMMUNICATION CONTROLLER .............................................................60
7.1 Protocol Description.....................................................................................................................60
7.1.1 HDLC Mode............................................................................................................................60
7.1.1.1 Address Mode 0.................................................................................................................60
7.1.1.2 Extended Transparent Mode.............................................................................................61
7.1.2 Asynchronous (ASYNC) Mode...............................................................................................61
7.1.2.1 Asynchronous Mode..........................................................................................................61
7.1.2.2 Isochronous Mode.............................................................................................................61
7.1.2.3 Receive Data Storage........................................................................................................61
7.1.2.4 Data Transmission.............................................................................................................62
7.1.2.5 Break Detection/Generation ..............................................................................................62
7.1.2.6 Flow Control.......................................................................................................................62
7.2 Clock Sources...............................................................................................................................63
7.3 Baud Rate Generation ..................................................................................................................63
7.4 Data Encoding...............................................................................................................................64
7.4.1 NRZ and NRZI Encoding........................................................................................................64
7.4.2 FM0 and FM1 Encoding .........................................................................................................65
7.4.3 Manchester Encoding.............................................................................................................65
7.5 Clock Recovery (DPLL) ................................................................................................................66
8CONFIGURATION HINTS...........................................................................................67
8.1 Big / Little Endian............................................................................................................................67
8.2 Configuration EEPROM..................................................................................................................67
8.3 Additional Termination Resistors....................................................................................................68
8.4 Transmit & Receive Clock Polarity..................................................................................................69
TPCE863 User Manual Issue 1.0.1 Page 5 of 72

9MODULE MANAGEMENT..........................................................................................70
9.1 On Board LEDs...............................................................................................................................70
10 PIN ASSIGNMENT – I/O CONNECTOR.....................................................................71
10.1 Front Panel I/O Connector..............................................................................................................71
TPCE863 User Manual Issue 1.0.1 Page 6 of 72

List of Figures
FIGURE 1-1 : BLOCK DIAGRAM....................................................................................................................10
FIGURE 6-1 : FPGA ON-CHIP BLOCK DIAGRAM ........................................................................................49
FIGURE 7-1 : HDLC ADDRESS MODE 0.......................................................................................................60
FIGURE 7-2 : CLOCK SOURCES ..................................................................................................................63
FIGURE 7-3 : NRZ AND NRZI DATA ENCODING.........................................................................................64
FIGURE 7-4 : FM0 AND FM1 DATA ENCODING...........................................................................................65
FIGURE 7-5 : MANCHESTER DATA ENCODING .........................................................................................65
FIGURE 8-1 : TRANSMIT & RECEIVE CLOCK POLARITY...........................................................................69
FIGURE 10-1 : FRONT PANEL I/O CONNECTOR NUMBERING.................................................................71
TPCE863 User Manual Issue 1.0.1 Page 7 of 72

List of Tables
TABLE 2-1 : TECHNICAL SPECIFICATION...................................................................................................11
TABLE 4-1 : PI7C9X111SL REGISTER MAP.................................................................................................13
TABLE 4-2 : PI7C9X111SL PCI-COMPATIBLE CONFIGURATION (TYPE 1) REGISTERS ........................14
TABLE 4-3 : PI7C9X111SL PCI-COMPATIBLE EXTENDED CAPABILITY REGISTERS.............................15
TABLE 4-4 : PCI CONFIGURATION SPACE .................................................................................................17
TABLE 5-1 : REGISTER SPACE ....................................................................................................................18
TABLE 5-2 : REGISTER MAP.........................................................................................................................18
TABLE 5-3 : GLOBAL REGISTER MAP.........................................................................................................20
TABLE 5-4 : SCC REGISTER MAP................................................................................................................21
TABLE 5-5 : GLOBAL COMMAND REGISTER..............................................................................................24
TABLE 5-6 : GLOBAL STATUS REGISTER...................................................................................................26
TABLE 5-7 : GLOBAL MODE REGISTER ......................................................................................................26
TABLE 5-8 : INTERRUPT QUEUE LENGTH REGISTER 0...........................................................................27
TABLE 5-9 : INTERRUPT QUEUE LENGTH REGISTER 1...........................................................................27
TABLE 5-10: IQSCCIRXBAR REGISTER.......................................................................................................28
TABLE 5-11: IQSCCITXBAR REGISTER.......................................................................................................28
TABLE 5-12 : FIFO CONTROL REGISTER 4.................................................................................................29
TABLE 5-13: IQCFGBAR REGISTER.............................................................................................................30
TABLE 5-14: FIFO CONTROL REGISTER 1..................................................................................................30
TABLE 5-15: CHICFG REGISTER..................................................................................................................32
TABLE 5-16: CHIBRDA REGISTER...............................................................................................................33
TABLE 5-17: CHIBTDA REGISTER................................................................................................................33
TABLE 5-18: CHIFRDA REGISTER ...............................................................................................................33
TABLE 5-19: CHIFTDA REGISTER................................................................................................................33
TABLE 5-20: CHILRDA REGISTER................................................................................................................33
TABLE 5-21: CHILTDA REGISTER................................................................................................................34
TABLE 5-22: VERSION REGISTER...............................................................................................................34
TABLE 5-23: GLOBAL CONTROL REGISTER ..............................................................................................35
TABLE 5-24: COMMAND REGISTER ............................................................................................................36
TABLE 5-25: STATUS REGISTER.................................................................................................................37
TABLE 5-26: CHANNEL CONFIGURATION REGISTER 0............................................................................39
TABLE 5-27: CHANNEL CONFIGURATION REGISTER 1............................................................................40
TABLE 5-28: CHANNEL CONFIGURATION REGISTER 2............................................................................42
TABLE 5-29: BAUD RATE REGISTER...........................................................................................................43
TABLE 5-30: TERMINATION CHARACTER REGISTER...............................................................................43
TABLE 5-31: INTERRUPT MASK REGISTER................................................................................................44
TABLE 5-32: INTERRUPT STATUS REGISTER............................................................................................46
TABLE 5-33: ADDITIONAL CONFIGURATION REGISTER ..........................................................................48
TABLE 5-34: PHYSICAL INTERFACE MODE SELECTION..........................................................................48
TABLE 6-1 : TRANSMIT DESCRIPTOR.........................................................................................................50
TABLE 6-2 : RECEIVE DESCRIPTOR ...........................................................................................................52
TPCE863 User Manual Issue 1.0.1 Page 8 of 72

TABLE 6-3 : RECEIVE DESCRIPTOR STATUS FIELD.................................................................................54
TABLE 6-4 : RECEIVE DATA SECTION STATUS BYTE (HDLC) .................................................................54
TABLE 6-5 : RECEIVE DATA SECTION STATUS BYTE (ASYNC)...............................................................55
TABLE 6-6 : CONFIGURATION INTERRUPT VECTOR................................................................................57
TABLE 6-7 : DMA INTERRUPT VECTOR......................................................................................................57
TABLE 6-8 : DMA INTERRUPT VECTOR SOURCE-IDS ..............................................................................57
TABLE 6-9 : SCC INTERRUPT VECTOR.......................................................................................................59
TABLE 6-10: SCC INTERRUPT VECTOR SOURCE-IDS..............................................................................59
TABLE 7-1 : PROTOCOL MODES .................................................................................................................60
TABLE 8-1 : CONFIGURATION EEPROM DATA ..........................................................................................68
TABLE 9-1 : ON BOARD LEDS ......................................................................................................................70
TABLE 10-1 : FRONT I/O PIN ASSIGNMENT................................................................................................72
TPCE863 User Manual Issue 1.0.1 Page 9 of 72

1 Product Description
The TPCE863 is a standard height, half length PCI Express 1.1 compliant module with four high speed serial
data communication channels.
The serial communication controller is implemented in FPGA logic, along with the bus master capable PCI
interface, guaranteeing long term availability and having the option to implement additional functions in the
future. The FPGA is connected to the PCI Express interface via a transparent PCI Express to PCI bridge.
Each channel provides a 512 DWORD (32 bit) receive FIFO and a transmit FIFO of up to 512 DWORD (32
bit) for high data throughput.
Data transfer on the PCI Express bus is handled via TPCE863 initiated DMA cycles with minimum host/CPU
intervention.
Several serial communication protocols are supported by each channel, such as asynchronous, isochronous,
synchronous and HDLC mode.
A 14.7456 MHz oscillator provides standard asynchronous baud rates. A 24 MHz and a 10 MHz oscillator
are provided for other (synchronous) baud rates.
Additionally each channel provides various interrupt sources, generated on INTA. The interrupt sources can
be enabled or disabled individually.
Multiprotocol transceivers are used for the line interface. The physical interface is selectable by software,
individually for each channel as EIA-232, EIA-422, EIA 449, EIA-530, EIA-530A, V.35, V.36 or X.21.
A HD68 SCSI-3 type connector at the front panel provides access to the I/O lines.
The following signals are provided by the TPCE863 for each channel:
Receive Data (RxD +/-), Transmit Data (TxD +/-), Receive Clock (RxC +/-), Transmit Clock (TxC +/-), Ready-
To-Send (RTS +/-), Clear-To-Send (CTS +/-), Carrier-Detect (CD +/-) and GND. Additionally serial channel 3
provides Data-Set-Ready (DSR3 +/-) and Data-Terminal-Ready (DTR3 +/-).
A serial EEPROM is used to store detailed board information and special configuration parameters.
Operating temperature range is -40°C to +85°C.
Figure 1-1 : Block Diagram
TPCE863 User Manual Issue 1.0.1 Page 10 of 72

2 Technical Specification
Interface
Mechanical Interface PCISIG conforming PCI Express Revision 1.1
Standard Height, Half Length
Electrical Interface PCISIG conforming PCI Express Revision 1.1
Single Link Width (x1)
On Board Devices
PCI Express / PCI Bridge
PI7C9X111SL (Pericom Semiconductor Corporation)
Serial Communication
Controller (FPGA) XC3S1500-4FG(G)320I
Spartan-3 FPGA (Xilinx)
I/O Interface
Number of Channels 4
Line Transceiver LTC2844/LTC2846 (Linear Technology) Multi-Protocol chip set,
software selectable, on-chip cable termination (LTC2846)
FIFO Main Transmit-FIFO per channel: up to 512 DWORD (2 Kbyte)
Main Receive-FIFO per channel: 512 DWORD (2 Kbyte)
SCC Transmit-FIFO per channel: up to 16 Byte
SCC Receive-FIFO per channel: 16 Byte
Data Rates Synchronous: 10 Mbit/s (Non-DPLL Modes), 2 Mbit/s (DPLL
Modes)
Asynchronous: 2 Mbit/s
I/O Connector Front panel HD68 SCSI-3 Type Connector
(AMP 787082-7 or compatible)
Physical Data
Power Requirements 51mA typical (no cable mode) @ +3.3V DC
81mA typical (V.28) @ +3.3V DC
1.15A typical (RS530/A) @ +3.3V DC
Temperature Range Operating
Storage -40°C to +85°C -40°C to +85°C
MTBF TPCE863-10R: 280988 h
MTBF values shown are based on calculation according to MIL-HDBK-217F and
MIL-HDBK-217F Notice 2; Environment: GB20°C.
The MTBF calculation is based on component FIT rates provided by the
component suppliers. If FIT rates are not available, MIL-HDBK-217F and
MIL-HDBK-217F Notice 2 formulas are used for FIT rate calculation.
Humidity 5 – 95 % non-condensing
Weight TPCE863-10R: 86 g
Table 2-1 : Technical Specification
TPCE863 User Manual Issue 1.0.1 Page 11 of 72

3 Handling and Operation Instructions
ESD Protection3.1
The TPCE863 is sensitive to Electrostatic Discharge (ESD).
Packing, unpacking and all other handling of the TPCE863 has to be done
in an ESD/EOS protected Area.
TPCE863 User Manual Issue 1.0.1 Page 12 of 72

4 On Board Devices
Overview4.1
The DMA capable serial communication controller is implemented in an on board FPGA with integrated PCI
bus interface (32 bit 33 MHz PCI bus).
The FPGA implements the serial communication controller logic and a register space and is the only
accessible device on the embedded TPCE863 PCI bus (except the PCIe/PCI bridge).
The PI7C9X111SL (Pericom Semiconductor Corporation) PCIe/PCI bridge is used as the bridging device
between the host PCIe interface and the on board PCI bus (i.e. the FPGA).
PI7C9X111SL PCIe/PCI Bridge4.2
The PI7C9X111SL is a PCI Express to PCI reversible bridge. On the TPCE863 the PI7C9X111SL is used in
transparent, forward mode only.
4.2.1 PI7C9X111SL Register Map
Register Group PCI Space Offset Address
Range
Configuration
Registers PCI-Compatible Configuration Registers 0x00 – 0x3C
Internal Configuration
Registers – 0x40 – 0x7C
PCI Compatible
Extended Capability
Registers for PCI
Express Interface
PCI-Compatible Extended Capability Registers 0x80 – 0xFF
PCI Express
Extended Capability
Registers PCI Express Extended Capability Registers 0x100 – 0xFFF
Table 4-1 : PI7C9X111SL Register Map
TPCE863 User Manual Issue 1.0.1 Page 13 of 72

4.2.2 PCI Express Configuration Space Register Mapping
4.2.2.1 PCI-Compatible Configuration (Type 1) Registers
PCI
CFG
Regist
er
Addres
s
31 24 23 16 15 8 7 0 Read after
initializati
on write
access
0x00 PCI Device ID PCI Vendor ID E111 12D8
0x04 PCI Status PCI Command 0010 0000
0x08 PCI Class Code PCI Device
Revision ID 060400 02
0x0C PCI Built-In Self-
Test
(Not Supported)
PCI Header Type Internal PCI Bus
Latency Timer PCI Cache Line Size 00 01 00 00
0x10 PCI Base Address 0 00000000
0x14 PCI Base Address 1 00000000
0x18 Secondary
Latency Timer Subordinate Bus Number Secondary Bus Number Primary Bus Number 00 00 00 00
0x1C Secondary Status I/O Limit I/O Base 0200 01 01
0x20 Memory Limit Memory Base 0000 8000
0x24 Prefetchable Memory Limit Prefetchable Memory Base 0001 8001
0x28 Prefetchable Memory Base Upper 32 Bits 00000000
0x2C Prefetchable Memory Limit Upper 32 Bits 00000000
0x30 I/O Limit Upper 16 Bits I/O Base Upper 16 Bits 0000 0000
0x34 Reserved PCI Capabilities
Pointer 000000 80
0x38 PCI Base Address for Expansion ROM 00000000
0x3C Bridge Control Internal PCI
Interrupt Wire Internal PCI Interrupt Line 0000 01 00
Table 4-2 : PI7C9X111SL PCI-Compatible Configuration (Type 1) Registers
TPCE863 User Manual Issue 1.0.1 Page 14 of 72

4.2.2.2 PCI-Compatible Extended Capability Registers
PCI
CFG
Registe
r
Addres
s
31 24 23 16 15 8 7 0 Read after
initializatio
n write
access
0x80 PCI-X Secondary Status PCI-X Next
Capability Pointer PCI-X Capability ID 0000 9007
0x84 PCI-X Bridge Status Register 0000FFF8
0x88 Upstream Split Transaction 00100010
0x8C Downstream Split Transaction 00100010
0x90 Power Management Capabilities Power Management
Next Capability
Pointer
Power Management
Capability ID C843 A801
0x94 PCI to PCI Support Extension Power Management Control/Status 0000 0000
0x98 Reserved -
0x9C Reserved -
0xA0 Chassis Number Slot Number Slot Identification
Capability Pointer Slot Identification Capability ID 0000 B004
0xA4 Secondary Clock and ClkRun Control 0001 0000
0xA8 Reserved Subsystem and
Subsystem Vendor
ID Capability Pointer
Subsystem and
Subsystem Vendor
ID Capability ID
0000 B00D
0xAc Subsystem ID Subsystem Vendor ID 0000 0000
0xB0 PCI Express Capabilities PCI Express Next
Capability Pointer PCI Express Capability ID 0071 D810
0xB4 Device Capabilities 0000 0022
0xB8 PCI Express Device Status PCI Express Device Control 0010 2000
0xBC Link Capabilities 00xx 3C11
0xC0 Link Status Link Control 1011 0000
0xC4 Slot Capabilities 0000 0000
0xC8 Slot Status Slot Control 0000 0000
0xCC XPIP Configuration 0 0400 1060
0xD0 XPIP Configuration 1 0400 0271
0xD4 XPIP Configuration 2 0019 0256
0xD8 VPD VPD Capability
Pointer VPD Capability ID 0000 F003
0xDC VPD Data 0000 0000
0xE0 Reserved -
0xE4 Reserved -
0xE8 Reserved -
0xEC Reserved -
0xF0 Message Signaled Interrupts Control Message Signaled
Interrupts Next
Capability Pointer
Message Signaled
Interrupts Capability
ID
0000 00 05
0xF4 Message Signaled Interrupts Address 0000 0000
0xF8 Message Signaled Interrupts Upper Address 0000 0000
0xFC Reserved Message Signaled Interrupts Data 0000 0000
Table 4-3 : PI7C9X111SL PCI-Compatible Extended Capability Registers
TPCE863 User Manual Issue 1.0.1 Page 15 of 72

4.2.3 Configuration EEPROM
After PCIe reset, the PI7C9X111SL loads initial configuration register data from an on board configuration
I2C EEPROM. The content is a complete set of configuration parameters based on the default settings with
the subsequent modifications.
For detailed information please refer to the PI7C9X111SL manual and Errata information.
Modifications are:
•Enable Lane Polarity Inversion (disabled by default)
SCC FPGA4.3
The Serial Communication Controller (SCC) FPGA resides on the on board 32 bit 33 MHz PCI bus and is the
only other PCI device on the embedded PCI bus (PCI device number 0).
The FPGA implements a set of control & status registers as a PCI target, accessible in the PCI memory
space.
The FPGA also implements a PCI DMA/Master engine used for the data transfers to and from host/system
memory.
The FPGA configures from a serial Flash after power-up.
TPCE863 User Manual Issue 1.0.1 Page 16 of 72

4.3.1 PCI Configuration Space
The SCC FPGA is assigned PCI device number 0 on the TPCE863 embedded PCI bus.
PCI Configuration Space Header
Offset 31 16 15 0
0x00 Device ID
(TPCE863: 0x735F) Vendor ID (TEWS Technologies 0x1498)
0x04 Status Command
0x08 Class Code
(0x028000) Rev ID
0x0C BIST Header Type
(0x00) Lat. Timer Line Size
0x10 Base Address Register 0 Target register space of high speed serial communication controller
(SCC FPGA)
0x14 Base Address Register 1 (not used)
0x18 Base Address Register 2 (not used)
0x1C Base Address Register 3 (not used)
0x20 Base Address Register 4 (not used)
0x24 Base Address Register 5 (not used)
0x28 CardBus CIS Pointer (not used)
0x2C Subsystem ID
(TPCE863-10R: 0x700A) Subsystem Vendor ID (TEWS Technologies 0x1498)
0x30 Expansion ROM Base Address (not used)
0x34 Reserved Cap. Pointer
(0x00)
0x38 Reserved
0x3C Max_Lat
(0x0A) Min_Gnt (0x03) Int_Pin (0x01) Int_Line
Table 4-4 : PCI Configuration Space
TPCE863 User Manual Issue 1.0.1 Page 17 of 72

5 Address Map
Register Space5.1
The Register Space is accessible in the PCI Memory Space of the TPCE863 embedded PCI bus.
The Register Space Base address is found at PCI BAR0 (Offset 0x10) in the PCI Configuration Space of the
SCC FPGA (PCI device number 0 on the TPCE863 embedded PCI bus)
PCI Device Number 0
Device ID 0x735F (TPCE863)
Vendor ID 0x1498 (TEWS Technologies)
PCI Base
Address
(Offset in PCI
Configuration
Space)
PCI Space
Mapping Size
(Byte) Port Width (Bit) Endian
Mode Description
0 (0x10) MEM 2048 32 Little Register Space
Table 5-1 : Register Space
Register Map5.2
Offset to PCI
Base Address Addresses range Number of used
DWORD registers Description
0x0000 0x0000…0x00FF 44 (0x0000…0x00EC) Global Registers
0x0100 0x0100…0x017F 10 (0x0100…0x0158) SCC0 Registers
0x0180 0x0180…0x01FF 10 (0x0180…0x01D8) SCC1 Registers
0x0200 0x0200…0x027F 10 (0x0200…0x0258) SCC2 Registers
0x0280 0x0280…0x02FF 10 (0x0280…0x02D8) SCC3 Registers
0x0300 0x0300…0x07FF 0 (reserved)
Table 5-2 : Register Map
TPCE863 User Manual Issue 1.0.1 Page 18 of 72

Global Register Map5.3
All registers are 32 bit organized.
Offset to PCI
Base Address Register Name
0x0000 GCMDR Global Command Register
0x0004 GSTAR Global Status Register
0x0008 GMODE Global Mode Register
Interrupt Queue IQ specific registers (+ FIFO Control registers):
0x000C IQLENR0 IQ Length Register 0
0x0010 IQLENR1 IQ Length Register 1
0x0014 IQSCC0RXBAR IQ SCC0 RX Base Address Register
0x0018 IQSCC1RXBAR IQ SCC1 RX Base Address Register
0x001C IQSCC2RXBAR IQ SCC2 RX Base Address Register
0x0020 IQSCC3RXBAR IQ SCC3 RX Base Address Register
0x0024 IQSCC0TXBAR IQ SCC0 TX Base Address Register
0x0028 IQSCC1TXBAR IQ SCC1 TX Base Address Register
0x002C IQSCC2TXBAR IQ SCC2 TX Base Address Register
0x0030 IQSCC3TXBAR IQ SCC3 TX Base Address Register
0x0034 FIFOCR4 FIFO Control Register 4
0x0038 reserved -
0x003C IQCFGBAR IQ CFG Base Address Register
0x0040 reserved -
0x0044 FIFOCR1 FIFO Control Register 1
0x0048 reserved -
0x004C reserved -
DMA Controller (DMAC) specific registers:
0x0050 CH0CFG Channel 0 Configuration Register
0x0054 CH0BRDA Channel 0 Base Rx Descr. Address
0x0058 CH0BTDA Channel 0 Base Tx Descr. Address
0x005C CH1CFG Channel 1 Configuration Register
0x0060 CH1BRDA Channel 1 Base Rx Descr. Address
0x0064 CH1BTDA Channel 1 Base Tx Descr. Address
0x0068 CH2CFG Channel 2 Configuration Register
0x006C CH2BRDA Channel 2 Base Rx Descr. Address
0x0070 CH2BTDA Channel 2 Base Tx Descr. Address
0x0074 CH3CFG Channel 3 Configuration Register
0x0078 CH3BRDA Channel 3 Base Rx Descr. Address
0x007C CH3BTDA Channel 3 Base Tx Descr. Address
0x0080...0x0097 reserved -
0x0098 CH0FRDA Channel 0 First Rx Descr. Address
TPCE863 User Manual Issue 1.0.1 Page 19 of 72

Offset to PCI
Base Address Register Name
0x009C CH1FRDA Channel 1 First Rx Descr. Address
0x00A0 CH2FRDA Channel 2 First Rx Descr. Address
0x00A4 CH3FRDA Channel 3 First Rx Descr. Address
0x00A8 reserved -
0x00AC reserved -
0x00B0 CH0FTDA Channel 0 First Tx Descr. Address
0x00B4 CH1FTDA Channel 1 First Tx Descr. Address
0x00B8 CH2FTDA Channel 2 First Tx Descr. Address
0x00BC CH3FTDA Channel 3 First Tx Descr. Address
0x00C0 reserved -
0x00C4 reserved -
0x00C8 CH0LRDA Channel 0 Last Rx Descr. Address
0x00CC CH1LRDA Channel 1 Last Rx Descr. Address
0x00D0 CH2LRDA Channel 2 Last Rx Descr. Address
0x00D4 CH3LRDA Channel 3 Last Rx Descr. Address
0x00D8 reserved -
0x00DC reserved -
0x00E0 CH0LTDA Channel 0 Last Tx Descr. Address
0x00E4 CH1LTDA Channel 1 Last Tx Descr. Address
0x00E8 CH2LTDA Channel 2 Last Tx Descr. Address
0x00EC CH3LTDA Channel 3 Last Tx Descr. Address
Other registers:
0x00F0 VR Version Register
0x00F4 ISPR ISP Register
0x00F8 GCTLR Global Control Register
0x00FC...0x00FF reserved -
Table 5-3 : Global Register Map
SCC Register Map5.4
The SCC registers are used to configure and control each of the four integrated Serial Communication
Controller (SCC).
There is one complete SCC register set for each of the four SCC channels (0 … 3).
The address of a certain SCC register is:
Register Space PCI Base Address + SCC Channel Offset + SCC Register Offset
Register Space PCI Base Address:
PCI Base Address 0
(Offset 0x10 in the PCI Configuration Space of the FPGA PCI Device)
TPCE863 User Manual Issue 1.0.1 Page 20 of 72
