Texas Instruments MCF8329EVM User manual

EVM User's Guide: MCF8329EVM
MCF8329 Evaluation Module
Description
The MCF8329EVM allows users to evaluate the
performance of a MCF8329 motor driver. The EVM
includes an onboard FTDI chip to convert USB
communication, from the micro-USB connector, into
UART. An onboard MSP430FR2355 microcontroller
(MCU) translates the UART communication into either
control signals or SPI formatted data, which is
sent to the MCF8329 device. There are many user-
selectable jumpers, resistors, connectors, and test
points to assist with evaluating the many features of
the MCF8329 IC and the configurable device-specific
settings.
Get Started
1. Download the latest design files from the
MCF8329EVM tool page on ti.com
2. Download the latest version of the Motor Studio
GUI and firmware from the Motor Studio tool page
on ti.com
Features
• GUI software to simplify the MCx tuning process
and performance evaluation
• MCU-to-MCx shunt jumper header with removable
shunts to disconnect main signals going to the
motor driver IC from the MCU
– The shunts can be removed if the user desires
to control the MCF8329 IC with an external
MCU or to use the EVM MCU to control an
external MCF8329 IC
Applications
•Cordless vacuum
•Cordless garden tools
•CPAP machine
•Ventilator
• Server fans
MCF8329EVM (Top View)
www.ti.com Description
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 1
Copyright © 2023 Texas Instruments Incorporated

1 Evaluation Module Overview
1.1 Introduction
This document is provided with the MCF8329 customer evaluation module (EVM) as a supplement to the
MCF8329 data sheet. This user's guide details the hardware setup instructions, GUI installation, and usage
instructions.
CAUTION
Hot surface temperature
The EVM can have high surface temperatures marked by the FIRE triangular symbol on the EVM.
Avoid toughing the marked hot surface are when driving high currents to prevent potential burn
damage.
1.2 Kit Contents
Table 1-1 lists the contents of the EVM kit. Contact the Texas Instruments Product Information Center nearest to
you if any components are missing. TI highly recommends that users check the TI website at https://www.ti.com
to verify that the latest version of the related software is being used.
Table 1-1. Kit Contents
Item Quantity
MCF8329EVM 1
USB A Male-to-USB B Micro Male Cable 1
1.3 Specification
The MCF8329EVM can support voltages up to 60 V and currents up to 30 A. To prevent damage to both the IC
and the EVM, confirm that these voltage and current specifications are not exceeded.
1.4 Device Information
The MCF8329 is a 4.5-V to 60-V, three-phase brushless-DC gate driver IC with code-free sensorless field
oriented control (FOC) for motor drive applications. The device provides three half-bridge gate drivers, each
capable of driving high-side and low-side N-channel power MOSFETs. The device generates the correct gate
drive voltages using an internal charge pump and enhances the high-side MOSFETs using a bootstrap circuit. A
trickle charge pump is included to support 100% duty cycle. The gate drive architecture supports peak gate drive
currents up to 1-A source and 2-A sink.
The internal sensorless FOC algorithm is highly configurable through register settings in a non-volatile EEPROM
ranging from motor start-up behavior to closed loop operation, which allows for the device to operate stand-alone
once the device has been configured. Motor current is sensed using an integrated current sense amplifier
supporting a single external shunt resistor. The device can receive a speed command through a PWM input,
analog voltage, variable frequency square wave, or I2C command. There are a large number of protection
features integrated into the MCF8329, intended to protect the device, motor, and system against fault events.
Evaluation Module Overview www.ti.com
2MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2 Hardware
2.1 Quick Start Guide
The MCF8329EVM requires a power supply source, which has a recommended operating range from a 4.5-V to
60-V. To setup and power the EVM, follow the sequence below:
1. Connect motor phases to A, B, and C on connector J11.
2. Do not turn on the power supply yet. Connect the motor supply to PVDD and GND on connector J10.
3. Select J6 to 5V_USB and J8 to 3V3COM to power MSP430 from USB power supply.
4. Connect the micro-USB cable into the computer.
5. Turn the potentiometer fully clockwise to set the motor to zero speed upon power up.
6. Flip the switch S1 to the top to configure BRAKE = RUN, switch S2 to the top to configure DRVOFF = ON,
switch S3 to the bottom to configure DIR = ABC, and switch S4 to the bottom to configure WAKE.
7. Flip the switch SW1 to left to configure SPEED/WAKE pin to SPEED mode and DACOUT/SOx/SPEED_ANA
pin to DACOUT mode. Note that flipping the switch SW1 to right configures SPEED/WAKE pin to WAKE
mode and DACOUT/SOx/SPEED_ANA pin to SPEED_ANA mode. When SW1 is flipped to right, switch S4
can be used to put the device in SLEEP or WAKE mode and potentiometer R47 can be used to apply analog
voltage to the DACOUT/SOx/SPEED_ANA pin.
8. Set J12 to leftmost position (closer to C6) to apply AVDD to VREG.
9. Set J13 to middle position to apply the analog voltage from potentiometer R47 to the SPEED/WAKE pin.
10. Turn on the motor power supply.
11. Use the potentiometer R47 to control the speed of the motor and the switches to disable the motor driver,
change the direction, or apply a brake to the motor. Optionally, use the GUI (as shown in Section 3) to
monitor the real-time speed of the motor, put the MCF8329 into a low-power sleep mode, and read status of
the LEDs.
Figure 2-1. Reference for Quick Start Guide
www.ti.com Hardware
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 3
Copyright © 2023 Texas Instruments Incorporated

2.2 Hardware Setup
The hardware required to run the motor is the MCF8329EVM, a micro-USB cable, and a power supply with a DC
output from 4.5-V to 60-V. Follow these steps to start up the MCF8329EVM:
1. Connect the DC power supply to header J10. Connect to PVDD and GND.
2. Apply user configurable jumper settings. See Section 2.7 for more information.
3. Flash the firmware into the MCU as described in Section 3.4. Launch Motor Studio and disconnect the 4-pin
JTAG connections.
4. Turn on the power supply to power up the MCF8329EVM.
5. Connect a Micro-USB cable to the MCF8329EVM and computer.
If using the MCF8329EVM with an external microcontroller, then remove all shunt jumpers from jumper bridge
J9. Connect with external jumpers to the right side of the jumper bridge from the external MCU.
2.3 Hardware Connections Overview
Figure 2-2 shows the major blocks of MCF8329EVM. The MCF8329EVM is designed for an input supply from
4.5 V to 60 V at 30 A max. The MCF8329EVM includes a power stage with six external N-channel power
MOSFETs (part number: CSD18536KTTT) and passive components. The MCF8329EVM also includes a 1 mΩ
current sense shunt resistor and an external N-channel MOSFET controlled by GCTRL to generate VREG. For
interfacing with the GUI, the MCF8329EVM has an onboard FTDI chip and MSP430.
Figure 2-2. MCF8329EVM Major Hardware Blocks
Hardware www.ti.com
4MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2.4 Connection Details
Figure 2-3 outlines which connections must be made to the MCF8329EVM in order to spin a 3-phase sensorless
brushless-DC motor.
Connect a 4.5-V to 60-V power supply to the PVDD and GND terminals on connector J10.
Connect the three phases of the BLDC motor to the A, B, and C terminals of the screw terminal connector J11.
Figure 2-3. Connections from Motor to MCF8329EVM
Figure 2-4 shows where the micro-USB cable is plugged into the MCF8329EVM to provide communication
between evaluation module and GUI. The USB data and 5 V power from the USB is converted, by the FTDI chip,
into UART data and 3.3 V power which is used to power the MSP430FR2355 microcontroller. The 5 V from the
USB power is limited to 500 mA and the 3.3 V from the FTDI chip is limited to 30 mA. If the user wants to supply
more current to these rails, then use the 5V_SEL jumper J6 and 3V3_SEL jumper J8 to connect external power
rails.
Figure 2-4. Micro-USB connector and USB-to-UART interface
www.ti.com Hardware
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 5
Copyright © 2023 Texas Instruments Incorporated

2.5 MSP430FR2355 Microcontroller
The MCF8329EVM includes a MSP430FR2355 low-power MCU, shown in Figure 2-5, to communicate via I2C
with the MCF8329 IC.
To program the MSP430FR2355, an external MSP430 FET programmer must be connected to the Spy-Bi-Wire
(SBW) interface connector J7. Many MSP430 LaunchPads™ provide an onboard eZ-FET Debug Probe that can
be jumper-wired to the MCF8329EVM to flash the firmware into the onboard MSP430FR2355 microcontroller.
The user can use the Reset (RST) button at any time to restart the MCU program. Two active-low LEDs, D13
and D14, can be used for debug purposes as well.
The 32-pin shunt jumper bridge J9 ties all signals between the microcontroller and MCF8329 IC. These jumpers
can be inserted or removed as needed to isolate the microcontroller from the gate driver. This allows for
microcontroller signal debugging or using the MCF8329EVM as a standalone gate driver with an external
microcontroller.
Figure 2-5. MSP430FR2355 MCU on MCF3829EVM
Hardware www.ti.com
6MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2.6 LED Lights
The MCF8329EVM has 5 status LEDs that provide the status of power supplies and functions of the evaluation
module. By default, the PVDD LED and AVDD LED lights up when the board is powered and the program
has been flashed onto the microcontroller. Table 2-1 shows LED descriptions including those that are on during
power up in bold with Figure 2-6 showing the locations of the LEDs.
Table 2-1. Description of MCF8329EVM LEDs (Default in Bold After Power Up)
Designator Name Color Description
D1 3.3V Green Lights up when AVDD is turned ON
D2 nFAULT Red Lights up when fault condition has occurred on
MCF8329
D3 PVDD Green Lights up when voltage is applied on PVDD
D13 MSP_LED1 Red Used for UART or debugging
D14 MSP_LED2 Red Used for UART or debugging
Figure 2-6. MCF8329EVM LED Locations
www.ti.com Hardware
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 7
Copyright © 2023 Texas Instruments Incorporated

2.7 User Configurable Settings
The MCF8329EVM includes a variety of user-selectable jumpers, switches, and resistors on the entirety of the
evaluation board to configure settings. Table 2-2 summarizes all of these configurable settings.
Table 2-2. Description of User-Selectable Settings on MCF8329EVM (Default in Bold)
Designator Setting Name Description Layer Position Function
J8 3V3_SEL Select 3.3 V source for MCU power Top J8 = 3V3EXT External
J8 = 3V3COM From FTDI (30 mA)
J6 5V_SEL Select 5 V source for FTDI power Top J6 = 5V_EXT External
J6 = 5V_USB From USB power (500 mA)
J13 SPEED_SEL Selects SPEED input source Top
J13 = EXT External EXT_SPEED test point
J13 = POT From Potentiometer R47
J13 = INT_PWM
From internal PWM. PWM Duty
cycle can be varied by rotating the
POT R47
J9
MSP to MCx
Shunt jumper
bridge
Connects signals from MVU and
user switches to MCF8329 when
jumpers are inserted
Top
DRVOFF_SW DRVOFF
DIR_SW DIR
BRAKE_SW BRAKE
SPEED_WAK SPEED/WAKE
MSP_POCI/SCL SCL
MSP_PICO/SDA SDA
MSP_CLK NC
MSP_STE NC
DAC/SPEED DAC/SPEED
MSP_A2 NC
MSP_A1 GCTRL
NC NC
MSP_nFAULT nFAULT
MSP_FGOUT FGOUT
NC NC
GND GND
J12 VREG_SEL Selects VREG power supply Top
Left position VREG powered by AVDD
Middle position VREG powered externally
Right position VREG powered by MOSFET Q7
J1 AVDD LED Connects AVDD LED to 3.3 V pull
up Top Connected D1 lights up when AVDD is turned ON
J2 nFAULT LED Connects nFAULT LED to 3.3 V
pull up Top Connected D2 Lights up when nFAULT is
pulled low
J3 PVDD LED Connects PVDD LED to 3.3 V pull
up Top Connected D3 lights up when voltage is
applied to PVDD
S1 Brake Turns on all low-side MOSFETs Top Bottom Break enabled
Top Brake disabled
S2 DRVOFF Disables gate drivers Top
Bottom MCF8329 Disabled
Top MCF8329 Disabled
S3 DIR Controls direction of motor rotation Top Bottom ABC
Top ACB
S4 SPEED/WAKE Pulls SPEED/WAKE pin to AVDD
and GND Top Bottom SPEED/WAKE pin pulled to AVDD
Top SPEED/WAKE pin pulled to GND
Hardware www.ti.com
8MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Table 2-2. Description of User-Selectable Settings on MCF8329EVM (Default in Bold) (continued)
Designator Setting Name Description Layer Position Function
SW1 N/A
Configure SPEED/WAKE pin to
SPEED mode and DACOUT/SOx/
SPEED_ANA pin
Top
Left
Configure SPEED/Wake pin to
SPEED mode and DCAOUT/SOx/
SPEED/ANA pin to DACOUT mode
Right
Configure SPEED/WAKE pin to
WAKE mode and DACOUT/SOx/
SPEED_ANA pin to SPEED_ANA
mode
www.ti.com Hardware
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 9
Copyright © 2023 Texas Instruments Incorporated

3 Software
3.1 Firmware and GUI Application
The MCF8329EVM includes a USB-to-UART interface, using a MSP430FR2355 microcontroller, that serves as a
communication bridge between a host PC and the MCF8329 device for configuring various device settings and
reading fault diagnostic information.
The MCF8329EVM is supported on the Motor Studio GUI which can be used to configure the MCF8329 though
this communication interface. The Motor Studio GUI simplifies the tuning process of the MCF8329 by offering
guided tuning instructions, a virtual oscilloscope for real-time variable monitoring, and more. The latest version of
the Motor Studio GUI can be downloaded on ti.com.
By default, the onboard MSP430 microcontroller already contains the firmware needed to communicate with the
Motor Studio GUI. If there is a firmware update or the GUI does not connect to the EVM, then the user must
flash the firmware code into the MSP430 by following the steps outlined in Section 3.4.
Flashing the firmware code onto the MSP430 requires an integrated development environment (IDE) and
an eZ-FET Debug Probe. The following example uses the Code Composer Studio™(CCS) IDE and the MSP-
EXP430FR2355 LaunchPad™ Development Kit to provide the eZ-FET Debug Probe.
3.2 Downloading and Running Motor Studio
1. Connect the MCF8329EVM as described in Section 2.2.
2. Download the latest version of the Motor Studio GUI.
3. Once the Motor Studio GUI is installed, run the Motor Studio GUI application.
4. Click the red Setup Now button under Hardware Setup on the bottom right side of the window.
5. After setting up the hardware settings of the MCF8329EVM, click on the Quick Spin option to begin
configuring the device.
Figure 3-1. Motor Studio GUI MCF8329A Home Page
Software www.ti.com
10 MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3.3 Downloading Code Composer Studio and Importing GUI Firmware
1. Download and extract the Motor Studio firmware to a location on your computer.
2. Download the latest version of Code Composer Studio to set up a folder in the directory C:\ti.
a. Accept all agreements, default install instructions, and select Next to proceed through the menus.
b. In the Selected Components window, make sure to check MSP430 Low-Power MCUs to install the
required packages for the MSP430 Launchpad Evaluation Kits.
3. After installing, run CCS and select a folder or the default to use as the workspace to store any new projects.
The location and naming convention can be changed based on the user's preference. Click the OK button to
accept.
4. In CCS, click on the Project tab and select Import CCS Projects. Click on Browse.
5. Select the folder created in step 1 by extracting the Motor Studio firmware.
6. Import the project into your workspace as shown in Figure 3-2
Figure 3-2. MSP430FR2355 Interface Firmware Code in Code Composer Studio
www.ti.com Software
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 11
Copyright © 2023 Texas Instruments Incorporated

3.4 Using eZ-FET to Program the Onboard MSP430FR2355
The eZ-FET Debug Probe on the MSP430FR2355 LaunchPad uses a Spy-Bi-Wire JTAG interface to program
the MSP430FR2355 MCU on the MCF8329EVM. Consult the MSP430 Launchpad Development Kits for
MSP430 Launchpad the include an onboard eZ-FET Debug Probe.
1. Remove the GND, 3V3, SBWTDIO, and SBWTCK jumpers from the MSP430 LaunchPad.
2. Connect the top pins on the eZ-FET side of the LaunchPad of the GND, 3V3, SBWTDIO, SBWTCK signals
to their respective pins on J7 of the MCF8329EVM as shown in Table 3-1 and Figure 3-3.
3. Connect a micro-USB cable to the MSP430 LauchPad and the PC.
4. Click on the Build Project icon or CTRL+B to make sure the project builds successfully. Accept any updates
if needed from the console
5. Click on Debug Project to set up a debug session and press the Play button to run the code.
6. Stop the debug session, close Code Composer Studio, disconnect the Spy-Bi-Wire jumpers, and unplug the
micro-USB cable from the MSP430 LaunchPad.
Table 3-1. Spy-Bi-Wire Connections Needed to Program the MSP430FR2355
MSP430 LaunchPad (eZ-FET Debug Probe Side) (J101) MCF8329EVM 4-pin Spy-Bi-Wire Header (J7)
GND GND
3V3 3V3
SBWTDIO SBWTDIO
SBWTCK SBWTCK
Figure 3-3. MSP430 LaunchPad eZ-FET Debug Probe Connected to MSP430FR2355
Software www.ti.com
12 MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

4 Hardware Design Files
4.1 Schematics
1
2
3
Y1
GND
DM
DP
CERAMIC RES 4.0000MHZ 39PF SMD
5V_USB Changed to q200
1uF
50V
C49
GND
MSP_TX_P4.2
GND
3V3_MCU
FTDI
MSP_nFAULT_P3.3
Micro USB Connector
47k
R16
470
R17
470
R18
3V3_MCU
3V3_MCU
12
S5
1nF
16V
C48
MCU PROGRAMMING
MSP_LED1_P2.2
MSP430FR2355
TX/RX LEDs
MSP_CLK_P4.5
MSP430 Reset / Pushbutton
GND
MSP_SIMO/SDA_P4.6
MSP_SOMI/SCL_P4.7
GND
GND
GND
DP
DM
5V_USB 3V3COM 3V3COM
DTR 2
3
RTS
VCCIO
4
5RXD
RI
6GND 7
NC
8
9DSR
DCD
10
CTS
11
CBUS4 12
CBUS2 13
CBUS3 14
15
16 USB
USB
D
D
P
M
3V3OUT 17
GND 18
RESET
19
VCC
20
GND 21
CBUS1 22
CBUS0 23
NC
24
AGND 25
TEST
26
OSCI
27 OSCO 28
1
TXD
U3
FT232RL
FTDI REGULATOR
3
2
1
J6
5V_SEL
5V_EXT
5V_EXT
GND
GND
GND GND
3V3EXT 3V3_MCU
1
2 3
J8
3V3COM
3.3V_SEL for MSP430
3V3EXT
D4
3V3COM 3V3_MCU
4
1
2
3
J7
3V3_MCU GND
1
2IO1
IO2
GND 3
IO3 4
IO4 5
6VCC
U4
ID
TPD4E004DRYR
5V_USB
DP DM
GND
L1
120 ohm
100nF
10V
C11
100nF
10V
C47
5VCC
10V
C46
4.7µF
100nF
10V
C16
ID
Remove jumpers from eZ-FET to MSP430 on Launchpad.
Use jumpers to connect J4 to GND, 3V3,
SBWTDIO, and SBWTCK of MSP430 Launchpad.
1VBUS
D-
2
3D+
ID
4
5GND
6 7 8
11 10 9
J5
1051640001
MSP_RX_P4.3
MSP_A3_P1.3
TB1.2 inputs FGOUT MSP_FGOUT_P2.1
MSP_TX_P4.2
MSP_RX_P4.3
MSP_STE_P4.4
MSP_LED0_P2.2 MSP_LED1_P2.2
MSP_SBWTCK
MSP_LED0_P2.2
MSP_SBWTDIO/nRST
MSP_SBWTDIO/nRST
MSP_XOUT_P2.6
MSP_XIN_P2.7
Populate jumpers to communicate onboard MSP430FR2355 to the MCx8329A
USB ESD Protection
MSP430FR2355
Signal Bank for connecting MSP430 + MCx8329A
To MSP430FR2355To MCx8329
MSP_SBWTDIO/nRST
MSP_SBWTCK
or depopulate jumpers to use standalone MSP430 or MCx8329A.
MSP_A1_P1.1
Red
1
MSP_A2_P1.2
2
D14
Red
12
LTST-C190KRKT
D13
LTST-C190KRKT
MSP_A3_P1.3
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15
17
19
21
23
25
27
29
31
16
18
20
22
24
26
28
30
32
J9
DRVOFF
DIR
GND
FGOUT
BRAKE
TSW-116 -07-G-D
SPEED/WAKE
GND
nFAULT
MSP_FGOUT_P2.1
DRVOFF_SW
DIR_SW
BRAKE_SW
SPEED_WAKE
DACOUT/SOX/SPEED_ANA
MSP_nFAULT_P3.3
MCX_SCL
MCX_SDA
MSP_SOMI/SCL_P4.7
MSP_SIMO/SDA_P4.6
MSP_A1_P1.1
MSP_A2_P1.2
MSP_CLK_P4.5
MSP_STE_P4.4
5V_USB
3V3COM
3V3_MCU
6
5
RST/NMI/SBWTDIO
3
2
1
48
34
33
32
31
30
29
28
27
11
10
9
8
47
46
45
44
38
37
36
35
26
25
24
23
15
14
13
12
43
42
DVCC
P1.0/UCB0STE/SMCLK/COMP0.0/A0/Veref+
P1.1/UCB0CLK/ACLK/OA0O/COMP0.1/A1
P1.2/UCB0SIMO/UCB0SDA/TB0TRG/OA0-/A2/Veref-
P1.3/UCB0SOMI/UCB0SCL/OA0+/A3
P1.4/UCA0STE/TCK/A4
P1.5/UCA0CLK/TMS/OA1O/A5
P1.6/UCA0RXD/UCA0SOMI/TB0.1/TDI/TCLK/OA1-/A6
P1.7/UCA0TXD/UCA0SIMO/TB0.2/TDO/OA1+/A7/VREF+
P2.0/TB1.1/COMP0.O
P2.1/TB1.2/COMP1.O
P2.2/TB1CLK
P2.3/TB1TRG
P2.4/COMP1.1
P2.5/COMP1.0
P2.6/MCLK/XOUT
P2.7/TB0CLK/XIN
P3.0/MCLK
P3.1/OA2O
P3.2/OA2-
P3.3/OA2+
P3.4/SMCLK
P3.5/OA3O
P3.6/OA3-
P3.7/OA3+
41
40
39
P4.0/UCA1STE/ISOTXD/ISORXD
P4.1/UCA1CLK
P4.2/UCA1RXD/UCA1SOMI/UCA1RXD
P4.3/UCA1TXD/UCA1SIMO/UCA1TXD
P4.4/UCB1STE
P4.5/UCB1CLK
P4.6/UCB1SIMO/UCB1SDA
P4.7/UCB1SOMI/UCB1SCL
22
P6.0/TB3.1 21
P5.0/TB2.1/MFM.RX/A8
P5.1/TB2.2/MFM.TX/A9
P5.2/TB2CLK/A10
P5.3/TB2TRG/A11
P5.4
P6.1/TB3.2 20
P6.2/TB3.3 19
P6.3/TB3.4 18
P6.4/TB3.5 17
P6.5/TB3.6 16
P6.6/TB3CLK
4
TEST/SBWTCK
DVSS 7
U5
POT
MSP430FR2355TPTR
MSP_TB0.1
DACOUT/SOX/SPEED_ANA
MCX_SDA
MCX_SCL
SPEED/WAKE
BRAKE
DIR
DRVOFF
SPEED_WAKE
BRAKE_SW
DIR_SW
DRVOFF_SW
FGOUT
nFAULT POT
MSP_TB0.1
DACOUT_SPEED_ANA
DACOUT_SPEED_ANA
Figure 4-1. Interfaces
www.ti.com Hardware Design Files
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 13
Copyright © 2023 Texas Instruments Incorporated

5.1k
R7
AVDD
MCx8329A
TP9
1TP1
9TP3
0TP1
4TP1
0
CPL
TP4
BSTA
nFAULT
BSTB
BSTC
GHA
GLA
GHB SHB
GLB
GHC
SHC
GLC
SP
SN
GND
GND
PVDD
GND
AVDD
AVDD
PVDD
GVDD
GHA
SHA
nFAULT
GLA
GHB
SHB
GHC
GLB
SHC
GLC
DRVOFF
LSS
SP
LSS
GHA GLA SHA GHB SHB GLB GHC SHC GLC
SP
LSS
SN
100nF
100V
C7
AVDD
PVDD LED
PVDD
STATUS LEDS
nFAULT LEDAVDD LED
AVDD
GND GND
Green
12
D1
Green
12
D3
Red
12
D2
2.00k
R15
nFAULT
nFAULT
MCT8329A Hardware Variant
100V
10uF
C6
GND
820
R13
820
R14
2
1
J1
2
1
J2
2
1
J3
25V
C8
1uF
25V
C9
1uF
25V
1uF
C10
SN
10 9 8 7 6 5 4 3 2 1 11 12 13 14
J4
BSTC BSTB
BSTA
GND
LSS
26 AVDD
36 DVDD
8GVDD
5PVDD
35 FAULT
34
9
BSTA
13
BSTB
17
BSTC
7
CPH 6
CPL
33
31
24
32
FG
28
3GCTRL
VREG
SPEED/WAKE
DACOUT/SOx/SPEED_ANA
EXT_CLK
BRAKE
DRVOFF
DIR
11
GHA
15
GHB
19
GHC
GLA 12
GLB 16
20
GLC
21
LSS
30 SCL
29 SDA
10
SHA
SHB 14
SHC 18
23
SN
SP 22
27
37
Thermal_pad
2
25
AGND
1
GND
GND 4
U1
MCT8329A1I
CPH
SHA
FGOUT
DRVOFF
SCL
SDA
R11 0
R12 0
MCX_SDA
MCX_SCL
AVDD
AVDD
5.1k
R8
AVDD
FGOUT
DIR
BRAKE
EXT_CLK
EXT_CLK
DACOUT/SOX/SPEED_ANA
DVDD
DACOUT/SOX/SPEED_ANA
GND
GND
25V
C5
10uF
VREG
GCTRL
GCTRL
SDA
Hardware Variant Resistors (MCT8329A hardware variant only)
GND
0
R2
GND
0
R1
GND
EXT_CLK
0
R4
GND
0
R5
GND
0
R3
RMP_2
RMP_1
SCL
LDANGLE
ILIMIT
DACOUT/SOX/SPEED_ANA
nFAULT
GND
0
R6
CONFIG_1
DIR
5.1k
R9
5.1k
R10
BRAKE
DIR
SPEED/WAKE
FGOUT
MCX_SCL
MCX_SDA
GCTRL
6.3V
C4
1uF
6.3V
C1
10uF
C2
0.1µF
6.3V
GND
GND
0
R46
1.00M
R50
DACOUT/SOX/SPEED_ANA
SPEED/WAKE
100k
R51
GND
VREG
DVDD
6.3V
10uF C37
GND
0.1µF
C38
6.3V
GVDD
GND
470nF
C3
100V
CONFIG_2
26 AVDD
36 DVDD
8GVDD
5PVDD
35 FAULT
34
9
BSTA
13
BSTB
17
BSTC
CPH 7
CPL 6
33
31
24
32
FG
28
3GCTRL
VREG
SPEED/WAKE
DACOUT/SOx/SPEED_ANA
EXT_CLK
BRAKE
DRVOFF
DIR
11
GHA
15
GHB
19
GHC
GLA 12
GLB 16
20
GLC
LSS 21
30 SCL
29 SDA
10
SHA
14
SHB
SHC 18
23
SN
SP 22
27
37
Thermal_pad
2
25
AGND
1
DGND
4
MCF8329A0REER
GND
DVDD
U2
GVDD
PVDD
AVDD
VREG
SPEED/WAKE
DACOUT/SOX/SPEED_ANA
BRAKE
EXT_CLK
DRVOFF
DIR
FGOUT
nFAULT
SCL
SDA
GCTRL
CPH
BSTA
CPL
SP
SN
GLA
GHA
SHA
GLB
GHB
SHB
BSTB
GHC
GLC
SHC
BSTC
LSS
GND
Figure 4-2. Driver
PHASE B PHASE C PHASE A
100V
0.01uF
C21
2nF
C27
50V
10
R28
10
R34
OUTA OUTB OUTC
TP15
GHA_FET
GLA_FET
GHA
SHA
GLA
GHB
SHB
GLB
GHC
SHC
GLC
SP
TP18
100V
0.01uF
C22
2nF
C28
50V
10
R29
10
R35
TP16
GHB_FET
GLB_FET
TP19
100V
0.01uF
C23
2nF
50V
C29
10
R30
10
R36
TP17
GHC_FET
GLC_FET
TP20
PVDD
D5
1N4448WX-TP
10
R31
10
R37 D8
1N4448WX-TP
10
R32 D6
1N4448WX-TP
10
R38 D9
1N4448WX-TP
10
R33 D7
1N4448WX-TP
10
R39 D10
1N4448WX-TP
NT1
Net-Tie
NT2
Net-Tie
NT3
Net-Tie
LSS
LSS
GHB
SHB
GLB
OUTB
GHA
SHA
GLA
OUTA
GHC
SHC
GLC
OUTC
SP
R40
1.50
100V
C26
3900pF
R41
1.50
100V
C24
3900pF
R42
1.50
100V
C25
3900pF
R26
1.50
100V
C13
3900pF
R25
1.50
100V
C12
3900pF
R27
1.50
100V
C14
3900pF
2nF
C17
50V
2nF
C15
50V
2nF
C19
50V
Populate diodes to control sink and source current independently
RC Snubber, HS Drain to LS Source cap, and GS Cap or Res
are all recommended, but optional, protection circuits
POWER STAGE AND FETS
330pF
100V
C32
330pF
C30
100V
Route as differential pair
Kelvin connection to shunt
50V
C31
0.01uF
GND
GND
0
R43
0
R45
GND
R44
0.001
GND
GND
GND
SN
External C_GS capacitors can be replaced with
k ohm pull down resistors if desired
1
3 4
Q4
CSD18536KTTT
1
3 4
Q1
CSD18536KTTT
1
3 4
Q5
CSD18536KTTT
1
3 4
Q2
CSD18536KTTT
1
3 4
Q3
CSD18536KTTT
1
3 4
Q6
CSD18536KTTT
SN
10k
R22
10k
R60
10k
R77
10k
R75
10k
R78
100V
4.7uF
C18
100V
4.7uF
C20
100V
4.7uF
C44
10k
R76
Figure 4-3. MOSFETs and Power Stage
Hardware Design Files www.ti.com
14 MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

CONNECTORS, SELECTORS, & ANALOG CONTROL INTERFACE
GND GND
TP22 TP23
GND GND
TP24
MAIN SUPPLY INPUT
PVDD
4.5-V to 60-V Operation
GND
OUTC
OUTB
OUTA
GND GND
TP30
OUTC
OUTB
OUTA
GND
TP25
GND
VREG Select
80V
10uF
C33
1
2
J10
PVDD_IN
1
2
3
J11
MOTOR_OUT
100V
C34
390uF
100V
C35
390uF
Motor Phase Connector
35A rated
TP27
65V ABS MAX
35A Rated connector
TP28 TP29
GND GND
TP21
AVDD AVDDAVDD
R47
GND
AVDD
2
1
3
S1
2
1
3
S3
2
1
3
S2
DIR_SWDRVOFF_SW
BRAKE_SW DIR_SW
DRVOFF_SW
BRAKE_SW
R19
10.0k
R24
10.0k
R21
10.0k
R23
10.0k
GND
R20
10.0k
GND
R48
10.0k
GND
Add arrows on silk screens
SPEED_IN
1 2
For Analog speed control or internal PWM Speed Control
3 4
5 6
J13
POT
MSP_TB0.1
BRAKE_SW DRVOFF_SW DIR_SW
POT
MSP_TB0.1
EXT_SPEED
TP33
2
GND
TP1TP8
GND
GNDGND
1 2
3 4
5 6
J12
VREG_SEL
VREG
VREG
AVDD
2
1
3
S4
B12AP
10.0k
R52
10.0k
R53
AVDD
GND
WAKE
1
2
3
4
5
6
SW1
G22AP
DACOUT_SPEED_ANA
POT
MSP_A3_P1.3
SPEED_WAKE
WAKE
SPEED_IN
MSP_A3_P1.3
R54
47.0 0
R49
GND
4
7,8
1,2,3
Q7
5,6,
VREG- External MOSFET Voltage Regulator
0
R57
0
R56
GCTRL
PVDD
0
R55
GND
100pF
C36
10V
VREG_EXT_FET
EXT_VREG
VREG_EXT_FET
50V
C39
2000pF
Figure 4-4. Power and Connectors
www.ti.com Hardware Design Files
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 15
Copyright © 2023 Texas Instruments Incorporated

4.2 PCB Layouts
Figure 4-5. EVM Board Dimensions
Hardware Design Files www.ti.com
16 MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 4-6. EVM Top Overlay
www.ti.com Hardware Design Files
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 17
Copyright © 2023 Texas Instruments Incorporated

Figure 4-7. EVM Top Layer
Hardware Design Files www.ti.com
18 MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 4-8. EVM Signal Layer 1
www.ti.com Hardware Design Files
SLLU373 – NOVEMBER 2023
Submit Document Feedback
MCF8329 Evaluation Module 19
Copyright © 2023 Texas Instruments Incorporated

Figure 4-9. EVM Signal Layer 2
Hardware Design Files www.ti.com
20 MCF8329 Evaluation Module SLLU373 – NOVEMBER 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated
