TPS658643 System Evaluation Board
This user’s guide describes the characteristics, operation, and use of the TPS658643EVM-752 evaluation
module (EVM). The TPS658643EVM-752 is a fully assembled and tested platform for evaluating the
performance of the TPS658643 single-chip, power management device. This document includes
schematic diagrams, a printed-circuit board layout, bill of materials, and test data.
Contents
1 Introduction .................................................................................................................. 3
1.1 Features ............................................................................................................. 3
1.2 Applications ......................................................................................................... 3
1.3 Requirements ....................................................................................................... 3
2 Electrical Performance Specifications .................................................................................... 3
3 Schematic .................................................................................................................... 4
4 Connector and Test Point Descriptions .................................................................................. 8
4.1 Headers and Switches ............................................................................................ 8
4.2 Jumpers ............................................................................................................. 9
5 Setup ........................................................................................................................ 10
6 TPS658643EVM Test Data .............................................................................................. 11
6.1 Operation Waveforms ............................................................................................ 11
7 EVM Assembly Drawings and Layout .................................................................................. 16
8 Bill of Materials ............................................................................................................. 20
List of Figures
1 HPA752A Schematic, Sheet 1 ............................................................................................ 4
2 HPA752A Schematic, Sheet 2 ............................................................................................ 5
3 HPA752A Schematic, Sheet 3 ............................................................................................ 6
4 HPA752A Schematic, Sheet 4 ............................................................................................ 7
5 SM0, Ch. 1 - VIN 1 V/div; Ch. 2 - SW 1 V/div; Ch. 3 - Vout 10 mV/div ............................................ 11
6 SM1, Ch. 1 - VIN 1 V/div; Ch. 2 - SW 1 V/div; Ch. 3 - Vout 10 mV/div ............................................ 12
7 SM2, Ch. 1 - VIN 1 V/div; Ch. 2 - SW 1 V/div; Ch. 3 - Vout 10 mV/div ............................................ 12
8 SM0, SM1, SM2, and LDO1 Start-Up .................................................................................. 13
9 LDO1, LDO2, LDO3, and LDO4 Start-Up.............................................................................. 13
10 LDO4, LDO5, and LDO9 Start-Up....................................................................................... 14
11 32-kHz Clock............................................................................................................... 15
12 Top Assembly – Silkscreen .............................................................................................. 16
13 Top Layer................................................................................................................... 16
14 Layer 2...................................................................................................................... 17
15 Layer 3...................................................................................................................... 17
16 Layer 4...................................................................................................................... 18
17 Layer 5...................................................................................................................... 18
18 Layer 6...................................................................................................................... 19
19 Bottom Layer............................................................................................................... 19
List of Tables
1
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com
1 Headers and Switches ..................................................................................................... 8
2 Jumpers ...................................................................................................................... 9
3 Bill of Materials............................................................................................................. 20
2TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com Introduction
1 Introduction
The TPS658643 is a single-chip, power management integrated circuit (IC) with multiple regulated power
supplies, system management, and display functions in a small package. The I2C interface enables
control of a wide range of subsystem parameters. Internal registers have a complete set of status
information, enabling easy diagnostics and host-controlled handling of fault conditions.
1.1 Features
• Three programmable step-down converters
– Eleven programmable general-purpose LDOs
• Three PWM outputs with programmable frequency and duty cycle
• Dual RGB LED drivers
• Eleven-channel ADC with three operating modes
• Power-Good monitoring on all supply outputs
• Interrupt controller with maskable interrupts
1.2 Applications
• Tablet Portable Computers
• Netbooks
• Smart phones
• Portable navigation devices
• Portable media players
1.3 Requirements
In order to operate this EVM properly, the hardware must be connected and properly configured. All
components and connectors are installed on the EVM as shipped, except the dc power supplies.
2 Electrical Performance Specifications
Input voltage, VIN, 3 V to 5.5 V
Output current, step-down converters, 1.5 A (SMO, SM2) and 2 A (SM1)
Output voltage LDOs, seven with output voltages of 1.25 V to 3.3 V, two with output voltages of 0.725 V to
1.5 V, one always on with output voltage of 1.25 V to 3.3 V, one with output voltage of 1.7 V to 2.475 V.
3
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

Schematic www.ti.com
3 Schematic
Figure 1. HPA752A Schematic, Sheet 1
4TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com Schematic
Figure 2. HPA752A Schematic, Sheet 2
5
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

Schematic www.ti.com
Figure 3. HPA752A Schematic, Sheet 3
6TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com Schematic
Figure 4. HPA752A Schematic, Sheet 4
7
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

Connector and Test Point Descriptions www.ti.com
4 Connector and Test Point Descriptions
4.1 Headers and Switches
The following table contains header and switch descriptions.
Table 1. Headers and Switches
Header/Switch Title Description
J1 CHG_DET Charger Detection Input, connected to CHG_DET (pin D11)
and NC (pins C12,13,D11-13)
J2 PWRGND Power ground, connected to ground plane
J3 TJ1 Test jumper, connected to VIN pins E13 and F11- 13
J4 PWRGND Power ground, connected to ground plane
J5 VIN Power supply input; connect BAT or ac adapter here to J5;
connected to pins A11 - A13, B11 - B13, and C11
J6 PWRGND Power ground, connected to ground plane
J7 TJ2 Test jumper, connected to VIN pins G10-13
J8 PWRGND Power ground, connected to ground plane
J9 ADC_IN Pins COMP (pin N1, input comparator for autoboot feature) and
ALNG1 - ALNG3 (pins L3, M1, M2) - inputs to analog-to-digital
converter. 20-kΩpulldown to AGND
J10 GPIO Connected to pins GPIO1 - GPIO4 (M3, M4, N3, N4) with 1-MΩ
pulldown to AGND
J11 USB-I2C ADAPTER Connection for USB-TO-GPIO TI tool which connects HPA752
board to PC for GUI. Connected to pins GPIO1 - GPIO4 with 1-
MΩpulldown to AGND, SAA_3V, SAA_GND, enable for I2C
port expander U2, SCLK ,and SDAT
J12 ADAPTER 3V Header to sense/supply voltage to I2C bus
J13 SUPERCAP/COINCELL Header to connect external real-time clock (RTC) supply
J14 32KHZOUT Header to probe pin OUT32K (C7, pin 1 of J14 is OUT32k and
pin 2 of J14 is analog ground)
J15 AGND Header with four connections to analog ground to facilitate
oscilloscope ground probe connection
J16 PWM Header to pin K9; this pin is a no-connect inside the IC (NC6)
J17 DIG_PWM Header to PWM, digital push-pull output; pin DIG_PWM (N11)
on the IC
J18 DIG_PWM2 Header to PWM, digital push-pull output; pin DIG_PWM2 (F4)
on the IC
J19 SM2 Output of dc/dc converter SM2
J20 PGND2 Power ground 2 for dc/dc converter SM2
J21 SM1 Output of dc/dc converter SM1
J22 PGND1 Power ground 1 for dc/dc converter SM1
J23 SM0 Output of dc/dc converter SM0
J24 PGND0 Power ground 1 for dc/dc converter SM0
J25 DGND2DT_EXTPWR For IT internal use only
J26 SPARE_OUT No internal connection
J27 NINT Header for nINT pin; interruption pin nINT is LO when interrupt
is requested by TPS65864x. Open-drain output
J28 NNORTC Header for nNORTC pin (D4); output status pin of RTC_OUT
LDO
J29 TNOPWR Header to monitor NOPOWER pulse width set pin TNOPWR
(A3)
J30 NHOT_RST Header for nHOT_RST pin (A2); reboot cycle request;
hardware reboot cycle control, pulled up to JP26 (SM2 or 2V2)
through 100 kΩ
J31 NNOPWR Header for pin nNOPOWER (M11)
J32 RESUME Header for pin RESUME (B2), connected to switch S3, and
pulled down to DGND through 1 MΩ
J33 SCLK/SDAT Header for pins SCLK (H4) pin 1 of header and SDAT (J2) pin
2 of header, for monitoring I2C bus
8TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com Connector and Test Point Descriptions
Table 1. Headers and Switches (continued)
Header/Switch Title Description
J34 SEQCTRL Connected to SEQ_CTL pin (B3), pulled down to DGND
through 1MΩ- Discrete input control
J35 LDO4PG Header for LDO4 Power Good output, pulled down to DGND
through 1MΩ
J36 EVM_3V Header to connect external supply for LED bias and I2C port
expander U2
J37 SYNCEN Header for SYNC enable pulled down to DGND through 1MΩ-
Discrete input control
J38 SM1PG Header for dc/dc converter SM1 Power Good output
J39 PWRGND Header for ground connection of external supply for LED bias
and I2C port expander U2
J40 SM1EN Header for enabling dc/dc converter SM1 pulled down to
DGND through 1MΩ- Discrete input control
J41 SM0PG Header for dc/dc converter SM0 Power Good output, pulled
down to DGND through 1M-Ohm
J42 SM0EN Header for enabling dc/dc converter SM0 pulled down to
DGND through 1 MΩ- Discrete input control
J43 AGND Header with four connections to analog ground
J44 DGND Header with four connections to digital ground
S1 NOPWRCTL Assertion of NOPWRCTL assets nNOPOWER output of PMU,
typically used as processor reset without rebooting PMU
S2 NHOT_RST Used for rebooting PMU
S3 RESUME Hold to wake up PMU or send PMU to sleep state
4.2 Jumpers
The following table shows the installed jumpers.
Table 2. Jumpers
Jumper Title Shunt Location Description
JP1 EXT_THERM Installed Jumper to connect thermistor (R2) to pin TS
(J13)
JP2 INT PULLUP Between pin 1 and pin 2 Jumper to select pullup voltage for INT pin
(L10). Pin 1 and pin 2 shorted INT pulled up
to 2V2. If pin 2 and 3 are shorted /INT is
pulled up to LDO8
JP3 I2C_PU Not Installed Jumper to select pullup voltage for SCLK
(H4) and SDAT (J2). Position 1 and position
2 shorted for 2V2 pullup; position 2 and
position 3 shorted for pullup to RTC_OUT
(H1).
JP4 32KOUT-PWR Installed Jumper to connect V32K (D7) to RTC_OUT
(H10)
JP5 32K-CLOAD Not Installed Jumper to connect 50-pF capacitor to
OUT32K (C7)
JP6 RESUME Not Installed Jumper to connect RESUME (B2) to pin P2
of the I2C port expander (U2)
JP7 SEQCTRL Between pin 1 and pin 2 Jumper to connect SEQCTRL (B3) to either
2V2 or pin P3 of the I2C port expander U2
JP8 SYNCEN Between pin 1 and pin 2 Jumper to connect SYNCEN (E10) to either
2V2 or pin P4 of the I2C port expander U2
JP9 SM1EN Between pin 1 and pin 2 Jumper to connect SM1EN (E11) to either
2V2 or pin P5 of the I2C port expander U2
JP10 SM0EN Not Installed Jumper to connect SM0EN (F10) to either
2V2 or pin P5 of the I2C port expander U2
JP11 VIN_LDO01 Between pin 2 and pin 3 Jumper to select VIN or SM2 as input to
LDO0 and LDO1
JP12 VIN_LDO23 Between pin 2 and pin 3 Jumper to select VIN or SM2 as input to
LDO2 and LDO3
9
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

Setup www.ti.com
Table 2. Jumpers (continued)
Jumper Title Shunt Location Description
JP13 VIN_LDO4 Between pin 2 and pin 3 Jumper to select VIN or SM2 as input to
LDO4
JP14 VIN_LDO678 Between pin 2 and pin 3 Jumper to select VIN or SM2 as input to
LDO6 - LDO8
JP15 VIN_LDO9 Between pin 2 and pin 3 Jumper to select VIN or SM2 as input to
LDO9
JP16 VIN_SM2 Installed Jumper to connect VIN to VIN_SM2
JP17 SM2_IL Installed Jumper to measure current through inductor
L1
JP18 LED_PWM_DRV Between pin 2 and pin 3 Jumper to select SM2 or VIN as supply for
LEDs, D14 - D17
JP19 VIN_SM1 Installed Jumper to connects VIN to VIN_SM1
JP20 SM1_IL Installed Jumper to measure current through inductor
L2
JP21 RGB_DRV Between pin 2 and pin 3 Jumper to select SM2 or VIN as supply for
RGB LED, D18
JP22 VIN_SM0 Installed Jumper to connects VIN to VIN_SM0
JP23 SM0_IL Installed Jumper to measure current through inductor
L3
JP24 RGB2_DRV Between pin 2 and pin 3 Jumper to select SM2 or VIN as supply for
RGB LED, D19
JP25 DGND2DT Between pin 2 and pin 3 For TI internal use only
JP26 JP26 Between pin 2 and pin 3 Jumper to select SM2 or 2V2 as pullup for
HOT_RST
JP27 STATUS_LED_PWR Between pin 1 and pin 2 Jumper to select VIN or EVM_3V J36 as bias
for status LEDs, D1 - D13
5 Setup
The following steps are intended to help users power up and evaluate the EVM.
1. To use the TPS65864xEVM with a personal computer, the TPS865864xEVM software is required
along with the HPA172 USB-to-I2C Interface Board (USB-TO-GPIO) and a USB cable. Two power
supplies capable of supplying 6 V at 2 A are required.
2. To test the HPA752, the computer must have the TPS65864xEVM software program installed. Install
the program from the TPS65864xEVM software zip file. This software zip file is supplied by Texas
Instruments. If the program does not automatically install properly, follow the instructions in the
Readme file.
3. Connect the USB cable between the computer and the HPA172. Connect the Molex cable between the
HPA172 and the HPA752 EVM (J11).
4. Verify the shorting jumpers are installed as noted in the shorting jumper table. The EVM ships with the
default jumper settings.
5. Supply 1: Set the input supply voltage to 3.3 V before connecting to the EVM, and turn the supply off.
While in the off state, connect the power supply positive lead to J36 (EVM 3V). Connect the power
supply return lead to J39 (GND).
6. Input Supply 2: Set the input supply voltage to 5 V before connecting to the EVM, and turn the supply
off. While in the off state, connect the power supply positive lead to J5 (VIN). Connect the power
supply return lead to J6 (GND).
7. First, turn on Input Supply 1 (3.3 V). Next, turn on Input Supply 2 (5 V).
8. To wake the PMU, hold the pushbutton switch, S1, RESUME, for one seconds and release. While the
PMU is awake, holding switch S1 for one second puts the PMU back into the sleep state. Different
combinations of the LDOs and switching converters turn on by default as per table 3-3: TPS65864x
Integrated Power Supply Power-Up Defaults in the corresponding device data sheet. Note, final silicon
can be marked as TPS658643 or P658643.
9. Using the GUI, select the LDOs tab on the left side. Press Read to load the contents of the I2C
10 TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com TPS658643EVM Test Data
registers into the GUI. Next, check all the unchecked boxes. This enables all the LDOs.
10. Using the GUI, select the SMs tab on the left side. Press Read to load the contents of the I2C
registers into the GUI. Next, check all the unchecked boxes. This enables all the SM converters.
6 TPS658643EVM Test Data
This section presents typical performance data for the TPS658643EVM. Actual performance data can be
affected by measurement techniques and environmental variables; therefore, these results are presented
for reference and may differ from actual results obtained by some users.
6.1 Operation Waveforms
Figure 5. SM0, Ch. 1 - VIN 1 V/div; Ch. 2 - SW 1 V/div; Ch. 3 - Vout 10 mV/div
11
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

TPS658643EVM Test Data www.ti.com
Figure 6. SM1, Ch. 1 - VIN 1 V/div; Ch. 2 - SW 1 V/div; Ch. 3 - Vout 10 mV/div
Figure 7. SM2, Ch. 1 - VIN 1 V/div; Ch. 2 - SW 1 V/div; Ch. 3 - Vout 10 mV/div
12 TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com TPS658643EVM Test Data
Figure 8. SM0, SM1, SM2, and LDO1 Start-Up
Figure 9. LDO1, LDO2, LDO3, and LDO4 Start-Up
13
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

TPS658643EVM Test Data www.ti.com
Figure 10. LDO4, LDO5, and LDO9 Start-Up
14 TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com TPS658643EVM Test Data
Figure 11. 32-kHz Clock
15
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

T
I
EXAS
NSTRUMENTS
EVM Assembly Drawings and Layout www.ti.com
7 EVM Assembly Drawings and Layout
Figure 12. Top Assembly – Silkscreen
Figure 13. Top Layer
16 TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com EVM Assembly Drawings and Layout
Figure 14. Layer 2
Figure 15. Layer 3
17
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

EVM Assembly Drawings and Layout www.ti.com
Figure 16. Layer 4
Figure 17. Layer 5
18 TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated

www.ti.com EVM Assembly Drawings and Layout
Figure 18. Layer 6
Figure 19. Bottom Layer
19
SLVU582A–December 2011–Revised May 2012 TPS658643 System Evaluation Board
Submit Documentation Feedback Copyright © 2011–2012, Texas Instruments Incorporated

Bill of Materials www.ti.com
8 Bill of Materials
Table 3. Bill of Materials
Count RefDes Value Description Size Part Number MFR
21 C1, C2, C4, 10uF Capacitor, Ceramic, 10V, X5R, 10% 0805 GRM21BR61A106KE19L muRata
C5, C8, C9,
C10, C11, C12,
C34, C35, C36,
C37, C39, C40,
C41, C42, C43,
C44, C45, C46
1 C13 2200pF Capacitor, Ceramic, 50V, C0G, 5% 0603 C1608C0G1H222J TDK
1 C14 6.8uF Capacitor, Ceramic, 10V, X5R, 10% 0805 C0805C685K8PACTU Kemet
3 C15, C16, C38 Open Capacitor, Ceramic 0603 Std Std
1 C18 50pF Capacitor, Ceramic, 50V, C0G, 5% 0603 06035A500JAT2A AVX
1 C3 4.7uF Capacitor, Ceramic, 10V, X5R, 10% 0805 GRM219R61A475KE19D muRata
17 C6, C17, C19, 2.2uF Capacitor, Ceramic, 10V, X5R, 10% 0603 GRM188R61A225KE34D muRata
C20, C21, C22,
C23, C24, C25,
C26, C27, C28,
C29, C30, C31,
C32, C33
1 C7 0.1uF Capacitor, Ceramic, 50V, X7R, 10% 0603 C1608X7R1H104K TDK
13 D1, D2, D3, LTST-C190GKT Diode, LED, Green, 2.1V, 10mA, 6mcd 0603 LTST-C190GKT Lite On
D4, D5, D6,
D7, D8, D9,
D10, D11, D12,
D13
4 D14, D15, D16, LTW-C193TS5 Diode, LED, White, 2.95V, 5mA 0603 LTW-C193TS5 Lite On
D17
2 D18, D19 LATBT66B Diode, LED, 20mA, Common Anode 0.118 x 0.134 LATBT66B-ST-1+TU7- Osram
35+QS-36-ZB-Z
ALTERNATE: LATBT66B-ST-
1+TU-35+QR-35-20-R18-ZB
38 J1, J2, J3, J4, PEC02SAAN Header, 2 pin, 100mil spacing, 0.100 x 2 PEC02SAAN Sullins
J5, J6, J7, J8,
J12, J13, J14,
J16, J17, J18,
J19, J20, J21,
J22, J23, J24,
J25, J26, J27,
J28, J29, J30,
J31, J32, J33,
J34, J35, J36,
J37, J38, J39,
J40, J41, J42
5 J9, J10, J15, PEC04SAAN Header, 4 pin, 100mil spacing, 0.100 x 4 PEC04SAAN Sullins
J43, J44
1 J11 N2510-6002-RB Connector, Male Straight 2x5 pin, 100mil 0.338 x 0.788 N2510-6002-RB 3M
spacing, 4 Wall
10 JP1, JP4, JP5, PEC02SAAN Header, 2 pin, 100mil spacing, 0.100 x 2 PEC02SAAN Sullins
JP6, JP16,
JP17, JP19,
JP20, JP22,
JP23
17 JP2, JP3, JP7, PEC03SAAN Header, 3 pin, 100mil spacing, 0.100 x 3 PEC03SAAN Sullins
JP8, JP9,
JP10, JP11,
JP12, JP13,
JP14, JP15,
JP18, JP21,
JP24, JP25,
JP26, JP27
1 L1 1.5uH Inductor, SMT, 3.1A, 78milliohm 0.169 x 0.169 inch LPS4414-152ML Coilcraft
2 L2, L3 1.5uH Inductor, SMT, 2.7A, 70milliohm 0.153 x 0.153 inch LPS4012-152ML Coilcraft
6 R1, R19, R20, 10k Resistor, Chip, 1/16W, 1% 0603 Std Std
R21, R23, R24
2 R13, R17 0 Resistor, Chip, 1/16W, 1% 0603 Std Std
20 TPS658643 System Evaluation Board SLVU582A–December 2011–Revised May 2012
Submit Documentation Feedback
Copyright © 2011–2012, Texas Instruments Incorporated
