Texas Instruments TPS65916EVM User manual

1
SLIU021–September 2016
Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated
TPS65916 EVM User’s Guide
Windows is a registered trademark of Microsoft Corporation.
All other trademarks are the property of their respective owners.
User's Guide
SLIU021–September 2016
TPS65916 EVM User’s Guide
This user’s guide describes the characteristics, operation, and use of the TPS65916EVM. An EVM
description, graphical user interface (GUI) description, interface requirements, and complete schematic
are included.
Contents
1 Introduction ................................................................................................................... 1
2 Schematics, Bill of Materials, and Layout ................................................................................ 4
3 Setup and Operation....................................................................................................... 16
List of Figures
1 EVM ........................................................................................................................... 2
2 Powered EVM................................................................................................................ 4
3 TPS65916 EVM Schematic (Page 1) ..................................................................................... 5
4 TPS65916 EVM Schematic (Page 2) ..................................................................................... 6
5 TPS65916 EVM Schematic (Page 3) ..................................................................................... 7
6 TPS65916 EVM Schematic (Page 4) ..................................................................................... 8
7 Composite - Top View..................................................................................................... 12
8 Top Layer ................................................................................................................... 13
9 Layer 1 GND................................................................................................................ 13
10 Layer 2 SIGNAL............................................................................................................ 14
11 Layer 3 POWER............................................................................................................ 14
12 Bottom Layer................................................................................................................ 15
13 Composite - Bottom View ................................................................................................ 15
14 Default GPIO Configuration............................................................................................... 16
15 GPIO Configuration After GPIO_1 Set to Logic High ................................................................. 17
16 Low Level Configuration Page............................................................................................ 18
17 Sample Script............................................................................................................... 19
List of Tables
1 Default Jumper Settings for TPS65916EVM............................................................................. 3
2 TPS65916EVM BOM........................................................................................................ 8
1 Introduction
The TPS65916 device is a power-management integrated circuit (PMIC) for industrial and consumer
applications. The device provides five configurable step-down converters, with up to 7 A of output current
for memory, processor core, input/output (I/O), or preregulation of LDOs. The TPS65916 device contains 5
LDO regulators for external use. For more details, see the device datasheet, TPS65916 Power
Management Unit (PMU) for Processor.

SMPS4
SMPS2
SMPS1
LDO outputs
GPIO_0 through GPIO_6
MicroUSB Port
SMPS3
SMPS5
Status LEDs
GND
VCC (3.135V to 5.25V)
Introduction www.ti.com
2SLIU021–September 2016
Submit Documentation Feedback
Copyright © 2016, Texas Instruments Incorporated
TPS65916 EVM User’s Guide
1.1 EVM Overview
The features of this EVM are as follows:
• Allows monitoring of all LDO and SMPS output voltages.
• Allows loading of all SMPS outputs.
• Allows access to the GPIOs and other logic signals to test functionality.
• Optimized layout for stable operation of all SMPS.
• Onboard MSP430 to enable communication with the PMIC.
• Graphical User Interface (GUI) on Windows®to allow access to the registers of the PMIC through
USB-I2C.
1.2 EVM with Components Identified
Figure 1. EVM
LEDs —Display status of POWERGOOD, RESET_IN, POWER_HOLD, LDOVRTC_OUT, RESET_OUT,
INT, and power supply of MSP430
USB —Connection to PC to enable communication through the GUI
MSP430 —Microcontroller used to convert USB data to I2C format
SMPSxx —Monitor point for SMPS outputs
LDO Outputs —Monitor point for LDO outputs
VIO SelectorX —Jumper used to select VIO voltage. P12 requires a jumper installed, and by default pins
11 and 12 are shorted to select external 1.8 V as VIO. Only one jumper should be installed
between P12 and P15.
GPIOs —Jumper that provides access to the GPIOs
VSYS —VSYS power supply input. P16 is the same connector as SMPS12_OUT and must not be
confused to prevent applying VSYS to SMPS-output.

www.ti.com Introduction
3
SLIU021–September 2016
Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated
TPS65916 EVM User’s Guide
1.3 Default Jumper Settings
Table 1 describes the default jumper settings for the TPS65916 EVM. No changes should be made to
these settings without consulting the TPS65916 EVM schematic.
Table 1. Default Jumper Settings for TPS65916EVM
JUMPER PURPOSE EVM CONFIGURATION
P12 VIO Selection Pins 11 and 12 are shorted to select external 1.8V as VIO
P15 VIO Selection No pins on this header are shorted since there is a shunt on
P12.
J2 POWERGOOD Pull-up resistor J2 is closed to enable the pull-up resistor for the POWERGOOD
signal
J3 Level Shifter Voltage Selection J3 is closed to select VIO as the level shifted voltage for U5,
U6, and U7
J7 I2C or SPI CLK J7 is closed to select the I2C_SCL signal
J10 I2C or SPI Data J10 is closed to select the I2C_SDA signal
J22 GPIO_1 GUI Control J22 is closed to allow GPIO_1 (RESET_IN) to be controlled
through the GUI
J26 GPIO_5 Selection GPIO_5 is shorted HIGH to allow the device to power-up
J30 BOOT Selection BOOT is shorted LOW to exercise the default power-up
sequence
J31 PWRON Selection PWRON is shorted HIGH
J32 LDO5 Input Selection J32 is closed to supply LDO5 from the same supply as the
other LDOs
J35 I2C_SCL Connection to PMIC J35 is closed to use the onboard SCL signal from the MSP430
J36 I2C_SDA Connection to PMIC J36 is closed to use the onboard SDA signal from the MSP430
J43 – J54 Level Shifter Direction Selection and
Enable Jumpers J43 through J54 should be left as they are configured to enable proper level shifter functionality
JP1 LDO Input Selection JP1 is closed to supply the LDOs from VSYS instead of an
external supply (VDD)
JP2 VCC_SENSE Selection VCC_SENSE is shorted to VSYS instead of an external supply
(VDD)
JP3 D2 Indicator Selection Pins 1 and 2 are shorted to allow the status of POWERGOOD
signal to be indicated by D2
JP6 D5 Indicator Selection Pins 1 and 2 are shorted to allow the status of the
POWER_HOLD signal to be indicated by D5
JP7 D7 Indicator Selection Pins 1 and 2 are shorted to allow the status of the RESET_IN
signal to be indicated by D7

Introduction www.ti.com
4SLIU021–September 2016
Submit Documentation Feedback
Copyright © 2016, Texas Instruments Incorporated
TPS65916 EVM User’s Guide
1.4 Power-Supply Requirements and Connections
To set up the EVM, ensure that VSYS (3.3 V to 5 V) is connected to the pin labeled VSYS of P16, and
that GND is connected to the pin labeled GND of P16.
1.4.1 VIO Selection
As mentioned in Table 1, there are two 12-pin headers (P12 and P15) for selecting the voltage to use for
the VIO supply voltage of the PMIC.
CAUTION
It is important to make sure that there is a total of one shunt populated between
P12 and P15. If there is a shunt on P12, there should not be one on P15 and
vice versa. Also, there should never be more than one shunt on either P12 or
P15. Violating this requirement will short two PMIC outputs together, which
could potentially damage the PMIC device.
Power for the MSP430 and the two fixed voltage LDOs (3.3-V and 1.8-V outputs) is supplied through the
USB connection, as shown in Figure 2.
Figure 2. Powered EVM
2 Schematics, Bill of Materials, and Layout
This section contains the schematics, bill of materials (BOM) and layout for the EVM.
