Texas Instruments TPS65300EVM User manual

User's Guide
SLVU685–February 2012
TPS65300EVM
Contents
1 Introduction .................................................................................................................. 2
2 Setup ......................................................................................................................... 2
2.1 Input/Output Connector Description ............................................................................. 2
2.2 Setup ................................................................................................................ 6
2.3 Operation ............................................................................................................ 6
3 Board Layout ................................................................................................................ 7
4 Schematic and Bill of Materials ........................................................................................... 9
4.1 Schematic ........................................................................................................... 9
4.2 Bill of Materials .................................................................................................... 10
List of Figures
1 EVM Board................................................................................................................... 2
2 IGN Jumper Settings ....................................................................................................... 3
3 EN Jumper Settings ........................................................................................................ 3
4 3.3V PWR Jumper Settings ............................................................................................... 4
5 1.2V PWR Jumper Settings ............................................................................................... 4
6 Bridge Jumper Settings .................................................................................................... 4
7 Top Assembly Layer........................................................................................................ 7
8 Top Layer Routing .......................................................................................................... 8
9 Bottom Layer Routing ...................................................................................................... 8
10 TPS653000EVM Schematic............................................................................................... 9
List of Tables
1 Device and Package Configurations ..................................................................................... 2
2 TPS65300EVM Bill of Materials ......................................................................................... 10
PowerPAD is a trademark of Texas Instruments.
1
SLVU685–February 2012 TPS65300EVM
Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated

Introduction www.ti.com
1 Introduction
The Texas Instruments TPS65300EVM evaluation module (EVM) helps designers evaluate the operation
and performance of the TPS65300 Switch Mode Power Supply – Multiple-output voltage regulator.
The EVM contains one DC / DC converter (see Table 1).
Table 1. Device and Package Configurations
Converter IC Package
U1 TPS65300QPWPRQ1 PWP-24
2 Setup
This section describes the jumpers and connectors on the EVM and how to properly connect, set up and
use the TPS65300EVM.
2.1 Input/Output Connector Description
Figure 1. EVM Board
2TPS65300EVM SLVU685–February 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated

IGN
Low, part disabled
at startup , (unless
supplied via
IGN-terminal )
IGN
High, part enabled
at startup , do not
install if connected
at IGN-terminal
EN
Low, part disabled
after ignition of
(IGN = low)
EN
High, part remains
enabled after
ignition off
(IGN = low)
www.ti.com Setup
Terminal blocks:
J1 – Input is the output terminal for the TPS65300 switch-mode converter. The terminal block provides a
power (VREG) and ground (GND) connection.
J2 – Output is the power input terminal for the device. The terminal block provides a power (VBAT) and
ground connection to allow the user to attach the EVM to a cable harness.
J3 – Sync is the input terminal to enable the TPS65300 at initial startup. The terminal block provides a
power (IGN) and ground (GND) connection. If this terminal is not used, install the IGN-Jumper to power-up
the device (see the respective description). If IGN is shut down again, the device will power down, unless
the EN-Jumper is installed.
J5 – Output is the output terminal for the TPS65300 linear regulator controller with 1.2V output. The
terminal block provides a power (1.2V) and ground (GND) connection. Please observe the Power-ratings
of the external bipolar-transistor: If powered from VREG, it allows approximately 120mA at room
temperature, approximately 50mA at 125°C ambient. Note, if the dropout is reduced by powering it from
the 3.3V-rail (installing BRIDGE jumper instead of 1.2V_PWR jumper), will allow higher currents on this
rail, but consider the extra power drawn from the 3.3V rail and its transistor
Jumpers:
IGN – required to power-up the device at startup: if IGN is low (IGN-terminal not supplied AND IGN-
jumper not installed) the part will not power-up (indifferent of EN-setting). Either supply IGN-terminal with a
High-level or install the IGN-jumper to power up the device:
Figure 2. IGN Jumper Settings
EN – Keeps the outputs of the devices active after ignition is turned off (IGN = low). However, a high level
on IGN is required for initial start-up. Before this, the EN-jumper has no effect. Note, as opposed to IGN,
the EN-pin is a logic-level-input, maximum input voltage should not exceed 5.25V.
Figure 3. EN Jumper Settings
3
SLVU685–February 2012 TPS65300EVM
Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated

3.3VPWR
unsupplied Supplied
by VREG
3.3VPWR
1.2VPWR
Disconnected
from VREG
Supplied by
VREG, remove
before installing
BRIDGE-jumper!
1.2VPWR
BRIDGE
Disconnected
from 3.3V rail
Supplied by 3.3V rail.
Remove 1.2V_PWR-
jumper before
installation
BRIDGE
Setup www.ti.com
3.3V_PWR – Supplies the Collector of the external bipolar transistor of the 3.3V rail. Installing connects it
to VREG (5.3V-output of the Buck-regulator). If uninstalled, the transistor in not powered (Note: at light
loads, the base-current may be sufficient to supply the output, but adding a load causes VOUT to drop).
Figure 4. 3.3V PWR Jumper Settings
1.2V_PWR - Supplies the Collector of the external bipolar transistor of the 1.2V rail. Installing connects it
to VREG (5.3V-output of the Buck-regulator). If uninstalled, the transistor in not powered (Note: at light
loads, the base-current may be sufficient to supply the output, but adding a load causes VOUT to drop). An
alternative to supply the 1.2V rail is to install the jumper on BRIDGE (see Figure 6), but make sure to
never have both jumpers (1.2V_PWR and BRIDGE) installed at the same time.
Figure 5. 1.2V PWR Jumper Settings
JP6 – Bridge - Supplies the Collector of the external bipolar transistor of the 1.2V rail. Installing connects
it to the 3.3V LDO-output. If connected, consider the extra current drawn from the 3.3V rail, which must be
supported by the power-dissipation of the 3.3V-transistor! Make sure to never have both jumpers
(1.2V_PWR and BRIDGE) installed at the same time.
Figure 6. Bridge Jumper Settings
4TPS65300EVM SLVU685–February 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated

www.ti.com Setup
Test Points:
• VBAT Power Input
• VIN_D, VIN Power Input after the reverse battery protection diode.
• IGN Ignition, monitors if IGN-input is high, powering up the device.
• IGN_EN Ignition enable (IGN after series resistor).
• BOOT_LDO Voltage at internal regulator, which supplies the power to charge the flying boot
capacitor.
• VREG Regulated output of switch-mode converter, supplying 5.3V.
• DELAY Input for reset delay.
• SS Input for soft start time.
• EN Enable pin, if high, the device remains active after IGN is transitioning to low.
• GND (x7) Ground
• PH Switch node, source of internal switching FET.
• nRST Reset output for Switcher, asserted high after VREG, 3.3V and 1.2V regulator
outputs are regulating and delay timer has expired.
• 3.3V 3.3V - Linear regulator output
• 3.3VDRIVE Base drive for external 3.3V-regulator bipolar transistor.
• 1.2V 1.2V - Linear regulator output.
• 1.2VDRIVE Base drive for external 1.2V-regulator bipolar transistor.
• VSENSE Inverting node of error amplifier for voltage mode control of VREG.
• IGN_ST Ignition input indicator. Asserted high while ignition input is high.
• 5V Output of the 5V linear regulator. Since no screw-terminal is provided for this
output, use the test-point to attach a load.
5
SLVU685–February 2012 TPS65300EVM
Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated

Setup www.ti.com
2.2 Setup
The input voltage range for the converter is 5.6 volts to 40 volts.
2.3 Operation
For proper operation of the TPS65300EVM, the jumpers should be properly configured. Set jumpers to
this configuration:
EN Open (device will power down if IGN is transitioning low.
3.3V_PWR Installed (supply 3.3V rail from VREG).
1.2V_PWR Installed (supply 1.2V rail from VREG, remove before installing BRIDGE-jumper!).
BRIDGE Open (install to supply 1.2V rail from 3.3V-rail, remove 1.2V_PWR jumper before
installing BRIDGE!).
IGN Installed (device powers up if VIN is applied).
In this configuration, the regulators will turn on when power is applied and will power down if Vin is falling.
To prohibit initial startup, remove IGN-jumper. While IGN is high, EN has no functionality. If IGN transitions
low after the device has powered up, a high level on EN (jumper installed) will keep the regulators active,
a low (EN open) will power down the regulators if IGN goes low.
The supply for the 1.2V rail is sourced from VREG in the above configuration. BRIDGE allows to power
the external transistor of this rail from the 3.3V output, make sure to remove the jumper on 1.2V_PWR
before installing BRIDGE-jumper. This reduces the drop-out-voltage on the external transistor and such
helps to reduce power dissipation on this transistor; however, consider the extra power drawn from the
3.3V rail, causing extra dissipation on the 3.3V-rail transistor.
The switching frequency is defined by the resistor on RT (R4), here 40.2kΩ, setting fSW to approximately
2.4MHz.
Regulator Configuration (out current s given for above configuration, i.e. 1.2V rail powered from VREG):
Regulator Output Voltage Maximum Output Current
Switcher 5.3 V 1.2 A
3.3V regulator 3.3 V 0.3A (at room temperature, less at high temperature)
1.2V regulator 1.2 V 0.1A (at room temperature, less at high temperature)
5V regulator 5 V 0.2A
6TPS65300EVM SLVU685–February 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated

www.ti.com Board Layout
3 Board Layout
Figure 7,Figure 8 and Figure 9 show the board layout for the TPS65300EVM PWB. The EVM offers
jumpers to enable the device in various ways and to select supply rails for 3.3V and 1.2V linear regulators.
Figure 10 shows the schematic.
The TPS65300 converter offers high efficiency, but does dissipate power. The PowerPAD™ package
offers an exposed thermal pad to enhance thermal performance. This must be soldered to the copper
landing on the PCB for optimal performance. The PCB provides a GND-plane on the bottom side to
dissipate heat from the device, transferred via the PowerPad™ and thermal vias underneath the device.
The external transistors have a smaller area on the top side connected to their collector to allow heat
dissipation.
Figure 7. Top Assembly Layer
7
SLVU685–February 2012 TPS65300EVM
Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated

Board Layout www.ti.com
Figure 8. Top Layer Routing
Figure 9. Bottom Layer Routing
8TPS65300EVM SLVU685–February 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated

10uH
2
1
L1
GND
GND
GND
0.1uF C2
GND
GND
EN
GND GND GND GND GND
GND GND GND GND GND
GND
GND
GND
VIN_D
10uF
2 1
+C1
GND
D2
D1
GND
GND
IGN_ST
E
3
4
C2
B
1
PBSS302NZ
Q1
E
3
4
C2
B
1
PBSS302NZ
Q2
GND
GND
VREG
IGN
GND GND
GND
5V
3.3V 1.2V
GND GND
GND
VIN
PH
IGN_EN
BOOT_LDO
VSENSE
1.2VDRIVE
3.3VDRIVE SS
nRST
30.1k
R1
IGN
EN
3.3V PWR
1.2V PWR
30.1k
R2
40.2k
R4
1uF
C7
6k
R3
27.4k
R6
30k
R8
240
R7 660 R5
1 2
J1
1 2
J2
1 2
J3
1 2
J4
1 2
J5
DELAY
1nF
C8
2.2uF
C11
470pF
C12 0.01uF
C5
0.033uF
C6
2.2uF
C13 2.2uF C10
0.1uF
C3
NC
7
VIN
4
PH
1
nRST 23
COMP 14
1.2VDRIVE 17
SS 20
RT/CLK
8
EN
9
5V
10
IGN_EN
5
VIN_D
2
BOOT
3
NC 13
PGND 24
1.2VSENSE 16
3.3VDRIVE 19
3.3VSENSE 18
BOOT_LDO
6
VSENSE 15
PAD
25
IGN_ST
11
GND
12
DELAY 21
VREG 22
U1 TPS65300
VBAT
GND
GND
2 1
+
10uF C4
DNP
2 1
+C9
GND
0.1uF
C14
GND
JP6
GND
0.1uF C15
GND
0R0 R41
www.ti.com Schematic and Bill of Materials
4 Schematic and Bill of Materials
4.1 Schematic
Figure 10. TPS653000EVM Schematic
9
SLVU685–February 2012 TPS65300EVM
Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated

Schematic and Bill of Materials www.ti.com
4.2 Bill of Materials
Table 2. TPS65300EVM Bill of Materials
COUNT REF DES DESCRIPTION SIZE MFR PART NUMBER
1 C1 Capacitor, ceramic, 10uF, 16V 1206 Panasonic EEV-FK1H221P
2 C2, C3 Capacitor, ceramic, 0.1uF, 50V, 10% 603 muRata GCM188R71H104KA57
1 C4 Capacitor, ceramic, 10uF, 63V Size D Panasonic ECE-V1JA100P
1 C5 Capacitor, ceramic, 0.01uF, 50V, 10% 603 muRata GRM188R71H103KA01D
1 C6 Capacitor, ceramic, 0.033uF, 25V, 10% 603 muRata GRM188R71E333KA01D
1 C7 Capacitor, ceramic, 1uF, 16V, 10% 603 muRata GRM188R61E105KA12D
1 C8 Capacitor, ceramic, 1000pF, 50V, 10% 603 muRata GRM188R71H102KA01D
1 C9 do not populate
3 C10, C11, C13 Capacitor, ceramic, 2.2uF, 50V, 10% 1210 muRata GCM31CR71H225KA55L
1 C12 Capacitor, ceramic, 470pF, 50V, 10% 603 muRata GRM188R71H471KA01D
2 D1, D2 Diode, Schottky, 3A, 100V PowerDI Diodes PDS360-13
5 J1, J2, J3, J4, J5 Terminal block, 2-pin, 6A, 3.5mm 0.25 x 0.27 OST ED1514
1 L1 Inductor, SMT, 10-uH 12.3mm x Coilcraft MSS1278T-103
12.3mm
26 1.2V, 3.3V, 1.2VDRIVE, Test point, 52-mil 0.052 Kobiconn 151-103-RC
3.3VDRIVE, 5V,
BOOT_LDO, DELAY, EN,
GND(7), IGN, IGN_EN,
IGN_ST, nRST, PH, SS,
VBAT, VIN, VIN_D,
VREG, VSENSE
5 1.2VPWR, 3.3VPWR, EN, Header, 2-pin, 100-mil spacing, (36-pin 0.100 x 2 Sullins PEC02SAAN
IGN, BRIDGE (J6) strip)
5 1.2VPWR, 3.3VPWR, EN, Connector jumper, shorting, 100-mil spacing 0.1 Sullins SPC02SYAN
IGN, BRIDGE (J6)
2 Q1, Q2 TRANS NPN 20V 5.8A SOT-223 NXP PBSS302NZ
3 R1, R2, R8 Resistor, chip, 30.1-kΩ, 1/10W, 1% 603 Panasonic ERJ-3EKF3012V
1 R3 Resistor, chip, 6.04-kΩ, 1/10W, 1% 603 Panasonic ERJ-3EKF6041V
1 R4 Resistor, chip, 40.2-kΩ, 1/10W, 1% 603 Panasonic ERJ-3EKF4022V
1 R5 Resistor, chip, 665-Ω, 1/10W, 1% 603 Panasonic ERJ-8ENF6650V
1 R6 Resistor, chip, 27.4-kΩ, 1/10W, 1% 603 Panasonic ERJ-3EKF2742V
1 R7 Resistor, chip, 240-Ω, 1/10W, 1% 603 Panasonic ERJ-8GEYJ241V
1 R41 Resistor, chip, 0R0Ω, 1/10W, 1% 603 Panasonic ERJ-3GEY0R00V
1 U1 IC, TPS65300-Q1PWPR TI TPS65300QPWP
- PCB, 3-inch x 3-inch x 0.062 Any TPS65300, REV G
10 TPS65300EVM SLVU685–February 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
