Premier Elite Speech Module
INSTALLATION INSTRUCTIONS
Introduction
The Premier Elite Speech Module provides four recordable 10 second audio messages, each
message is assigned to a Digi Channel, which in turn can be triggered from one of the many output
functions of the control panel. A COM2400 must be installed to enable the Premier Elite Speech
Module, it will not function with a COM300. Only the first four Digi Channels are used by the
Premier Elite Speech Module. The Premier Elite Speech Module is supported by the following
Texecom control panels:
• Premier Elite all models factory built V3 and later, all models fitted with a DTMF decoder.
If the Speech Module is fitted to a V3 panel that does not have the DTMF decoder chip fitted,
it may not be possible to acknowledge the received calls. This will result in repeated calls
until all programmed dial attempts have been used..
Hardware Identification
Premier Elite 24
The DTMF chip is located below the Barcode
label and is identified with a green dot.
Premier Elite 48/88/168 & 640
The DTMF chip is located just below the
digi pins and is identified with a green dot.
Premier Elite 12-W/24-W/48-W
The DTMF chip is located to the left of the
main processor and is identified with a
green dot.
PCB Layout and Connections
The figure below shows the PCB layout of the Premier Elite Speech Module.
Microphone
Record/Play Indicator
Control panel connector
Record Buttons
Figure 1. Premier Elite Speech Module PCB Layout
Figure 2. Premier Elite Speech Module Connected to Expansion Port on PCB
Premier Elite Speech Module Installation
To install the Premier Elite Speech Module proceed as follows:
Ensure that all power is removed from the control panel before connecting the Premier Elite
Speech Module.
Plug the Premier Elite Speech Module (see Figure 2) onto the 7 way Expansion Port of the control
panel.
Plug the COM2400 onto the onboard digi pins, and connect to a telephone line. When using an
RJ11 plug, this should be connected before the COM2400 is fitted in place.
Re-apply power to the system and proceed to the next section.
Premier Elite Speech Module Locations
Use the self-adhesive mounting posts to locate the Speech Module as shown.
Premier Elite Small Polymer Housing (e.g. 12-W Live) mount to the rear of the housing
Premier Elite Large Polymer Housing (e.g. 24 & 48-W) mount to the inner wall of the housing
Premier Elite Metal Housing (e.g. 48.88 & 168) mount inside the top of the housing.
Tamp
Strb 0V Bell+12V Op1 Aux
12V
Spk -
Bell Aux 12VNetwork
F4
F3
F1
F6
Engineer
Remote
Com2
Com1
Load Defaults
Tx Rx
+-Aux/Fault
Bell +12V
Enable
Network
2 Wire
Smoke
Enable
Expansion
Batt Charge
0.75A 0.3A
Kick Start
F2
Batt
DC
F8
F9
!
USE WITH
TEXECOM PSU
ONLY
Com 2
F1
F5
JP7
Aux 12v
1Amp
Network 2 1Amp
Com 1
Heartbeat
Load
Defaults Expansion
F3
Network 1 1Amp
Kick
Start
Tx1 Rx1 Tx2 Rx2
Box
Tamp
100mV = 1Amp
V
F6
F2
F8
F7
F9
!
USE WITH
TEXECOM PSU
ONLY
F4
Eng Keypad
Bell/Strb - 1Amp
JP10
Engineer REM
OPTIONS
Tamper
Disable
100 Vm = 1 Amp
V
F3
F4 F5 F6
F1
F8 Batt Charge
0.75A 0.3A
F2
!
BAR CODE
USE WITH
TEXECOM PSU
ONLY
F7
21
3
4
Com 2
F1
F5
JP7
Aux 12v
1Amp
Network 2 1Amp
Com 1
Load
Defaults Expansion
F3
Network 1 1Amp
Tx1 Rx1 Tx2 Rx2
F9
Eng Keypad
INS656-2

Texecom Limited, Bradwood Court, St. Crispin Way, Haslingden, Lancashire BB4 4PW,
England.
Technical Support:
UK Customers Tel: [phone]
(Calls charged at 3.36 pence per minute from a BT landline. Calls from other networks may vary.)
International Customers Tel: [phone]
Email: [e-mail]
© Texecom Limited 2015
INS656-2
Recording Messages
The Premier Elite Speech Module can store four 10-second audio messages. Message 1 is
allocated to channel 1 and message 2 is allocated to channel 2 etc. To record a message proceed
as follows:
Press and hold the [RECORD] button, then press and hold either [REC1] for message 1 or
[REC2] for message 2 [REC3] for message 3 or [REC4] for message 4
Speak clearly into the microphone to record your message. During the recording process,
the record indicator will illuminate.
To stop the recording process, release the record buttons. The recording process will
automatically end after 10 seconds and the record indicator will go out.
Repeat steps 1 to 3 for other messages, if required.
Programming the Control Panel
The control panel will then need to be programmed correctly in order for the Premier Elite Speech
Module to function as expected:
Program Onboard Com2400 & Expansion Port
Enter the engineer code 
Press then /(UDL/Digi Options).
Press then /for (Com Port Setup/Onboard Digicom).
Press /then to select COM2400
Press /
Press (Expansion Port).then /
Press (Speech Module) then /
Digi Enabled & Dial All Numbers
If you have more than one communication device connected to the control panel, Dial All
Numbers MUST be enabled; continuing from the previous
Press /then then /(Digi Options)
Press /
Press Digi is Enabled (Eshown on Screen)
Press Dial All Numbers (Ashown on screen)
Press/
Program ARC's
Press /thenthen /(Program Digi)
Press /
Using the Scroll key select Which ARC you wish to use
Press /and scroll to change the ARC protocol to Speech Module
Press /twice then /
In the Pri. Tel No: screen enter the telephone number you wish to dial.
Press /
In the Sec. Tel No: enter an additional telephone number if required.
Press /
Program any additional ARC requirements to add additional telephone numbers.
Inserting an * after the number will force dialling of the next number even if the message is
acknowledged.
The reporting options for the Premier Elite Speech Module are fixed and should not be
changed. All types of alarm programmed for channels 1-4 will be reported for the selected
Areas, however Restores will not.
Programming Digi Channels
The default Digi Channels on the panels are programmed as follows:
Channel
Default
Channel 1
All Areas Fire Alarm
Channel 2
All Areas PA Alarm
Channel 3
All Areas Guard Alarm
Channel 4
All Areas Armed
If you need to change the defaults proceed as follows:
Enter the engineer code 
Press then /(System Outputs).
Press then /for (Digi Channels).
Press /then use the to select the output type
Press /then use the to select the output
Press /then select the Areas
Press /to accept
Use the to select the next Output and repeat the previous steps.
Only channels 1-4 are used by the Premier Elite Speech Module.
Testing the Premier Elite Speech Module
The procedure below shows how to perform a simple operational test for the Premier Elite Speech
Module
Press /twice then /(UDL/Digi Options)
Press/then /(Start Test Call)
Press to start the test call. All communication devices on the system will carry out a test
call.
If you have a telephone on the same line as the control panel, you can pick it up and listen to the
message.
During the test call you may press ,,or to switch between playing messages 1 2
3 & 4.
The person listening to the message on their telephone can acknowledge the call by pressing the
[#] key. This will cause the panel to hang-up the call. If not acknowledged it will continue to dial all
of the programmed numbers.
Supply Voltage: 9 –16VDC
Current Consumption (Standby): 1mA
Current Consumption (Active): 7mA
Messages/Channels: 4
Message Length: 10 Seconds each
Dimensions: 52mm x 30mm x 10mm
Packed Weight: 25g
Texecom declares that this product complies with the requirements of the
following directives:
2004/108/EC EMC Directive
2006/95/EC LVD Directive
2011/65/EU RoHS Directive
The product therefore meets all the requirements to enable it to be CE
marked.
WEEE Directive: 2012/19/EU (WEEE directive): Products marked with this
symbol cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your local
supplier upon the purchase of equivalent new equipment, or dispose of it
at designated collection points. For more information see:
www.recyclethis.info.
This product is suitable for use in systems designed to comply with EN 50131-1, at Grade 2
and Environmental Class II.
Warranty
All Texecom products are designed for reliable, trouble-free operation. Quality is
carefully monitored by extensive computerised testing. As a result, the Premier Elite
Speech Module is covered by a two-year warranty against defects in material or
workmanship.
