texet LMA4P User manual

LMA4P Laminator Specification:
Rollers: 2 Roller (hot shoe)
Entry width: 234mm
Min lamination thickness: 150(2x75) micron
Max lamination thickness: 200 (2x100) micron
Min ouch size: Credit card size (54x86mm)
Max ouch size: A4 size (216x303mm)
Max lamination de th: 0.6mm
Lamination s eed: 23cm / min
Warm-u : 2-3minutes
Power consum tion: 300watts
In ut: AC 220-240V,50Hz,
Dimensions: 340 x 120 x 95 mm (L x D x H)
Model LMA4P
Type Laminator
Compliant with:-
BS EN 609 0-1: 2006 &
EMC - EN 014-1: 2006
EN 014-2: 1997+ A1
EN 61000-3-2: 2006
EN 61000-3-3: 2008
MADE IN CHINA
Visit our Website at www.texet.com , to see our full range of products.
Disposal:
UK: Waste Electrical roducts/batteries should not be dis osed
of with household waste. Facilities exist, for your nearest
facilities see www.recycle-more.co.uk or in store for details.
LMA4P A4 Laminator

Thank you for choosing a TEXET laminator. e aim to supply quality
machines that create excellent results. Before operating the laminator
– please read and keep the user instructions for reference.
When using electrical a liances, basic recautions should always be followed to
reduce risk of injury or electric shock, including the following:
1. Always un lug the a liance when not in use.
2. This a liance is not intended for use by ersons, (including Children), with
reduced hysical, sensory or mental ca abilities or lack of ex erience or
knowledge. They should be given su ervision and instruction in the use of
the a liance, by a erson res onsible for their safety.
3. The laminator will become very hot in use and care should be taken when
handling the machine.
4. Protect against the risk of electrical hazards. Do not immerse the ower
cord, lug or a liance in water or other liquids, or use near water.
5. Do not insert any metal objects or other foreign objects such as jewellery,
hair, fingers or clothing into the a liance.
6. Remove a er cli s and sta les before laminating.
7. Do not o erate the a liance with a damaged lug or ower cord or after the
a liance has malfunctioned or become damaged in some manner.
8. If the Power Cord is damaged , it must be re laced by a qualified Engineer
in order to avoid a hazard,
9. The a liance should be installed near the outlet socket and the socket
should be easily accessible.
10. Only laminate a er or board. Do not laminate unusual objects.
11. Do not use aerosol dusters or cleaners.
12. Do not s ray anything into or lubricate the a liance.
Setup:
1. O erate the machine on a flat and stable surface.
2. Ensure there is enough clear s ace at the rear of the machine for the
laminated ouch to exit the machine.
3. The LMA4P o erates with laminating ouches 150 (2x75) micron –
200(2x100) micron thick (Credit card size to A4 size)
Operating the laminator:
The LMA4P is o erated by a rocker switch, located at the right hand side of the
a liance. There are 2 ositions ON (l) and OFF (O)
1. Plug the machines cable into a convenient 13 Am domestic su ly
outlet.
2. To Laminate select the ON (I) setting, laminating can begin when the
Green “Ready” light comes on, which indicates the Laminator is hot
enough to laminate, (Allow a rox 2-3 minute for the Laminator to warm
u ).
3. Pre are the laminating ouch for inserting into the machine. See How
to load a laminating pouch below Do not use ouches thicker
than 200mic (2x100mic er side)
4. When the machine has reached o erating tem erature, you may insert
the ouch, (sealed edge first), squarely into the machine until it engages
with the rollers. Never insert a ouch o en edge first into the machine.
5. The ouch will move through the machine and exit at the rear.
6. During the rocess the READY light may go out as heat is absorbed by
the laminating ouch. This is normal.
7. Turn the laminator to OFF (O) after use.
8. Remove the lug from the ower su ly.
IMPORTANT!
Do not touch the to of the machine during use, as this gets very hot. The
Intermittence O eration on this machine is 30mins on and 10mins off, but we
recommend that you allow the machine to cool down for at least 15mins after
30mins use. Do not lace items on to of the machine at any time.
Laminating capacity:
The LMA4P is a ersonal laminator designed for hot lamination.
The minimum laminating thickness is 150 (2x75) microns and the maximum
thickness is 200 (2x100) microns.
How to load a laminating pouch:
The laminating ouch is sealed along one side. O en the ouch and lace the
a er to be laminated centrally inside the ouch as close to the sealed edge as
ossible. Ensure there is an equal border all round the a er (e.g.: A4 a er should
have a 3mm border). The sealed edge (not the o en edges) is laced into the entry
slot to start the lamination rocess. Always watch the ouch during the
Laminating rocess to ensure it comes out the other side of the Laminator.
It may wra around the rollers if not laced squarely and centrally in the entry slot.
arranty & service:
Never service the roduct yourself. The a liance is guaranteed for 12 months
from date of urchase, subject to normal use. If the laminator is under warranty
then return it to the oint of urchase for re lacement or re air.
