Theben Timeguard WFADAPM Manual

Installation & Operating Instructions
WiFi Smart Plug
Model: WFADAPM

1
1. General Information
These instructions should be read carefully
in full before installation, and retained
for further reference and maintenance.
2. Safety
• Do not plug in any appliance that exceeds
the capacity of the Smart Plug.
• Always ensure the plug of any appliance
is fully inserted into the Smart Plug outlet.
• If cleaning of the Smart Plug is required,
remove from mains power and wipe Smart
Plug with a dry cloth.
• Do not immerse in water or any other liquid.
• For indoor use only.
3. Technical Specifications
• 230V AC 50 Hz
• This unit is of class II construction
• Switching capacity: 13A

2
• Manual ON/OFF Controls
• Operating temperature: -10°c to +45°c
• Operating Humidity: ≤80%RH
• WLAN-Standard: 802.11 b/g/n
• Encryption: WEP/WPA/WPA2
• CE Compliant
• EC Directives: Conforms to latest directives
• Dimensions (H x W x D): 58.2 x 58.2 x 55.5mm
4. System Requirements
• Smartphone/Tablet with at least iOS 8.0
or Android 5.0
• WLAN-enabled router: 2.4GHz
(Separate Band)
• Tuya Smart App

3
5. Downloading App
and Registration
Note: the smartphone or tablet must
be connected to a 2.4GHz band on
the router. Paring on the 5GHz band
will result in paring either timing out
or being unsuccessful. Refer to your ISP
(Internet Service Provider) on separating
the bands if required.
• Ensure your phone or tablet is connected
to your local WiFi network.
• Download the Tuya Smart App onto
your phone or tablet by searching
for ‘Tuya Smart’ on Google Play Store
or the App Store. You can also scan the
applicable QR code right;

4

5
• Install the App and open it to the registration
screen. Click on the ‘Register’ button.

6
• Install the App and open it to the registration
screen. Click on the ‘Register’ button.

7
• Choose your region by selecting the Country
Code. Enter your email address or phone
number and click ‘Get Verification Code’.

8
• Enter the Verification Code sent to the email
address or phone number that you provided.
Once you have successfully entered
the code, it will automatically move
you to the Password screen.

9
• Assign a Password (this must be between
6 to 20 characters including letters and digits)
and click ‘Done’.

10
• You are now registered and by default will
see the App home page.

11
6. Home Management
Note: Before adding any devices to your
account, structuring your household
(or the property) may be a consideration
if you plan on using Smart devices
in different rooms or locations.
• Select the ‘Me’ option from the home
page which will navigate you to your
personal settings. From here you can
setup a nickname for your profile i.e.
‘Mr Smith’s Account. After this select
the ‘Home Management’ option.

12

13

14
• Select the ‘Home Name’ option and
enter your last name or even ‘My Home’
if preferred. (This is required to allocate
devices to separate rooms later once paired).
• Next tick the rooms you wish to assign
to your account; this can be changed
at any time and custom room names
can also be added.

15
• To navigate back to the home screen,
press the ‘Back’ button, and then
click Home.

16
7. Pairing your Device(s)
• To add a new device to your account,
click the ‘Add Device’ button (or click on
the + button in the top right hand corner)

17
• Notice the different categories of products;
it is essential that the correct product
is selected for the pairing process
to be successful. For the WiFi Smart Plug,
choose the ‘Socket (Wi-Fi)’ option
from the list.

18
• Plug the Wi-Fi Smart Plug into a socket
with the power switch in the ON position.
The Wi-Fi light (Smart Plug ON/OFF power
button LED) will begin to flash.
• When the Wi-Fi light is flashing, press the
‘Confirm indicator rapidly blinking’
button. Enter the password for the network
and press the ‘Confirm’ button to pair the
product to your account (In most cases
the password should autofill).
