QUICK REFERENCE Part. No. ZP-PKGA-0594 Pub. No. MAN0005496 Rev. A.0
FLoid™Cell Imaging Station
For Research Use Only. Not for use in diagnostic procedures.
Contents
FLoid™Cell Imaging Station
Power cord
Keyboard
Wireless mouse
USB memory device (containing
user manual)
Quick reference card
Printer (Cat. No. 4472351)
Catalog No. 4471136
1. Install battery in mouse
2. Connect accessories 3. Power on device
a. Remove cover from mouse.
b. Insert battery.
c. Turn on power switch.
Keyboard
Wireless mouse
Printer
Power cord
Outlet
USB memory device
Light shield
Indicator light
Objective opening
Stage
Stage movement knob
USB port
LCD screen
USB ports
Focus knobs
On/off switch
10
9
8
7
6
5
4
3
2
1
5
4
3
2
1
6
3
21
5
46
7
1
2
3
4
5
6
8
10
9

For support, visit thermosher.com/support.
23 July 2018
Important Licensing Information: This product may be covered by one or more Limited Use Label Licenses.
By use of this product you accept the terms and conditions of all applicable Limited Use Label Licenses.
Manufacturer: Life Technologies Corporation | 22025 20th Ave SE | Bothell, WA 98021
© 2018 Thermo Fisher Scientific Inc. All rights reserved. All trademarks are the property of Thermo Fisher Scientific and its subsidiaries unless otherwise specified.
4. Capture image 5. Process image
a. Place sample on stage over objective opening.
b. Turn on light by selecting light bulb icon.
c. Focus image using focus knobs.
d. Capture image(s) then press Processing button.
a. Adjust brightness and contrast as needed.
b. Save image to USB ash drive and print image.
Image pane
Focus assist gauge
Black/White toggle
Light intensity slider
Capturing/processing toggle
Capture button
Light switch (OFF)
Light switch (ON)
Text box
Image thumbnail
5
4
3
2
1
42
1
10
9
8
7
6
8
3
5
6
10
9
9
9
9
7
7
Zoom scale
Brightness slider
Color selector
Contrast slider
Scale bar
Save button
Print button
5
4
3
2
1
6
7
5
2
1
6 7
43
Capture screen
Process screen
